Motorola Focus72 Manuel utilisateur

USER’S GUIDE

Wi-Fi® Outdoor Home Video Camera

Model: Focus72, Focus72-2, Focus72-3, Focus72-4

Focus72-W, Focus72-W2, Focus72-W3, Focus72-W4

The features described in this user’s guide are subject to modications without prior notice.

Welcome...

to your new Motorola Wi-Fi®Outdoor Home

Video Camera!

Thank you for purchasing your new Motorola Wi-Fi®Outdoor Home Video

Camera.

If you have always wondered what happens when you are away, wonder no

more. Now you can monitor your children, pets or property with this easy to

use system. You can install the Camera only from your iPhone®/iPad®or

Android™ devices and view the Camera video from your PC or Notebook,

as well as from your iPhone®/iPad®or Android™ devices.

Please keep your original dated sales receipt for your records. For warranty

service of your Motorola product, you will need to provide a copy of your

dated sales receipt to confirm warranty status. Registration is not required for

warranty coverage.

For product related questions, please call:

US and Canada 1-888-331-3383

Email: support@motorolastore.com

On the Web: www.motorolastore.com/support

This User’s Guide has all the information you need to make the most out of

your product.

Please read the Safety Instructions on pages 5 - 7 before you install the unit.

Inside the Box

●1x Wi-Fi Camera Unit

●1x Antenna

●1x Power Adapter

●1x Quick Start Guide

●3x Mounting Screws and Dry Wall Plugs

●1x Wrench Key

●1x Lan Cable Connector

In multi-camera packs, you will find one or more additional Camera Units with

power adapter units.

Overview of your Camera

* An Ethernet connection is required when the Wi-Fi®connection is

not optimal. Connect the Ethernet cable (not supplied) to the LAN

interface, and then connect the other end to a spare port on your router.

Important guidelines for installing your Wi-Fi®Camera Unit

• Use of other 2.4 GHz products, such as other wireless networks,

Bluetooth™systems or microwave ovens may cause interference with this

product. Keep the Wi-Fi®Camera Unit away from these types of products, or

turn them off if they appear to be causing interference.

• Always ensure that you have a good Wi-Fi®connection available.

1. Antenna

2. Camera Base Plate

3. Camera Lens

4. IR-LED Window

5. Motion detect Window

6. Cable

7. Power Socket

8. Pair Button

9. LAN Socket

10. Status LED

10 10

RED LED GREEN LED

4Table of contents

Table of contents

1. SafetyInstructions ..................................................................................... 5

2. System Requirements .................................................................................7

3. Getting started - Connecting Devices ...................................................... 8

3.1 How to register your Camera to Hubble account ......................................... 8

3.1.1 Setting Up the Camera...................................................................... 8

3.1.2 Install your Camera .............................................................................. 9

3.1.3 How to assemble the waterproof plug for the LAN cable............... 11

3.1.4 Status of LED Indication:.................................................................. 12

3.2 User Account and Camera Setup on Android™ Devices ............................ 13

3.2.1 Power ON and Connect the Camera ............................................. 13

3.2.2 Download the Hubble App.............................................................. 13

3.2.3 Run Hubble for Motorola Monitors App on Android™ Devices.... 13

3.2.4 Add the Camera to your account...................................................... 14

3.3 User Account and Camera Setup on iPhone®/iPad®.............................. 17

3.3.1 Power ON and Connect the Camera ............................................. 17

3.3.2 Download the Hubble App.............................................................. 17

3.3.3 Run Hubble for Motorola Monitors App on iPhone®/iPad®......... 17

3.3.4 Add the Camera to your account.................................................... 18

4. App menu ................................................................................................ 21

5. Working with PC/Notebook.................................................................... 22

6. Help.......................................................................................................... 23

7. General Information ................................................................................ 29

8. TechnicalSpecications.......................................................................... 35

ENGLISH

Safety Instructions

1. Safety Instructions

WARNING:

Wi-Fi®CAMERA UNIT SET UP & USE：：：：：：：：

• Determine a location forthe Wi-Fi®Camera Unit that will provide the

best view of the area you would like to monitor (ie back yard or front

door).

• Fix the camera to a flat wall using the wall mounting plate and following

the instructions provided.

