The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

morsedrum.com

CONTENTS

Page

Receiving Procedures. . . . . . . . . . . . . . . . . 1

Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Safety Information. . . . . . . . . . . . . . . . . . . . . 1 - 2

Machine Description. . . . . . . . . . . . . . . . . . . 3 - 4

Accessories. . . . . . . . . . . . . . . . . . . . 3

Start-Up Procedure. . . . . . . . . . . . . . . . 5

Operating Instructions. . . . . . . . . . . . . . . . . . . 5

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . 6

Safety Information

While Morse Manufacturing Co. drum handling equipment is

engineered for safety and e󰀩ciency, a high degree of responsibility

must be placed upon the machine operator to follow safe practices,

based primarily on common sense, upon which true safety

depends.

Failure to follow the safety precautions in this manual can result in

personal injury or property damage. Observe the same precautions

as with similar machinery where carelessness in operating or

maintenance is hazardous to personnel. Carefully read the safety

precautions below and throughout this manual.

Receiving Procedures

Every Morse drum handler is inspected prior to shipping. However,

damage may be incurred during transit.

• Check for visible damage. If you choose to accept damaged

freight, always sign noting the damage on the BILL OF LADING.

• Document the damage and have the truck driver sign. We

recommend keeping a digital camera at your receiving dock for

this purpose.

• Open packages expeditiously to check the condition of the

goods. There is only a 24 hour window to notify the carrier of any

concealed damage.

• IMMEDIATELY REPORT ALL DAMAGE TO THE SHIPPING

COMPANY! Then you may contact Morse for assistance with

your freight claim.

• Morse Manufacturing will not be held responsible for any

damaged freight that is not signed for as damaged.

Delivery to non-business addresses without a loading dock result

in additional freight charges. Residential delivery fees, inside

delivery fees, re-delivery charges, and lift gate services will be

added by the truck line, and are non-negotiable.

Limited 2 Year Warranty

Morse drum handling equipment is guaranteed against defects in

workmanship or materials for TWO YEARS when used properly

within its rated capacity. Warranty does not cover wear from

normal use or damage from accident or abuse. Motors and

other purchased parts carry the warranties of their manufacturers.

For warranty claims, contact your Morse Dealer to obtain a

return authorization number, and for return freight advice. Return

freight must be prepaid.

In all instances, liability is limited to the purchase price paid or to

repairing or replacing the product. Customer assumes liability for

any modications, unauthorized repairs or parts substitution.

Operator’s Manual

for Morse Hydra-Lift Drum Karrier

Model 400A-60-117

Serial Number 400000 to ______

The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

Operator’s Manual for Morse Hydra-Lift Karrier Model 400A-60-117

Serial Number 400000 to ______

morsedrum.com

Safety Information (continued)

DANGER - Indicates a situation which, if not avoided, will result in serious injury or

death. This signal word is limited to the most extreme situations.

WARNING - Indicates a situation which, if not avoided, could result in serious

injury or death.

CAUTION - Indicates a situation which, if not avoided, can result in damage to the

machine.

CAUTION – Do Not Transport with Drum Raised

ALWAYS LOWER THE DRUM HOLDER TO LOWEST POSITION BEFORE TRANSPORTING. The

unit can become unstable when transporting with a raised load.

DANGER - Stay Clear of Power Lines

KEEP WELL CLEAR OF POWER LINES. Never approach a power line. Current in a high voltage line

may arc some distance from the wire to the steel framed, grounded machine.

WARNING

The Hydra-Lift Karrier is designed to handle one drum of the types listed at the top of page 3, under 2.

Machine Description. DO NOT attempt to handle any other type of drum or object. DO NOT exceed

the weight capacity.

WARNING - Level Floors Only

For operation only on clean, level oors of suitable bearing capacity. Do not use on sloped surfaces,

ramps, irregular or debris strewn oors.

WARNING - Do Not Modify the Unit

Under no circumstances should any modications be made to the Morse machinery without factory

authorization. Any modications may void the warranty. This machine was designed to perform a

specic job and alterations may result in injury to operator or machine.

