Morphy Richards CoffeMaker Manuel utilisateur

Pump espresso coffee maker

Please read and keep these instructions

www.morphyrichards.com

getting the best from your

new coffee maker

•Safety first

Caution must be used when handling hot water, coffee or steam.

•Run water through your machine before first

use

It is important to run water through your coffee maker in order to

rinse the machine. You can also run water through to warm your

coffee machine.

•Descale as appropriate for the hardness of the

water in your area

It is important to descale as the performance of your coffee

maker may be impaired by limescale and other impurities in the

water supply.

47507 Rev 1 5/4/05 4:02 PM Page 1

Important safety

instructions

The use of any electrical appliance

requires the following common sense safety

rules.

Primarily there is danger of injury or

death and secondly the danger of damage

to the appliance. These are indicated in the

text by the following two conventions:

WARNING: Danger to the person!

IMPORTANT: Damage to the appliance!

In addition we offer the following safety

advice.

Location

•Remove all the packaging and retain for

future reference.

•Ensure the coffee maker is used on a

firm, flat surface.

•Do not use the coffee maker outdoors or

in a bathroom.

•Do not place the coffee maker on a

highly polished wooden surface as

damage may occur to the surface.

•Do not place the coffee maker on or near

hot surfaces such as a hot plate or

radiant rings or near a naked flame.

•WARNING: Do not place the coffee

maker onto a metal tray or metal

surface whilst in use.

•Do not lift the coffee maker by gripping

the water reservoir. Hold the body of the

coffee maker.

Children

•Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use

this appliance.

Personal safety

•Disconnect the coffee maker from the

mains supply when filling, cleaning or

not in use.

•If the unit stops producing coffee, unplug

and see cleaning instructions page 7.

•Keep the outside of the coffee maker

area clean and dry at all times.

•Do not touch hot surfaces. Always use

handles or knobs.

•Do not touch metal parts until the unit

has cooled.

•WARNING: Do not immerse the

coffee maker itself in water and

always ensure the electrical

connections are kept dry.

•Do not operate any appliance with a

damaged cord or plug or after the

appliance malfunctions or has been

damaged in any manner. Ring the

helpline number for advice on

examination and repair.

•The use of attachments or tools not

recommended or sold by Morphy

Richards may cause fire, electric shock

or injury.

•Do not use abrasive cleaners on the

outside of the coffee maker, they may

scratch the surface. Clean only with a

soft damp cloth.

•Do not use the coffee maker for anything

other than its intended purpose.

•Caution must be used when handling hot

water, coffee or steam.

Product safety

•Never use warm or hot water to fill the

water reservoir.

•Do not overfill the water reservoir.

•Operate the appliance only with the drip

tray in place.

Treating scalds

•Run cold water over the affected area

immediately. Do not stop to remove

clothing, get medical help quickly.

Choice of coffee

•Choose a finely ground espresso coffee

to use with this machine.

Note: Avoid blends that are very

powdery. When the coffee is too finely

ground it may block the filter.

47507 Rev 1 5/4/05 4:02 PM Page 2

STEAM

COFFEE

OFF

The first time you use your coffee maker

Operate the coffee maker with water only.

Electrical requirements

Check that the voltage on the rating

plate of your appliance corresponds with

your house electricity supply which must be

A.C. (Alternating current).

For appliances with fitted plug.

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance the plug should be removed and

the appropriate one fitted.

WARNING : The plug removed from

the mains lead, if severed, must be

destroyed as a plug with bared flexible

cord is hazardous if engaged into a

live socket outlet.

Should the fuse in the 13 amp plug

require changing a 13 amp BS1362 fuse

must be fitted.

WARNING: This appliance must be

earthed.

