Morphy Richards Total Control Manuel utilisateur
FP400015 MU Rev 1
Stand Mixer
GUARANTEE
2
YEAR
Please read and keep these instructions for future use
* Register online for your 2 year guarantee. See the back of this instruction book for details (U and Ireland customers only).
www.facebook.com/morphyrichardsuk
@loveyourmorphy
www.morphyrichards.co.uk/blog
For competitions, product hints and tips
and more join us at
download the
free app
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 1
2
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
•This appliance shall not be used by children.
•This appliance can be used by persons with reduced physical,
sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction
concerning the use of the appliance in a safe way and understand
the hazards involved.
•Children shall not play with the appliance.
•eep the appliance and its cord out of reach of children.
•Switch off the appliance and disconnect from the supply before
changing accessories or approaching parts that move.
•CAUTION: In order to avoid a hazard due to inadvertent resetting
of the thermal cut out, this appliance must not be supplied
through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by
the utility.
•For cleaning refer to page 10.
•Do not mix for longer than the time periods recommended in
‘Usage’ on page 7.
•Switch off the appliance and disconnect from the supply before
cleaning accessories or approaching parts that move in use.
•If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified person in
order to avoid a hazard.
Health And Safety
Location
•Always locate your appliance away from the edge of the
worktop.
•Do not place the bowl used with the appliance on a
highly polished wooden surface as damage may occur to
the surface.
•Do not place the appliance on or near a hot surface,
such as a hot plate or radiant rings or near a naked
flame.
Mains cable
•Do not let the mains cable hang over the edge of the
worktop where a child could reach it.
•Do not let the lead run across an open space e.g.
between a low socket and a table.
•Do not let the cable run across a cooker or other hot area
which might damage the cable.
•The mains cable should reach from the socket to the
base unit without straining the connections.
Personal safety
•WARNING: To protect against the risk of electric shock,
NEVER immerse the appliance body in water or in any
other liquid and always ensure the electrical connections
are kept dry.
•It is advisable to use the Bowl Cover on the bowl for
whisking.
•Ensure the attachments have stopped rotating before
lifting the mixer head upwards.
Other safety considerations
•The use of attachments or tools not recommended or
sold by Morphy Richards may cause fire, electric shock
or injury.
•Do not use the appliance for anything other than its
intended purpose.
Electrical requirements
Check that the voltage on the rating plate of your
appliance corresponds with your house electricity supply
which must be A.C. (Alternating Current).
Should the fuse in the mains plug require changing, a 13
amp BS1362 fuse must be fitted.
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 2
3
Health And Safety ......................................................... 2
Introduction .................................................................. 3
Total Control ................................................................. 4
Product Overview ........................................................ 5
Before First Use ........................................................... 6
Using Your Stand Mixer .............................................. 6
Usage ........................................................................... 7
Capacity ....................................................................... 7
Hot Food ...................................................................... 7
Automatic Programs .............................................. 8
Automatic Program Times ..................................... 9
Pausing ........................................................................ 9
Bowl Cover .................................................................. 9
Attachments ................................................................ 10
Care And Cleaning ....................................................... 10
Contact Us ................................................................... 10
Recipes ........................................................................ 11
Guarantee ..................................................................... 20
Contents
Thank you for your recent purchase of this Morphy Richards Total
Control Stand Mixer.
Y
our Stand Mixer comes with beater, whisk and dough hook accessories to
make a multitude of dishes. Please read the instructions for information on
how to use your Mixer before use.
Remember to visit www.morphyrichards.co.uk to register your product’s two
year guarantee.
Introduction
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 3
4
Giving you the power to create with
confidence.
Introducing the Total Control Stand Mixer
the simple way to bring confidence to your
cooking.
The Total Control Stand Mixer allows you to create
delicious cakes, meringues and more with the
confidence and reassurance the Smart Response
Technology delivers.
Smart Response Technology allows you to have
Total Control of the mixing process with the
simple touch of a button. The Smart Response
Technology gently feeds power into the mixer as
you need it ensuring a constant speed is
maintained giving you perfect results every time.
Either select from the pre-set automatic
programs; bread dough, eggs or cake, add your
ingredients by following the recipe and let the
Total Control Stand Mixer do all the work
for you.
Alternatively to personalise your recipe simply use
the Total Control Stand Mixer on the manual
setting by selecting your mixing speed. The Smart
Response Technology will feed power gradually
building to your chosen speed for the job at hand.
Even with heavier mixtures the Smart Response
Technology will gently feed power into the motor
to ensure a constant speed is achieved for
perfect results every time.
The Total Control Stand Mixer, giving you the
power to create with confidence.
