Base Station

INSTALLATION GUIDE

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

Notice

The information contained in this document is believed to be accurate in all respects but is

not warranted by Mitel Networks™ Corporation (MITEL®). Mitel makes no warranty of any

kind with regards to this material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. The information is subject to change

without notice and should not be construed in any way as a commitment by Mitel or any of

its affiliates or subsidiaries. Mitel and its affiliates and subsidiaries assume no responsibility

for any errors or omissions in this document. Revisions of this document or new editions of

it may be issued to incorporate such changes.

No part of this document can be reproduced or transmitted in any form or by any means -

electronic or mechanical - for any purpose without written permission from Mitel Networks

Corporation.

TRADEMARKS

The trademarks, service marks, logos and graphics (collectively "Trademarks") appearing

on Mitel's Internet sites or in its publications are registered and unregistered trademarks of

Mitel Networks Corporation (MNC) or its subsidiaries (collectively "Mitel") or others. Use of

the Trademarks is prohibited without the express consent from Mitel. Please contact our

legal department at [email protected] for additional information. For a list of the worldwide

Mitel Networks Corporation registered trademarks, please refer to the website: http://

www.mitel.com/trademarks

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

1 INTRODUCTION

This document describes how to install the Base Station.

The document is intended for service technicians.

For information on how to operate the device, see the applicable Installation and

Operation Manual for the device.

For information about supported PBXs contact your supplier.

1.1 ABBREVIATION AND GLOSSARY

Base

Station Common name for IPBS, DECT Base Station (BS3x0) and TDM-DECT

Base Station.

DECT Digital Enhanced Cordless Telecommunications:

global standard for cordless telecommunication.

DECT Base

Station Another name for BS3x0

TDM-DECT

Base

Station

Another name for BS3x2.

GUI Graphical User Interface

IP Internet Protocol:

global standard that defines how to send data from one computer to

another through the Internet

IPBS Also referred to as IPBS Base Station. Previously called IP-DECT Base

Station

LAN Local Area Network:

a group of computers and associated devices that share a common

communication line.

PBX Private Branch Exchange:

telephone system within an enterprise that switches calls between local

lines and allows all users to share a certain number of external lines.

RFP Radio Fixed Part. DECT base Station part of the DECT Infrastructure.

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

2 DESCRIPTION

This section gives a general description of the following devices:

• IPBS4x0, see 2.1 IPBS4x0

• IPBS4x2, see 2.2 IPBS4x2 on page 4

• BS3x0, see 2.3 BS3x0 on page 8

• BS3x2, see 2.4 BS3x2 on page 10

2.1 IPBS4X0

The following versions of the IPBS4x0 are available:

• IPBS430

• IPBS440

2.1.1 IPBS430 WITH INTERNAL ANTENNA

Figure 1. IPB430 Overview

Contents of the Box

The box in which the IPBS430 is packed contains:

• An IPB430 with integrated antennas

• A mounting bracket

• Two screws with wall plugs

Test

(RJ12)

LAN

(RJ45)

Power Supply

(RJ45)

Front view Back view

LED1

LED2

005

Reset

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

Power Distribution

The IPBS4x0 can be powered using the following methods:

• Power over Ethernet, IEEE 802.3af

• A local AC-adapter

NOTE: For more information about power distribution, see 3.3 Power the Base Station

on page 22.

Software

The software in the IPBS4x0 can be updated by downloading new software without

disconnecting the equipment. The new software is stored in flash memory. For

information on how to update the software in the IPBS4x0, see the applicable

Installation and Operation Manual for the IPBS4x0.

Connectors

• Two 8-pin RJ45 modular jacks for LAN/PoE and powering

• A 6-pin RJ12 modular jack for factory testing

LEDs

2.1.2 IPBS440 WITH EXTERNAL ANTENNAS

The IPBS440 is available with two omni-directional external antennas. Other external

antennas can be mounted as well. This section contains the differences between the

IPBS4x0 with internal and external antennas. For all other information see 2.1.1

IPBS430 with Internal Antenna on page 2.

Status of LED1 (lower LED) Description

Steady Green Operational

Flashing fast amber Download of firmware in progress.

Steady Amber TFTP mode

Alternating red/green No Ethernet connection

Status of LED2 (upper LED) Description

Not lit IPBS 4x0 operational and no traffic on the IPBS

4x0.

Steady green IPBS 4x0 operational and traffic on the IPBS

4x0.

