SERVICE STATION MANUAL

2Q000297

V7 III ABS

SERVICE STATION

MANUAL

V7 III ABS

THE VALUE OF SERVICE

As a result of continuous updates and specific technical training programmes for Moto Guzzi products,

onlyMotoGuzziOfficialNetworkmechanicsknowthisvehiclefullyandhavethespecifictoolsnecessary

to carry out maintenance and repair operations correctly.

Thereliabilityofthevehiclealso dependsonitsmechanical conditions.Checkingthevehicle beforeriding

it, its regular maintenance and the use of original Moto Guzzi spare parts only are essential factors!

For information on the nearest Official Dealer and/or Service Centre consult our website:

www.motoguzzi.com

Only by requesting Moto Guzzi original spare parts can you be sure of purchasing products that were

developed and tested during the actual vehicle design stage. All Moto Guzzi original spare parts undergo

quality control procedures to guarantee reliability and durability.

Thedescriptionsandimagesinthispublicationaregivenforillustrativepurposesonlyandarenotbinding.

While the basic characteristics as described and illustrated in this booklet remain unchanged, Piaggio &

C.S.p.A. reserves theright, at anytime and withoutbeing required toupdate this publicationbeforehand,

to make any changes to components, parts or accessories, which it considers necessary to improve the

product or which are required for manufacturing or construction reasons.

Notallversions/modelsshowninthispublicationareavailableinallcountries.Theavailabilityofindividual

versions should be checked with the Official Moto Guzzi sales network.

The Moto Guzzi brand is owned by Piaggio & C. S.p.A.

in part is prohibited.

Piaggio & C. S.p.A. Viale Rinaldo Piaggio, 25 - 56025 PONTEDERA (PI), Italy

www.piaggio.com

SERVICE STATION MANUAL

V7 III ABS

This manual provides the main information to carry out regular maintenance operations on your vehicle.

This manual is intended to Moto Guzzi Dealers and their qualified mechanics; several concepts have

been deliberately omitted as they are considered unnecessary. As it is not possible to include complete

mechanical notions in this manual, users should have basic mechanical knowledge or minimum

knowledge about the procedures involved when repairing scooters. Without this knowledge, repairing or

checking the vehicle may be inefficient or even dangerous. As the vehicle repair and check procedures

are not described in detail, be extremely cautious so as not to damage components or injure individuals.

In order to optimise customer satisfaction when using our vehicles, Moto Guzzi commits itself to

continually improve its products and the relative documentation. The main technical modifications and

changes in repair procedures are communicated to all Moto Guzzi Sales Outlets and its International

Subsidiaries.These changes willbe introduced inthe subsequent editionsof the manual.In case ofneed

or further queries on repair and check procedures, consult Moto Guzzi CUSTOMER DEPARTMENT,

which will be prepared to provide any information on the subject and any further communications on

updates and technical changes related to the vehicle.

NOTE Provides key information to make the procedure easier to understand and carry out.

CAUTION Refers to specific procedures to carry out for preventing damages to the vehicle.

WARNING Refers to specific procedures to carry out to prevent injuries to the repairer.

Personal safety Failure to completely observe these instructions will result in serious risk of personal

injury.

Safeguarding the environment Sectionsmarked withthis symbol indicate the correctuse of the vehicle

to prevent damaging the environment.

Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious

damage to the vehicle and sometimes even the invalidity of the guarantee

INDEX OF TOPICS

CHARACTERISTICS CHAR

SPECIAL TOOLS S-TOOLS

MAINTENANCE MAIN

ELECTRICAL SYSTEM ELE SYS

ENGINE FROM VEHICLE ENG VE

ENGINE ENG

POWER SUPPLY P SUPP

SUSPENSIONS SUSP

CHASSIS CHAS

BRAKING SYSTEM BRAK SYS

BODYWORK BODYW

PRE-DELIVERY PRE DE

INDEX OF TOPICS

CHARACTERISTICS CHAR

Rules

Safety rules

Carbon monoxide

If you need to keep the engine running while working on the vehicle, please ensure that you do so in

an open or very well ventilated area. Never run the engine in an enclosed area. If you do work in an

enclosed area, make sure to use a fume extraction system.

CAUTION

EXHAUSTEMISSIONSCONTAINCARBONMONOXIDE, APOISONOUS GASWHICHCANCAUSE

LOSS OF CONSCIOUSNESS AND EVEN DEATH.

