Morphy Richards IB73090 Manuel utilisateur

Pod vacuum cleaner

Please read and keep these instructions

getting the best from

your new cleaner...

If your cleaner isn’t picking up as well as

it should, please check

• Dust filter

It is important to clean it everytime you empty the pod,

otherwise the performance of the cleaner will be impaired.

See page 5 - Cleaning the dust filter. A spare dust filter is

provided.

• Blockages

Check the nozzle, tube and hose for blockages.

www.morphyrichards.co.uk

73090 Rev 1 28/4/04 5:42 PM Page 1

Important safety

instructions

The use of any electrical appliance requires

the following of common sense safety rules.

Primarily there is danger of personal injury

and secondly danger of damage to the

appliance and property. These are indicated in

the text by the following two conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following essential

safety advice.

Location

•Do not use or keep this product outside

when it is raining.

•Do not store the appliance near hot ovens

or heating appliances.

Mains lead

•Do not allow the mains lead to become

strained or run this appliance over it.

•If the electrical cable becomes damaged

the complete cable assembly must be

replaced. Do not attempt this task yourself,

contact Morphy Richards using the

helpline number.

Children

•Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use this

appliance.

Other safety considerations

•Never use the appliance without the filters

installed.

•Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

•Never use in the presence of explosive

liquids or vapours.

•Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or

other volatile substances. Never pick up

acids, asbestos or asbestos dust.

•Always disconnect the appliance from the

mains supply after use or prior to cleaning

or emptying.

•The appliance should never be left running

unsupervised.

•Never modify the cleaner in any way.

•Repairs to electrical appliances are only to

be undertaken by trained personnel.

Unprofessional repairs can be dangerous

for users.

•Use only genuine Morphy Richards spare

parts and accessories

Electrical

requirements

Check that the voltage on the rating plate

of your appliance corresponds with your

house electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and

the appropriate one fitted.

WARNING: The plug removed from the

mains lead, if severed, must be

destroyed as a plug with bared flexible

cord is hazardous if engaged into a live

socket outlet.

Should the fuse in the 13 amp plug require

replacement, a BS1362 13 amp fuse must be

fitted.

Description

Your Pod vacuum cleaner is a versatile

machine that can be used as an upright

cleaner or as a handheld.

73090 Rev 1 28/4/04 5:42 PM Page 2

⁄

‡

›

‚

ﬁ

ﬂ

Features

⁄Telescopic handle release button

¤On/off switch

‹Telescopic tube extension button

›Telescopic handle

ﬁHandle locking release pin (not shown)

ﬂCarrying handle

‡Pod release button

·Dust collection pod

‚Wheels

„Mesh filter (inside)

‰Dust filter (inside)

ÂBrush storage location

ÊFlexible hose

ÁHose end location

ËHose end

ÈExhaust filter cover

ÍCable storage hanger

ÎCable storage quick release lever

ÏFloor nozzle release button

ÌBody

Accessories you should have:

ÓTelescopic handle tube

ÔFloor nozzle

Plastic extension tube

ÒCrevice tool (stored inside )

ÚBrush attachment



ÒÚ

‹

‰

„



73090 Rev 1 28/4/04 5:42 PM Page 3

Assembly

To use as an upright

1Fit the floor nozzle by pressing in the locking

pin and insert the nozzle into the hole at the

base of the body D. Push down fully.

2Locate the telescopic handle into the body

by pushing in the locking pin and lowering

the handle in until the locking pin locates in

the locking hole E. To remove, press in the

release button ⁄and lift the handle out.

3Adjust the telescopic handle by sliding the

button ‹down and pulling out or pushing

in the lower half F.

To use as a handheld

1Remove the telescopic handle.

2Remove the floor nozzle by pressing in the

release button Ï and pulling the floor

nozzle away from the body G.

3Slide the hose end Ëfrom the hose end

location Á. H

4Fit the extension tube to the hose end

Ë.

5Fit the crevice tool Ò to the extension tube.

