Jet Steam & Jet Stream

ironing system

Please read and keep these instructions

Getting the best from your new ironing system....

Safety first

Caution must be used when handling this appliance as it does get very hot. Always switch off

the unit and allow to cool before cleaning or storing.

Water tank (certain models are illuminated)

The water tank can be removed and re-filled at any time during ironing. Certain Morphy

Richards steam generators have an illuminated water tank. The changing colours enhance the

mood for ironing by creating a colourful atmosphere to help you glide through your washing

basket.

Performance

To extend the performance and life of your steam generator, ensure that you replace the

anti-scale medium regularly.

RN42277 MUK Rev 6

If you have a problem or complaint, please call our dedicated UK based helpline

before returning your product to the retailer from where it was purchased.

UK Helpline: 0844 871 0953

Replacement Parts: 0844 873 0719

Ireland Helpline: 1800 409 119

!To improve the life of your new product and to ensure the cleanliness of your

clothes, we strongly recommend the use of distilled or demineralised water.

42277 rev6:42288 rev1 08/04/2009 10:24 Page 1

IMPORTANT

SAFETY

INSTRUCTIONS

The use of any electrical

appliance requires the use

of common sense and

strict following of safety

rules.

Primarily there is danger of

injury or death and

secondly the danger of

damage to the appliance.

These are indicated in the

text by the following two

conventions:

WARNING: Danger to the

person!

IMPORTANT: Damage to

the appliance!

In addition, we offer the

following safety advice.

Location

• Do not use outdoors.

• The steam generator must

be used and rested on a

stable surface.

• When placing the iron unit

on the base unit or on its

heel, ensure that the

surface on which the heel

or base unit is placed is

stable.

Children

• Children do not understand

the dangers associated

with operating electrical

appliances. Never allow

children to use, or play

with, this appliance.

• Close supervision is

necessary when any

appliance is used near

children.

• Children should be

supervised to ensure that

they do not play with this

appliance.

Personal Safety

• Burns can occur from

touching hot metal parts,

hot water or steam. Use

caution when using your

steam generator. If your

iron is placed for a few

moments on the iron rest

plate, this plate may reach

very high temperatures. In

this instance, do not touch

the iron soleplate or the

iron rest plate until the iron

and the iron rest have

cooled down.

• Do not use the vertical

steam feature on clothes

that are being worn.

• Do not leave the steam

generator unattended

whilst plugged in or on an

ironing board. Never allow

the mains lead to over

hang the work surface.

• The mains socket should

always be switched off

before plugging or

unplugging from the

socket. Never yank the

cord to disconnect from

the socket, instead, grasp

the plug and pull to

disconnect.

• This appliance is not

intended for use by

persons (including children)

with reduced physical,

sensory or mental

capabilities, or lack of

experience or knowledge,

unless they have been

given supervision or

instruction concerning the

use of the appliance by a

person responsible for their

safety.

Other safety

considerations

• Use the steam generator

only for its intended use.

• Never hold the generator

base set under the tap.

• To protect against the risk

of electric shock, do not

immerse the appliance in

water or in any other liquid.

• Always disconnect the tank

from the base unit when

filling with water and

emptying.

• Always disconnect the

steam generator from the

electrical supply when

cleaning or when not in

use.

• If the supply cord is

damaged, it must be

replaced by the

manufacturer, its service

agent or similarly qualified

person(s) in order to avoid

a hazard.

• Do not operate the steam

generator with a damaged

cord or if the iron has been

dropped or if there are

visible signs of damage or

if it is leaking. To avoid the

risk of electric shock, do

not disassemble the iron or

steam generator, but

telephone Morphy Richards

for advice. Incorrect

reassembly can cause a

risk of electric shock when

the iron is used.

• If the need arises to

change the mains cable on

your steam generator or

the iron, please return to

Morphy Richards service

department at the address

on the back page.

Special

instructions

• If your steam generator

does not work, check the

following points:

Has the iron temperature

control been set to the

required temperature? Is

the plug in its socket? Is

the plug itself or the socket

faulty? (Check by plugging

in another appliance).

• To prevent damage to the

textile being ironed, follow

the temperature guide

carefully. (Test on the inside

of the hem of the garment).

