Minuteman AD100 Manuel utilisateur
Your Air Mover Provider
®
®
Minuteman International specializes in innovative design and manufacturing of reliable
air movers, while providing exible and efcient real-world solutions to meet our
customer’s changing needs. Our movers are small and lightweight yet powerful enough
to meet your restoration, drying, and ventilation needs. Our products are made to be
durable and high performing.
The contents of this manual are based on the latest product information available at the time of publication. We reserve
the right to make changes or improvements to the machine without notice.
Minuteman International •14N845 U.S. Route 20 •Pingree Grove, IL 60140
www.minutemanintl.com
C43000-02 USER MANUAL
Your Air Mover Provider
®
®
PAGE PB PAGE 1
PREFACE
Thank you for your purchase of the industry standard for industrial
equipment. Minuteman International takes great pride in offering the
most dependable, reliable and best value in industrial equipment; we set
the standard.
Our Customer Service department would like to hear from you. If you see
any errors, omissions or something that needs clarication in this spare
parts catalog please let us know. We are working hard toward perfection in
our corner of the process to bring you the best you can buy. Please copy
the form below, ll out and comment on how you found our catalog.
Thank you.
Name: ______________________________________________________________
Title: _______________________________________________________________
Company: __________________________________________________________
Address: ___________________________________________________________
Country: ____________________________________________________________
Type of equipment or model number: _________________________________
Comments:
Please return to: Minuteman International, Inc.
14N845 U.S. Route 20
Pingree Grove, Illinois 60140 USA
Your Air Mover Provider
®
®
PAGE 2
NOTES
Your Air Mover Provider
®
®
PAGE 2 PAGE 3
NOTES
Your Air Mover Provider
®
®
PAGE 4
NOTES
Your Air Mover Provider
®
®
PAGE 4 PAGE 5
GENERAL SAFETY WARNINGS
• Do not operate your air mover with a cut or frayed cord. Do
not run power cord under carpeting. Do not cover power cord
with rugs, runners, or similar covers. Place power cord away
from trafc area to prevent tripping.
• Do not unplug your unit by pulling on its cord. Firmly grasp the
plug and pull it out of the wall socket or power receptacle.
• The plug has a safety ground pin installed that must not be
removed. If the pin is damaged or missing, replace the power
cord before further use. Visually inspect the power cord before
each use. Ignoring these safety precautions may result in a re
or electrical shock.
• Always use a GFCI outlet. Contact a qualied electrician
for verication and/or installation of a GFCI receptacle
if necessary.
• To reduce the risk of re or electrical shock, do not use this
fan with any after-market or solid-state speed control device.
• To prevent electric shock, do not operate the unit in standing
water. Never plug in or unplug the unit with wet hands or while
standing in water.
• Do not drop the unit. Sudden and severe impact may result in
damage to internal components.
Your Air Mover Provider
®
®
PAGE 6
• Do not operate unit with the safety grills, existing covers,
shields, or housing removed. Personal injury may result. Do
not stick ngers or objects into the safety grills.
• To avoid injury, do not direct air ow at face or body. Do not
allow children to play with or around unit at any time.
• Do not move or carry air mover while unit is operating.
• Drop cloths or other loose fabrics can be drawn against
the unit thereby restricting airow. This may cause the unit
to overheat. Keep area around unit free and clear of any
obstructions.
• Save the shipping carton in case your air mover needs to
be returned.
• This unit should never be serviced or cleaned while it is
plugged into a live electrical power source.
• Keep away from heat, chemicals, and other potential
hazardous materials.
• Use equipment as instructed and with manufacturer’s
recommended accessories.
• Do not operate this equipment while impaired, distracted, or
under the inuence of alcohol, drugs, or medication.
Your Air Mover Provider
®
®
PAGE 6 PAGE 7
OPERATING INSTRUCTIONS
When operating the unit, please adhere to the following:
• Inspect unit upon receipt for any freight damages. Be sure
to keep all original packaging if return process is required. If
you discover any damages, please contact your distributor or
Minuteman International.
• Check the machine for any obstructions in the fan or airow
areas before plugging the unit in for operation.
• Set the machine in the desired orientation for operation.
• Ensure the switch is in the (OFF) position.
• Plug the power cord into a GFCI outlet.
• Do not use an extension cord.
• Do not use an adapter.
• Do not plug more than a total of 12 amps into the GFCI outlet.
• Turn unit on
Your Air Mover Provider
®
®
PAGE 8
USER SERVICING
Never service or clean this unit while it is plugged into outlet.
SYMPTOM PROBLEM SOLUTION
Unit will not turn on • Not plugged in
• Switch is worn
• Tripped circuit
breaker
• Short in power cord
• Capacitor on motor is
damaged
• Plug unit into proper
outlet
• Replace switch
• Reset breaker
• Replace power cord
or replace cord end
• Replace motor
Air mover will not
operate on all speeds
• Switch is worn
• Capacitor on motor is
worn or damaged
• Replace switch
• Replace motor
Air mover runs or starts
slowly
• Capacitor terminal
may be shorting
• Replace motor
The fan is rubbing • Fan is off-center • Replace fan
Air mover is making
strange noises
• There is a foreign
object stuck near fan
• Motor bearing is worn
• Fan is rubbing
• Turn off motor and
unplug unit then
remove foreign object
• Replace motor
• Replace fan
Your Air Mover Provider
®
®
PAGE 8 PAGE 9
MODEL SPECS
Power 230V, 50/60Hz
Motor 1 HP, 3 Speed, Sealed
Amps 7.6 / 8.5 / 9
Safety ETL listed
Cord Length 15 ft.
Airow 1600 CFM
Weight 32.5 lbs.
Dimensions 16.5 x 19.75 x 18.75 inches
Material High Density Polyethylene Roto Mold
