Consult the owner’s manual for complete installation instructions and proper clearances to
combustible surfaces prior to installing fireplace.
All specifications, framing dimensions, product designs, materials and colors are subject to
change without notice. The actual flame pattern and color may vary slightly from the illustrations.
Diagrams and illustrations are not to scale.
Options & accessories may have associated surcharge.
Warranty: The manufacturer warrants this fireplace to be free from defects in materials and
workmanship at the time of manufacture. There is a limited 10 year warranty on the firebox; 5 year
limited warranty on the burner and 1 year limited warranty on the pilot burner assembly and fan
motors (if included). The valve carries a limited 1 year warranty unless otherwise specified in the
installation manual. Glass, plated/painted finishes and refractory lining are exempt.
DX Cast Stove with ceramic
Porcelain Green Finish shown
Ceramic Porcelain Black
Ceramic Porcelain Ivory
Ceramic Porcelain Blue
Ceramic Porcelain Green
Ceramic Porcelain Brown
Painted Charcoal Grey
Painted Black
Clearance to Combustibles
Model# Floor Back Control
Side
Right
Side Top
DXFS 0” 3½" 24" 10½” 42”
Features:
❏ Double burner system
❏ 6-piece fibre logset
❏ Approved as a Vented Gas Fireplace Heater
❏ Ceramic glass windows on three sides provides a
full view of the spectacular fire
❏ Outer door may be left open while the stove is in
operation
❏ Hi/Lo control for adjusting flame level
❏ Millivolt control with Piezo spark ignition allows for
continuous operation, even during a power failure
❏ 100% fail-safe shut-off valve
Options:
❏ Variable-speed blower kit for increased heat
circulation into the living space
❏ Remote Control
❏ 5 beautiful designer finishes and 2 attractive
painted finishes to choose from (see color swatches)
Fireplace BTU/H Input
Model# Natural Gas Liquid Propane
DFSP 28,000 28,000
Rio-DX Direct Vent
Cast Stove
Direct Vent
“Through the roof”
Direct Vent
“Through-the-wall”
18"15¼"
24¼"
Top view
18"
15¼"
6¼"
8 "
Side view
24¼"
16"
29"
6"
1
Front view