Fuel

CAUTION

THE FUEL USED TO POWER INTERNAL COMBUSTION ENGINES IS HIGHLY FLAMMABLE AND

MAY BE EXPLOSIVE UNDER CERTAIN CONDITIONS. IT IS THEREFORE RECOMMENDED TO

CARRY OUT REFUELLING AND MAINTENANCE PROCEDURES IN A VENTILATED AREA WITH

THEENGINE SWITCHEDOFF.DO NOTSMOKEDURING REFUELLING ORNEAR FUEL VAPOUR.

AVOIDANYCONTACTWITHNAKEDFLAME, SPARKS OR OTHER HEAT SOURCES WHICH MAY

CAUSE IGNITION OR EXPLOSION.

DO NOT ALLOW FUEL TO DISPERSE INTO THE ENVIRONMENT.

KEEP OUT OF THE REACH OF CHILDREN.

Hot components

The engine and the exhaust system components become very hot and remain hot for some time after

the engine has been switched off. When handling these components, wear insulating gloves or wait

until the engine and the exhaust system have cooled down.

Used engine oil and transmission oil

CAUTION

IT IS ADVISABLE TO WEAR PROTECTIVE IMPERMEABLE GLOVES WHEN SERVICING THE VE-

HICLE.

THE ENGINE OR GEARBOX OIL MAY CAUSE SERIOUS INJURIES TO THE SKIN IF HANDLED

FOR PROLONGED PERIODS OF TIME AND ON A REGULAR BASIS.

WASH YOUR HANDS CAREFULLY AFTER HANDLING OIL.

HAND THE OIL OVER TO OR HAVE IT COLLECTED BY THE NEAREST USED OIL RECYCLING

COMPANY OR THE SUPPLIER.

DO NOT DISPOSE OF OIL IN THE ENVIRONMENT

KEEP OUT OF THE REACH OF CHILDREN.

V7 III ABS Characteristics

CHAR - 7

Brake and clutch fluid

BRAKE AND CLUTCH FLUIDS CAN DAMAGE THE PLASTIC OR RUBBER PAINTED SURFACES.

WHEN SERVICING THE BRAKING OR THE CLUTCH SYSTEM PROTECT THESE COMPONENTS

WITH A CLEAN CLOTH. ALWAYS WEAR PROTECTIVE GOGGLES WHEN SERVICING THESE

SYSTEMS. BRAKE AND CLUTCH FLUIDS ARE EXTREMELY HARMFUL FOR YOUR EYES. IN

THE EVENT OF ACCIDENTAL CONTACT WITH THE EYES, RINSE THEM IMMEDIATELY WITH

PLENTY OF COLD, CLEAN WATER AND SEEK MEDICAL ADVICE.

KEEP OUT OF THE REACH OF CHILDREN.

Battery electrolyte and hydrogen gas

CAUTION

THE BATTERY ELECTROLYTE IS TOXIC, CORROSIVE AND AS IT CONTAINS SULPHURIC ACID,

IT CAN CAUSE BURNS WHEN IN CONTACT WITH THE SKIN. WHEN HANDLING BATTERY

ELECTROLYTE, WEAR TIGHT-FITTING GLOVES AND PROTECTIVE APPAREL. IN THE EVENT

OF SKIN CONTACT WITH THE ELECTROLYTIC FLUID, RINSE WELL WITH PLENTY OF CLEAN

WATER. IT IS PARTICULARLY IMPORTANT TO PROTECT YOUR EYES BECAUSE EVEN TINY

AMOUNTSOF BATTERYACIDMAY CAUSEBLINDNESS. IF THEFLUID GETSINCONTACT WITH

YOUR EYES, WASH WITH ABUNDANT WATER FOR FIFTEEN MINUTES AND CONSULT AN EYE

SPECIALIST IMMEDIATELY. THE BATTERY RELEASES EXPLOSIVE GASES; KEEP IT AWAY

FROM FLAMES, SPARKS, CIGARETTES OR ANY OTHER HEAT SOURCES. ENSURE ADE-

QUATE VENTILATION WHEN SERVICING OR RECHARGING THE BATTERY.

KEEP OUT OF THE REACH OF CHILDREN.

BATTERY LIQUID IS CORROSIVE. DO NOT POUR OR SPILL ON PLASTIC COMPONENTS IN

PARTICULAR. ENSURE THAT THE ELECTROLYTIC ACID IS COMPATIBLE WITH THE BATTERY

BEING ACTIVATED.

Maintenance rules

GENERAL PRECAUTIONS AND INFORMATION

When repairs, disassembly and reassembly of the vehicle is carried out, follow the following recom-

mendations strictly.

