Modern Forms ORB 62 Manuel utilisateur

INSTALLATION INSTRUCTIONS

MOTOR

WET SMART

works with the

Google Assistant modernforms.com

ORB 62” & 82”

FR-W1816-62L | FR-W1816-82L

All Modern Forms Smart Fans are:

Durably nished and Rated for

interior and exterior use

Able to coordinate with smart

devices for voice-activated and

thermostat control

Quiet, reliable, and up to 70%

more ecient than AC fans

Wi-Fi and RF enabled for

unlimited control

MOTOR

SMARTWET

Wet Location-listed to the strictest

ETL/cETL safety regulations

RF WALL CONTROL

F-WC-WT

Included with each fan

6 Fan speeds

Dims light to 1%

ON/OFF

WI-FI TOUCH PANEL

WALL CONTROL

F-TS-BK Black

F-TS-WT White

Sold separately

Full app control

FREE APP DOWNLOAD

Sync with our exclusive Modern Forms

app to control fan speed, use smart

features like Adaptive Learning, create

groups and reduce energy costs

APP INSTRUCTIONS AND SMART HOME DEVICE INTEGRATION modernforms.com/mfappins

3FR-W1816

1. Safety Rules .................................................................................................................................................................4

2. FTC Energy Guide & Specication.............................................................................................................................5

3. Tools and Materials Required ...................................................................................................................................5

4. Package Contents .......................................................................................................................................................6

5. Mounting Options.......................................................................................................................................................8

6. Installing the Mounting Bracket................................................................................................................................9

7. Attaching the Fan Blades .........................................................................................................................................10

8. Installing the Lower Housing...................................................................................................................................10

9. Installing the LED Luminaire Module .....................................................................................................................11

10. Hanging the Fan......................................................................................................................................................12

11. Making the Electrical Connections .......................................................................................................................14

12. Installing the Wall Control .....................................................................................................................................16

13. Finishing the Installation........................................................................................................................................18

14. Installing the Glass Shade......................................................................................................................................19

15. Wall Control Operating Instructions ....................................................................................................................20

16. Application...............................................................................................................................................................22

17. Troubleshooting .....................................................................................................................................................23

18. Accessories .............................................................................................................................................................24

Table Of Contents

4FR-W1816

1. Safety Rules

For operation, maintenance, and troubleshooting information, visit modernforms.com/help.

1. To reduce the risk of electric shock, ensure electricity has been

turned o at the circuit breaker or fuse box before beginning.

2. All wiring must be in accordance with the National Electrical Code

“ANSI/NFPA 70” and local electrical codes. Electrical installation

should be performed by a qualied licensed

and insured electrician.

3. The outlet box and support structure must be securely mounted

and capable of reliably supporting a minimum

of 35 lbs (15.9 kg). Use only UL-listed outlet boxes marked

“FOR FAN SUPPORT.”

4. The fan must be mounted with a minimum of 7 ft. (2.1m)

clearance from the trailing edge of the blades to the oor.

5. Avoid placing objects in the path of the blades.

6. To avoid personal injury or damage to the fan and other

items, be cautious when working around or cleaning the fan.

7. Do not use chemicals when cleaning the fan or fan blades.

A dry dust cloth or lightly dampened cloth will be suitable

for most cleaning.

8. After making electrical connections, spliced conductors

should be turned upward and pushed carefully up into

the outlet box. The wires should be spread apart with

the grounded conductor and the equipment-grounding

conductor on one side of the outlet box and ungrounded

conductor on the other side of the outlet box.

9. All set screws must be checked and re-tightened where

necessary before installation.

5FR-W1816

WARNING: To reduce the risk of electric shock, this fan must be

installed with the supplied wall control, or controlled from the Modern Forms app or wall panel.

WARNING: To reduce the risk of personal injury, do not bend the blade arms, when installing the brackets,

balancing the blades or cleaning the fan.

WARNING: Do not insert foreign objects between rotating fan blades.

WARNING: To reduce the risk of re, electric shock or personal injury, mount the fan to the outlet box

marked acceptable for fan support with the screws provided with the outlet box.

