Essentials mini bagged cylinder

vacuum cleaner

Please read and keep these instructions

VC73179 MUK Rev 1

For replacement parts, help with using your Morphy Richards product,

problems and lots more, contact us by phone or through our website.

UUKKHHeellpplliinnee::0088444488771100994499

RReeppllaacceemmeennttPPaarrttss::0088444488773300771155

IIrreellaannddHHeellpplliinnee::11880000440099111199

Getting the best from your new cleaner...

If your cleaner is not picking up as well as it should, please check:

Dustbags

It is important to replace them when full, otherwise the performance of

the cleaner will be impaired. The dustbag compartment lid will not close

unless the dustbag is fitted correctly. See ‘Replacing the dustbag’.

Filters

It is important that the filters are cleaned every time you change the

dustbag. Replace the filters every 5 dustbag changes, otherwise the

performance of the cleaner will be impaired. See ‘Cleaning the filters’.

Blockages

Check the nozzle, tubes and hose for blockages.

73179 rev1 17/3/08 16:04 Page 1

IMPORTANT

SAFETY

INSTRUCTIONS

The use of any electrical

appliance requires the

following common sense

safety rules.

Primarily there is danger of

injury or death and

secondly the danger of

damage to the appliance.

These are indicated in the

text by the following two

conventions:

WARNING: Danger to

the person!

IMPORTANT: Damage to

the appliance!

In addition, we offer the

following safety advice.

Location

• Do not use or keep this

product outside.

• Do not store the appliance

near hot surfaces, eg.

ovens or heating

appliances.

Mains lead

• Do not allow the mains

lead to become strained or

run this appliance over it.

• If the electrical cable

becomes damaged, the

cable assembly must be

replaced. Do not attempt

this task yourself, contact

the helpline number at the

bottom of the page.

Personal safety

•WARNING: Keep loose

clothing, hair, fingers etc.

away from the floor

nozzle whenever the

cleaner is connected to

the mains.

• Never touch the plug or

cable with wet hands.

• Disconnect from the mains

supply before attempting to

clear blockages and clear

the brush.

• The plug must be removed

from the wall socket before

cleaning or maintaining the

appliance.

• Never use in the presence

of explosive liquid or

vapours.

• Never pick up inflammable

or poisonous liquids such

as petrol, copier toner or

other volatile substances.

Never pick up acids,

asbestos or asbestos dust.

• Unprofessional repairs can

be dangerous for users.

• The appliance must never

be left running

unsupervised.

• This appliance is intended

for domestic use only.

Misuse or use for

commercial or any other

purpose will render the

guarantee invalid.

• Always disconnect the

appliance from the mains

supply after use or prior to

emptying or cleaning.

• To protect against fire,

electric shock and personal

injury, do not immerse the

cord, plug or cleaner in

water or other liquid.

• This appliance is not

intended for use by

persons (including children)

with reduced physical,

sensory or mental

capabilities, or lack of

experience and knowledge,

unless they have been

given supervision or

instruction concerning the

use of the appliance by a

person responsible for their

safety.

Product safety

• Never use the appliance

without the filters or bag

installed.

• Never use the appliance to

vacuum hot ashes, broken

glass, sharp objects or

liquids.

• Use only Morphy Richards

spare parts and

accessories.

• Never modify the cleaner in

any way.

Children

• Children do not understand

the dangers associated

with operating electrical

appliances. Never allow

children to use this

appliance.

• Children should be

supervised to ensure that

they do not play with the

appliance

, or stumble over

the power cord.

ELECTRICAL

REQUIREMENTS

Check that the voltage on

the rating plate of your

appliance corresponds with

your house electricity

supply which must be A.C.

(Alternating Current).

If the socket outlets in your

home are not suitable for

the plug supplied with this

appliance, the plug should

be removed and the

appropriate one fitted.

If you cut off the plug and

let go of the cable, it will

rewind into the machine,

therefore, you must pull out

a length of cable and

secure it before cutting the

plug off and re-fitting a new

one.

WARNING: The plug

removed from the mains

lead, if severed, must be

destroyed, as a plug with

a bared flexible cord is

hazardous if engaged

into a live socket outlet.

Should the fuse in the 13

amp plug require changing,

a 13 amp BS1362 fuse

must be fitted.

