Brief introduction...................................................................................................1

Main specifications...............................................................................................1

Main configuration........................................................................................... ....1

Products constitution....................................................................................... ....1

Assemble processes...............................................................................................2

Adjustment steps....................................................................................................3

Safety precautions..................................................................................................4

Charging method and cautions.........................................................................4

Caution and Notice for Li-po battery .............................................................5

Caution and notice for ESC ................................................................................5

Trouble shooting.....................................................................................................6

Spare parts.................................................................................................................7

1.Please read this manual carefully and follow the instruction of the manual before

you use this products;

2.Our airplane is not a toy, which is only suitable for the experienced manipulator or

under the guidance of the experienced pilot.

3. Not recommended for the children under 14 years old.

4.Please adjust this plane according to the instruction and make sure that the finger

and other parts of your body be out of the rotating parts of the plane, or it may cause

damage to the plane or injury to your body.

5.Do not fly in the thunderstorm, strong wind or bad weather.

6.Never fly the plane where there are power lines overhead, automobiles, near

airdrome , railway or highway.

7.Never fly our plane where are crowds of people .Give yourself plenty of room

flying, as the plane can fly at a high speed. Remember that you are responsible for

others safety.

8.Do not attempt to catch the plane when you are flying it.

9.The user should bear full responsibility of proper operation and usage with regards

to this model. We, Top RC together with any distributor of us will not be responsible

for any liability or loss due to improper operation.

󾙓



󾙓





Thanks for your purchasing our Lightning 2100 aircraft

from Top RC Hobby, hope this aircraft will bring the

endless joy to you.

★Lightning 2100 is very easy to assemble in several

minutes and the wings are removable, very easy to

carry and maintain.

★Embedded carbon spars and strips in fuselage and

wings, makes the Lightning 2100 with high strength

and make sure of the plane won’t be twisted during

the high speed flights.

★Configured with left wing, right wing and middle

wing, Lightning 2100 can be easily switched to the

smaller size Lightning 1500 if you take out the middle

wing, one model you buy it but enjoy two different

flight experiences.

★With 10 inch foldable propeller, makes the flight

with a high efficiency and protects it from the damage

of the landing.

󽘀

★Wingspan: 2100mm

★Length: 1016mm

★Weight: 1320g

★Thrust: ≥915g

★Flight time: ≥15min

󽘀

★Motor: C2415-1150KV

★ESC: 40A

★Servo: 9g (plastic gear)*3+9g (metal gear)*1

★R/C System: 2.4GHz 4Ch /optional

★Battery: 3S LiPo 11.1V 2200mAh >25C

★Very nice appearances with good proportions,

impressing people with a very good visual impact.

★Very stable flight and flexible performances, easy to

control, can realize the roll and high speed flights.

★Full-moving tail, very easy to control.

★With perfect design of the heat dissipation holes on

the body, the motor, ESC and battery could be cooled

fully during the high-speed flying, which makes our

flight very safe.

★Under the protection of landing skid and spoilers,

Lightning 2100 can land from the ground without any

damages for the foam parts.

★Unique hidden pushrod design (elevator & rudder

pushrods are hidden in the foams ) makes the model

more simple and nice.

Fuselage, Main wings, Horizontal wing, Connectiong Rod for Horizontal Wings, Connecting rod for Main Wings, accessories bag

Kit with Servos, ESC, Motor, Propeller



󾙔

4. Close the canopy, then the assembly finished.

1. Please take out the left, right and middle wing, wing connecting rod, accessory bag. Insert the connecting rod to the

middle wing, then connect the left and right wings to the middle wing. Connect the female plug from the middle wing to

the servo cables, then fix the wings with nylon screws.

2. Please take out the fuselage and horizontal wing, short wing connecting rod. Insert the short wing connecting rod into the

assembly holes from the rudder, then make the connecting rod insert into the left and right horizontals wings. Fix the wings

with screw.

3. Put the assembled main wings to the right position on the top of the fuselage, fix well the wings with screws to the fuselage.

󾙕



1. If you have the simulator, we suggest that you can practise your skill by the simulator before you fly

this model, which will bring some help for you.

2. Please climb the plane above the 50 meters with half throttle to fly it when you fly it for your first time,

then you will be familiar with the performance of this plane.

3. You should learn how to control this model blandly, it will reduce the possibility of crash and prolong

the usage life of the plane.

4. The turn radius should not be too little, or it will stall and it will increase the possibility of crash.

5. When taking off or landing the plane, you should against the wind.

6. Do not fly the model over your head or behind you, you should fly the model in front of you.

7. Please check all fitments, screws for tighter fit before each flight. Also check and control surfaces, control

rods and your RC equipment for proper function.

72mm

Check the center of gravity and make sure that the CG of the plane

should be within the range as indicated by the arrows.





1. While charging is in process, please do not make it near flammable materials.

2. Use only adequate and specific chargers for charging lithium batteries correctly.

3. While charging, please keep it out of the reach of Children.

4. When the charger is in use, please do not go away and leave it unwatched, if any abnormality occurs

(such as the power indicator is off, the temperature of the battery rise rapidly, etc.) stop charging immediately.