NOTE: For use only with light kits marked “Suitable for use in Wet Locations.”

NOTE: A maximum of 12 fans can operate on a circuit through an on/o switch or breaker

when utilizing the app for the fan control without the wall control in the circuit.

NOTE: A maximum of 2 fans can operate on a circuit through the wall control.

6FR-W1816

2. FTC Energy Guide & Specication

FAN FAN SIZE VOLTS N.W.

(lbs)

G.W.

(lbs)

STANDARD ELECTRICITY AIR FLOW ENERGY

COSTS*

FAN EFFICACY

Orb 62 62” 120 7.28 11.50

High Speed 44W 8123 CFM $12/yr 183.4 CFM/W

3.90 5.40 Weighted Average 24W 4875 CFM $7/yr 202 CFM/W

FAN FAN SIZE VOLTS N.W.

(lbs)

G.W.

(lbs)

STANDARD ELECTRICITY AIR FLOW ENERGY

COSTS*

FAN EFFICACY

Orb 82 82” 120 7.28 11.50

High Speed 48W 9064 CFM $13/yr 190.4 CFM/W

5.40 6.90 Weighted Average 26W 5470 CFM $7/yr 211 CFM/W

* Estimated annual energy cost based on $0.12 per kWh and 6.4 hours use per day.

3. Tools and Materials Required

Electrical tapePhillips screwdriver Step ladder Wire cutters

7FR-W1816

REF. DESCRIPTION PART NO.

ABlade Set of 5 (62”) RPL-F1816-62-BD-**

Blade Set of 5 (82”) RPL-F1816-82-BD-**

BHanger Assembly RPL-F1816-HANGER-**

w/ Mounting Bracket ---

CCanopy w/ Canopy Ring RPL-CAN-RND-**

DCoupling Cover RPL-COU-CVR-**

EMotor Assembly ---

FBottom Housing ---

GLED Module F3IN-120V-R1-30

HLight Shade (Aluminum and glass) (1 pc each) RPL-F1816-GLA***

IControl Receiver w/Hardware (62”) RPL-F1816-62-**

Control Receiver w/Hardware (82”) RPL-F1816-82-**

JWall Control w/Hardware F-WC-WT

KHardware Bag

RPL-ORB-PARTS

3/16”x15mm Phillip Flat Head Screw (16)

Φ4.7x14x2mm Rubber Washer (16)

Φ6.5x19x2mm Flat Washer (1)

3/16”(Φ5.2x8.4x1.0mm) Spring Washer (1)

#10x76mm Pan Head Phillip Wood Screws (1)

5/32”x19mm+S Phillip Truss Head Screw (Diameter 7.5mm) (4)

M4x14x1mm Flat Washer (4)

4. Package Contents Unpack your fan and check the contents. You should have the following items:

NOTE: ** denotes nish code of fan

8FR-W1816

FIG. 1

Outlet Box

Provides Strong Support

Mounting Bracket

Recessed

Outlet Box

SLOPED CEILING

MAX 30° ANGLE

FIG. 2

FIG. 4

FIG. 3

Joist

Support

Brace

5. Mounting Options

CAUTION: To prevent electrical shock, ensure electricity has been

turned o at the circuit breaker before beginning.

If there isn’t an existing UL/cUL listed outlet box, please refer to the

following instructions. Secure the outlet box directly to the building

structure. Use appropriate fasteners and building materials. The

outlet box and support structure must be able to fully support the

moving weight of the fan (at least 35 lbs/15.9 kg). Do not use plastic

outlet boxes. Use only UL/cUL listed outlet boxes marked

“FOR FAN SUPPORT.”

Secure the outlet box directly to the building structure.

Use appropriate fasteners and building materials. The outlet box

and its support must be able to fully support the moving weight

of the fan (at least 35 lbs). Do not use plastic outlet boxes.

Figures 1-4 are examples of dierent ways to mount the

outlet box.

NOTE: To hang your fan where there is an existing xture but no

ceiling joist, you may need an installation hanger bar.

