RS419

RING SCANNER

QUICK REFERENCE GUIDE

Motorola Solutions reserves the right to make changes to any product to improve reliability,

function, or design.

Motorola Solutions does not assume any product liability arising out of, or in connection with, the

application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise under any patent

right or patent, covering or relating to any combination, system, apparatus, machine, material,

method, or process in which Motorola Solutions products might be used. An implied license exists

only for equipment, circuits, and subsystems contained in Motorola Solutions products.

Warranty

For the complete Motorola Solutions hardware product warranty statement, go to:

http://www.motorolasolutions.com/warranty.

Service Information

If you have a problem using the equipment, contact your facility’s Technical or Systems Support. If

there is a problem with the equipment, they will contact the Motorola Solution Global Customer

Support Center at: http:www.motorolasolutions.com/support.

For the latest version of this guide go to: http://supportcentral.motorola.com.

Introduction

The RS419 ring scanner is a modular, wearable laser scanner that allows the operator hands-free bar

code scanning capability. The scanner is used with the WT4090 and WT41N0 wearable terminal.

The RS419 is worn on the operator’s index finger, and utilizes a thumb-operated trigger. The

RS419 connects via an interface cable to the wearable terminal, which provides power and

performs the data collection functions. The RS419 is available in two configurations; a short cable

version for connection to a wrist mounted wearable terminal, and a long cable version for

connection to a hip mounted wearable terminal.

Scan LED

Exit Window

Finger Strap

Assembly

Connector

Scan Trigger

Trigger Assembly

Scan Assembly

Short Cable Version Shown

Changing Trigger Position

The trigger assembly of the RS419 rotates to provide left-hand or right-hand

use.

1. Determine whether the RS419 is used on the right or left hand.

2. Rotate the trigger assembly so that the scan trigger is positioned next to

the thumb when the RS419 is placed on the index finger.

Installation

The RS419 connects to the wearable terminal and mounts on the index finger.

1. On the wearable terminal, remove the connector cap.

2. Connect the RS419 interface cable to the wearable terminal interface connector. If connecting

to a wrist mounted wearable terminal, connect to the interface connector closest to the wrist.

CAUTION The trigger assembly only rotates 180° around the

back of the scan assembly. Do not rotate the trigger

assembly past the designed stops.

3. Slide the RS419 onto the index finger with the scan trigger next to the thumb.

4. Tighten the finger strap.

Scanner

Cable

Connector

Interface Connector

5. If required, cut excess finger strap material.

6. Warm boot the wearable terminal.

Using the Scanner

Not to be used in condensing environments.

To scan bar codes:

1. Turn on the wearable terminal.

2. Launch a scanning application.

3. Press the scan trigger and aim the RS419 at a bar code.

The scan LED lights red to indicate the laser is on.

4. Position the red laser beam so that it covers the entire length of the bar code.

5. If the decode is successful the LED turns green. The terminal beeps if programed accordingly.

Scanning Tips

• For larger bar codes, hold the RS419 farther away from the bar code.

• For bar codes with bars that are closer together, hold the RS419 closer to the bar code.

• The optimal scanning distance varies with bar code density, but 10 to 25 cm (4 to 10 inches)

generally works. Practice to determine what distances to work within.

• Do not position the RS419 exactly perpendicular to the bar code being scanned. In this

position, reflected light can bounce back into the exit window, and possibly prevent a

successful decode.

Finger Strap Assembly Replacement

The finger strap assembly can be changed for each user or for replacement. To replace the finger

strap assembly:

1. Press down on the finger strap assembly release tab.

2. Slide the finger strap assembly out of the trigger assembly.

3. Align a new finger strap assembly with the slot in the trigger assembly.

4. Push the finger strap assembly into the trigger assembly until the release tab clicks into place.

5. Insert your index finger through the finger strap. Tighten the strap and press the hook and pile

together.

6. If required, cut excess finger strap material.

Release Tab

Replacing the Trigger Assembly

To replace the trigger assembly:

1. Remove the finger strap assembly.

2. Turn the RS419 upside-down.

3. Remove the set screw with

screwdriver.

4. Turn the trigger assembly

counter-clockwise until the exit

window and scan trigger align.

5. Lift the trigger assembly off the scan

assembly.

6. Align replacement trigger assembly

with scan assembly.

7. Rotate trigger assembly 1/4 turn

clockwise.

8. Tighten the set screw with

screwdriver.

9. Replace finger strap assembly.

Cleaning

Approved Cleanser Active Ingredients

100% of the active ingredients in any cleaner must consist of one or some combination of the

following: isopropyl alcohol, bleach/sodium hypochlorite, hydrogen peroxide or mild dish soap.

Harmful Ingredients

The following chemicals are known to damage the plastics on the RS419 and should not come in

contact with the device: ammonia solutions, compounds of amines or ammonia; acetone; ketones;

ethers; aromatic and chlorinated hydrocarbons; acqueous or alcoholic alkaline solutions;

ethanolamine; toluene; trichloroethylene; benzene; carbolic acid and TB-lysoform.

CAUTION Always wear eye protection.

Read warning label on compressed air and alcohol product before using.

If you have to use any other solution for medical reasons please contact

Motorola Solutions for more information.

WARNING!AVOID EXPOSING THIS PRODUCT TO CONTACT WITH HOT OIL

OR OTHER FLAMMABLE LIQUIDS. IF SUCH EXPOSURE OCCURS,

UNPLUG THE DEVICE AND CLEAN THE PRODUCT IMMEDIATELY

IN ACCORDANCE WITH THESE GUIDELINES.
