VEHICLE POWER
ADAPTER NNTN8040
USER GUIDE
en-US zh-CN zh-TW ja-JP ko-KR de-DE
fr-FRes-ES it-IT nl-NL pt-PT ru-RU ar-EG
68012004083_ba.book Page 1 Tuesday, January 5, 2021 4:49 PM
1
English
IMPORTANT
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This document contains important safety
and operating instructions. Please read
these instructions carefully and save them
for future reference.
Before using the battery charger, read all the
instructions and cautionary markings on (1)
the charger, (2) the battery, and (3) the radio
using the battery.
WARNINGS
2. Use of accessories not recommended by
Motorola Solutions may result in risk of fire,
electric shock, or injury.
3. To reduce risk of damage to the electric plug
and cord, pull by the plug rather than the
cord when disconnecting the charger.
WARNING
1. To reduce risk of injury, charge
only rechargeable Motorola
Solutions authorized batteries.
Other batteries could explode
causing personal injury and or
damage.
English
68012004083_ba.book Page 1 Tuesday, January 5, 2021 4:49 PM
2
English
5. Do not disassemble the charger - it is not
repairable and replacement parts are not
available. Disassembly of the charger may
result in risk of electric shock or fire.
OPERATIONAL SAFETY
GUIDELINES
• This equipment is not suitable for outdoor
use. Use only in dry locations/conditions.
• Connect equipment only to an
appropriately fused and wired supply of
the correct voltage (as specified on the
product).
• Make sure the cord is located where it will
not be stepped on, tripped over, or
subjected to water, damage, or stress.
• Output power from power supply unit must
not exceed the ratings stated on the
product label located on the bottom of the
charger.
• The equipment may become warm during
operation. If it becomes hot to touch,
unplug from the outlet immediately and
discontinue use.
4. To reduce risk of fire, electric
shock, or injury, do not operate
the charger if it has been
broken or damaged in any
way.
WARNING
68012004083_ba.book Page 2 Tuesday, January 5, 2021 4:49 PM
3
English
DESCRIPTION
The Vehicle Power Adapter is used to
charge the Lithium Ion (Li-Ion) batteries of
the radio. The charger contains circuitry that
monitors the battery temperature and
adjusts the charge voltage to protect against
overcharging and overheating. Frequent
charging will not adversely affect the cycle
life of the battery.
Part
Number Description
NNTN8020 Li-Ion Battery 1700 mAh
NNTN8023 Li-Ion Battery 2200 mAh
PMNN4801 IMPRES 2 Li-Ion Battery IP68
1900
PMNN4802 IMPRES 2 Li-Ion Battery IP68
3400T
PMNN4582 IMPRES 2 Li-Ion Battery IP68
2900T
68012004083_ba.book Page 3 Tuesday, January 5, 2021 4:49 PM
4
English
OPERATING SPECIFICATIONS
Input voltage range: 10.8 to 33 Vdc
OPERATING INSTRUCTIONS
The Vehicle Power Adapter is not to be used
with any other radio accessories except for
the Remote Speaker Microphone.
Attaching the Vehicle Power Adapter :
(Refer to Figure 1 on page 5)
1. Attach the accessory connector to the
bottom end of the radio.
2. Plug the Vehicle Power Adapter into
the cigarette lighter socket of the
vehicle.
68012004083_ba.book Page 4 Tuesday, January 5, 2021 4:49 PM
5
English
Removing the Vehicle Power Adapter :
(Refer to Figure 1 on page 5)
1. Unplug the Vehicle Power Adapter from
the cigarette lighter socket of the
vehicle.
2. Press the top of the accessory
connector and pull away from the radio.
Figure 1:Attaching and Removing the
Vehicle Power Adapter
Radio
Connector
To vehicle
auxiliary
power socket
68012004083_ba.book Page 5 Tuesday, January 5, 2021 4:49 PM
6
English
LED Indicator Status
LED Indicator Status
Off
The Vehicle Power Adapter is
receiving no power from the
outlet.
On (Blue)
The Vehicle Power Adapter is
receiving power from the
outlet.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and
the Stylized M logo are trademarks or registered
trademarks of Motorola Trademark Holdings, LLC and
are used under license. All other trademarks are the
property of their respective owners.
© 2012 and 2021 Motorola Solutions, Inc. All rights
reserved
68012004083_ba.book Page 6 Tuesday, January 5, 2021 4:49 PM
1
简体中文
重要安全说明
请妥善保管这些说明
本文档包含重要的安全和操作说明。请仔细
阅读这些说明，并妥善保管以供日后参考。
使用电池充电器之前，请阅读所有说明以及
(1) 充电器、(2) 电池和 (3) 使用电池的对讲机
上的警示标记。
警告
2. 使用非 Motorola Solutions 推荐的附件可能
会引发火灾、导致触电或人员受伤。
3. 为了减少损坏电插座和电源线的风险，断开
充电器时请拉拔插头而不是电源线。
4. 为了降低火灾、触电或人员受伤的风险，
请勿使用有任何破损或损坏的充电器。
5. 请不要自行将此充电器拆开 – 该设备不可维
修并且不提供更换部件。擅自拆开该充电器
可能导致触电或引发火灾。
警告
1. 为了降低受伤的风险，请仅为
Motorola Solutions 批准的充电
电池充电。为其他电池充电可能
会发生爆炸，导致人身伤害或
损伤。
????
68012004083_ba.book Page 1 Tuesday, January 5, 2021 4:49 PM
2
English
简体中文
安全操作指南
• 本设备不适合在室外使用。请仅在干燥的
场所/环境下使用。
• 此设备只能与配有保险丝且电压匹配
（产品上指定的电压）的电源连接。
• 确保将电源线置于适当的位置，以避免
发生踩踏、绊倒、浸水、损伤或挤压等
意外。
• 电源设备的输出电压不能超过充电器底部
产品标签上标明的额定值。
• 该设备可能会在操作过程中变热。如果设
备热得烫手，应立即拔下电源插头并停止
使用。
68012004083_ba.book Page 2 Tuesday, January 5, 2021 4:49 PM
3
简体中文
说明
车载电源适配器用于为对讲机的锂电池充
电。充电器内含电路板，可监测电池温度并
调节充电电压，以避免过度充电及过热。频
繁充电不会对电池使用寿命产生负面影响。
工作规格
输入电压范围：10.8 至33 V 直流
部件号 说明
NNTN8020 锂离子电池 1700 mAh
NNTN8023 锂离子电池 2200 mAh
PMNN4801 IMPRES 2 IP68 1900T
锂离子电池
PMNN4802 IMPRES 2 IP68 3400T
锂离子电池
PMNN4582 IMPRES 2 IP68 2900T锂离子
电池
68012004083_ba.book Page 3 Tuesday, January 5, 2021 4:49 PM