NOTE: Downrod fans can be suspended up to a maximum

recommended length of 72” using additional downrods

(sold separately) and the included 80” lead wire.

NOTE: The sloped ceiling kit (sold separately) is required for sloped

ceiling applications, and will accommodate slopes up to 45° (Fig.3).

NOTE: You may need a longer downrod to maintain proper blade

clearance when installing on a steep, sloped ceiling (Fig. 3).

9FR-W1816

6. Hanging the Fan

REMEMBER to turn o power at the breaker.

Follow the steps below to hang your fan properly:

1. Disconnect power at the breaker to the fan location. A licensed

electrician must install the fan (FIG. 5).

2. Remove 1 of 2 screws from the bottom of mounting bracket and

save for use in section 9. Loosen the other screw (FIG. 6).

3. Pass the 120-volt supply wires through the center hole in the

ceiling mounting bracket as shown in (FIG. 7).

4. Secure the mounting bracket to the ceiling outlet box with the

screws and washers provided with your outlet box (FIG. 7).

FIG. 5

FIG. 7

UL/cUL Listed

Electrical Box

Mounting

Bracket

Mounting Screws

(supplied with

outlet box)

120V Wire

Mounting

Bracket

FIG. 6

Screw

10 FR-W1816

7. Attaching the Fan Blades

8. Installing the Lower Housing

Screws with

Rubber Washers

Slot

Blade

Mounting Ring

Screw

Adapter

Plate

1. Locate motor assembly and place it upside-down on a soft

surface.

2. Insert the fan blade through the slot in the housing. Align the

holes in the blade with the fan motor assembly holes and secure

with a blade attachment screw with rubber washers (Fig. 8).

3. Repeat this procedure with the remaining fan blades.

1. Remove one of the three mounting plate screws from the

mounting ring and loosen the other two screws (Do not remove).

2. Place the key holes in the lower housing over the two screws

previously loosened from the mounting ring. Turn the adapter

plate until the mounting plate locks in place at the narrow section

of the key holes (Fig. 9).

3. Securely tighten the two mounting plate screws previously

loosened and the one previously removed.

FIGURE 8

FIGURE 9

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Modern Forms Ventilateur

Modern Forms

Modern Forms Aviator 5 Manuel utilisateur

Modern Forms

Modern Forms VORTEX FR-W1810 Manuel utilisateur

Modern Forms

Modern Forms Renegade 52 Manuel utilisateur

Modern Forms

Modern Forms FR-W2202-62L-SB/MB Manuel utilisateur

Modern Forms

Modern Forms Slim Manuel utilisateur

Modern Forms

Modern Forms F-WC-WT Manuel utilisateur

Modern Forms

Modern Forms FR-W1811-54 Manuel utilisateur

Modern Forms

Modern Forms NIRVANA FR-W1916-56L Manuel utilisateur

Modern Forms

Modern Forms Roboto XL Manuel utilisateur

Modern Forms

Modern Forms Aura Manuel utilisateur

Modern Forms

Modern Forms Torque Manuel utilisateur

Modern Forms

Modern Forms Axis 44 FR-W1803-44 Manuel utilisateur

Modern Forms

Modern Forms Aviator Flush FH-W1811-54 Manuel utilisateur

Modern Forms

Modern Forms Roboto 52 Manuel utilisateur

Modern Forms

Modern Forms Mykonos 5 Manuel utilisateur

Modern Forms

Modern Forms Aviator 5 Flush Manuel utilisateur

Modern Forms

Modern Forms TipTop FH-W2004 Manuel utilisateur

Modern Forms

Modern Forms PARADOX FR-W1922-56L Manuel utilisateur

Modern Forms

Modern Forms Morpheus Manuel utilisateur

Modern Forms

Modern Forms FR-D2102-54U Manuel utilisateur

Modern Forms

Modern Forms Renegade FR-W2001 Manuel utilisateur

Modern Forms

Modern Forms Skylark Flush Manuel utilisateur

Modern Forms

Modern Forms VOX FLUSH Series Manuel utilisateur

Modern Forms

Modern Forms Axis 52 Flush Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