BEFORE DISASSEMBLING COMPONENTS

•Remove the dirt, mud, dust and foreign objects from the vehicle before disassembling com-

ponents. Wherever required, use the special tools designed for this vehicle.

DISASSEMBLING COMPONENTS

•Do not loosen and/or tighten the screws and nuts using pliers or other tools, but always use

the specific wrench.

•Mark the positions on all the connection joints (hoses, cables, etc.) before separating them

and identify them with different distinctive marks.

•Each piece should be clearly marked in order to be identified during the installation phase.

•Carefully clean and wash the disassembled components with detergents with a low flam-

mability grade.

Characteristics V7 III ABS

CHAR - 8

•Keep the coupled parts together because they have "adapted" to one another following

normal wear.

•Some components must be used together or replaced entirely.

•Keep away from heat sources.

REASSEMBLING COMPONENTS

CAUTION

BEARINGS MUST ROTATE FREELY, WITHOUT JAMMING AND/OR NOISE, OTHERWISE, THEY

NEED TO BE REPLACED.

•Only use ORIGINAL Moto Guzzi SPARE PARTS.

•Comply with lubricant and consumables use guidelines.

•Lubricate parts (whenever possible) before reassembling them.

•When tightening nuts and screws, start from the ones with the largest section or from the

internal ones, moving diagonally. Tighten nuts and screws in successive steps before ap-

plying the tightening torque.

•Always replace self-locking nuts, washers, sealing rings, circlips, O-rings (OR), cotter pins

and screws with new ones if their tread is damaged.

•When assembling the bearings, make sure to lubricate them well.

•Check that each component is assembled correctly.

•After a repair or routine maintenance procedure, carry out pre-ride checks and test the ve-

hicle on private grounds or in an area with low traffic density.

•Clean all coupling surfaces, oil guard rims and gaskets before refitting them. Smear a light

layer of lithium-based grease on the oil guard rims. Reassemble oil guards and bearings

with the brand or lot number facing outward (visible side).

ELECTRICAL CONNECTORS

Electric connectors must be disconnected as described below; failure to comply with this procedure

causes irreparable damage to both the connector and the wiring harness:

Press the relative safety clips, if applicable.

•Grip the two connectors and disconnect them by pulling them in opposite directions.

•If any signs of dirt, rust, moisture, etc. are noted, clean the inside of the connector carefully

with a jet of compressed air.

•Ensure that the cables are correctly fastened to the internal connector terminals.

•Then connect the two connectors, ensuring that they couple correctly (if fitted with clips, you

will hear them "click" into place).

CAUTION

DO NOT DISCONNECT CONNECTORS BY PULLING THE CABLES.

NOTE

THE TWO CONNECTORS CAN ONLY BE CONNECTED IN ONE DIRECTION: CONNECT THEM

THE RIGHT WAY ROUND.

TIGHTENING TORQUES

CAUTION

V7 III ABS Characteristics

CHAR - 9

IF UNSCREWING A SELF-LOCKING NUT, IT MUST BE REPLACED WITH A NEW ONE.

CAUTION

REMEMBER THAT THE TIGHTENING TORQUE FOR ALL THE FIXING ELEMENTS LOCATED ON

WHEELS, BRAKES, WHEEL AXLES AND OTHER SUSPENSION COMPONENTS PLAY A FUN-

DAMENTAL ROLE IN GUARANTEEING THE SAFETY OF THE VEHICLE AND MUST BE KEPT AT

THE PRESCRIBED VALUES. REGULARLY CHECK THE TIGHTENING TORQUE OF THE FIXING

ELEMENTS AND ALWAYS USE A TORQUE WRENCH WHEN REFITTING. IF THESE WARNINGS

ARE NOT OBSERVED, ONE OF THESE COMPONENTS COULD LOOSEN AND COME OFF,

BLOCKING A WHEEL OR CAUSING OTHER PROBLEMS THAT WOULD COMPROMISE MA-

NOEUVRABILITY, LEADING TO A CRASH WITH THE RISK OF SERIOUS INJURY OR EVEN

DEATH.

Running-in

Engine run-in is essential to ensure engine long life and correct operation. Twisty roads and gradients

are ideal to run in engine, brakes and suspensions effectively. Vary your riding speed during the run-

in. This ensures that components operate under both "loaded" and "unloaded" conditions, allowing the

engine components to cool.

CAUTION

THE CLUTCH MAY EMIT A SLIGHT BURNING SMELL WHEN FIRST USED. THIS PHENOMENON

SHOULD BE CONSIDERED NORMAL AND WILL DISAPPEAR AS SOON AS THE CLUTCH

PLATES GET ADAPTED.