Features

⁄Warming plate

¤Power light

‹Hot water/steam selector

›On/off switch

ﬁBrewing head

ﬂFilter lock

‡Filter holder

·Drip tray water level indicator

‚Non slip rubber feet

„1 cup filter

‰2 cup filter

ÂMeasuring spoon

ÊCompactor

ÁRemovable drip tray

ËFroth attachment

ÈSteam nozzle

ÍDisplay

Î1.7L removable water reservoir

ÏPod filter

ÌCoffee or steam lever

⁄

‹

›

ﬁ

ﬂ

‡

‚

„

‰

Before first use

Before using your coffee maker for the

first time or if you have not used it for some

time, rinse the machine by running water

through. Follow the procedure for making

espresso coffee overleaf, without coffee in

the filter holder.

For best results before making your

espresso/cappuccino the cups should be

warmed. This can be done on the warming

plate but please note that this may take up

to 20 minutes depending upon the type of

cup used.

47507 Rev 1 5/4/05 4:02 PM Page 3

Espresso operation

Filling the water reservoir

1Remove to fill the water reservoir, A

slide the water tank upwards using the

handle. Open the lid of the water

reservoir Îby pulling up and sliding

backwards.

IMPORTANT: Do not overfill or carry with

the handle when full.

2Fill the water reservoir Îusing cold tap

water, 1.7 litres maximum. B

3Replace the water reservoir by sliding it

back into place. C

Using with ground coffee

Ensure the coffee/steam lever Ìis in

the off position.

1Plug the unit into the power outlet.

2Switch the unit on by pressing the on/off

switch ›. The blue 'power light' ¤and

the display Íwill illuminate.

3Pre-heat your coffee cups by placing

them upside down on the warming

plate ⁄.

Note: This machine is designed for use

with espresso or cappuccino cups only. The

coffee will emerge much weaker if larger

cups are used.

4Select the required filter „for 1 cup or

‰for 2 cups and place in the filter

holder ‡. D

Note: The 1 and 2 cup filters have many

inlet holes and a single outlet hole.

5Using your measuring spoon Â

supplied, place one or two measures of

ground coffee into the filter, depending

on filter choice. With the other end of the

measuring spoon, use the compactor Ê

to tamp down the coffee. E

IMPORTANT: Be sure not to overfill the

filter with too much coffee, and wipe around

the edge of the filter to remove any coffee

grounds.

6Place the filter holder ‡on the brewing

head ﬁand position the handle so it

points to the left. F

•Ensure the filter holder is flat against the

brewing head and turn the handle

towards the right Gas far as it will go.

7Place 1 or 2 pre-heated cups below the

holes in the filter holder Hand I. When

the coffee maker is at the correct

temperature the sign will be

displayed.

8Move the lever down to the coffee

setting. You will hear the machine make

a pumping noise, this is normal.

9Once the cups are filled to the desired

level, pull the lever to the off position.

Water will still filter through for

approximately 8 seconds after the

machine has been turned off.

10Carefully remove the filter holder by

turning the handle slowly to the left.

47507 Rev 1 5/4/05 4:02 PM Page 4

11To remove the used coffee grounds from

the filter, push the filter lock ﬂforward

over the edge of the filter and turn the

filter holder upside down. Gently tap out

the coffee. J

12Once the sign shows, your machine

is ready to make the next espresso.

Note: It is normal for the symbols on the

display to cycle on and off during the water

heat up process.

Using with the coffee pods

1Select the pod filter Ïand place in the

filter holder ‡. K

2Remove the espresso pod from the

packaging. L

3Place the coffee pod in the filter Ï.

Ensure that the flap is placed inside the

filter. M

4Place the filter holder ‡on the brewing

head ﬁand position the handle so it

points left. Ensure the filter holder is flat

against the brewing head and turn the

handle towards the right Nas far as it

will go.

5Place a pre-heated cup below the holes

in the filter holder. O

Note: One coffee pod has the measured

amount of coffee for one single espresso.

When the coffee is at the correct

temperature the sign will be displayed.

6Move the lever down to the coffee

setting. You will hear the machine

making a pumping noise, this is normal.

7Once the cup is nearly filled to the

desired level, move the lever back to the

off position. Water will filter through for

approximately 8 seconds after the

machine has been turned off.

8Remove by turning the filter holder

slowly to the left.