5. Please do not disassemble the plane, the charger or its accessories.

6. When the battery is not cool down, please do not urge to charge it.

7. Do not charge unobserved.

8. Do not charge or store the battery inside the plane.

How to charge a lithium battery?

󾙖



1. Do not disassemble or reconstruct the battery.

2. Do not short-circuit the battery.

3. Do not use or leave the battery nearby the fire, stove or heated place (more than 80�).

4. Do not immerse the battery in water or sea water, do not get it wet.

5. Do not charge the battery under the blazing sunlight.

6. Do not drive a nail into the battery, strike it by hammer or tread it.

7. Do not impact or toss the battery.

8. Do not use the battery with conspicuous damage or deformation.

9. Do not charge a warm battery. Allow it to cool completely before attempting to charge.

10. Do not reverse charge or over discharge the battery.

11. Do not connect the battery to the ordinary charger socket or car cigarette jack.

12. Do not use the battery for unspecified equipment.

13. Do not touch the leaking battery directly, please wash your skin or clothes with

water if they are bedewed by liquid leaking from the battery.

14. Do not mix the Li-Poly battery with other un-chargeable battery in using.

15. Do not continue charging the battery over the prescribed time.

16. Do not put the battery into the microwave oven or high-pressure container.

17. Do not use the abnormal battery.

18. Do not use or keep the battery under the sunlight.

19. Do not use the battery nearby the place where generates static electricity (over 64V).

20. Do not charge the battery when the environmental temperature is under 0� or over 45�.

21. If you find the battery leaking, smelling or abnormal, stop using it and return it to the seller.

22. When the battery is charging, please do not make it near the flammable materials!

23. Keep the battery away from the children.

24. Use the specified charger and observe charging requirement (under 1A).

25. When using by minors, parents should show them to the correct instruction.

26. Do not charge unobserved.

27. Do not charge or store the battery inside the plane.

󾙘



  

Controls reversed. Channels are reversed in the

transmitter.

Aircraft will not respond to

the throttlebut responds to

other controls.

-ESC is not armed.

-Throttle channel is reversed.

-Lower throttle stick and throttle trim to

lowest settings.

-Reverse throttle channel on transmitter.

Extra propeller noise

or extra vibration.

-Damaged spinner, propeller,

motor or motor mount.

-Loose propeller and spinner parts.

-Propellor installed backwards.

-Replace damaged parts.

-Tighten parts for propeller adapter, propel-

ler and spinner.

-Remove and install propeller correctly.

Reduced flight time

or aircraft

underpowered.

-Flight battery charge is low.

-propeller installed backward.

-Flight battery damaged.

-Completely recharge flight battery.

-Replace flight battery and follow flight

battery

instructions.

Control surface does

not move, or is slow to

respond to control

inputs.

-Control surface, control horn,

linkage or servo damage.

-Wire damaged or connections

loose.

-Replace or repair damaged parts and adjust

controls.

-Do a check of connections for loose wiring.

Do the control direction test and adjust

controls for aircraft and transmitter.

-Motor loses power

-Motor power pulses

then motor loses

power.

-Damage to motor, or battery.

-Loss of power to aircraft.

-ESC uses default soft Low

Voltage Cutoff(LVC).

-Do a check of batteries, transmitter, receiver,

ESC, motor and wiring for damage(replace as

needed).

-Land aircraft immediately and recharge flight

battery.

LED on receiver

flashes slowly. Power loss to receiver.

-Check connection from ESC to receiver.

-Check servos for damage.

-Check linkages for binding.

󾙙



󽘁

󾙔󾙓󾙒󾙒

󾙔󾙚󾙛󾙚󾙛󾙚



󾙔󾙚󾙛󾙚󾙛󾙛



󾙔󾙚󾙕󾙔󾙕󾙙



󾙔󾙚󾙕󾙔󾙕󾙚



Strict ground inspections must be done before each flight, which can effectively avoid flight accidents.

1. Check if the screws of the whole airplane are installed in place or not, the servo arms and horns are connected

reliable or not and wings fixing are locked or not.

2. Install the battery and adjust the aircraft's center of gravity to the recommended position in the manual.

3. Make sure power battery, remote control transmitter battery, etc. are fully charged and in a reliable working

condition.

4. Gently push the throttle to check if the propeller is turning correctly or not.

5. After all checks are completed, the flight can be started. The first flight for beginners needs the assistance of

experienced enthusiasts to avoid flight accidents due to improper operation.

The recommended flight time by the manufacturer is using the battery what we request, and the flight test is

completed by experienced enthusiasts on a breeze day. This flight time is related to battery parameters, aircraft

weight, flight conditions and flight methods. Different conditions may result in different flight times.

It is recommended that enthusiasts use the "timing function" of the remote control during flight. It is recommended

that the initial flight time be set within 4 minutes.

When there is a countdown alarm, please land the aircraft and measure the battery voltage. At the end of the battery

discharge period, it is forbidden to fly the aircraft into the leeward zone (the far end of the wind direction) to prevent

the aircraft from being unable to return safely due to insufficient power.