2UK Helpline 0844 871 0953 Replacement Parts 0844 873 0719 Ireland Helpline 1800 409 119

42277 rev6:42288 rev1 08/04/2009 10:24 Page 2

For details of other Morphy Richards products, please see our website:

Symbol

(120°C Max) Cool (160°C Max) Warm (210°C Max) Hot

Control knob

positions

Do not iron

at all

Fabric Nylon, Acetates

e.g. Acrilan

Courtelle, Orlon

Triacetates, e.g.

Tricel/Polyester

Wool, Polyester

mixtures e.g.

Polyester/Cotton

Cotton, Linen

Rayon, Rayon

mixtures,

e.g. Rayon/Linen

Ironing Iron on wrong side,

if moisture required

use damp cloth

(Not Acetate)

Fabrics requiring this

setting usually require

steam pressing for heavy

cotton, denim etc.

Steaming

Dry

‘Max setting’

INSTRUCTIONS FOR USE

Temperature guide

• When ironing is complete,

remove the plug from the

socket, empty any remaining

water from the tank, and allow

to cool before storage.

• If you drop or severely knock

your steam generator, this could

cause internal damage even if

the outside appears alright.

Have it checked by a qualified

electrician.

• The temperature of accessible

surfaces may be high when the

appliance is operating.

WARNING: Do not use the

product on a surface which

could be damaged by heat or

steam such as a worktop or a

polished wood surface.

If in doubt, contact Morphy

Richards.

ELECTRICAL

REQUIREMENTS

Check that the voltage on the

rating plate of your appliance

corresponds with your house

electricity supply which must be

A.C. (Alternating current).

If the socket outlets in your

home are not suitable for the

plug supplied with this

appliance, the plug should be

removed and the appropriate

one fitted.

WARNING: A damaged or

severed mains cable fitted

with a plug should never be

connected to the mains

supply. It must be destroyed,

as a damaged cable becomes

hazardous if connected to a

power socket.

Should the fuse in the 13 amp

plug require changing, a 13 amp

BS1362 fuse must be fitted.

WARNING: This appliance

must be earthed.

Heat setting markings on the adjustable control dial of all Morphy Richards irons match those of

the International Textile Care Labelling Code.

42277 rev6:42288 rev1 08/04/2009 10:24 Page 3

COMPONENTS OF

YOUR STEAM

GENERATOR

Iron unit

⁄Steam trigger

¤Temperature control knob

‹Soleplate

›Temperature indicator light

ﬁSupply cord from base unit

Base unit

ﬂAnti-scale cartridge

‡Water tank

(illuminated on certain models)

·Power cord

‚Power switch

„Mode indicator light:

• Appliance off = no lights

• Pre-heating = flashing red light

• Ready to use = green light

• Auto shut-off mode =

flashing red and green light

‰Replace anti-scale medium

indicator

ÂSteam level indicators

LOCATION

Locate the steam generator

horizontally on the iron rest plate

of your ironing board (if large

enough) or on a heat resistant

stand at the same height as

your ironing board or below it.

Always ensure the generator is

on a firm surface when ironing.

WARNING: Do not use the

product on a surface which

could be damaged by heat or

steam such as a worktop or a

polished wood surface.

If in doubt, contact Morphy

Richards.

BEFORE USE

Remove any protective sticker

from the soleplate and the base

unit, if any.

Unwind and straighten the

power cord ·and supply cord

ﬁ.

Slide out the water tank ‡ and

fill (see filling instructions).

When ironing with the iron

temperature set at 2-dot setting,

the steam output should be set

at the lower end of the steam

range.

Textiles and clothes are

supposed to carry ironing

instructions. If they don’t, you

should follow the fabric guide on

page 3, but be sure to test the

temperature by ironing the hem

of the garment or similar area

first.

If you turn the control dial down

from a hot setting to a cooler

setting, wait until the iron

temperature has stabilised

before you continue ironing.

4UK Helpline 0844 871 0953 Replacement Parts 0844 873 0719 Ireland Helpline 1800 409 119

⁄

‹

›

ﬁ

ﬂ

‡

„

‚

‰Â

COMPONENTS OF YOUR STEAM GENERATOR

42277 rev6:42288 rev1 08/04/2009 10:24 Page 4

FILLING

1Place the steam generator on a

stable ironing board or table,

with the iron resting on its stand.

2Release the detachable water

tank by sliding outwards A.

3Remove the anti-scale cartridge

by pulling upwards B.

4Fill the tank to the ‘fill to here’

line with clean tap water C.

IN HARD WATER AREAS, THE

USE OF DISTILLED OR

DEMINERALISED WATER IS

RECOMMENDED.