WARNING - No Loose Fitting Clothing

Wear close-tting clothing and safety equipment appropriate to the job. Loose tting clothing may

become caught on the machinery and cause severe personal injury.

WARNING - Hydraulic Fluid Under Pressure Can Be Hazardous

Escaping hydraulic uid under pressure can penetrate the skin, causing serious injury. Avoid the

hazard by relieving pressure before disconnecting hydraulic lines. Keep hands and body away from

pinholes and nozzles, which eject uid under high pressure. Use a piece of cardboard to search for

leaks. If an accident occurs, see a doctor immediately and inform them of the nature of the accident.

CAUTION - Wear Safety Shoes

Wear safety shoes with non-slip soles and hard toe protection.

WARNING: This product can expose you to chemicals including barium sulfate, cobalt, titanium

dioxide, and 2-methylimidazole, which are known to the State of California to cause cancer, and

bisphenol-A, which is known to the State of California to cause birth defects or other reproductive harm.

For more information go to www.P65Warnings.ca.gov

The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

Operator’s Manual for Morse Hydra-Lift Karrier Model 400A-60-117

Serial Number 400000 to ______

morsedrum.com

Machine Description

The Model 400A-60-117 Hydra-Lift Karrier will pour a drum up to 72” (183

cm) high, measured from the oor to the lowest point of a horizontal drum.

It is designed to lift, transport, and dispense a 55-gallon (210 liter) steel

drum 22” to 23.5” (56 to 59.7 cm) in diameter.

Maximum full-drum capacity is 800 Lb. (363 kg). Capacity is derated to

500 Lb. (227 kg) for a half-full drum. Half-full rating is based on the tilt

mechanism’s capacity for handling an unbalanced bottom-heavy drum.

55/30 Series Diameter Adapters for drum with diameter smaller than 22”

(56 cm). To handle a smaller drum, insert the correct size Diameter Adapter

into the standard drum holder. See Diameter Adapter info at:

https://morsedrum.com/products/diameter-adapters

ONLY Diameter Adapters for drum with 17.5” (44.5 cm) diameter or smaller

have integrated brackets to prevent drum slipping length-ways.

NOTE: For 30-gallon (114 Liter) PLASTIC drum, insert Diameter Adapter;

AND install Bracket or Top Rim Clamp to prevent drum slipping.

IMPORTANT: To prevent 30 to 55 gallon (114 to 210 L) size plastic drum from

slipping, you MUST install either Top Rim Clamp Kit or Bracket Assembly Kit.

1. Bracket Assembly Kit # 4556-P is required to handle a RIMLESS

plastic drum (gure 2.1), and is also recommended for a ber drum.

The Bracket adjusts for a 31” to 39” (79 to 99 cm) tall drum.

You can also handle a rimmed drum with the Bracket installed.

2. Top Rim Clamp Kit # 4560B-P to handle a RIMMED plastic drum

(gure 2.2). Install the Top Rim Clamp Kit to handle a RIMMED

plastic, steel or ber drum with suitable top rim.

ACCESSORIES

Figure 2.2

Kit # 4560B-P

Install Top Rim Clamp Kit

to handle RIMMED plastic

drum

Figure 2.1

Kit # 4556-P

Install Bracket Assembly Kit

to handle RIMLESS or

RIMMED plastic drum

The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

Operator’s Manual for Morse Hydra-Lift Karrier Model 400A-60-117

Serial Number 400000 to ______

morsedrum.com

Figure 2.3

WARNING - Watch Out for Pinch Points

Stay clear of moving parts. Operator should

remain behind the push handle during the lift

operation.

Floor Lock

The screw-down oor lock is located on the base of the tower

(gure 3.1). Turning the oor lock clockwise until it locks in the

down position activates the oor lock. When the oor lock is

activated it prevents unwanted free wheeling of the unit. Floor

conditions determine the e󰀨ectiveness of the oor lock. The

operator should verify its holding action before depending on it to

hold.

Drum Holder Assembly

The MORCINCHTM Drum Holder (Saddle) assembly is the

component on intended to hold the drum. It is designed to secure

a standard ribbed 55-gallon (210 liter) steel drum around it’s middle

using a cinch chain and ratchet tightening system. It automatically

adjusts for 22” to 23.5” (56 to 59.7 cm) diameter drum.