UUKKHHeellpplliinnee0088444488771100994499RReeppllaacceemmeennttPPaarrttss0088444488773300771155IIrreellaannddHHeellpplliinnee11880000440099111199

73179 rev1 17/3/08 16:04 Page 2

FEATURES

⁄Hose handle with airflow

control

¤Extension tubes

‹Brush attachment

›Crevice tool

ﬁCombination floor nozzle

ﬂHose

‡Hose inlet

·Carrying handle

‚Dust bag compartment lid

release

„Dust bag compartment lid

‰On/off Eco Switch

ÂCable rewind switch

ÊDust bag condition

indicator

ÁExhaust filter cover

ËOn tube tool storage

ÈTurbo nozzle

(certain models only)

Í & ÎStair and hair tool

ﬂ

„

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

⁄

‹

ﬁ

‡

‰Ë

‚

Í Î

›

73179 rev1 17/3/08 16:04 Page 3

OPERATING THE

APPLIANCE

1Assemble the nozzle, tubes and

hose as shown in ‘Features’.

2Pull out the cable to it’s full

length and plug in to the mains

supply.

3Switch on by pressing the on/off

Eco Switch.

OPERATION

Accessories

1Fit the hose to the cleaner by

inserting the hose end into the

hose inlet ‡ A.

2To remove, press the release

button down on the hose and

pull out.

3Attach the extension tubes ¤ to

the hose handle which features

an airflow control which can be

adjusted as required.

4Attach the combination floor

nozzle to the extension tubes.

The floor nozzle ﬁhas a pedal

to switch between two

positions:

• Brush up for carpets, rugs etc.

• Brush down for hard floors, tiles

etc.

5The other accessories include:

• Crevice tool ›for awkward

places, behind radiators etc.

• Brush attachment ‹for

pelmets, delicate objects etc.

This attaches to the crevice tool.

To alternate between the brush

and crevice tool, push the

button down and slide B.

Tools storage

The crevice tool and brush can

be stored on the tubes for

added convenience.

Product storage C

When finished, you can store

the vacuum cleaner as shown

by inserting the hook on the

floor nozzle into the slot on the

cleaner body.

Turbo nozzle È

(certain models only)

This nozzle is suitable for

cleaning and rejuvenating cut

pile carpets and is ideal for

picking up stubborn dirt and pet

hairs.

Cleaning the turbo

nozzle (certain models only)

The turbo nozzle should be

regularly cleaned and any hairs

or fibres wrapped around the

brush bar removed to maintain

optimum performance.

Using the stair and

hair tool

Attach the stair tool Í to the

hose handle ⁄ or extension

tubes ¤for effective stair

cleaning.

Attach the hair tool Î to the

stair tool for fantastic pet hair

pick-up.

UUKKHHeellpplliinnee0088444488771100994499RReeppllaacceemmeennttPPaarrttss0088444488773300771155IIrreellaannddHHeellpplliinnee11880000440099111199

73179 rev1 17/3/08 16:04 Page 4

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

CONTROLS

Power -

On/Off Eco Switch

NOTE: The Eco Switch allows

you to turn down the power

when cleaning more delicate

items such as curtains and

upholstery, saving energy and

reducing running costs.

To switch the cleaner on, press

the on/off Eco Switch ‰

inwards. To switch off, press the

on/off switch again.

The suction power can be

adjusted using this switch again.

Turn the switch to the desired

level D.

Suction may also be varied with

the fingertip control on the

handle:

Closed: full suction

Open: reduced suction

Automatic cable

rewind

After use, unplug and press the

cable rewind button Âto retract

the cable.

WARNING: When using the

cable rewind, always hold

the plug as the cable will

rewind quickly.

DUSTBAG

Dustbag condition

indicator

If the suction power decreases

or if the dustbag condition

indicator shows fully red, then

the bag must be emptied

immediately and/or the motor

protection filter cleaned - even if

the bag does not appear full.

This will also occur if the nozzle,

tubes or hose have become

blocked.

• The dustbag indicator may

occasionally show red during

use - this is quite normal.

Replacing the

dustbag

To obtain the best results from

your cleaner, be sure to check

and change the dustbag

regularly, otherwise the airflow

and cleaning power of your

cleaner will be reduced and you

may damage your cleaner.

1Lift the dust compartment lid

‚.