WARNING: Never use battery

topping up fluid or water

containing any substances

like starch or sugar, or

defrosted water from a

refrigerator.

5Re-install the anti-scale

cartridge and re-position the

water tank on the base unit and

push securely into place. Please

make sure the tank is secure D.

6Always pour out any remaining

water after use.

Re-filling ‘in use’

1When the water level becomes

low, the pump begins to emit a

clicking noise. This is due to air

being pumped instead of water

and is quite normal.

Refilling can be done whilst the

appliance is in operation. It is

not necessary to wait for the

appliance to cool down.

2Slide out the water tank and fill

(see filling instructions).

Steam ironing

1Unwind and straighten the

power cord ·and supply cord

ﬁ.

2Slide out the water tank and fill

(see filling instructions).

3Connect the appliance to a

suitable mains outlet, and

switch on the socket. All 5 red

lights will flash once only and a

beep will be heard. Press the

power on switch ‚and the unit

will turn on, it will default to Max

steam, and the “on” light will

flash red whilst heating up.

When ready for use, the light will

turn green.

4Press the power switch again to

scroll through steam settings to

the “no steam” position (no

steam lights illuminated). Press

the power switch again to go to

the maximum steam position.

5Turn the temperature dial on the

iron in a clockwise direction,

select dot-1, dot-2 or dot-3

according to the

recommendation of the garment

label.

6The iron’s temperature indicator

light ›goes off when the

required temperature is reached.

7Depress the steam button ⁄for

1 minute to clear the system of

air (first time use only) which will

be accompanied by a clicking

noise which is quite normal.

8Begin first time ironing with an

old towel. Note: If you press the

steam button before the steam

generator reaches its required

temperature, a warning double

bleep will sound. It takes about

1 minute to reach the required

temperature.

9Press the power button ‚to

choose the steam level from

‘steam off’, ‘low steam’,

‘medium steam’ and ‘maximum

steam’.

10 The appliance is ready to use.

11 Press the steam button ⁄for

steam ironing.

12 To switch the iron off, turn the

temperature dial on the iron in

an anti-clockwise direction to

‘Min’.

13 Depress and hold the power

switch for 2 seconds, the base

console will beep and switch to

off.

Helpline 0870 060 2614 Replacement Parts 0870 157 6645 Ireland Helpline 1800 409119

For details of other Morphy Richards products, please see our website:

42277 rev6:42288 rev1 08/04/2009 10:24 Page 5

www.morphyrichards.com

UK Helpline 0844 871 0953 Replacement Parts 0844 873 0719 Ireland Helpline 1800 409 119

Dry ironing

1Connect the appliance to a

suitable mains outlet.

2Press the power switch 3 times

until all three steam level

indicators go off (steam off

mode).

3Turn the temperature dial on the

iron in a clockwise direction,

select dot-1, dot-2, or dot-3

according to the

recommendation of the garment

label.

4The temperature indicator light

glows on the iron, indicating that

it is switched on.

5When the required temperature

is reached, the temperature

indicator light on the iron goes

off. The iron is ready to use.

It is always a good idea to begin

with ‘cool’ fabrics and work up

to higher settings.

An iron heats up quicker than it

cools down so you’ll save time

and electricity.

Auto-shut off

An auto-shut off system will

activate if the steam is not used

for over 15 minutes. The mode

indicator light „will flash

between green and red,

indicating the unit is in ‘sleep

mode’.

When this occurs, press the

steam trigger ⁄or the power

switch ‚once. The appliance

will switch on immediately and

you need to select the required

setting.

ANTI-SCALE SYSTEM

The anti-scale cartridge is

designed to reduce the build-up

of limescale which occurs

during steam ironing. This will

prolong the working life of your

iron. However, please note that

the anti-scale cartridge will not

completely stop the natural

process of limescale build-up.

Replacing anti-scale

medium

How often you need to replace

the medium depends on how

often you use your iron with its

steam functions and how ‘hard’

your water supply is. Water

hardness varies greatly from one

area to another. For advice on

the relative hardness of your

water, contact your local water

supplier.

If, on average, you spend 2

hours per week ironing, then we

suggest you replace your

anti-scale medium as shown in

the table below. If you iron more

or less frequently, then you

should alter the interval between

refills accordingly.

Replacement

anti-scale refills

To obtain replacement anti-scale

refills, telephone our spares

number on: 0844 873 0719.