The MORCINCHTM Drum Holder also accepts accessories to

handle a plastic drum, ber drum, or a smaller diameter drum.

Figure 3.1

Motor Information

Motor is dual voltage and can be wired for 1-phase 110V 50Hz or 1-phase 220V

50Hz. Motor does NOT come with switch, cord or plug. Consult an electrician

to install and wire according to local codes.

Controls

There are two functions for the operator to control (Figure 2.3):

1. “LIFT” and lower function for vertical positioning of the drum

2. “TILT” function to control the degree of rotation of the drum

1. LIFT and Lower Function

To raise the drum

a. Plug the motor into power supply.

b. Turn the motor on by holding the momentary switch in the on position.

c. With the motor on, raise the LIFT handle.

To lower the drum

a. With the motor o󰀨, push in the LOWER handle.

2. TILT Function

To tilt the drum forward for pouring

a. Turn on the motor by holding momentary switch in the on position.

b. With the motor on, raise the tilt handle.

To return the drum to vertical position

a. Turn on the motor by holding momentary switch in the on position.

b. Push the tilt handle down.

The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

Operator’s Manual for Morse Hydra-Lift Karrier Model 400A-60-117

Serial Number 400000 to ______

morsedrum.com

CAUTION – Do Not Transport with Drum Raised

ALWAYS LOWER THE DRUM HOLDER TO LOWEST POSITION BEFORE TRANSPORTING. The

unit can become unstable when transporting with a raised load.

5.) Lift drum to desired pouring height. Operate the tilt control as described in “Machine Description - Controls” (page

3) to adjust the drum attitude. This is especially important when lifting an open drum. The oor lock should be engaged

while dispensing / draining.

6.) When dispensing is complete, tilt drum back to upright position. Disengage the oor lock and lower the drum to trans-

porting height; about 6” (15 cm) o󰀨 the oor.

WARNING - Stay Clear of Raised Drum

NEVER allow anyone to be below any part of a raised drum handler or drum. Remain behind

the push handle while handling a drum.

WARNING – Do NOT Disengage the Cinch Chain When Drum is o󰀨 the Ground

When the drum is in the upright position, lower the drum to the oor before releasing the cinch

chain.

7.) Push unit to drum storage area and lower drum to oor in upright position. Release cinch chain from ratchet by applying

pressure to ratchet handle in a clockwise direction with one hand and opening pawl to free ratchet with the other hand.

Remove cinch chain link from ratchet.

Figure 3.2

START-UP Procedure

Machine is shipped with hydraulic uid.

1. Install provided hydraulic control levers (threaded rods with black ball handles).

2. IMPORTANT: BEFORE operation, remove the RED shipping plug from the hydraulic reservoir, and replace with the

provided BLACK breather.

Operating Instructions

1.) Push Hydra-Lift Karrier to drum.

2.) Using “LIFT” control as described in “Machine Description -

Controls”, position drum holder assembly with back band at

middle of drum (Figure 3.1). With ratchet plate swung open

and cinch chain hanging from chain hook, push unit until back

band rests rmly against drum. Some adjustment to tilt angle

of saddle may be necessary to ensure band ts ush on drum.

3.) Attaching the drum:

Drape chain across front of drum and engage a link into notch

in ratchet (Figure 3.2). Turn ratchet clockwise to tighten chain.

If ratchet turns until the pawl is beyond last ratchet tooth,

turn ratchet back and slide next link into ratchet notch and try

tightening again. Chain must be held tightly against drum with

pawl engaged securely in ratchet teeth.

4.) Operate lift function to lift drum clear of oor. Roll to dispensing

location. NOTE: Do NOT allow drum to impact on oor,

pouring station, etc. or a spill or damage could occur.

The Specialist In Drum Handling Equipment

Model 400A-60-117

Hydra-Lift, 60”, AC Power Lift & Tilt

Operator’s Manual for Morse Hydra-Lift Karrier Model 400A-60-117

Serial Number 400000 to ______

morsedrum.com

Maintenance

Periodic inspection for the general condition of structural and mechanical components is imperative for safe and e󰀩cient

operation.