Flashing slow green Fully occupied with traffic.

Flashing red No air synchronization - searching for air sync

candidates.

Flashing fast red Download of RFP software in progress.

Alternating red/green RFP not initialized.

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

Contents of the Box

The box in which the IPBS440 is packed contains:

• An IPBS440 for external antennas

• Two antennas

• A mounting bracket

• Two screws with wall plugs

NOTE: The IPBS440 cannot be mounted with the antennas pointing downwards as the

mounting bracket does not support it.

Insert the antennas into the IPBS440 before following the installation instructions in 3.2

Install the Base Station on page 15.

2.2 IPBS4X2

The following versions of the IPBS4x2 are available:

• IPBS432 with internal antenna

• IPBS442 with external antennas

The IPBS 4x2 is backward compatible with the IPBS 4x0 when it comes to coverage,

functionality, accessories and mounting bracket. If an old IPBS 4x0 has to be replaced

you just reuse the mounting bracket and install the IPBS4x2.

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

2.2.1 IPBS432 WITH INTERNAL ANTENNA

Figure 2. IPBS2 Overview

Contents of the Box

The box in which the IPBS432 is packed contains:

• An IPBS4x2 with integrated antennas

• A mounting bracket

• Two screws with wall plugs

Power Distribution

The IPBS4x2 can be powered using the following methods:

• Power over Ethernet, IEEE 802.3af

• A local AC-adapter

NOTE: For more information about power distribution, see 3.3 Power the Base Station

on page 22.

Front view

LED

LAN

(RJ45)

Power Supply

(RJ45)

Back view while lying down

Used for cable ties

to provide strain

relief for cables

Back view

Reset

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

Software

The software in the IPBS4x2 can be updated by downloading new software without

disconnecting the equipment. The new software is stored in flash memory. For

information on how to update the software in the IPBS4x2, see the applicable

Installation and Operation Manual for the IPBS4x2.

Connectors

• Two 8-pin RJ45 modular jacks for LAN/PoE and powering

LEDs

The IPBS4x2 has one RGB LED to indicate status. This section describes the different

indications and when they shall be used. In the illustrations below: Each blink pattern is

represented by a number of blocks where each block is 100 ms. Light grey blocks

means that the LED is off. Whenever the indication is changed the new pattern always

starts from the first block.

Idle/OK Solid blue. IPBS4x2 operational and

no traffic on the IPBS4x2.

Starting up/

searching 100 ms blue, 100 ms off. The IPBS4x2 is in start-up

phase, e.g. waiting for

parameters from PARI

Master, or is searching for

air synchronization, or the

radio is disabled.

Active traffic 400 ms off, 2000 ms blue. IPBS4x2 operational and

traffic on the IPBS4x2.

Fully occupied

for speech traffic 400 ms red, 2000 ms blue. Fully occupied with traffic.

Software

download 400 ms blue, 600 ms off. Download of firmware in

progress.

Mini firmware 100 ms yellow, 100 ms off. The IPBS4x2 is in mini

firmware mode.

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

2.2.2 IPBS442 WITH EXTERNAL ANTENNAS

This section contains the differences between the IPBS4x2 with internal antenna and

external antennas. For all other information see 2.2.1 IPBS432 with Internal Antenna

on page 5.

TFTP mode Solid yellow. TFTP mode.

Error 100 ms red, 100 ms off. No Ethernet connection.

Fatal error Solid red. Fatal hardware error.

Deployment:

Good sync 2000 ms blue, 400 ms yellow. The IPBS4x2 is in

deployment mode and has

good air sync coverage.

Deployment:

Bad sync 400 ms blue, 600 ms off, 400 ms blue,

600 ms off, 400 ms yellow. The IPBS4x2 is in

deploymentmodeanddoes

not have adequate air sync

coverage.

Deployment:

No sync 2000 ms red, 400 ms yellow. The IPBS4x2 is in

deployment mode and has

no air sync coverage.

32/1531-ANF 901 43 Uen B2 2016-04-01

Installation Guide

Base Station

Figure 3. IPBS442 with MCX connectors for external antennas

Contents of the Box

The box in which the IPBS442 is packed contains:

• An IPBS442 with external antennas.

• A mounting bracket

• An antenna bracket

• Two antenna coaxial cables.

• Two antennas.

• Four screws with wall plugs

2.3 BS3X0

The following versions are available:

• BS330 with Internal antenna

• BS340 with External antennas

Back view while lying down

MCX connectors
