Mitsubishi Electric MELSEC FX Series Manuel utilisateur

INDUSTRIAL AUTOMATION

MITSUBISHI ELECTRIC

MELSEC FX Series

Programmable Logic Controllers

Introduction to

FX Positioning Control Systems

Beginners Manual

Art. no.: 214562

21 03 2014

Version C Version check

Beginners Manual

Introduction to MELSEC FX Positioning Control Systems

Art. no: 214562

Version Revisions / Additions / Corrections

A 05/2008 pdp - rw First edition

B 08/2012 pdp - dk Addition of FX3G main units

C 03/2014 pdp - dk Addition of FX3GC, FX3GE and FX3S main units

About This Manual

The texts, illustration, diagrams and examples in this manual are provided

for information purposes only. They are intended as aids to help explain the

operation, programming and use of programmable controllers of the programmable

logic controllers of the MELSEC FX

, FX

2N,

2NC

, FX

3GC

, FX

3GE

, FX

and FX

3UC

series.

If you have any questions about the installation and operation of any of the

products described in this manual please contact your local sales office or distributor (see back cover).

You can find the latest information and answers to frequently asked questions on our website at

https://eu3a.mitsubishielectric.com.

MITSUBISHI ELECTRIC EUROPE BV reserves the right to make changes

to this manual or the technical specifications of its products at any time without notice.

MITSUBISHI ELECTRIC EUROPE B.V.

FX Positioning Control Systems I

Safety Guidelines

General safety information and precautions

For use by qualified staff only

This manual is only intended for use by properly trained and qualified electrical technicians who are

fully acquainted with the relevant automation technology safety standards. All work with the

hardware described, including system design, installation, configuration, maintenance, service and

testing of the equipment, may only be performed by trained electrical technicians with approved

qualifications who are fully acquainted with all the applicable automation technology safety

standards and regulations. Any operations or modifications to the hardware and/or software of our

products not specifically described in this manual may only be performed by authorised Mitsubishi

Electric staff.

Proper use of the products

The programmable logic controllers of the FX

, FX

2N,

2NC

, FX

3GC

, FX

3GE

, FX

and

3UC

series are only intended for the specific applications explicitly described in this manual. All

parameters and settings specified in this manual must be observed. The products described have all

been designed, manufactured, tested and documented in strict compliance with the relevant safety

standards. Unqualified modification of the hardware or software or failure to observe the warnings on

the products and in this manual may result in serious personal injury and/or damage to property. Only

peripherals and expansion equipment specifically recommended and approved by Mitsubishi

Electric may be used with the programmable logic controllers of the MELSEC FX family.

All and any other uses or application of the products shall be deemed to be improper.

Relevant safety regulations

All safety and accident prevention regulations relevant to your specific application must be observed

in the system design, installation, configuration, maintenance, servicing and testing of these

products. The regulations listed below are particularly important in this regard. This list does not claim

to be complete, however; you are responsible for being familiar with and conforming to the

regulations applicable to you in your location.

●VDE Standards

– VDE 0100

Regulations for the erection of power installations with rated voltages below 1000 V

– VDE 0105

Operation of power installations

– VDE 0113

Electrical installations with electronic equipment

– VDE 0160

Electronic equipment for use in power installations

– VDE 0550/0551

Regulations for transformers

– VDE 0700

Safety of electrical appliances for household use and similar applications

– VDE 0860

Safety regulations for mains-powered electronic appliances and their accessories for house-

hold use and similar applications.

MITSUBISHI ELECTRIC

●Fire safety regulations

●Accident prevention regulations

–VBGNr.4

Electrical systems and equipment

Safety warnings in this manual

In this manual warnings that are relevant for safety are identified as follows:

DANGER:

Failure to observe the safety warnings identified with this symbol can result in health and injury

hazards for the user.

WARNING:

Failure to observe the safety warnings identified with this symbol can result in damage to the

equipment or other property.

FX Positioning Control Systems III

General safety information and precautions

The following safety precautions are intended as a general guideline for using PLC systems together

with other equipment. These precautions must always be observed in the design, installation and

operation of all control systems.

DANGER:

●Observe all safety and accident prevention regulations applicable to your specific applica-

tion. Always disconnect all power supplies before performing installation and wiring work

or opening any of the assemblies, components and devices.

●Assemblies, components and devices must always be installed in a shockproof housing fitted

with a proper cover and fuses or circuit breakers.

●Devices with a permanent connection to the mains power supply must be integrated in the

building installations with an all-pole disconnection switch and a suitable fuse.

●Check power cables and lines connected to the equipment regularly for breaks and insulation

damage. If cable damage is found immediately disconnect the equipment and the cables

from the power supply and replace the defective cabling.

●Before using the equipment for the first time check that the power supply rating matches that

of the local mains power.

●Take appropriate steps to ensure that cable damage or core breaks in the signal lines cannot

cause undefined states in the equipment.

●You are responsible for taking the necessary precautions to ensure that programs inter-

rupted by brownouts and power failures can be restarted properly and safely. In particular,

you must ensure that dangerous conditions cannot occur under any circumstances, even for

brief periods.

●EMERGENCY OFF facilities conforming to EN 60204/IEC 204 and VDE 0113 must remain fully

operative at all times and in all PLC operating modes. The EMERGENCY OFF facility reset

function must be designed so that it cannot ever cause an uncontrolled or undefined restart.

●You must implement both hardware and software safety precautions to prevent the possibil-

ity of undefined control system states caused by signal line cable or core breaks.

●When using modules always ensure that all electrical and mechanical specifications and

requirements are observed exactly.

MITSUBISHI ELECTRIC
