User's Manual
For MS-E8221
Version:V1.0
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM
CONTENT
1. PRODUCT INTRODUCTION .............................................................................................................1
1.1 Product summarise..............................................................................................................1
1.2 Functional features..............................................................................................................1
1.2.1. EPON port Functional features.......................................................................................1
1.2.2. Functional features of other ports...................................................................................4
1.3 Size and weight....................................................................................................................6
2EQUIPMENT INSTALLATIONS .........................................................................................................6
2.1 Installation enviroment........................................................................................................6
2.2 EPON Port connection........................................................................................................6
2.3 Uplink SFP installation .......................................................................................................7
2.4 Equipment electrify..............................................................................................................8
2.5 Power requiement................................................................................................................8
2.6 Equipment electrify..............................................................................................................8
3TECHNOLOGY SPECIFICATIONS......................................................................................................9
3.1 EPON optical port specification..........................................................................................9
3.2 Up link data port................................................................................................................10
3.3 Console interface...............................................................................................................10
3.4 Out-band network management interface..........................................................................11
3.5 Management configuration: ..............................................................................................11
3.6 Common fault analysis ......................................................................................................11
APPENDIX ASECURITY PROMPT .........................................................................................................14
APPENDIX BTROUBLE HANDLING.......................................................................................................14
APPENDIX CPRODUCTAPPLICATION...................................................................................................15
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 1/16
1. Product introduction
1.1 Product summarise
MS-E8221 is the Central Office mainfram box platform of
GEPON series products which is researched and developed by
our company; it is Able to provide a variety of integrated
services access, such as broadband, voice, IPTV, CATV.
It includes 2 independent fiber terminals (OLT) unit and 2
SFP GE uplink port, 1 console port, 1 Of-band management port,
1 RS485 port.
All the GEPON series products of our company are using
passive optical network (PON) technologies, which is better
than traditional access products in cost performance,
maintenance, expansibility and etc.
1.2 Functional features
1.2.1. EPON port Functional features
In GEPON system, as the OLT unit, PON port is responsible
for the register of ONU, transfers the Ethernet message received
from network in the downlink to EPON optical signal, and sent
it to ONU by passive network. In up link,
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 2/16
it receives EPON optical signal sent by ONU and transfer it to
ethernet message then send to swich core equipment.
It includes 2 PON port of 1.25G; usually each PON port
can access 32 pieces of ONU equipment in the transmission
distance of 20kms.
The equipment is composed by high integrated OLT chips
and independent control modules, offering reliable assurance
for users in functions and performences.
The functional features of this board are summerized as
follows:
¾Support ONUs communicate under the same PON port
¾Support 802.3 MPCP protocal
¾Support 802.3 OAM and expand protocal(slave port),
have abundent OAM function design, offer
long-distance management through OLT
¾Have double-channal independent OLT
¾Support long-distance update for software
¾High integration level and integration management,
and have the function of double layer exchange
¾Support data encrypt service in downlink, secure the
data transition security for users
¾Support ONU authentication, avert illegal ONU
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 3/16
accesss to network
¾Support DBA dynamic bandwidth allocation
¾Support IGMP Proxy
¾Support ACL functions
¾Support QOS functions
¾Support 4K MAC address with single channal OLT
¾Support VLAN divided by LLID
¾Offer abundant statistical information
¾Support hot plug by the board
¾Offer 2G uplink
¾The uplink is SFP, and could be configured as
electrical port or optical port
¾If configured as electrical port,it should work as the
pattern of 1000M
¾Support the VLAN division on the basis of port
¾Support 4096 entries of VLAN
¾The capacity of MAC address is 8K
¾Uplink support port trunk, port monitoring and
mirroring
¾Offers 2 control interface, local and network
¾Support 3 types of management CLI, TELNET and
SNMP
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 4/16
¾The net Work control supports in-band and out-band
Support read of SFP mode
1.2.2. Functional features of other ports
The sketch map of front panel is as follows:
Chart 1 Product appearance diagram
Descriptions of the interface
From left toright, the discriptions are as follows:
¾The RS485 interface, use to transfer serial informations
from ONU
¾RST button, press this button to trigger the board
restoration
¾Consloe port, local management interface, RS232,
connector type RJ45
¾Manage port, out-band management interface,
10M/100M full or duplex ethernet interface, connect
type: RJ45
¾GE1&GE2 port, uplink, SFP mode, it can configured as
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 5/16
fiber or electical mode
¾PON1&PON2 port, downlink, SFP mode
Discriptions of indicator lights from the left to right and
up to down
Indicator light color Definition
Off: power is abnomal
PWR Green
On: power is nomal
Off: abnormal system operation
SYS Green
On: normal system operation
Flash: there are data passing from uplink
port
ACT1 Green
Off: there are no data passing from
uplink port
On: uplink port is connect
GE1
LINK1 Green
Off: uplink port isn’t connect
Flash: there are data passing from uplink
port
ACT2 Green
Off: there are no data passing from
uplink port
On: uplink port is connect
GE2
LINK2 Green Off: uplink port isn’t connect
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 6/16
On: The first port connected to ONU
PON1 LINK1 Green Off: The first port not connected to ONU
On: The second port connected to ONU
PON1 LINK2 Green Off: The second port not connected to
ONU
Table 1 the discription of indicator lights of panel
1.3 Size and weight
Size: 441mm*192mm*43mm
Weight: about 3kg
2Equipment installations
2.1 Installation enviroment
Installed in the center room on the rack.
2.2 EPON Port connection
First install the OLT SFP optical module, and after
installing the optical module, insert SC/PC fiber to SFP optical
mode, and the process is completed.
Note: Keep the joint of fiber clean, and please preserve
the cap of flange for later use.
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 7/16
2.3 Uplink SFP installation
The uplink port of the board is SFP interface, the default
option of the board before leaving the factory is no SFP
module, users could use proper SFP module according to his
own situations.
SFP is standard parts, when you install it, directly inserting
it to the SFP slot of the board. The board could identify that the
module which the user insert is optical module or electrical
module.
In default conditions, the board works in the normal
exchange mode, in that mode, the 2 SFP interfaces of board are
same, and the uer could use any one of it. But in isolation and
converge mode, user should choose the specific port
In isolation mode, the corresponding relations of up link
ports and PON ports are as follows:
SFP uplink port PON port
GE1 PON1
GE2 PON2
Table 2 the corresponding table of ports
SHENZHEN MISENSE COMMUNICATION TECHNOLOGY CO., LTD.
WWW.MISENSECOM.COM Page 8/16
2.4 Equipment electrify
SFP up link port: on the basis of different type of modules,
use net cable or optical fiber to connect up link port and
up-layer network equipment (such as switch, router).
CONSOLE port: use the DB9/RJ45 special connection
cable which is the accessory of the equipment to connect
CONSOLE port and DB9 interface of PC.
Manger port: use crossing-line or parallel line to connect
this port with PC or HUB.
NOTE: The net cable or fiber is no available when the
machine left the factory, and the user needs to prepare it.
2.5 Power requiement
The power of the board is supplied by common AC power
range is from: AC100V～AC250V
Power consumption: < 15W
2.6 Equipment electrify
The board supports hot plug, and when the power is
applied to it, you could judge if it works normally or not
through the indicator light conditions. If the board has already
connected with power or started to work, the conditions of
