Motorola (logo above) EN

Quick Start Guide

MODELS: SH043

Product ID: Escape 800 ANC

Bluetooth ID: D036701

FCC ID: VLJ-SH043

IC: 4522A-SH043

Frequency Band: 2.402 –2.480 GHz

Working temperature: 0oC –45oC

1. At a Glance

1. Left Ear cup

2. Right Ear cup

3. ANC on / off

4. Volume Up/Next Track

5. Volume Down/Last Track

6. Micro USB Port

7. LED Indicator

8. Microphone

9. Play / Pause / Power

10. AUX-IN

2. Charge

Fully charge before use. Any attempt to remove or replace your battery will damage your headset.

•Charge: Before use, charge until the status light turns blue.

•When battery runs out, charge headphones for 1 second before using with included headphone

cable to continue listening.

3. Connect & Go

Note: The Battery should only be removed by a recycling facility. Any attempt to remove or

replace your battery will damage the product and void your warranty.

Caution: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED PRODUCT PROPERLY.

Wall charger not

included

Turn Bluetooth on

Turn headset on(charge before use)

Long press for 4 sec

Status Light –Blue flash rapidly Go to your

Bluetooth setting and pair ‘Escape 500 ANC’

4. Buttons Operation

Music

Play/Pause

Press

Volume Down/Up

Press - / +

Next Track

Long press + for 2s

Previous Track

Long press - for 2s

ANC on / off

Slide ANC switch button

Calls

Answer/ end call

Press

Reject a call/

Long Press - / + for 2s

Call waiting

Receive incoming call and end ongoing call

Press

Mute during call

Press - and +

Pair

Enter pairing mode (first time)

Press and hold for 4s

Enter pairing mode

Press and hold for 2s

Voice

To issue a voice command during idle mode,

then say the command

Double Press

5. LED Indicators

Charging Case (LED at the front)

Pairing

Blue flash

Standby

LED off

Charging

Red steady

Fully charged

Blue steady

Battery low

Red flash

6. Hubble ConnectTM for VerveLifeTM

Download ‘Hubble Connect for VerveLife’ app for free at the App Store® or Google PlayTM (AndroidTM 4.4.4

or higher) to find more functions:

•Last connected location: Locate in a map where your earbuds were connected to your device last

time.

•Help: Get help and support.

•Update for more advanced functions to come

Note: Application feature may change over time, please download the latest version of the app to see all

current features supported.

7. Safety Instructions

To avoid hearing damage, keep the volume at a moderate level. Avoid listening to music at loud volume

levels for prolonged periods of time as this may cause permanent hearing damage or hearing loss.

Don't use this product when it is unsafe to do so. For example, while operating a vehicle, cycling, crossing a

road, or any activity which requires your attention and ability to hear.

7. Help & more

•Get help: Visit www.motorolastore.com/support or visit www.verve.life for help videos, FAQ's and

more.

•Find accessories at: www.motorolastore.com or www.verve.life

Manufactured, distributed, or sold by Binatone Electronics International LTD., official licensee for this

product. MOTOROLA and the Stylized M logo are trademarks or registered trademarks of Motorola

Trademark Holdings, LLC. and are used under license. Apple logo is a trademark of Apple Inc., registered in

the U.S. and other countries. App Store is a service mark of Apple Inc. Google Play and Android are

General information

Safety, Regulatory & Legal

If your product is not working properly, read this Quick Start Guide or the

User’s Guide of one of the models listed on page 1.

Contact Customer Service:

+44 (0) 844 557 0890 (UK only –Calls cost 7p per minute plus your

telephone company’s access charge.) +44 (0) 8187 62092 (ROI)

+1-888-331-3383 (US and Canada)

On the Web: www.motorolastore.com/support

Consumer Products and Accessories Limited Warranty (“Warranty”)

Thank you for purchasing this Motorola branded product manufactured under

license by Binatone Electronics International LTD (“BINATONE”).

What Does this Warranty Cover?

Subject to the exclusions contained below, BINATONE warrants that this

Motorola branded product (“Product”) or certified accessory (“Accessory”)

sold for use with this product that it manufactured to be free from defects in

materials and workmanship under normal consumer usage for the period

outlined below. This Warranty is your exclusive warranty and is not

transferable.

Who is covered?

This Warranty extends only to the first consumer purchaser, and is not

transferable.

What will BINATONE do?

BINATONE or its authorized distributor at its option and within a commercially

reasonable time, will at no charge repair or replace any Products or

Accessories that does not conform to this Warranty. We may use functionally

equivalent reconditioned / refurbished / pre-owned or new Products,

Accessories or parts.

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF

THIS LIMITED WARRANTY, OTHERWISE THE REPAIR OR

REPLACEMENT PROVIDED UNDER THIS EXPRESS LIMITED

WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS

PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR

IMPLIED. IN NO EVENT

SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT

OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF

THE PURCHASE PRICE OF THE PRODUCT OR ACCESSORY, OR FOR

ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES

OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF

BUSINESS, LOSS OF INFORMATION OR OTHER FINANCIAL LOSS

ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY

TO USE THE PRODUCTS OR ACCESSORIES TO THE FULL EXTENT

THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some jurisdictions do not allow the limitation or exclusion of incidental or

consequential damages, or limitation on the length of an implied warranty, so

the above limitations or exclusions may not apply to you. This Warranty gives

you specific legal rights, and you may also have other rights that vary from

one jurisdiction to another.

