Monster Moto MM-E250 Manuel utilisateur
This operator’s manual contains important safety informaon and maintenance
informaon. Read it carefully before using this vehicle. Failure to follow the warnings
contained in this operator’s manual could result in INJURY or DEATH.
Keep this manual in a safe place. It is very important that this owner’s manual be
reviewed by all riders and it should be considered a permanent part of the mini bike
and should remain with the vehicle when transferred to a new owner.
This manual contains the latest product informaon available before prinng. Due to
product improvements or producon changes, there could be discrepancies between
the informaon contained in this manual and accurate product informaiton. Monster
Moto, LLC (Monster Moto) reserves the right to make changes to its products at any me,
without noce and without obligaon to make the same or similar changes to any vehicle
previously built or sold.
No part of this publicaon may be reproduced or copied without wrien permission
from Monster Moto.
© Monster Moto, LLC, 2013
Owner’s Manual
Monster Moto, LLC
1001 S. Jupiter Rd.
Garland, TX 75042
Phone: 855-833-6483
All rights reserved. © 2013
MADE IN CHINA
MM-E250
Electric Mini Bike
855-833-6483 OR EMAIL US AT info@monstermoto.com
PROBLEMS? DO NOT RETURN TO STORE! CALL US!
2
Contents
Warranty 1
Introducon and Safety Messages 2 - 5
Operang Controls 5 - 7
Inial Set-Up 8
Pre-Ride Checklist 9
Basic Operaon 10 -11
Maintaining your Mini Bike 12-15
Rear Brake Adjustment 12
Drive Chain 13
Tire Pressure 14
Fuse Replacement 14
BaeryReplacement 15
Troubleshoong 16 - 18
Product Registraon 19 - 20
855-833-6483 OR EMAIL US AT info@monstermoto.com
1
Warranty Informaon
Congratulaons on your decision to purchase a Monster Moto power sports product! We are
pleased that you have chosen a Monster Moto product, and we are dedicated to supporng your
successful and safe power sports recreaon experience!
We are grateful for your business, and in order to assure your quality experience, please review
and make note of the following warranty related issues:
KEEP YOUR RECEIPT: Proof of purchase will be required to substanate any warranty claim.
WHAT IS COVERED: Monster Moto warrants to the original retail purchaser of this Product that this
Product is free from defects in material or workmanship and agrees, at Monster Moto’s discreon,
to either repair, provide replacement parts for, or replace (without charge or labor), any product
component having a material defect for a period of ninety (90) days from the date of purchase,
except as limited below. Monster Moto may require the purchaser to return to Monster Moto, at
their expense, the part claimed to be defecve for Monster Moto’s inspecon, at which me the
returned parts or product become property of Monster Moto.
WHAT IS NOT COVERED: This warranty does not cover any condions caused by misuse, neglect,
negligence, accident or operaon in any way contrary to the operang instrucons located in the
operator’s manual. Normal wear, alteraon, modicaon, improper or inadequate maintenance,
or use of unauthorized replacement parts or service provided by anyone other than an Authorized
Monster Moto Service Center are not covered under this warranty. This warranty does not cover
products used for rental or commercial purposes or used in compeon, nor does it cover
transportaon costs for warranty service. Without liming the above, this warranty is VOID with
respect to any product that has sustained damage resulng from impacts, accidents, jumping,
or any other uses considered outside of the scope of normal and safe operaon.
LIMITATIONS OF LIABILITY: This Warranty is non-transferable aer the Product’s inial sale. No
unapproved modicaons can be made to the Product, its performance or otherwise, in order for
this Limited Warranty to remain in eect. No reimbursement is provided for towing, loss of me, loss
of use, inconvenience, incidental or consequenal damages. This Limited Warranty covers only parts
and labor due to manufacturer defect. This Warranty does not cover minor surface blemishes, rips,
tears, or other cosmec damages due to normal use, or other intenonal or unintenonal damage to
the Product. This Limited Warranty will not cover any damage which results from the applicaon of
improper cleaners, solvents or chemicals to the Product, or from smoke or soot, or from exposure to
saltwater, sea breeze or salt. This Limited Warranty will not cover any damage resulng from product
storage in the elements. This Limited Warranty does not cover improper repair or misdiagnosis of
product problems.