2Pull the dustbag retaining clip

forward to release. Carefully lift

the dustbag clear of the cleaner

and dispose of the dustbag.

3To fit the new dustbag, first

place the bottom end of the

dustbag collar into the guide

slot at the bottom of the

dustbag compartment, then pull

the collar forward until it locates

into the securing clip E.

4The arrow on the collar of the

dustbag must point downwards

when fitting F.

NOTE: The dustbag

compartment lid will not close

unless the dustbag is fitted

correctly.

IMPORTANT:

• All filters should be checked

regularly for signs of damage,

preferably after each cleaning

task. The filters must be

replaced immediately if they

become damaged.

• Always disconnect the cleaner

from the mains when checking

filters or replacing the dustbag.

• Always make sure the dustbag,

grill and filters are fitted before

use. Failure to do so may result

in damage to your product.

73179 rev1 17/3/08 16:04 Page 5

FILTERS

Motor filter

The motor filter must be

cleaned every time the bag is

changed to remove the fine dust

particles collected. This can be

done by shaking it.

However, after approximately 5

dustbag changes, the filter

should be replaced.

The motor filter is found behind

the dustbag. Remove the filter

grill, press the centre tab and

pull out G. Pull out the filter H,

shake to clean and replace. The

grill must be replaced after the

filter has been cleaned.

Exhaust filter

The exhaust filter must be

cleaned every time the bag is

changed to remove the fine dust

particles collected. This can be

done by shaking it.

However, after approximately 5

dustbag changes, the filter

should be replaced.

The exhaust filter is located

behind the exhaust filter cover

Á. To remove, unclip the cover

and remove the filter Iand

clean and replace.

HINTS & TIPS

Cleaning and

maintenance

Your cleaner is manufactured to

withstand normal day-to-day

use, but an occasional wipe

over will help maintain it’s good

looks. Abrasive cleaners should

not be used.

Purchasing dustbags

and replacement

filters

Use only Morphy Richards

replacement dustbags and

filters which can be purchased

from specialist retailers or by

calling the number below.

HELPLINE

If you have any difficulty with

your appliance, do not hesitate

to call us.

We are more likely to be able

to help than the store from

where you bought it.

Please have the following

information ready to enable our

staff to deal with your query

quickly.

• Name of the product

• Model number as shown on the

underside of the appliance.

• Serial number as shown on

underside of the appliance.

UK Helpline 0844 871 0949

Replacement Parts 0844 873 0715

Ireland Helpline 1800 409 119

UUKKHHeellpplliinnee0088444488771100994499RReeppllaacceemmeennttPPaarrttss0088444488773300771155IIrreellaannddHHeellpplliinnee11880000440099111199

73179 rev1 17/3/08 16:04 Page 6

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

YOUR TWO YEAR

GUARANTEE

It is important to retain the

retailer’s receipt as proof of

purchase. Staple your receipt to

this back cover for future

reference.

Please quote the following

information if the product

develops a fault. These numbers

can be found on the base of the

product.

Model no.

Serial no.

All Morphy Richards products

are individually tested before

leaving the factory. In the unlikely

event of any appliance proving

to be faulty within 28 days of

purchase, it should be returned

to the place of purchase for it to

be replaced.

If the fault develops after 28

days and within 24 months of

original purchase, you should

contact the Helpline number

quoting Model number and

Serial number on the product, or

write to Morphy Richards at the

address shown.

You may be asked to return a

copy of proof of purchase.

Subject to the exclusions set out

below (see Exclusions), the

faulty appliance will then be

repaired or replaced and

dispatched usually within 7

working days of receipt.

If you suspect a fault, follow the

simple checks detailed below

before retrying the appliance or

calling the helpline.

• Check the filters for blockages.

• Check the tools / tubes for

blockages.

• Check the plug is firmly in the

socket.

• Check the socket is working by

trying another appliance.

• Check the fuse in the plug.

If, for any reason, this item is

replaced during the 2 year

guarantee period, the guarantee

on the new item will be

calculated from the original

purchase date. Therefore, it is

vital to retain your original till

receipt or invoice to indicate the

date of initial purchase.

To qualify for the 2 year

guarantee, the appliance must

have been used according to the

instructions supplied.