ITIS IMPORTANTTO STRAINENGINECOMPONENTSDURINGRUN-IN, HOWEVER,MAKE SURE

NOT TO OVERDO THIS.

CAUTION

THE FULL PERFORMANCE OF THE VEHICLE IS ONLY AVAILABLE AFTER THE SERVICE AT

THE END OF THE RUNNING IN PERIOD.

Follow these guidelines:

•Do not twist the throttle grip abruptly and completely when the engine is working at a low

revs, either during or after run-in.

•During the first 100 Km (62 miles) use the brakes gently, avoiding sudden or prolonged

braking. That is to permit the adequate adjustment of the pad friction material to the brake

discs.

AFTER THE SPECIFIED MILEAGE, TAKE THE VEHICLE TO AN OFFICIAL Moto Guzzi DEALER

FOR THE CHECKS INDICATED IN THE "AFTER RUN-IN" TABLE IN THE SCHEDULED MAINTE-

NANCE SECTION TO AVOID INJURING YOURSELF, OTHERS AND /OR DAMAGING THE VEHI-

CLE.

Vehicle identification

SERIAL NUMBER LOCATION

These numbers are necessary for vehicle registration.

NOTE

ALTERING IDENTIFICATION NUMBERS MAY BE SERIOUSLY PUNISHABLE BY LAW. IN PAR-

TICULAR, MODIFYING THE CHASSIS NUMBER IMMEDIATELY VOIDS THE WARRANTY.

Characteristics V7 III ABS

CHAR - 10

Table des matières

Autres manuels MOTO GUZZI Moto

MOTO GUZZI

MOTO GUZZI Quota 1000 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI BELLAGIO Manuel utilisateur

MOTO GUZZI

MOTO GUZZI nevada Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V7 III Special Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manuel utilisateur

MOTO GUZZI

MOTO GUZZI V1000 I-Convert Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V1000 G5 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI California III Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 1000 SP III Manuel d'instructions

MOTO GUZZI

MOTO GUZZI BREVA V1100 Manuel de la liste des pièces

MOTO GUZZI

MOTO GUZZI MGS-01 Corsa Manuel d'instructions

MOTO GUZZI

MOTO GUZZI 1200 SPORT Mode d’emploi

MOTO GUZZI

MOTO GUZZI V1000 G5 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI V7 Stone Instructions de construction

MOTO GUZZI

MOTO GUZZI V 35 Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Robin Manuel utilisateur

MOTO GUZZI

MOTO GUZZI 850 Le Mans III Manuel utilisateur

MOTO GUZZI

MOTO GUZZI Sport 1100i 2007 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI CALIFORNIA EV Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Breva V1100 2006 Manuel de la liste des pièces

MOTO GUZZI

MOTO GUZZI GRISO 1100 Manuel utilisateur

MOTO GUZZI

MOTO GUZZI California III Manuel d'instructions

MOTO GUZZI

MOTO GUZZI Stelvio 1200 8V Mode d’emploi

MOTO GUZZI

MOTO GUZZI California Titanium Manuel utilisateur

Manuels Moto populaires d'autres marques

OHVALE

OHVALE GP-0 Manuel de la liste des pièces

Yamaha

Yamaha Star XV19CTSZ 2009 Manuel utilisateur

KTM

KTM 350 XCF-W USA Manuel utilisateur

HYOSUNG

HYOSUNG ST7 Manuel utilisateur

Husqvarna

Husqvarna FC 250 2016 Manuel utilisateur

Ducati

Ducati SCRAMBLER 800 Manuel d'instructions

APRILIA

APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manuel utilisateur

Yamaha

Yamaha 2006 YZF-R1V Manuel utilisateur

KTM

KTM Freeride E-XC 2021 Manuel utilisateur

Fantic

Fantic Enduro 125 Manuel utilisateur

Ducati

Ducati Supersport 750 desmodue Manuel utilisateur

MV Agusta

MV Agusta 2008 F4 312RR 1078 Manuel d'instructions

Yamaha

Yamaha XVS650A Manuel utilisateur

Yamaha

Yamaha YZF-R6T(C) Manuel

Ducati

Ducati 748 monoposto strada Manuel utilisateur

ATK

ATK 1988 250 Manuel utilisateur

Excelsior-HENDERSON

Excelsior-HENDERSON 1999 HCX Manuel utilisateur

Triumph

Triumph Thunderbird Manuel utilisateur