OWNER'S RESPONSIBILITIES: As the vehicle owner, you are responsible for performing required
maintenance and maintaining a record of all receipts for maintenance performed on your mini bike.
Your warranty claim may be denied solely because of your failure to ensure the performance of all
scheduled maintenance or lack of maintenance records or receipts. As the vehicle owner, you may
be denied your warranty coverage if your vehicle or a part has failed due to abuse, neglect, improper
maintenance or unapproved modicaons.
855-833-6483 OR EMAIL US AT info@monstermoto.com
PROBLEMS? DO NOT RETURN TO STORE! CALL US!
2
Introducon
Your Monster Moto MM-E250 electric mini bike was designed as a recreaonal mini bike
for a single rider. This mini bike is ideal for younger riders with basic experience.
Always check and obey any local laws or regulaons which may aect the locaon the
MM-E250 may be used and safely operated. This vehicle is intended for use on solid, at,
clean and dry surfaces such as pavement or level ground without loose debris such as
gravel or dirt. Icy or rough terrain can create hazardous riding condions resulng
in an accident. Do not operate in wet condions or through standing water because you
can permanently damage the electrical system and components. Never use the MM-E250
on carpet or indoor ooring because it will damage those surfaces. Be careful to watch for
pedestrian trac wherever you ride your MM-E250. The bike is built for smaller riders.
Before riding, please take your me to get acquainted with your MM-E250 and how it
works. To protect your investment, we urge you to keep it well maintained. In addion
to regular maintenance, it is important to observe and perform all pre-ride and periodic
checks outlined in this manual. In this manual, you will nd helpful safety informaon,
instrucons, facts, and helpful ps. To make it easier to use, there is a table of contents
at the beginning.
As you read through this manual you will nd informaon that is preceded with a NOTICE
symbol. This informaon is intended to help you avoid damage to your mini bike. This
manual covers basic maintenance procedures.
Read the warranty page carefully so that you understand the coverage on your mini bike
and are aware of your rights and responsibilies.
If you have any quesons or you need any special service or repair, remember that
your Monster Moto authorized service center knows your mini bike best and will be
dedicated to your complete sasfacon. Replacement parts and technical support can be
obtained online at www.monstermoto.com or by phone at 855-833-6483. Please be sure
to register your Monster Moto product and nofy us of any address changes so we may
contact you in the future with any important product informaon.
You can also visit our website at www.monstermoto.com to view service videos and
informaon about all Monster Moto products.
855-833-6483 OR EMAIL US AT info@monstermoto.com
3
Important Safety Informaon
Your personal safety, and the safety of those around you, is extremely important. Operang this
mini bike safely is an important responsibility.
Monster Motor has provided operang procedures and other informaon on labels on your mini bike
and in this manual to help you make informed decisions about safety. This informaon will alert you
to potenal hazards that could harm you or others.
It is understood that it is not praccal or possible to warn you about all possible hazards associated
with operang and maintaining a mini bike. You must use your own good judgment.
Safety informaon will come in a variety of dierent forms, including:
•Safety Labels on the mini bike
• Safety Messages preceded by a safety symbol and one of these three signal words:
DANGER, WARNING or CAUTION.
Below are the denions of these three words:
You WILL be KILLED or SERIOUSLY INJURED if you do not follow instrucons.
You CAN be KILLED or SERIOUSLY INJURED if you do not follow instrucons.
You CAN be INJURED if you do not follow instrucons.
•Safety Headings such as important safety reminders and/or precauons.
•Safety Secons such as mini bike safety.
•Instrucons on how to use the mini bike safely and correctly.
This enre manual is lled with important safety informaon - please read it carefully.
!
DANGER
!
WARNING
!
CAUTION
!
855-833-6483 OR EMAIL US AT info@monstermoto.com
PROBLEMS? DO NOT RETURN TO STORE! CALL US!
4
Important Safety Informaon
A mini bike can provide many years of service and pleasure, provided you take responsibility
for safety, properly maintain your mini bike and understand the challenges you may
encounter while riding.
