Motorola HS830 HANSFREE Manuel utilisateur

HS830

Helmet Adapter for

Wireless Module

Adaptateur de module

sans fil pour

casque protecteur

Adaptador de casco

para Módulo

inalámbrico

6809482A58-O

Export Law Assurances

This product is controlled under the export

regulations of the United States of America and

Canada. The Governments of the United States

of America and Canada may restrict the

exportation or re-exportation of this product to

certain destinations. For further information

contact the U.S. Department of Commerce or

the Canadian Department of Foreign Affairs and

International Trade.

The use of wireless devices and their

accessories may be prohibited or restricted in

certain areas. Always obey the laws and

regulations on the use of these products.

MOTOROLA and the Stylized M Logo are

registered in the US Patent & Trademark Office.

The Bluetooth trademarks are owned by their

proprietor and used by Motorola, Inc. under

license.

All other product or service names are the

property of their respective owners.

Note: Before using this product, read

the Important Safety and Legal

Information included at the back of

your phone's user guide, and follow

its instructions.

Install your Helmet

Adapter

Action

Choose a clear space on the side

of your helmet where the adapter

fits.

Hold the adapter on the helmet in

the desired location to make sure

the microphone boom can reach

close to your mouth, and the

speaker and the speaker wire can

be routed inside the helmet and

placed by your left ear.

Use the cleaning pad to clean the

surface of the helmet where the

adapter will be attached.

Action

Helmet

Adapter

Microphone

Speaker

Peel the backing off the back of

the adapter and mount the adapter

to the helmet in the desired

location.

Peel the backing off the Velcro

the speaker. Place the speaker

inside the helmet where it will be

close to your ear.

Alternatively, insert the tie wrap

through the slots on the back of

the speaker and use the tie wrap

to strap the speaker inside the

helmet. You may have to push the

tie wrap through the liner of the

helmet.

Action

Installing the Wireless

Module

Point the microphone toward your

mouth.

For best performance, the side of

the microphone with the white dot

on it should be closest to your

mouth.

Action

Press the outside latch to open the

helmet adapter cover.

Action

Insert the HS830 Wireless Module

into your helmet adapter. Slide

your Wireless Module completely

onto the audio plug in the helmet

adapter.

Close the helmet adapter cover

completely to secure the Wireless

Module.

While wearing the helmet, point

the microphone boom close to

your mouth for best voice pickup.

Action

Wireless Module

Latch

Helmet Adapter

Microphone Plug

Pairing Your Wireless

Module and Phone

With the headset and phone near each

other:

Action

With the wireless module off,

press and hold the MFB until the

LED remains on (about 5

seconds).

Perform a

device

discovery

from

your phone.

For details on device discovery

for your phone, refer to the

phone’s user’s guide.

When the scan is complete, your

phone displays the devices found.

Select Motorola HS830 from the

discovered devices list and

confirm following the on screen

prompts.

When prompted by the phone,

enter the passkey (

0000

)and

confirm to pair the wireless

module with the phone.

The device ID is now stored in

your phone’s memory.

Pairing is successful when your

wireless module indicator flashes

rapidly.

Action

Using Your Helmet

Adapter

Note:

The use of wireless devices and

their accessories may be prohibited or

restricted in certain areas. Always obey

the laws and regulations on the use of

these products.

You can activate call functions as

follows:
