Mitel 3000 5330 Manuel utilisateur

5330 IP Phone Quick Reference

User Guide

Mitel 5330 IP Phone

Quick Reference User Guide

Introduction to your Mitel 5330 IP Phone

The Mitel 5330 IP Phone provides the similar functionality as the Mitel 3000 Feature Phone.

It can be connected directly to the Mitel 3000 system or installed at a remote location and

connected to the system via the Internet. When connected remotely, it retains all the

functionality and features of an extension directly connected to the system.

Extension Pairing

The IP Phone can be paired with another extension. For example, a user can have two

paired extensions, one in the ofce and one at home. By entering a 3-digit code in either

extension, the ofce extension can be transferred to the user’s home and the home

extension transferred to the ofce. The extension number and all programmed features,

including voicemail, are transferred, providing the user with all their normal telephony

facilities at home.

Call Quality

When the IP Phone is installed at a remote location, it uses the Internet to connect to the

Mitel 3000 system. The call quality depends on the amount of bandwidth available to the

IP Phone via the Internet connection. If the IP Phone is sharing the Internet connection

with PCs which are browsing or engaged in le transfers, the call quality may vary during

this activity.

Introduction to Programming your Mitel 5330 IP Phone

There are three steps of programming before your Mitel 5330 IP Phone is active.

Step 1. Program the Broadband Module.

Step 2 Connecting the Mitel 5330 IP Phone.

Step 3 Program the Mitel 5330 IP Phone.

Mitel 5330 IP Phone

Quick Reference User Guide

1. Programming the Broadband Module.

Before attempting to program IP extensions it is important that the following are

checked:

If any of the IP extensions are located remotely ensure that the broadband service

is connected to and working on the Broadband Module. The VoIP programming is not

available unless an IP address is provided on the WAN interface. This address is shown

on the status page. See the broadband module manual for more information.

The broadband service provides a static IP address.

If the IP extensions are located on the LAN only and no broadband service is sup-

ported then the VoIP interface must be changed to IP LAN. See the broadband

module manual for more information.

1. Connect to the Broadband Module programming Interface using the Wizard

or Browser Click VoIP from the Setup panel in the main Broadband Module

screen.

•

WARNING Your service provider MUST provide a static IP address for

IP phones to work remotely.

Mitel 5330 IP Phone

Quick Reference User Guide

2. Click the link Change your VoIP endpoint types here ...

3. Choose a free endpoint and select IP Extension from it’s drop-down menu. Note that

the extension number associated with the endpoint will be assigned to the Mitel 5330 IP

Phone.

If the Endpoint screen is not shown it is because an IP address is not available

to the WAN.

Ensure the broadband connection is available and working on the Broadband

Module.

Note

Mitel 5330 IP Phone

Quick Reference User Guide

4. Click Confirm Changes.

5. Enter the password (this must match the password programmed into the

Mite 5330 IP Phone, in default this is “iptpassw”)

The password is set at iptpassw which matches the default password in the IP

phones. This should not be changed.

The MAC address is printed on a label on the base of the IP Phone.

Click Next >

Mitel 5330 IP Phone

Quick Reference User Guide

6. Click Confirm Changes

7. Click Restart

Restart the Broadband Module. Once the Broadband Module has restarted step 1 of

the programming is now complete. The Mitel 5330 IP Phone will now connect to the

Mitel 3000 system.

Click Next >

Mitel 5330 IP Phone

Quick Reference User Guide

2. Changing the VOIP Interface.

Programming the IP Phone involves entering the ICP IP ADDRESS. This IP address will

be provided by the Mitel system administrator. The WAN address is for users who will

be accessing Remotely and internally. The LAN address is used for local users when

no external internet connection is available. If you want to use the LAN address, you

must change the VOIP Interface to IPLAN.

1. Connect to the Broadband Module programming Interface using the Wizard or

Browser

Click VoIP from the Setup panel in the main Broadband Module screen.

2. Scroll down and Click the link Change Advanced VoIP Settings here ...

Mitel 5330 IP Phone

Quick Reference User Guide

3A. From the VOIP Interface section select IPWAN (default) from the

drop-down menu if used as a remote user.

3B. ONLY if the IP phone is used as stand alone of the PBX within the

LAN, from the VOIP Interface section select IPLAN from the drop-down

menu.

Click Next >

4. Enter the Public IP address of your DSL connection on the VoIP Gate-

way Address box.

Mitel 5330 IP Phone

Quick Reference User Guide

5. Click Restart

4. Click Confirm Changes.

Mitel 5330 IP Phone

Quick Reference User Guide

3. Connecting the Mitel 5330 IP Phone.

The IP Phone is supplied with a transformer and two Ethernet cables. Connect an

Ethernet cable to the LAN/PWR connector on the back of the IP Phone and connect

the other end of the cable to the PHONE connector on the Transformer.

Connect the other Ethernet cable to the LAN connector on the Transformer and

connect the other end of the cable to an Ethernet port on the Broadband Module (IP

Phone connected locally to the Mitel 3000) or broadband router (IP Phone installed

at a remote location).

Connect the transformer to a power source.

A PC can be connected to the broadband router via the PC port on the back of the IP

Phone if required.

Note

The Mitel 5330 IP Phone can also be powered via

a power over Ethernet LAN switch.