EXCLUSIONS

Morphy Richards shall not be

liable to replace or repair the

goods under the terms of the

guarantee where:

1The fault has been caused or is

attributable to accidental use,

misuse, negligent use or used

contrary to the manufacturer’s

recommendations or where the

fault has been caused by power

surges or damage caused in

transit.

2The appliance has been used on

a voltage supply other than that

stamped on the products.

3Repairs have been attempted by

persons other than our service

staff (or authorised dealer).

4The appliance has been used for

hire purposes or non domestic

use.

5The appliance is second hand.

6Morphy Richards are not liable

to carry out any type of servicing

work under the guarantee.

7The guarantee excludes

consumables such as filters and

dust bags.

• This guarantee does not confer

any rights other than those

expressly set out above and

does not cover any claims for

consequential loss or damage.

This guarantee is offered as an

additional benefit and does not

affect your statutory rights as a

consumer.

• This guarantee is valid in the UK

and Ireland only.

For electrical products sold

within the European

Community. At the end of the

electrical products useful life,

it should not be disposed of

with household waste.

Please recycle where facilities

exist. Check with your Local

Authority or retailer for

recycling advice in your

country.

73179 rev1 17/3/08 16:04 Page 7

Morphy Richards products are intended for household use only.

Morphy Richards has a policy of continuous improvement in product quality and

design. The company, therefore reserves the right to change the specification of

it’s models at any time.

The After Sales Division

Morphy Richards Ltd

Mexborough, SouthYorkshire,

England, S64 8AJ

Helplines (office hours)

UK 0844 871 0949

Spare Parts 0844 873 0715

Republic of Ireland 1800 409 119

VC73179 MUK Rev 1 03/08

FFoorrddeettaaiillssooffootthheerrpprroodduuccttssiinntthheeMMoorrpphhyyRRiicchhaarrddssrraannggee,,pplleeaasseesseeeeoouurrwweebbssiittee......

wwwwww..mmoorrpphhyyrriicchhaarrddss..ccoomm

73179 rev1 17/3/08 16:04 Page 8

Table des matières

Autres manuels Morphy Richards Aspirateur

Morphy Richards

Morphy Richards Supervac Sleek Pro Manuel utilisateur

Morphy Richards

Morphy Richards IB73350 Manuel utilisateur

Morphy Richards

Morphy Richards ESSENTIAL MINI VACUUM CLEANER - REV 1 Manuel utilisateur

Morphy Richards

Morphy Richards Vacuum Cleaner Manuel utilisateur

Morphy Richards

Morphy Richards BAGLESS CYLINDER VACUUM CLEANER - REV 2 Manuel utilisateur

Morphy Richards

Morphy Richards Ecovac 70096 Manuel utilisateur

Morphy Richards

Morphy Richards 732000 Supervac Manuel utilisateur

Morphy Richards

Morphy Richards ESSENTIALS CYCLONIC BAGLESS UPRIGHT VACUUM CLEANER - REV... Manuel utilisateur

Morphy Richards

Morphy Richards ORB CYCLONE VACUUM CLEANER - REV 3 Manuel utilisateur

Morphy Richards

Morphy Richards VC73111 MUK Manuel utilisateur

Morphy Richards

Morphy Richards Bagged cylinder Vacuum Manuel utilisateur

Morphy Richards

Morphy Richards Steam cleaner Manuel utilisateur

Morphy Richards

Morphy Richards VORTICITY Manuel utilisateur

Morphy Richards

Morphy Richards 73294 Manuel utilisateur

Morphy Richards

Morphy Richards Ecolectric 73383 Manuel utilisateur

Morphy Richards

Morphy Richards Supervac Manuel utilisateur

Morphy Richards

Morphy Richards BAGLESS UPRIGHT VACUUM CLEANER - REV 1 Manuel utilisateur

Morphy Richards

Morphy Richards ECO PRIUS Manuel utilisateur

Morphy Richards

Morphy Richards Supervac Deluxe Manuel utilisateur

Morphy Richards

Morphy Richards IB73301 Manuel utilisateur

Morphy Richards

Morphy Richards GrimeBuster steam cleaner Manuel utilisateur

Morphy Richards

Morphy Richards BIG POD BAGLESS VACUUM CLEANER - REV 2 Manuel utilisateur

Morphy Richards

Morphy Richards PremAir Cyclonic 70035 Manuel utilisateur

Morphy Richards

Morphy Richards Allergy cylinder vacuum cleaner Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