9To remove the pod from the filter, push

the filter lock ﬂforward over the edge

of the filter and turn the filter holder

upside down. P

10Once the sign shows, your machine

is ready to make the next espresso.

Note: It is normal for the symbols on the

display to cycle on and off during the water

heat up process.

K L P

47507 Rev 1 5/4/05 4:02 PM Page 5

Steam function

The froth attachment makes it easy to

produce frothy milk for cappuccino.

Ensure the coffee/steam lever is in the

off position.

1Before using the steam nozzle, remove

the filter holder.

2Attach the froth attachment Ëto the

end of the steam nozzle È. Q

IMPORTANT: For the froth enhancing

attachment to work you must ensure that it

is pushed firmly onto the steam nozzle.

3Fill the water reservoir with cold tap

water.

4Swing the steam nozzle with the froth

attachment to the side of the machine.

5Press the steam button ‹when the unit

is ready to make steam, the sign

shows. This sign will flash on the display

until the machine reaches the correct

temperature to make steam when it

becomes fixed.

6Pour cold milk into a suitable jug. Use

approximately 100ml for each

cappuccino.

Note: For best results we recommend to

use refrigerated milk and a stainless steel

jug that is well chilled.

7Hold the jug under the steam nozzle so

that the head of the froth attachment is

immersed in milk and push the lever up

to the steam setting. RYou will hear the

machine making a pumping noise, this is

normal.

IMPORTANT: Do not allow the tip of the

nozzle to touch the bottom of the jug

because this could obstruct the passage of

steam.

8Once the froth has been produced push

the lever down to the off position and

remove the jug.

Note: Do not be alarmed by the

escaping steam from the base.

Note: It is normal to hear a pumping

sound when switching from steam mode to

coffee mode or hot water mode.

The milk is ready as soon as it forms a

soft, thick layer of foam on the top. If the

milk starts to make large popping bubbles,

you have boiled the milk and it will therefore

not froth. If this happens replace with

chilled milk. Do not boil the milk.

Frothing tips

•For best results use fresh, cold milk from

the refrigerator.

•Skimmed milk or fat reduced milk will

make frothing easier.

Q R

47507 Rev 1 5/4/05 4:02 PM Page 6

Hot water drinks

You may want to top up your espresso

with hot water for a longer drink or to make

other hot water drinks such as tea or

instant soups using the steam nozzle.

1Ensure the unit is cold before removing

the froth attachment from the steam

nozzle.

2Press the steam/hot water button. ‹

The display shows the icon flashing.

3Follow the 'steam function' instruction,

push the lever up to the steam/hot water

function R.

Note: You will hear the machine making

a pumping noise, this is normal.

4The symbol will show on the digital

display as water is dispensed through

the steam nozzle.

5Once the water has reached the desired

level, push the lever down to the off

position.

Note: It is normal for the symbols on the

display to cycle on and off during the water

heat up process.

Preheating coffee

maker

To make hotter coffee and to warm your

coffee cups you may preheat your machine.

This can be achieved by following the

'espresso operation' by passing hot water

through the coffee maker but without using

coffee.

Cups should be placed upside down on

the warming plate. Please note that this

may take up to 20 minutes depending upon

the type of cup used.

Cleaning and

maintenance

You must clean the steam nozzle and

froth attachment immediately after each

use.

1Simply wipe the steam nozzle, warming

plate and exterior with a clean, damp

cloth. Do not use any abrasives or metal

scourers as this will damage the finish

on the unit.

Briefly push the lever to the steam

setting to clear any remaining milk out of

the steam nozzle.

WARNING: Steam from the nozzle is

extremely hot and can scald.

2Place the froth attachment under warm

running water to remove excess milk.

IMPORTANT: Never wash your coffee

machine accessories in a dishwasher.

3The filters, filter holder and water

reservoir should be washed after each

use by rinsing them under water. To

assist in keeping the filters clean we

recommend you periodically run the

machine with the filter in place, without

coffee, using water only.

Should the holes in the filters become

blocked with coffee granules use a fine

bristled brush.

When your coffee maker is not being

used, we recommend that you do not leave

the filter holder attached to the machine as

this will reduce the life of the gasket.