Automatic Programs
Speed Control
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 4
5
Features
(1) Head Unit
(2) Bowl Cover
(3) Mixing Bowl
(4) Head Release Lever
(5) Preset Cake Button
(6) Preset Egg Button
(7) Preset Dough Button
(8) Start/Pause Button
(9) Variable Speed Control
(10) Bowl Locator
(11) Attachment Sleeve
(12) Attachment Socket
(13) Splash Guard
(14) Beater
(15) Dough Hook
(16) Whisk
(17) Mains Switch (Side Face)
1
2
3
10
4
12
14 15 16
11
13
5
7
6
8
9
17
Product Overview
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 5
6
5
Press the Head Release Lever (4) and lower
the Head Unit (1) pressing down until locked
in position. (You will hear an audible click and
the Lever will return).
4
Place the attachment and Splash Guard into
the Attachment Socket (12). Rotate the
Attachment Sleeve (11) clockwise to secure
into place.
2
Place the Mixing Bowl (3) into the recessed
Bowl Locator (10). Twist anti-clockwise to lock
into place.
1
Press the Head Release Lever (4) and lift the
Head Unit (1). The Head Unit will lock in the
upright position. You will hear an audible click.
Using Your Stand Mixer
6
Add the ingredients to the Mixing Bowl (3).
Do not exceed the maximum quantity (1.5kg).
Before using your Stand Mixer for the first time,
clean the Bowl Cover (2) Mixing Bowl (3) Splash
Guard (13) and attachments (14),(15),(16) in warm
soapy water. Dry thoroughly.
o parts are dishwasher safe.
Ensure the mains switch is in the on position ‘1’.
This is positioned on the side of the mixer, near the
mains cable entry point.
Before First Use
3
Place the Splash Guard (13) onto the required
attachment (14),(15),(16). The Splash Guard
will fix into the two notches on either side of
the screw thread.
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 6
7
Your Stand Mixer features a safety cut out
designed to protect the motor from overheating.
To prevent overheating after 5 minutes of
continuous use you will need to switch off your
stand mixer and leave to cool for 10 minutes,
especially important when mixing heavier
mixtures. If your machine cuts out during mixing
turn the Speed Control (9) to position ‘0’ and
leave to cool for 10 minutes.
The automatic programs are designed for longer
run periods.
Maximum usage is calculated on the Mixer
running at full speed and full load. On lower
speeds such as the Preset Dough Program
or lighter loads it may be able to run for longer
periods without issue.
Do not overfill the Mixing Bowl (3). Overfilling may
cause damage to the mixer and other areas of
your kitchen. The maximum quantity is 1.5kg.
Your Stand Mixer is capable of mixing hot foods,
however the Mixing Bowl is made of stainless
steel which may get hot during use.
Care must be taken when handling hot food and
liquid in the Mixing Bowl.
Usage
Hot Food
Capacity
8
Alternatively turn the Speed Control to
position ‘P’ to pulse for short bursts.
7
T
urn the Speed Control (9) to position 1 to
start the Stand Mixer, increase the speed as
required.
10
Twist the Mixing Bowl (3) clockwise to unlock and
remove from your Stand Mixer before emptying
its contents.
9
When finished, turn your Stand Mixer off. Press
the Head Release Lever (4) and lift the Head Unit
(1). The Head Unit (1) will lock in the upright
position. Rotate the Attachment Sleeve (11)
anti-clockwise to release the attachment.
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 7
8
Your Stand Mixer comes with 6 automatic programs,
designed to perfectly whisk, knead and beat a range
of cakes, breads and meringues to perfection.
See page 12 for our automatic recipes.
Preset Cake Button (5)
1Using the Beater (14), setting 1 is used to mix
cake batter for sponge cakes.
2Using the Beater, setting 2 is used to make
buttercream.
Preset Egg Button (6)
1Using the Whisk (16) setting 1 is used to whisk
egg whites for meringues or making desserts.
2Using the Whisk, setting 2 is used to whip
double cream.
Preset Dough Button (7)
1Using the Dough Hook (15), setting 1 is for
making and kneading white bread dough.
2Using the Dough Hook, setting 2 is for making
and kneading granary bread dough.
Automatic Programs
4
Press the Start/Pause Button (8). Your Mixer
will start the mixing program.
2
Press the Preset Button (5),(6),(7) for the
desired Program /Attachment.
The button will illuminate.
1
Follow steps 1-6 of ‘Using Your Stand Mixer’.
Insert the relevant Attachment (14),(15),(16) to
the Head Unit (1) for the desired program.
3
Turn the Speed Control (9) to position 1 or 2 to
select the program. Your Stand Mixer will not
start if set to any other speeds.
6
While paused, add any other ingredients
(as required). Press the Start/Pause Button (8)
to continue. When finished, your Stand Mixer
will stop and all lights will extinguish.