WARNING

This Wi-Fi® Camera Unit is compliant with all relevant electromagnetic eld

standards and is, when handled as described in the User’s Guide, safe to use.

Therefore, always read the instructions in this User’s Guide carefully before

using the device.

• Keep this user’s guide for future reference.

• Do not cover the Wi-Fi®Camera Unit with a towel or blanket.

• Test the Wi-Fi®Camera Unit and all its functions so that you are familiar with it

prior to use.

• Do not install the Wi-Fi®Camera Unit near a heat source.

• Only use the power adapter provided. Do not use other power adapters as

this may damage the device.

• Never use extension cords with power adapters.

• Do not touch the plug contacts with sharp or metal objects.

Important instructions:

• Read and Follow Instructions - Please read all the safety and operating

instructions before operating the product.

• Retain Instructions - The safety and operating instructions should be retained

for future reference.

6Safety Instructions

• Heed Warnings - Comply with all warnings on the product and in the

operating instructions.

• Power Sources - This product should be operated only from the type of

power source indicated on the marking label. If you are not sure of the type

of power supplied to your location, consult your camera dealer or local power

company.

• Overloading - Do not overload wall outlets or extension cords as this can

result in the risk of re or electric shock. Overloaded AC outlets, extension

cords, frayed power cords, damaged or cracked wire insulation, and broken

plugs are dangerous. They may result in a shock or re hazard. Periodically

examine the cord, and if its appearance indicates damage or deteriorated

insulation, have it replaced by your service technician.

• Power-Cord Protection - Power supply cords should be routed so that they

are not likely to be walked on or pinched by items placed upon or against

them. Pay particular attention to cords at plugs, convenience receptacles,

and the point where they exit from the product.

• Surge Protectors - It is highly recommended that the camera equipment be

connected to a surge protector. Doing so will protect the equipment from

damage caused by power surges. Surge protectors should bear the CE

approval mark.

• Uninterruptible Power Supplies (UPS) - Because this product is designed

for continuous, 24/7 operation, it is recommended that you connect the

product to an uninterruptible power supply. An uninterruptible power supply

has an internal battery that will keep the product running in the event of a

power outage. Uninterruptible power supplies should bear the CE approval

mark. CAUTION: Maintain electrical safety. Power line operated equipment

or accessories connected to this product should bear the CE approval mark

on the accessory itself and should not be modied so as to defeat the safety

features. This will help avoid any potential hazard from electrical shock or re. If

in doubt, contact

qualied service personnel.

• Attachments - Do not use attachments unless recommended bythe product

manufacturer, as they may cause a hazard.

• Heat - The product should be located away from heat sources such as

radiators, heat registers, stoves, or other products (including ampliers) that

produce heat.

ENGLISH

System Requirements

• Any mounting of

the product should be according to the manufacturer’s

instructions and use a

mounting accessory recommended bythe manufacturer.

• Camera Extension Cables - Check the rating of your extension cable to

verify

its compliance prior to installation.

• Mounting - The cameras provided with this system should be mounted only

instructed in this guide or the instructions that came with your cameras.

• Camera Installation - Cameras are not intended for submersion in

water.

When installing cameras outdoors, installation in a sheltered area is

recommended.

2. System Requirements

Web Portal

• Windows®7

• Mac OS®10.7

• Chrome™ 24

• Internet Explorer®9

• Safari®6

• Java™ 7

• Firefox®18.0

• Adobe®Flash®Player 15.0

Android™ System

• Version 4.2 or above

iPhone®/iPad®iOS

• Version 7.0 or above

Wi-Fi®requirements:

• At least 0.6 Mbps upload bandwidth per camera. Testyour Internet speed at:

http://www.speedtest.net/

8Getting started - Connecting Devices

3. Getting started - Connecting Devices

How does it work?

FOCUS66S

Camera

Hubble

Service

Wi-Fi Router

When a user tries to access the Camera, our secure server authenticates the

user’s identity and permits access to the Camera.

3.1 How to register your Camera to Hubble account

3.1.1 Setting Up the Camera

Pair button

Via WIFI

Step 1: Connect the antenna with the connector on the rear surface of

the camera.

Step 2: Insert the power adapter connector into the camera's power

socket and screw in the waterproof cover. Connect the power

adaptor plug to a suitable mains socket and wait for the LED to

start blinking RED.

