MULTIMEDIA DATA/VIDEO PROJECTORS

Entry level, with high specs.

Once your presentation is over, you can simply hit

the power button, disconnect the XD211U and go

off to your next task. Engineered with the instant

shutdown feature there is no longer any awkward

idle time waiting for the projector to completely

power off. Now there is no longer any shut down

delays and now your projector can keep up with

your busy presentation schedule.

Instant Shutdown

Auto Search function displays the connected

input sources automatically. Users don't have to

get distracted by ensuring the appropriate

source is manually selected.

Also, +/-20 steps of vertical keystone correction

and 1.2x optical zoom gives users a greater

flexibility of positioning.

Easy Setup

The XD211U combines the features of

an advanced DLP®(Digital Light Processing) chip,

a newly developed optical engine and a high-

efficiency 180W light source lamp to produce an

incredible picture with rich and vibrant colors.

Additionally with its compact and lightweight

design, the new XD211U allows you easy

portability and quick setups for those

presentations on the go.

New DLP® chip, 2200lm of brightness and

weighs less than 6.0 lbs

The XD211U is equipped with a 5 segmented color

wheel (R,G,B,W,Y), BrilliantColorTM technology and

a newly designed dynamic lamp power control

system to produce superior and more natural color

reproduction.

Superior Color Reproduction

Users have the flexibility to adjust the light intensity

of the whiteness of the color wheel of up to 11 levels.

Allowing users to configure the overall brightness

and picture parameters tailored to their individual

preference.

White Intensity

White enhancement 0 White enhancement 5 White enhancement 11

Optimum high-contrast picture quality, to brighten up PC images.

NEW

An anti-theft security hook* is built into the projector

to help prevent theft and any unauthorized removal

of the projector.

Anti-theft Security Hook

* Mitsubishi Electric cannot accept responsibility for thefts occurring despite use of

this safety feature.

Detachable Keypad

The keypad* can be removed from the projector

to be used as a remote control. Since the keypad

is used to control the projector, detaching it also

doubles as a key-lock function preventing others

from making

adjustments and helps

discourages theft.

* An extra remote keypad is included

with the XD211U should the original

keypad get lost.

S-188-8-B7963-A KYO-0803 Printed in Japan(MDOC)

New publication, effective Mar. 2008

Specifications subject to change without notice.

Unit:mm

Input and Output Terminals

MOBILE XGA PROJECTOR

XD211U

1 2 3 7654

Screen size and Projection distance

As seen from the side

XD211U

Height

Projection Distance (L)

63.9

14.590

88 88

106

107

29.8

27.8

177.8

122.8

200.8

302

221

XD211U

0.55" 1-Chip DMD

1024 x 768 (Total 786,432 pixels)

2200lm

2000 : 1

40" - 300"

Model

Display Technology

Resolution

Brightness

Contrast Ratio

Picture Size

Specifications

PC Compatibility 640 x 480 - 1280 x 1024,

True : 1024 x 768, Sync on Green available

NTSC / NTSC 4.43 / PAL

(

including PAL - M , N

)

/ SECAM / PAL - 60

Component Video ; 480i/p (525i/p), 576i/p (625i/p),

720p (750p), 1080i (1125i 60Hz), 1080i (1125i 50Hz)

Video Compatibility

150W (life up to 3000hrs)with Low Mode,

180W (life up to 2000hrs)with Standard Mode

Source Lamp

*All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.

RGB ; mini D-sub 15pin x 1

Audio ; Stereo mini jack (ø3.5mm)x 1

RGB ; mini D-sub 15pin x 1

Audio ; Stereo mini jack (ø3.5mm)x 1

PC Input Terminals

Output Terminals

Video Input Terminals

Communication Terminal

Audio Speaker

Dimension (W x H x D)

Weight

Power requirements

Optional Lamp

RCA x 1 + S-VIDEO x 1

RS-232C x 1

2W Mono

302 x 105 x 221 mm / 11.9 x 4.1 x 8.7 inch

2.7kg / 6.0lbs

AC 100 - 240V, 50 / 60Hz

VLT-XD210LP

Screen

Diagonal size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

120

150

180

Distance from screen (L)Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

120

160

200

240

122

163

203

305

406

508

610

122

152

229

305

381

457

inch

112

141

212

283

354

425

1.4

2.1

2.8

3.6

5.4

7.2

9.0

10.8

inch

103

137

172

259

345

432

1.7

2.6

3.5

4.4

6.6

8.8

11.0

inch

1.8

2.7

3.6

4.5

6.8

9.0

11.3

13.5

Screen size chart (4:3 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

Screen

Diagonal size Width (W)Max. Zoom Min. Zoom

Height (H)

inch

123

147

Distance from screen (L)Height projected

image (Hd)

inch

100

150

200

250

300

102

152

203

254

381

508

635

762

inch

131

174

218

261

133

177

221

332

443

553

664

100

125

187

249

311

374

inch

122

153

231

308

386

463

1.5

2.3

3.1

3.9

5.9

7.8

9.8

11.8

inch

112

149

187

282

376

471

1.9

2.8

3.8

4.8

7.2

9.6

12.0

inch

5.2

7.9

10.5

13.1

19.6

26.2

32.7

39.3

100

Screen size chart (16:9 aspect ratio)

The above numbers are approximate, and may be slightly different from the actual measurements.

Audio output

S-Video

PC/Component

Video output

SerialRS-232C

PC/Component

Video input

(mini D-sub 15pin)

RCA

Audio input

(stereo mini jack)