• If a new re-fill is not available,

you may continue operating the

appliance but scale will build up

in the system. Replace the anti-

scale refill as soon as possible.

1Disconnect the appliance from

the mains outlet.

2Slide out the tank and remove

the antiscale cartridge E.

3Pull the plate from the end of

the cartridge F.

4Remove the foam pad Gand

slide out the spent antiscale

sleeve H.

5Place the refill into the cartridge,

reposition the foam pad and clip

the plate onto the cartridge,

making sure it locks in position.

6After changing the anti-scale

cartridge, press the anti-scale

button once before replacing the

water tank I.

Water

hardness Soft Medium Hard

Refill interval

(months) 6 3 11/2

42277 rev6:42288 rev1 08/04/2009 10:24 Page 6

Helpline 0870 060 2614 Replacement Parts 0870 157 6645 Ireland Helpline 1800 409119

FEATURES OF

YOUR STEAM

GENERATOR

Temperature

indicator light

The indicator light shows

that the iron is warming up.

When the required

temperature is reached, the

light will go out and will

cycle on-off during

operation.

Steam function

During the steaming

process, small amounts of

water may be ejected from

the soleplate. This is normal

and can be avoided by

using the steam for short

amounts of time and only

when the iron is at the

correct temperature (the

indicator light on the iron

goes out when ready).

Sudden jolts of the boiler

unit can also cause water

droplets on the soleplate;

therefore, do not move the

base unit during ironing. We

recommend for the first

time ironing that you iron

over an old towel.

Vertical steam

Hold the iron in a vertical

position between 1cm and

2cm away from the item J.

Press the steam trigger ⁄,

this will create vertical

steam.

This feature is especially

useful for removing creases

from hanging clothes,

curtains, wall hangings, etc.

Emptying and

storing

When you have finished

ironing, unplug your steam

generator.

1Slide out the water tank

and remove the anti-scale

cartridge K.

2Empty the water in the tank

by holding it upside down

3Replace the anti-scale

cartridge and reinstall the

water tank.

Unplug the generator and

leave the iron to cool off for

15 minutes minimum. The

iron must be placed on the

iron rest plate.

The iron and boiler can now

be stored together.

MAINTENANCE

To clean a stainless steel

soleplate

To keep the soleplate of

your iron clean and free of

limescale, we recommend

that you use one of the

gentle chrome, silver or

stainless steel cleaners that

are generally available.

Always follow the

manufacturer’s instructions.

To clean off melted man-

made fibres, set the iron at

3-dot position and pass it

over a clean piece of cotton

which will draw the deposit

off the surface.

To clean a coated

soleplate

(certain models only)

In the unlikely event of any

man-made fibre fusing to

the soleplate, set the iron at

the 3-dot position and pass

it over a clean piece of

cotton, this will draw the

deposit off the surface.

Do not use scouring

powder or solution, as this

could cause damage to the

coating.

To clean the

exterior

Allow the steam generator

to cool and wipe over with

a damp cloth and mild

detergent, then wipe with a

dry cloth.

HELPLINE

If you have any difficulty

with your appliance, do not

hesitate to call us.

We are more likely to be

able to help than the store

from where you bought it.

Please have the following

information ready to enable

our staff to deal with your

query quickly.

• Name of the product

• Model number and Serial

number as shown on

underside of the appliance.

UK Helpline

0844 871 0953

Replacement Parts

0844 873 0719

Ireland Helpline

1800 409 119

WEBSITE

You may also contact us

through our website, or visit

the site to browse and

purchase appliances, spare

parts and accessories from

the extensive Morphy

Richards range.

For details of other Morphy Richards products, please see our website:

42277 rev6:42288 rev1 08/04/2009 10:24 Page 7

Morphy Richards products are intended for household use only.

Morphy Richards has a policy of continuous improvement in product quality and

design. The company, therefore, reserves the right to change the specification of

its models at any time.

The After Sales Division

Morphy Richards Ltd

Mexborough, South Yorkshire,

England, S64 8AJ

Helplines (office hours)

UK 0844 871 0953

Spare Parts 0844 873 0719

Republic of Ireland 1800 409 119

RN42277 MUK Rev 6 04/09

YOUR TWO YEAR

GUARANTEE

It is important to retain the

retailer’s receipt as proof of

purchase. Staple your

receipt to this back cover

for future reference.

Please quote the following

information if the product

develops a fault. These

numbers can be found on

the base of the product.