Access your

Camera locally View your Camera from any

compatible device remotely

ENGLISH

Getting started - Connecting Devices

Step 3: Press and hold the pair button for 3 seconds or more until both

RED and GREEN LEDs blink together.

Step 4: From the APP, press "+" camera to search for the Focus72, then

follow the instructions from the APP.

Via LAN

Step 1: Connect the LAN cable to the camera's LAN socket and the

other end to your router, and screw in the waterproof cover.

Step 2: Insert the power adapter connector into the camera's power

socket and screw in the waterproof cover. Connect the power

adaptor plug to a suitable mains socket and wait for the LED to

start blinking RED.

Step 3: Press and hold the pair button for 3 seconds or more until both

RED and GREEN LEDs blink together.

Step 4 : From the APP, press "+" camera to search for the Focus72, then

follow the instructions from the APP.

3.1.2 Install your Camera

NOTE: We recommend you set up your camera with your router and make

sure that the camera operates fully with your Wi-Fi / LAN in the location you

are going to mount it, before you start to drill holes for the installation.

A. Drill the Screw Holes

• Mark the position on the wall using the camera base plate as a template,

making sure the cable guide in the base plate is correctly aligned for the

direction you want the camera wires to leave the mounting, unless you

pass them directly through the wall behind the base plate.

• Drill 3 holes (4.5mm diameter) and hammer the expansion plugs (included)

into the holes as needed.

• If you want to pass the camera wires through the wall behind the base plate,

drill a 22mm diameter hole in the midpoint between the screw holes.

4.5mm

45.73 mm

39.60 mm

10 Getting started - Connecting Devices

B. Fixing the Camera unit to the wall or ceiling

• Pass the camera wires through the cable guide of the base plate or through a

hole in the wall or ceiling directly behind the base plate.

• Fasten the base plate on the wall or ceiling with the 3 screws provided.

• Make sure the unit is fixed firmly on the wall or ceiling.

C. Adjust angle and secure the camera unit

• Loosen the tamper-proof screws with the wrench key (provided).

• Adjust the camera angles to give your required field of view, then

tighten the tamper-proof screws.

D. Connecting LAN with the Camera Unit

• The LAN socket provides an option for you to connect directly via a LAN

cable if necessary. Insert the LAN jack into the LAN socket through the

water proof cover and fasten the cover, as shown.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Motorola Caméra de sécurité

Motorola

Motorola FOCUS73 Manuel utilisateur

Motorola

Motorola SCOUT73 Manuel utilisateur

Motorola

Motorola HMVC3075 Manuel utilisateur

Motorola

Motorola iDEN NTN9298 Manuel utilisateur

Motorola

Motorola FOCUS66-B2 Manuel utilisateur

Motorola

Motorola Avigilon H4 Series Manuel utilisateur

Motorola

Motorola SCOUT73 Manuel utilisateur

Motorola

Motorola hmvc3020 Manuel utilisateur

Motorola

Motorola Avigilon H4SL-MT-NPTA Manuel utilisateur

Motorola

Motorola EASY START KIT HMEZ1000 - CELL PHONE SET UP Comment utiliser

Motorola

Motorola EASY START KIT HMEZ1000 - CELL PHONE SET UP Manuel utilisateur

Motorola

Motorola Avigilon 2.0C-H5A-B1 Manuel utilisateur

Motorola

Motorola EASY START KIT HMEZ1000 - CELL PHONE SET UP Manuel utilisateur

Motorola

Motorola FOCUS50-W Manuel utilisateur

Motorola

Motorola FOCUS89 Manuel utilisateur

Motorola

Motorola HMWL1010 Manuel utilisateur

Motorola

Motorola Avigilon H4A-D1 Manuel utilisateur

Motorola

Motorola Avigilon H4A-ETD-KIT Manuel utilisateur

Motorola

Motorola FOCUS89-2 Manuel utilisateur

Motorola

Motorola Avigilon H4 SL Series Manuel utilisateur

Motorola

Motorola FOCUS73 Manuel utilisateur

Motorola

Motorola HMWC1020 Manuel utilisateur

Motorola

Motorola HMEZ2000 - Homesight Wireless Home Security... Manuel utilisateur

Motorola

Motorola SCOUT73 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