This mini bike has been designed for younger riders. However, not all youngsters meet the
physical and emoonal levels that are needed for riding. Before parents allow any children
to ride this mini bike, we strongly recommend that both of you read this enre manual so
you are fully informed before deciding if your children are ready to ride. Listed below are
some of the most important safety measures one should take when riding.
Ride with proper are The following statement is a proven fact: ``Helmets
signicantly reduce the number and severity of head injuries.” Never ride your mini bike
without a helmet or eye protecon. Even a crash at slow speed can result in a fatal head
injury if you are not wearing a helmet. Monster Moto recommends wearing helmets that
have been cered for safety by helmet tesng organizaons which are independent
from the helmet manufacturer. We also recommend that you wear other approved safety
gear such as elbow and knee pads. Always wear shoes, keep laces ed, and never ride
barefooted or with sandals.
Never Carry a Passenger This mini bike has been designed for ONE rider
only. There are no passenger pegs, footrests, handles or seat room for a passenger. Riding
with a passenger can interfere with your ability to operate and/or control the mini bike
and may result in serious injury or death.
Ride O-Road Only This mini bike has been designed and manufactured
for o-road use only. The mini bike is not equipped with lights, turn signals, horn and other
features required to drive a mini bike on public roads.
Ride Within Your Limits Never aempt to ride your mini bike in a manner
that is beyond your skill level. It takes me to learn proper riding skills. Learn to ride your
mini bike step by step. Start by praccing on safe terrain at slow speeds and gradually
build your skill level. Instrucon from an experienced rider(s) is highly recommended.
Parental Supervision Required The MM-E250 is an electric power sports
vehicle and not a toy. The recommended rider age of 8 or older is only an esmate and
can be aected by the rider’s maturity levels, weight and skills. Any rider who cannot
comfortably t on the mini bike should not ride the unit.
Keep small children away from this unit. Only supervised or approved riders who are
capable of handling the mini bike are allowed to sit on and ride the unit.
DANGER
!
WARNING
!
WARNING
!
WARNING
!
DANGER
!
855-833-6483 OR EMAIL US AT info@monstermoto.com
Use Safe Riding Pracces
• Do not jump, or aempt stunts, with your MM-E250.
• Hold onto handle bars at all mes.
• Never wear earphones or operate a cell-phone or video game while riding.
• Keep all loose arcles of clothing (laces, pants, sleeves, scarfs, etc.) away from
moving parts such as the drive sprocket and chain.
• Never hitch a ride from another gas-powered or electric vehicle.
• Do not ride the MM-E250 near pools, or in wet weather and do not immerse mini
bike in water. Water will damage the electric components and void your warranty.
• Always operate at a safe speed. The bike is set on the “slow” speed, but if you want
to increase speed, see secon “Check Speed Switch” to change to higher speed.
• Always use common sense when faced with problems. If there is any doubt about a
situaon or problem with your unit, do not operate further and call our customer
service line – 855-863-6483.
Improper accessories or modicaons can cause a crash in which riders
can be seriously hurt or killed. Follow all instrucons in this owner’s manual regarding
modicaons and accessories.
5
Operang Controls and Component Locaons
When you ride your mini bike, you need to operate the throle, brakes, and other controls
without stopping to look at them. Please read this secon carefully before you ride your
mini bike. This secon of the manual will describe the funcon, locaon, and operaon of
all the basic controls of your mini bike.
Brake Lever
Foot Peg
Chain Tensioners
(both sides of mini mike)
Throle
DANGER
!
WARNING
!
Important Safety Informaon
ON/OFF Switch
Baery
Charging
Port
Baery
Cover
Kick
Stand
855-833-6483 OR EMAIL US AT info@monstermoto.com
PROBLEMS? DO NOT RETURN TO STORE! CALL US!
Operang Controls
ON/OFF Switch
The ON/OFF switch is used to control power to the motor.
When the switch is in the “OFF” posion, no power is
supplied to the motor. To ride the mini bike, ip the switch
up. This is the “ON” posion. To shut o the bike, close the
latch or move the switch down to the “OFF” posion.
Throle
The throle controls the speed of the motor. To increase
emotor speed, slowly twist the throle grip toward you. To
reduce motor speed, twist the throle grip away from you.