Periodically inspect all moving parts, framework, and contact areas for signs of wear, fatigue, or loosening. Tighten, adjust,

or replace parts as necessary to prevent failure and maintain proper function.

Inspect the hydraulic system for oil drips, hose damage, or other signs of wear. Inspect the level and condition of the hy-

draulic uid. Replace any parts that show signs of wear.

Grease wheel bearings periodically. Oil or grease all moving parts including: the three clevis pins and the surfaces of the

boom which contact the inside of the mast cap, the hinge pin, the gears and sprockets in the tilt drive, and the ratchet and

pawl.

Worn or damaged parts must be properly replaced with the correct, genuine Morse parts.

Hydraulic pump is shipped lled with Noco Premium plus automatic transmission uid d/m. Material safety data sheet

(MSDS) is available online. Change oil yearly, sooner depending on dirty conditions or outdoor use. Replace oil with Mobil

dte 24 or equivalent for indoor use (Mobil dte 13 for outdoor use).

Table des matières

Autres manuels morse Système de levage

morse

morse 185i/E Manuel utilisateur

morse

morse 510 Manuel utilisateur

morse

morse 400A-72SS-110 Manuel utilisateur

morse

morse 410-114 Manuel utilisateur

morse

morse 400A-96-117 Manuel utilisateur

morse

morse 515-N-110 Manuel utilisateur

morse

morse 82H-SS-125 Manuel utilisateur

morse

morse 525-N-115 Manuel utilisateur

morse

morse 400A-60-120 Manuel utilisateur

morse

morse Kontrol-Karrier 185A Manuel utilisateur

morse

morse 510-120 Manuel utilisateur

morse

morse 8A-GT-125 Manuel utilisateur

morse

morse 400Z-60 Manuel utilisateur

morse

morse Hydra-Lift Drum Karrier 400AM-60-124 Manuel utilisateur

morse

morse 400A-96SS-117 Manuel utilisateur

morse

morse 520 Manuel utilisateur

morse

morse 185A-HDSS Manuel utilisateur

morse

morse 510M-124 Manuel utilisateur

morse

morse 40 Manuel utilisateur

morse

morse 510SS-110 Manuel utilisateur

morse

morse 510M-114 Manuel utilisateur

morse

morse 400A-96-127 Manuel utilisateur

morse

morse 410M-124 Manuel utilisateur

morse

morse 525-N-115 Manuel utilisateur

Manuels Système de levage populaires d'autres marques

Braun

Braun NL955 Series Manuel utilisateur

haacon

haacon 1889.10 Manuel utilisateur

Protekt

Protekt AT 252 Manuel utilisateur

R. Beck Maschinenbau

R. Beck Maschinenbau HS 600 Manuel utilisateur

Nova Technology International, LLC

Nova Technology International, LLC NAS Series Manuel utilisateur

Genie

Genie Z-60/34 Manuel utilisateur

Screen Technics

Screen Technics INTERFIT Vertical Up Lift Manuel utilisateur

Mortuary Lift

Mortuary Lift ULTIMATE 1000 Manuel utilisateur

Custom Equipment

Custom Equipment Hy-Brid 3 Series Manuel de programmation

Custom Equipment

Custom Equipment Hy-Brid Lifts 2 Series Manuel de programmation

Hy-Brid Lifts

Hy-Brid Lifts HB-P3.6 Manuel de programmation

BERG

BERG BeNomic EasyLeaf Manuel utilisateur

Powermate

Powermate LiftGate LG-3 Manuel utilisateur

Snorkel

Snorkel TM12 Series Manuel utilisateur

Terberg

Terberg OMNIDEKA Manuel utilisateur

Harmar Mobility

Harmar Mobility AL625 Mode d'emploi

Rotary

Rotary SPO16 Manuel utilisateur

Ricon

Ricon Mirage F9T Manuel utilisateur

morse 400A-60-117 Manuel utilisateur

Manuels Système de levage populaires d'autres marques