Model no.

Serial no.

All Morphy Richards

products are individually

tested before leaving the

factory. In the unlikely event

of any appliance proving to

be faulty within 28 days of

purchase, it should be

returned to the place of

purchase for it to be

replaced.

If the fault develops after

28 days and within 24

months of original

purchase, you should

contact the Helpline

number quoting Model

number and Serial number

on the product, or write to

Morphy Richards at the

address shown. You may

be asked to return a copy

of proof of purchase.

Subject to the exclusions

set out below (see

Exclusions), the faulty

appliance will then be

repaired or replaced and

dispatched usually within 7

working days of receipt.

If, for any reason, this item

is replaced during the 2

year guarantee period, the

guarantee on the new item

will be calculated from the

original purchase date.

Therefore, it is vital to retain

your original till receipt or

invoice to indicate the date

of initial purchase.

To qualify for the 2 year

guarantee, the appliance

must have been used

according to the

manufacturer’s instructions.

For example, kettles should

have been regularly

descaled.

EXCLUSIONS

Morphy Richards shall not

be liable to replace or

repair the goods under the

terms of the guarantee

where:

1The fault has been caused

or is attributable to

accidental use, misuse,

negligent use or used

contrary to the

manufacturer’s

recommendations or where

the fault has been caused

by power surges or

damage caused in transit.

2The appliance has been

used on a voltage supply

other than that stamped on

the products.

3Repairs have been

attempted by persons other

than our service staff (or

authorised dealer).

4The appliance has been

used for hire purposes or

non domestic use.

5The appliance is second

hand.

6Morphy Richards are not

liable to carry out any type

of servicing work, under the

guarantee.

7Plastic filters for all Morphy

Richards kettles and coffee

makers are not covered by

the guarantee.

• This guarantee does not

confer any rights other than

those expressly set out

above and does not cover

any claims for

consequential loss or

damage. This guarantee is

offered as an additional

benefit and does not affect

your statutory rights as a

consumer.

• This guarantee is valid in

the UK and Ireland only.

For electrical products sold within the

European Community. At the end of the

electrical products useful life, it should

not be disposed of with household

waste.

Please recycle where facilities exist.

Check with your Local Authority or

retailer for recycling advice in your

country.

42277 rev6:42288 rev1 08/04/2009 10:24 Page 8

Autres manuels pour JET STREAM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Morphy Richards Fer

Morphy Richards

Morphy Richards Comfigrip 300007 Manuel utilisateur

Morphy Richards

Morphy Richards IB40620 Manuel utilisateur

Morphy Richards

Morphy Richards ECOLECTRIC 40652 Manuel utilisateur

Morphy Richards

Morphy Richards RN40310MUK - REV 3 Manuel utilisateur

Morphy Richards

Morphy Richards ELITE PRO Manuel utilisateur

Morphy Richards

Morphy Richards SEMI-ELECTRONIC 40715 Manuel utilisateur

Morphy Richards

Morphy Richards IB40614 Manuel utilisateur

Morphy Richards

Morphy Richards Advanced Finish 40743 Manuel utilisateur

Morphy Richards

Morphy Richards Comfigrip Advanced 40741 Manuel utilisateur

Morphy Richards

Morphy Richards Precise Steam Iron Manuel utilisateur

Morphy Richards

Morphy Richards 40734 Manuel utilisateur

Morphy Richards

Morphy Richards JET STREAM Manuel utilisateur

Morphy Richards

Morphy Richards breeze Manuel utilisateur

Morphy Richards

Morphy Richards JET STREAM ELITE+ - AUTRE Manuel utilisateur

Morphy Richards

Morphy Richards ADVANCED FINISH SEMI ELECTRONIC IRON Manuel utilisateur

Morphy Richards

Morphy Richards 303100 Manuel utilisateur

Morphy Richards

Morphy Richards SPEED STEAM Series Manuel utilisateur

Morphy Richards

Morphy Richards IB4050X Manuel utilisateur

Morphy Richards

Morphy Richards ELITE 42288 Manuel utilisateur

Morphy Richards

Morphy Richards Speed Steam Pro Manuel utilisateur

Morphy Richards

Morphy Richards 40692 Manuel utilisateur

Morphy Richards

Morphy Richards INTELLIDOME Manuel utilisateur

Morphy Richards

Morphy Richards IB42370 Manuel utilisateur

Morphy Richards

Morphy Richards 40707 Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