The throle is spring loaded and will return to the closed
posion (motor idle) when you remove your hand.
Because this is an electric product, small
movements in the throle produce an instant response in
the motor. Do not suddenly twist throle or you risk severe
injury.
Rear Brake
The brake lever is used to apply the brake to the rear wheel
and will slow or stop the mini bike. When you pull back on
the lever, the brake cable pulls the caliper on the brake disc.
The amount of force that you use when pulling the brake
lever will determine how much braking power is applied. To
release the rear brake, release the brake lever.
Kick Stand
The kick stand is used to support the mini bike when it is
parked. To operate, use your foot to lower the stand. Always
raise the stand before riding the mini bike.
6
WARNING
!
Switch
855-833-6483 OR EMAIL US AT info@monstermoto.com
Operang Controls
Brake Mechanism
The MM-E250 mini bike is equipped with a rear disc brake.
It provides power to safely bring the mini bike to a stop.
Refer to the Basic Maintenance Procedures secon for brake
adjustment instrucons.
Chain Tensioner
Chain tension is maintained and adjusted by the bolts on both
sides of the rear wheel. The adjustment screw will increase or
decrease the slack on the chain. Please see Basic Maintenance
Procedures to understand how to determine proper chain
tension and for instrucons on how to make adjustments to
maintain proper tension.
7
Brake
Caliper
Disk
Adjustment
Screw
Adjustment
Screw
855-833-6483 OR EMAIL US AT info@monstermoto.com
PROBLEMS? DO NOT RETURN TO STORE! CALL US!
8
YourMonsterMotoMM-E250isshippedwith
the handlebars NOT bolted on.
To aach the handlebars follow the steps below:
1. Aer unpacking your mini bike, place it on the kick stand on a
at level surface.
2. While sing on the bike, place the handle bars in the lower
clamp in a comfortable posion, being careful to center in the
clamps.
4. Replace upper clamps and bolts and ghten to 12 foot-lbs
with the allen wrench provided. Do not overghten.
2. Aaching the Handlebars
Top View
Handlebar Clamps
1. Locate All Accessories in Package Before Proceeding
- Owner’s Manual
- Tools (2 allen wrenches, 2 box end wrenches, 2 handlebar clamps & 4 bolts, screwdriver)
- Charger
Inial Set-Up
NOTICE The rst me you charge your baery it must be fully charged. While it will be
tempng to charge for a short amount of me to be able to ride the mini bike immediately,
failure to properly charge will severely shorten the run me as the baery ages and limit
the number of recharges the baery will take. Your mini bike will be ready to ride when the
indicator light on the charger turns GREEN.
1) Make sure the on/o switch is in the o (“down”) posion.
2) Locate the charger and nd the baery port on the right
front side of the mini bike.
3) Remove the plasc protecve cap, align the notch on
the charger and port and insert charger.
4) Plug the other end of the charger into a standard 110-volt
household outlet.
5) Connue to charge unl GREEN light on charger appears.
6) Unplug charger from wall, disconnect charger from port
and install port cover once charging is complete.
7) Conduct pre-ride inspecon and begin having fun!
Remove charger from bike once GREEN light appears on charger. Extending
charging me will NOT extend operang me.
THE UNIT WILL NOT TURN ON WHILE THE CHARGER IS PLUGGED INTO THE
CHARGING PORT! Disconnect the charger from the port before aempng to ride the bike.
3. Charge the Baery
WARNING
!
Bolts
CAUTION
!
Charging
Port
Autres manuels pour MM-E250
1
Table des matières
Autres manuels Monster Moto Moto
Manuels Moto populaires d'autres marques
MOTO GUZZI
MOTO GUZZI QUOTA 1100 ES Manuel utilisateur
APRILIA
APRILIA ETV MILLE CAPONORD - PART1 02-2001 Manuel utilisateur
Yamaha
Yamaha 2006 YZF-R1V Manuel utilisateur
KTM
KTM Freeride E-XC 2021 Manuel utilisateur
Fantic
Fantic Enduro 125 Manuel utilisateur
Ducati
Ducati Supersport 750 desmodue Manuel utilisateur
