Montigo H38-DF Mode d’emploi

Brackets to be

flush with top of

fireplace frame,

(Typical)

Align (2) attachment brackets

on center of frame verticals

(Left and Right side Typical)

Moving Brackets (2)

(Left and Right side Typical)

Mounting Holes (3) per side.

(Left and Right side Typical)

Bracket to be

Flush with

outside edge

of fireplace,

(Typical)

Installing the H38 & H42 Surround

for use with:

H-Series; H38-DF

H-Series; H42-DF

Parts Included

1) 1-Pc,Surround

2) 2-Pcs,AttachmentBrackets

3) 2-Pcs,MovingBrackets

4) 1-Pkg.Hardware

Dimensions

Figure1. Surround Dimensions

C US

Tools Required

1) PowerDrill,(six1/8"holes)

2) #8HexheadDriver,(tomatchhardware)

3) Carpenterslevel(FinalStep,ifrequired)

Installing the Surround

 ToinstalltheMontigoStainlesssteelorBlackcontemporarysur-

roundtootheH38DF&H42DFfollowthesefewsimplesteps.

Step 1. Mark the location of the holes needed.

 FromthepackageofhardwarelocateoneoftheAttachment

Brackets.HoldthispartinplaceasshowninFigure 2.Withapen-

cilorpenmarkthe(6)sixholesonthefaceofthereplaceframe,

(seeFigure2.)Note:Ensure the brackets align with Figure 2. Below.

Figure2.Bracket Alignment

Step 2. Drill holes.

Before you go any farther now is the time to double check the loca-

tion of the holes, do they agree with Figure 2. Ifyouaresatised

withthelocationoftheholes,useapunchtomarktheholes,then

usinga1/8"drill,drilloutthesixholes.

1”

M (Hor. open’g)

H38DF 35 25 49

N (Vert. open’g)

Surround Dimensions

H42DF

39 28

XG0903-013111

f i r e f e a t u r e

Movable Bracket

Fixed Bracket

Supplied, 1/2”Long

10/24 machine screw.

Fixed 10/24 Nutsert

Step 3. Install the (2) two Attachment Brackets.(See Figure 2)

 Nowit'stimetoinstallthetwo(2)AttachmentBracketsyouused

asaguide.HavesomeoneholdoneoftheBracketsinplace,

usingtheHex-tool,placeaself-tapping#8-18sheetmetalhex

screwintotheholeandtwistitintotheholehalfway.

Followthisprocedurefortheremainingtwo(2)screwsintherst

bracket.Afterthethree(3)screwsareinplacetightenthemin

place.RepeattheprocedureinStep 3forthesecondAttachment

Bracket.

Step 4. Install the (2) two Movable Brackets.(If installed disregard this

step. If not See Figure 3)

 Nowit'stimetoinstallthetwo(2)MovableBrackets.(These

move up or down to level and align the surround. This will pro-

duce a symmetrical reveal when correctly adjusted).

Figure3. Installing the Movable Brackets

Pickuponeofthebrackets,usingthesuppliedhardware,mountitinto

place.Slidetheboltthroughthebracket'fronttoback',(SeeFig-

ure3),thentightentheboltusingaopenendwrenchorsocket.

FollowthisprocedurefortheremainingboltinthesecondMovable

Bracket.

Step 5. Placing the Surround

 Finallyit'stimetoinstalltheStainlesssteelorBlackSurround.

Forthisstepitwouldbehelpfultohavesomeonehelpyouhold

thesurroundinplace.

Liftthesurroundoverthetwo(2)MovableBracketsandswingthesur-

rounddownward.Ifthesurrounddoesn'tclearthetoporbottom

ofthereplaceyouwillhavetoadjustthemovablebracketsupor

down.Removethesurroundplaceitaside.Adjustthebracketas

required.Repeatasnecessary.

Step 6. Final adjusting of the Surround

 Thisstepisnotnecessaryifthesurroundtstightlyaroundthe

replace,ortheadjustmentisacceptable.But,ifyoursurround

hasanunevenreveal,orunequalgaparound/betweenthere-

placeandsurround,usingacarpentersleveladjusttheMovable

bracketsasneeded.

FinallyplacetheadjustedSurroundbackontheBracketsandadmire

yourContemporaryMontigoreplace.