󾙔󾙓󾙒󾙒

󾙚

󾙔󾙚󾙕󾙔󾙕󾙛

󾙓󾙒󾙙

󾙔󾙚󾙕󾙔󾙖󾙒



󾙔󾙚󾙕󾙔󾙖󾙓



󾙔󾙚󾙛󾙚󾙘󾙛

󾙛󾙓󾙗󾙒



󾙔󾙚󾙛󾙚󾙙󾙒

󾙛󾙓󾙗󾙒



󾙔󾙚󾙛󾙚󾙘󾙙



󾙔󾙖󾙓󾙗󾙓󾙓󾙗󾙒

󾙔󾙚󾙕󾙔󾙖󾙔



󾙔󾙚󾙕󾙔󾙖󾙕

󾙖󾙒



󾙔󾙚󾙕󾙔󾙗󾙗

󾙛󾙖󾙒󾙒







Kurze Einführung........................................................................................................1

Hauptspezifikationen.......................................................................................1

Hauptkonfiguration..................................................................................................1

Aufbau der Produkte...............................................................................................1

Montageverfahren..................................................................................................2

Einstellungsschritte...................................................................................................3

Sicherheitsvorkehrungen........................................................................................4

Ladeverfahren und Vorsichtsmaßnahmen..........................................................4

Warnhinweise und Maßnahmen für Li-po-Akkus ...............................................5

Warnhinweise und Maßnahmen für ESC ...........................................................5

Fehlersuche............................................................................................................6

Ersatzteile...............................................................................................................7

1. Lesen Sie dieses Handbuch sorgfältig durch und befolgen Sie die Anweisungen bevor Sie

das Produkt verwenden.

2. Unser Flugzeug ist kein Spielzeug - nur für erfahrene Piloten geeignet

oder unter der Anleitung eines erfahrenen Piloten.

3. Nicht empfohlen für Kinder unter 14 Jahren.

4. Bitte stellen Sie das Flugzeug entsprechend der Anleitung ein und achten Sie darauf, dass

die Finger und andere Körperteile nicht in die rotierenden Teile des Flugzeugs geraten, sonst

kann es zu Schäden am Flugzeug oder Verletzungen am Körper kommen.

5. Fliegen Sie nicht bei Gewitter, starkem Wind oder schlechtem Wetter.

6. Fliegen Sie das Flugzeug niemals in der Nähe von Hochspannungsleitungen, Autos,

Flugplätzen, Eisenbahnen oder einer Autobahn.

7. Fliegen Sie unser Flugzeug nie in der Nähe von Menschenmengen, sondern lassen Sie

genügend Platz, da das Flugzeug mit hoher Geschwindigkeit fliegen kann. Denken Sie daran,

dass Sie verantwortlich für die Sicherheit anderer sind.

8. Versuchen Sie nicht, das Flugzeug zu fangen, wenn Sie es fliegen.

9. Der Benutzer trägt die volle Verantwortung für den ordnungsgemäßen Betrieb und die

Nutzung des Modells. Wir und unsere Vertriebspartner, sind nicht verantwortlich für

für jegliche Haftung oder Verlust durch unsachgemäßen Betrieb.

Table des matières

Langues :

Autres manuels MODSTER Jouet

MODSTER

MODSTER SPORT CUB S2 Manuel utilisateur

MODSTER

MODSTER HeliX 150 Manuel utilisateur

MODSTER

MODSTER Spit Fire MK II Manuel utilisateur

MODSTER

MODSTER Arrows P-47 980mm Manuel utilisateur

MODSTER

MODSTER Phoenix V2 Manuel utilisateur

MODSTER

MODSTER CLIK R21 Manuel utilisateur

MODSTER

MODSTER Easy Trainer 600 Manuel utilisateur

MODSTER

MODSTER Predator 4x4 Crawler Manuel utilisateur

MODSTER

MODSTER FLASH HOTLINER Manuel utilisateur

MODSTER

MODSTER Vector SR48 Manuel utilisateur

MODSTER

MODSTER T-28 Trojan Manuel utilisateur

MODSTER

MODSTER Trainstar Ascent Manuel utilisateur

MODSTER

MODSTER Vector SR48 Manuel utilisateur

MODSTER

MODSTER P-51D Mustang Warbird-Trainer Manuel utilisateur

MODSTER

MODSTER Vector SR48 Manuel utilisateur

MODSTER

MODSTER Arrows Hobby Bigfoot Manuel utilisateur

MODSTER

MODSTER CLIK R21 Manuel utilisateur

MODSTER

MODSTER HOBBY ARROWS Zivko Edge 540 Manuel utilisateur

MODSTER

MODSTER Arrows HOBBY TWIN 64MM F-15 Manuel utilisateur

MODSTER

MODSTER SLICK SUPERLITE Manuel utilisateur

MODSTER

MODSTER Trip 1800 Manuel utilisateur

MODSTER

MODSTER COMPASS 206212 Manuel utilisateur

MODSTER

MODSTER Ranger 1600 Manuel utilisateur

MODSTER

MODSTER EC-135 Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
