Mothers choice Torero Mode d’emploi
IMPORTANT! RETAIN FOR FUTURE REFERENCE
Illustrations are representative only.
Design and style may vary.
Instruction Manual & User Guide
Torero 3 Wheel Stroller
2
Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Instruction Manual & User Guide
Page 5 Opening stroller
Page 6 - 7 Wheels assembly
Page 8 Bumper bar
Page 9 Canopy
Front swivel wheel
Page 10 Operating brakes
Adjusting handle
Page 11 Adjusting legrest
Adjusting backrest
Page 12 Securing your child
Page 13 Adjusting harness height
Page 14 Tether strap
Raincover
Page 15 Folding stroller
Page 16 Product care and maintenance
Contact details
Page 3 Warnings
Page 4 Component list
Note:
• The weight of the child using this stroller should not be more than 17kg.
• Total weight for the shopping basket should be more than 4kg.
• Maximum weight for the pocket should not be more than 1kg.
CONTENT
ASSEMBLING THE STROLLER
USING THE STROLLER
MAINTENANCE AND CONTACTS
3
Instruction Manual & User Guide Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
These instructions detail the safe use, assembly and maintenance
of your product. Please read these instructions carefully and
ensure that they are followed at all times. Failure to do so could
result in serious injury or death.
• FOLLOW THE MANUFACTURE’S INSTRUCTIONS.
• ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS
STATIONARY.
• DO NOT LEAVE CHILDREN UNATTENDED.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS
STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS
IF YOU ADJUST THE STROLLER, OTHERWISE THEY MAY BE
INJURED.
• SECURE THE CHILD IN THE HARNESS AT ALL TIMES AND
ENSURE THAT THE SAFETY HARNESS IS ADJUSTED FIRMLY
BUT COMFORTABLY TO THE CHILD’S BODY.
• A harness can form loops that may be a strangulation hazard, never
leaveharnessstrapsconnectedwhennotttedtoachildinthestroller.
• Use the tether strap to prevent the stroller rolling away.
• Do not allow children to stand on the seat or footrest.
• Do not attempt to lift the stroller by the bumper bar.
• Remove the child from the stroller before going up or down stairs or
escalators.
• Engage front wheel swivel locks when travelling on rough or uneven
surfaces.
• Inatetyreto28psi/2.0Bar(195kPa).Overinationmayresultintyre
blowout.
• Regularly inspect the stroller for any parts that are loose, broken, torn
or missing. Attend to the problem as soon as it is noticed.
• Use only those accessories which are supplied by Dorel Australia and
approved for use with this stroller.
• Donotusethestrollernearanopenre,barbecueorexposedame.
• This product is not intended for commercial use.
• Do not run or jog with this stroller.
WARNING TO AVOID INJURY OR DEATH:
4
Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Instruction Manual & User Guide
Component List:
Canopy
Bumper Bar
Footrest
Adjustable
Legrest
Front Wheel
Carry Basket
Rear Wheel
Assembly
Brake Lever
Folding Lock
(Both Sides)
Storage Lock
Handle
Handle
Height
Adjustment
Button
Swivel
Wheel Lock
Safety Harness
Accessories included: Raincover
5
Instruction Manual & User Guide Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Assembling: Torero 3 Wheel Stroller
OPENING STROLLER
• If the stroller has a security tie, please remove it.
• Release the storage latch, as per Figure 1A.
• To unfold the stroller, simultaneously lift handle (A) while resting your foot
on the bar beneath the back of the shopping basket (B) until the locking
mechanism engages, as per Figure 1B.
Figure 1A Figure 1B
Storage
Latch
Press
Lift
A
B
6
Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Instruction Manual & User Guide
To remove the rear wheel assembly.
Press and hold the metal tab, as per Figure 3B. Remove rear
wheel from the axle. Repeat on the other side.
Push
Press
Assembling: Torero 3 Wheel Stroller (cont.)
TO ATTACH REAR AXLE
• Align the rear axle over the rear leg tubes, as per Figure 2A.
• Pushtherearaxleontherearlegtubesuntilthelockingpinmechanism
engages, as per Figure 2B.
Note: This process has to be even on both sides to avoid jamming.
TO FIT REAR WHEEL ASSEMBLY
• Slide rear wheel onto the axle, as per Figure 3A.
• PressthemetaltabandpushwheeluntilitlocksFigure 3B.
• Repeat for other side.
Push
Push Pin
Figure 2A
Figure 3A Figure 3B
Figure 2B
Note:
7
Instruction Manual & User Guide Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Push Push
Pin
Figure 4A Figure 4B Figure 4C
Assembling: Torero 3 Wheel Stroller (cont.)
TO FIT FRONT WHEELS
• Laytheopenstrollerwiththehandleontheoorandtheforkfacingupwards
as per Figure 4A.
• Align the wheel assembly to the front forks.
• Pushthetwoblackplasticconnectorsoverthefrontwheelforktubes,as
per Figure 4B.
• The front wheel assembly will be locked in place when the two locking pins
fully engage, as per Figure 4C.
Note: To detach the front wheel assembly.
Push the two locking pins in while pulling the plastic connectors
off the front wheel forks.
8
Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Instruction Manual & User Guide
Press
Assembling: Torero 3 Wheel Stroller (cont.)
BUMPER BAR
• Opentheswivelclipsttedtoeachsideofthebumperbar.
• Align bumper bar with the frame, as per Figure 5A.
• Clip the ends of the bumper bar onto the frame, as per Figure 5B.
• Close the clips on both sides, as per Figure 5C.
Note: To remove bumper bar, open the clips and separate from frame.
TO ATTACH CROTCH PAD
• Wrap the crotch pad around the bumper bar and attach the press stud, as
per Figure 6.
Figure 6
Figure 5A Figure 5B Figure 5C
Note: To detach the front wheel assembly.
Push the two locking pins in while pulling the plastic connectors
off the front wheel forks.
9
Instruction Manual & User Guide Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Pull
Using: Torero 3 Wheel Stroller
CANOPY
• Pullthefrontedgeofthecanopytoopen,asperFigure 7A & 7B.
Note: To close canopy, simply push backwards.
Note: The canopy is permanently attached to the stroller.
FRONT SWIVEL WHEEL
• Positionfrontwheel,asperFigure 8A
• TO LOCK:Pushtheswivellockupwards,asperFigure 8B.
• TO UNLOCK:Presstheswivellockdownwards,asperFigure 8C.
To lock
To unlock
Figure 7A Figure 7B
Figure 8A Figure 8B Figure 8C
10
Instruction Manual & User Guide
014242 - MC Torero 3 Wheel Stroller - 04 - 13
Instruction Manual & User Guide
APPLY ALL THE BRAKES WHENEVER YOU PARK THE STROLLER.
Press Lift
Using: Torero 3 Wheel Stroller
OPERATING BRAKES
• Toapplythebrakes.Pressdownrmlyonthebrakebarusingtheballof
your foot, as per Figure 9A.
• To release the brakes. Lift the brake bar until the brakes have fully
disengaged. See Figure 9B.
WARNING
ADJUSTING HANDLE
• Pressbothadjustmentbuttonssimultaneouslyandrotatetothedesired
position, as per Figure 10.
Note: Listen for click.
Press
Press
Rotate
Figure 9A
Figure 10
Figure 9B