47507 Rev 1 5/4/05 4:02 PM Page 7

Descaling

•If you live in a hard water area, we

recommend that your coffee maker is

descaled at regular intervals, e.g. every

2-3 months. In areas of moderately hard

water you should descale every 6

months.

•If the water filters through more slowly

than usual, it is a sign that descaling is

necessary.

•We recommend you use proprietary

liquid descaler which is especially made

for coffee makers and plastic kettles.

Follow the instructions on the bottle or

sachet, and then operate the coffee

maker with just water 3 times before

making coffee.

•Do not use kettle descaler unless the

packet specifically states it it suitable for

coffee makers.

Note: The permanent filters should not

be used during descaling.

Drip tray

1The water level indicator ·appears

through the grid to indicate that the drip

tray is full.

2Remove the grid of the drip tray by

placing fingers in the two holes in the

centre of the drip tray and lift off. SThis

must be done regularly or as soon as the

red water level indicator appears through

the grid.

3Lift the front of the drip tray up and slide

it out. T

4Lift off the plastic lining of the drip tray.

UClean the drip tray and its grid with

water and a little washing up liquid, rinse

and dry.

5Reverse the procedure to reassemble.

Note: Ensure that when you are

replacing the drip tray that the plastic lining

is in the correct position.

47507 Rev 1 5/4/05 4:02 PM Page 8

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We are

more likely able to help than the store from

where you bought it.

Please have the following information

ready to enable our staff to deal with your

query quickly.

•Name of the product

•Model number and serial number as

shown on the underside of the

appliance.

47507 Rev 1 5/4/05 4:02 PM Page 9

Display guide

• <FLASHING>

Warming up to make coffee or hot water

•Ready to make coffee

or making coffee (lever down)

• <FLASHING>

Warming up to make steam

• Ready to make steam

or making steam (lever up)

•Making hot water (lever up)

47507 Rev 1 5/4/05 4:02 PM Page 10

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Morphy Richards Cafetière

Morphy Richards

Morphy Richards meno Espresso Manuel utilisateur

Morphy Richards

Morphy Richards IB47480 Manuel utilisateur

Morphy Richards

Morphy Richards IB47011 Manuel utilisateur

Morphy Richards

Morphy Richards 47490 COMBINATION COFFEE MAKER Manuel utilisateur

Morphy Richards

Morphy Richards IB172020 Manuel utilisateur

Morphy Richards

Morphy Richards ARC 47110 Manuel utilisateur

Morphy Richards

Morphy Richards 12 CUP FILTER COFFEE MAKER - REV 2 Manuel utilisateur

Morphy Richards

Morphy Richards 162100 Manuel utilisateur

Morphy Richards

Morphy Richards Redefine Manuel utilisateur

Morphy Richards

Morphy Richards 172002 Manuel utilisateur

Morphy Richards

Morphy Richards 47031 Manuel utilisateur

Morphy Richards

Morphy Richards IB47009 Manuel utilisateur

Morphy Richards

Morphy Richards IB47071 Manuel utilisateur

Morphy Richards

Morphy Richards FoodFusion Manuel utilisateur

Morphy Richards

Morphy Richards Accents Pour Over Filter Manuel utilisateur

Morphy Richards

Morphy Richards Accents 47087 Manuel utilisateur

Morphy Richards

Morphy Richards MR47082 Manuel utilisateur

Morphy Richards

Morphy Richards VECTOR Manuel utilisateur

Morphy Richards

Morphy Richards VERVE Manuel utilisateur

Morphy Richards

Morphy Richards Accents Espresso Manuel utilisateur

Morphy Richards

Morphy Richards PUMP ESPRESSO COFFEE MAKER 47507 Manuel utilisateur

Morphy Richards

Morphy Richards ELIPTA 47160 Manuel utilisateur

Morphy Richards

Morphy Richards MISTER CAPPUCINO EXPRESSO AND FILTER COFFEE... Manuel utilisateur

Morphy Richards

Morphy Richards IB47390 Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