6If required fit the brush Ú to the end of the

crevice tool.

Attachments

Uses for the brush attachment include

stairs, upholstery, mattresses, curtains and hard

surfaces like door mouldings and skirting

boards. The crevice tool is particularly useful for

cobwebs and in narrow gaps in the car around

the handbrake and seat.

‹

73090 Rev 1 28/4/04 5:42 PM Page 4

‰

„

Using

Unwind the cable or turn the quick release

lever Î and plug into a mains socket.

Switch on. I

Dust disposal

Ensure the Pod is switched off and

disconnected from the mains supply.

1Slide the pod release button up and pull the

dust pod away from the cleaner. J

Note: When the floor nozzle is fitted the

cleaner must be tilted slightly backwards to

remove the dust pod.

2Lift out the dust filter. K

3Pull out the mesh filter. L

4Empty the dust into a bin.

5Clean the filters as described in next

section.

6Replace the mesh filter into the pod.

7Insert the dust filter, rear section first into the

pod (ensuring it lies level with

the pod). M

‰

73090 Rev 1 28/4/04 5:42 PM Page 5

Cleaning the mesh

and dust filters

IMPORTANT: Every time the pod is emptied,

clean the filters by shaking rigorously, or by

using the brush attachment.

To maintain high suction, the dust filter ‰

should also be washed regularly in warm water,

but do not use detergent.

Allow the filter to dry naturally and ensure it

is totally dry before installing it back into the

cleaner.

A spare dust filter is provided to allow you to

continue using your vacuum whilst the original

filter is washed and dried.

Replacing dust

container

1Insert the hook at the bottom rear of the

dust pod into the tray on the body. N.

2Push the dust pod towards the cleaner body

until it clicks into place.

Exhaust filter

After approximately 5 emptyings of the dust

container the exhaust filter should be cleaned.

1Unclip the exhaust filter cover Èby lifting

the bottom tab. O

2Remove foam filter.

3Shake the filter vigorously to remove any

build up of dust.

4Refit exhaust filter cover by inserting top two

pegs then clip in the bottom tab.

Depending on usage, the exhaust filter

should be replaced approximately every 6

months.

Purchasing

replacement filters

The lifetime of the dust filter is dependant

largely upon usage of the cleaner. Should the

dust filter become damaged or if there is a

noticeable drop in performance even after

washing, it should be changed immediately. Use

only Morphy Richards replacement filters which

can be purchased from specialist retailers or by

calling the number on the front page of this

leaflet.

73090 Rev 1 28/4/04 5:42 PM Page 6

Cleaning the

machine

Use the brush attachment on the hose and

use the Pod to vacuum itself. To keep the

underside of the cleaning head clean, vacuum it

at regular intervals using the crevice tool.

Or, disconnect the Pod from the mains

supply and remove dust by using a soft damp

cloth and wipe dry. Do not use scourers or

abrasive cleaners.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought it.

Please have the following information ready

to enable our staff to deal with your query

quickly:

•Name of the product;

•Model number as shown on the underside

of the appliance;

•Serial number.

73090 Rev 1 28/4/04 5:42 PM Page 7

VC73090M UK Rev 1 0204

Your two-year

guarantee

•It is important to retain the retailers

receipt as proof of purchase. Staple your

receipt to this back cover for future

reference.

Please quote the following information if the

product develops a fault. These numbers can

be found on the base of the product.

Model no. Serial no.

All Morphy Richards products are

individually tested before leaving the factory. In

the unlikely event of any appliance proving to

be faulty within 28 days of purchase it should

be returned to the place of purchase for it to be

replaced.

If the fault develops after 28 days and within

24 months of original purchase, you should take

the appliance to your nearest service agent. A

list containing details of your nearest service

agent is included with your appliance but

please contact the helpline quoting model

number and serial number should you require

further assistance. Repair or replacement of the

product is subject to the exclusions set out

below (1-6).

If you suspect a fault, follow the simple

checks detailed below before returning the

appliance or calling the helpline.