Consumer Products

One (1) year from the date of the products

original purchase by the first consumer

purchaser of the product

Consumer

Accessories

Ninety (90) days from the date of the

accessories original purchase by the first

consumer purchaser of the product

Consumer

Accessories that are

Repaired or

Replaced

The balance of the original warranty or for Ninety

(90) days from the date returned to the

consumer, whichever is longer.

commercial purposes or subjecting the Product or Accessory to abnormal

usage or conditions; or (d) other acts which are not the fault of MOTOROLA

or BINATONE, are excluded from coverage.

Use of Non-Motorola branded Products and Accessories. Defects or damage that

result from the use of Non-Motorola branded or certified Products or

Accessories or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification. Defects or damages resulting from

service, testing, adjustment, installation, maintenance, alteration, or

modification in any way by someone other than MOTOROLA, BINATONE or

its authorized service centers, are excluded from coverage.

Altered Products. Products or Accessories with (a) serial numbers or date tags

that have been removed, altered or obliterated; (b) broken seals or that show

evidence of tampering; (c) mismatched board serial numbers; or (d)

nonconforming or non-Motorola branded housings, or parts, are excluded

from coverage. Communication Services. Defects, damages, or the failure of

Products or Accessories due to any communication service or signal you may

subscribe to or use with the Products or Accessories is excluded from

coverage. How to Obtain Warranty Service or Other Information? To obtain

service or information, please call: +44 (0) 844 557 0890 (UK only –Calls

cost 7p per minute plus your telephone company’s access charge.) +44 (0)

8187 62092 (ROI)

US and Canada 1-888-331-3383 On the Web: www.motorolastore.com/support You

will receive instructions on how to ship the Products or Accessories at your

expense and risk, to a BINATONE Authorized Repair Center. To obtain

service, you must include: (a) the Product or Accessory; (b) the original proof

of purchase (receipt) which includes the date, place and seller of the

Product;(c) if a warranty card was included in your box, a completed warranty

card showing the serial number of the Product; (d) a written description of the

problem; and, most importantly; (e) your address and telephone number.

European Union Directives Conformance Statement

The following CE compliance information is applicable to Motorola products

that carry one of the following CE marks:

Hereby, Binatone declares that this product is in compliance with:

• The essential requirements and other relevant provisions of RED Directive

2014/53/EU

• All other relevant EU Directives

• The Declaration of Conformity can be obtained from the full user guide at

https://hubbleconnected.com/eu/eu-documents-of-conformity

FCC Notice to Users

The following statement applies to all products that bear the FCC logo and/or FCC

ID on the product label.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

Industry Canada Notice to Users

This device contains licence-exempt transmitter(s)/receiver(s) that comply with

Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).

Operation is subject to the following two conditions:

(1) This device may not cause interference.

(2) This device must accept any interference, including interference that may cause

undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est

conforme aux CNR d’Innovation, Sciences et Développement économique Canada

applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux

deux conditions suivantes :

(1) L’appareil ne doit pas produire de brouillage;

(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage

est susceptible d’en compromettre le fonctionnement.

This equipment complies with IC RSS‐102 radiation exposure limits set forth for an

uncontrolled environment.

Cet équipement est conforme aux limites d'exposition aux radiations IC CNR‐102

établies pour un environnement non contrôlé.

Do not use AUX while charging.

Autres manuels Motorola casque

Motorola

Motorola IMPRES PMLN6127 Manuel utilisateur

Motorola

Motorola H690 Manuel utilisateur

Motorola

Motorola H730 Manuel utilisateur

Motorola

Motorola 89333N Manuel utilisateur

Motorola

Motorola H12 - MOTOPURE H12 - Headset Manuel utilisateur

Motorola

Motorola HS805 Manuel utilisateur

Motorola

Motorola H390 - Headset - In-ear ear-bud Manuel utilisateur

Motorola

Motorola WHISPER Manuel utilisateur

Motorola

Motorola MOTOPURE H15 Manuel utilisateur

Motorola

Motorola SF600 Manuel utilisateur

Motorola

Motorola H790 - Headset - Monaural Manuel utilisateur

Motorola

Motorola H500 Manuel utilisateur

Motorola

Motorola H700 - H700 Manuel utilisateur

Motorola

Motorola 6803578F47 Manuel utilisateur

Motorola

Motorola H390 - Headset - In-ear ear-bud Manuel utilisateur

Motorola

Motorola H780 - Headset - Over-the-ear Manuel utilisateur

Motorola

Motorola ELITE SLIVER Manuel utilisateur

Motorola

Motorola 98405RH Manuel utilisateur

Motorola

Motorola H790 - Headset - Monaural Manuel utilisateur

Motorola

Motorola HS850 - Headset - Over-the-ear Manuel utilisateur

Motorola

Motorola H270 - Headset - Over-the-ear Manuel utilisateur

Motorola

Motorola HK255 Manuel utilisateur

Motorola

Motorola HK255 Manuel utilisateur

Motorola

Motorola 89504N Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