5
On the cake preset, your Stand Mixer will
pause part way through the programme and
the button will flash. If required, scrape the
sides of the bowl down with a spatula.
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 8
9
Automatic Program Times
•Cake -1 (02:30)
Cake Batter
•Beater (14) •01:30 •Yes •01:00
•Egg -2 (03:00)
Double Cream
•Whisk (16)
Program Attachment Stage 1 Pause Stage 2
•Cake -2 (03:00)
Buttercream
•Beater (14) •01:30 •Yes •01:30
•Egg -1 (04:09)
Egg Whites
•Whisk (16)
•Bread -1 (10:00)
White
•Dough Hook
(15)
•Bread -2 (10:00)
Granary/
Wholemeal
•Dough Hook
(15)
•While any automatic program is running, you can pause at any time by pressing the Start/Pause
Button (8). Press the Start Button again to continue. Timings are in minutes/seconds.
Pausing
The Cake programs will automatically pause part
way through, enabling you to scrape the bowl
down with a spatula or add ingredients
(if necessary).
To pause your Stand Mixer while running any
of the programmes, press the Start/Pause
Button (8).
When paused, the selected Program Button will
flash (highlighting the programme hasn’t yet
finished). Press the Start/Pause Button to
continue. While paused, you can raise the
Head Unit or allow the mixture to rest for up
to 3 minutes.
To prevent ingredients splashing out of the Mixing
Bowl (3), or to stop flour becoming airborne, your
Stand Mixer is supplied with a Bowl Cover (2).
The Bowl Cover is fixed to the Head Unit (1) by
pushing it onto the Head Unit when your Stand
Mixer Head Unit is in the raised position.
Attach the Cover before fitting the attachment
(14),(15),(16). It is advisable to place the Bowl
Cover on the Mixing Bowl when mixing.
Pausing Bowl Cover (2)
The mixer automatically adjusts the speed and time according to the selected program.
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 9
10
Your Stand Mixer is supplied with three mixing
attachments, each is designed for a specific task.
Beater (14)
Use the Beater for creaming butter and sugar,
mixing cake mixes and making short crust pastry.
When using the Beater it is recommended to use
speeds 1-4 as higher speeds may cause
splashing.
Dough Hook (15)
The Dough Hook is designed to knead dough for
baking fresh bread.
Whisk (16)
The Whisk is ideal for whisking egg whites and
cream. It is recommended to use the maximum
speed with this attachment.
When beating egg whites, it will take roughly 2-3
minutes to achieve soft peaks. Mix a minimum of
4 large egg whites (200ml), use a maximum of 12
egg whites at one time.
•Before cleaning, switch your Stand Mixer off and
unplug from the mains.
•Ensure your Stand Mixer has cooled completely
before cleaning.
•To clean the Main Unit, use a damp cloth. Do not
immerse in water. Do not use any abrasive or
solvent-based cleaner.
•Wash the attachments in hot soapy water.
Dry thoroughly.
o parts are dishwasher safe.
•WAR I G: ever immerse the main unit in
water or other liquid.
Helpline
If you are having a problem with your appliance,
please call our Helpline, as we are more likely to
be able to help than the store you purchased the
item from.
Please have the product name, model number
and serial number to hand when you call to help
us deal with your enquiry quicker.
U Helpline: 0344 871 0944
IRE Helpline: 1800 409 119
Spares: 0344 873 0710
Talk To Us
If you have any questions or comments, or want
some great tips or recipe ideas to help you get
the most out of your products, join us online:
Blog: www.morphyrichards.co.uk/blog
Facebook: www.facebook.com/morphyrichardsuk
Twitter: @loveyourmorphy
Website: www.morphyrichards.com
Attachments
Care And Cleaning
Contact Us
FP400015 MUK REV1.qxp_Layo t 1 02/09/2015 10:30 Page 10
Autres manuels pour Total Control
12
Table des matières
Autres manuels Morphy Richards Mixer
Morphy Richards
Morphy Richards Total Control Manuel utilisateur
Morphy Richards
Morphy Richards Kitchen machine with attachments Manuel utilisateur
Morphy Richards
Morphy Richards 48405 Manuel utilisateur
Morphy Richards
Morphy Richards Accents Manuel utilisateur
Morphy Richards
Morphy Richards KITCHEN MACHINE Manuel
Morphy Richards
Morphy Richards MIXSTAR 400520 Manuel utilisateur
Morphy Richards
Morphy Richards Accents 48992 Manuel utilisateur
Morphy Richards
Morphy Richards Total Control 400405 Manuel utilisateur
Morphy Richards
Morphy Richards 400004 Manuel utilisateur
Morphy Richards
Morphy Richards Latitude 48970 Manuel utilisateur