•Check the filters for blockages.

•Check the hose and tubes for blockages.

•Check the plug is firmly in the socket and

the supply is switched on.

•Make sure the socket is working by trying

another appliance.

If for any reason this item is replaced during

the two-year guarantee period, the guarantee

on the new item will be calculated from original

purchase date. Therefore it is vital to retain your

original receipt or invoice to indicate the date of

initial purchase.

To qualify for the two-year guarantee the

appliance must have been used according to

the manufacturers instructions.

Morphy Richards shall not be liable to replace

or repair the goods under the terms of the

Guarantee where:

1The fault has been caused or is attributable to

accidental use, mis-use, negligent use or used

contrary to the manufacturers

recommendations or where the fault has been

caused by power surges or damage caused in

transit.

2The appliance has been used on a voltage

supply other than that stamped on the

products.

3Repairs have been attempted by persons other

than our service staff (or authorised dealer).

4Where the appliance has been used for hire

purposes or non-domestic use.

5The guarantee excludes consumables such as

the filters.

6Morphy Richards are not liable to carry out any

type of servicing work, under the guarantee.

This guarantee does not confer any rights

other than those expressly set out above and

does not cover any claims for consequential

loss or damage. This guarantee is offered as an

additional beneﬁt and does not affect your

statutory rights as a consumer.

•This guarantee is valid in the UK and Ireland

only.

The After Sales Division,

Registered address,

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK 0870 060 2604

Republic of Ireland 1800 409119

Morphy Richards products are intended

for household use only

Morphy Richards has a policy of

continuous improvement in product

quality and design. The Company,

therefore, reserves the right to change

the specification of its models at any

time.

For additional information on Morphy Richards products www.morphyrichards.co.uk

73090 Rev 1 28/4/04 5:42 PM Page 8

Table des matières

Autres manuels Morphy Richards Aspirateur

Morphy Richards

Morphy Richards Bagged cylinder Vacuum Manuel utilisateur

Morphy Richards

Morphy Richards Perfom air VC71067MUK Manuel utilisateur

Morphy Richards

Morphy Richards IB73370 Manuel utilisateur

Morphy Richards

Morphy Richards IB70045 Manuel utilisateur

Morphy Richards

Morphy Richards IB73091 Manuel utilisateur

Morphy Richards

Morphy Richards Scoot bagless vacuum cleaner Manuel utilisateur

Morphy Richards

Morphy Richards Supervac deluxe Manuel utilisateur

Morphy Richards

Morphy Richards IB73350 Manuel utilisateur

Morphy Richards

Morphy Richards IB70041 Manuel utilisateur

Morphy Richards

Morphy Richards Goblin 73276 Manuel utilisateur

Morphy Richards

Morphy Richards GrimeBuster steam cleaner Manuel utilisateur

Morphy Richards

Morphy Richards VC73184 Manuel utilisateur

Morphy Richards

Morphy Richards STORM LIGHT UPRIGHT VACUUM CLEANER - REV 3 Manuel utilisateur

Morphy Richards

Morphy Richards ORB PETS CYCLONE VACUUM CLEANER - REV 1 Manuel utilisateur

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuel utilisateur

Morphy Richards

Morphy Richards IB73170 Manuel utilisateur

Morphy Richards

Morphy Richards PremAir Cyclonic 70035 Manuel utilisateur

Morphy Richards

Morphy Richards VC73215 MUK Manuel utilisateur

Morphy Richards

Morphy Richards 732000 Supervac Manuel utilisateur

Morphy Richards

Morphy Richards Supervac gold Manuel utilisateur

Morphy Richards

Morphy Richards CYCLONIC BAGLESS VACUUM CLEANER - REV 4 Manuel utilisateur

Morphy Richards

Morphy Richards ESSENTIALS COMPACT BAGLESS VACUUM CLEANER - REV... Manuel utilisateur

Morphy Richards

Morphy Richards VORTICITY Manuel utilisateur

Morphy Richards

Morphy Richards VC7341DMUK Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
