Minox 35 PL Manuel utilisateur

MINOXGmbH,Postfach6020,D-6300Giessen1

WestGermany

482e

Modificationsreserved· PrintedinGermany

VIII/83

Owner'smanual

Thisdetailedinstructionmanualwill

helpyoutomakethemostofyour

Minox35PL.Themostimportanttext

sectionsareprintedinboldtype.

Referencestoparts,controlsor

camerasignalsarefollowedbya

numeralinbrackets;Thisisthenum-

berofthatpartintheannotatedillu-

strationsonpages4 and5.

Mosthandlingstepsworkwithouta

filminthecamera.Sogetfamiliarwith

yourcamerabytryingitoutbefore

actuallytakingpictures.

ManyoperationsoftheMinox35PL

arecontrolledelectronically.The

camerathereforeonlyworkswitha

battery.

Despiteitssmalldimensionsthe

Minox35PLisafull-frame24x36mm

miniaturecameraandtakesany

standard35mm(No.135)cartridge.

Annotatedcameraviews

Frontview

Rearview

Handlingthecamera

Thebattery

Insertingthebattery

Batterycheck

Openingandclosingthecamera

Theviewfinder

Holdingitright

Releasing

Advancingthefilm

Theframecounter

Settingthefilmspeed

Daylightexposures

Programautomation

Theslow-speedwarning

Thebacklightswitch

Flashexposures

Thesefltimer

Thedistancesetting

Loadingthefilm

Unloadingthefilm

Careofthecamera

Accessories

Specialcomputerflashunits

MinoxFC35

MinoxTC35

Theever-readycase

Thebeltandwristpouch

Thepockettripod

Push-onfilters

Theskylightfilter

Theneutraldensityfilter

Technicaldata

1Framecounter

2Shutterrelease

3Batterycheckbutton

4Backlightswitch

5Hotshoe

6Slow-speedwarningLED

7BatterycheckLED

8Filmrewindcrank

9SefltimerLED

10Viewfinder

11Batterycompartment

12Aperturering

13Distancescale

14Lens

15CdScell

16Frontcover

17Viewfindereyepiece

18Selftimerswitch

19Filmtransportlever

20Take-upspool

21Rewindrelease

22Tripodbush

23Filmspeedscale

24Backcoverlock

25Filmchamber

CertainfunctionsoftheMinox35

PL.suchastheshutterandautomatic

exposuresettings,arecontrolled

electronically.Thecameratherefore

onlyworkswithabattery.Itrequiresa

5.6voltmercuryoxidebattery,for

instance:

DuracellPX27

VartaV 27PX

orequivalents.

Openthefrontcover(16).

Unscrewthebatterycompartment

cover(11)anticlockwise,withacoinif

necessary.

Insertthebatterysothatthe+ end

facestheinsideofthecompartment

cover,alsomarkedwitha + sign.

Replacethecoverandscrewtight

again.

Aclickonpressingthereleasedoes

notnecessarilyindicatecorrectoper-

ationoftheelectronicshutter.So

checkthebattery.

Openthefrontcover(16),fully

advancethefilmtransportlever(19)

-seepage12- andcheckasfollows:

Fullydepressthesmallrectangul-

arbatterycheckbutton(3)between

thehotshoeandthegreenrelease

button.Iftheleft-handgreenLED(7)

infrontofthehotshoelightsup,the

batteryisOK.

IfthegreenLED(7)failstolightthe

batteryisexhaustedorwasinserted

thewrongwayaround.

IfthegreenLED(7)goesdimwithin

2-3seconds,thebatteryisnearly

exhausted- soreplaceitassoonas

possible.

Thebatterycheckdoesnotindicate

howmuchlongerthebatterywilllast.

Tobeonthesafeside,replacethebat-

teryoncea yearbya newone,evenif

thebatterycheckisstillpositive.

Apparentearlyfailureofthebattery

mayinfactbeduetoa poorcontact.

Removethebatteryfromthecamera,

firmlyrubdownbothcontactfaces

witha roughclothandreplace.

Neverkeepspentortoooldbatter-

iesinthecamera.Alsoremovethe

batteryifyoudonotexpecttousethe

cameraforsometime.

Note:Thebatteryusedherecon-

tainsmercurycompoundsthatcould

posea healthrisk.Soneverthrow

usedbatteriesona fire;alsokeep

themoutofthereachofsmallchild-

ren.Photodealersusuallyaccept

spentbatteriesfordisposal.

TopreparetheMinox35PLfor

shooting,fullypulldownthefront

cover(16).Aftershootingpushthe

coverupagainagainstthecamera

body.

Openingthefrontcoverautomati-

callyextendsthelens(14),closingthe

coverretractsit.

Theclosedcoveralsocoversthe

viewfinder,blocksthereleaseand

switchesoffallelectriccircuits.

Withthecameraclosedyoucanstill

advancethefilm(page12)orrewind

anexposedfilm(page24).

Thebrightframeinthefinder(17)

outlinesthefieldofview.

Incertainlightconditionsa red

signalappearsinthefinderbelowthe

brightframeattheright.Thisisthe

slow-speedwarningsignal(page16).

Theclosedfrontcover(16)also

blocksthefinderview.Sowhenyou

seenothingthroughthefinderyou

mustopenthecover.

Thepictureattheleftshowsa con-

venientcameraholdforhorizontal

shots,theillustrationoppositeasuit-

ableholdforuprightviews.

Tominimisetheriskofcamera

shakeholdyour35PLsteadywhile

you

shoot

Keepyourfingersclearofthelens

(14)andoftheCdScell(15).Preferably

pressyourfingersflatagainstthe

frontofthecamerabody.

Onceyouhaveframedtheviewyou

wantinthebright-linefinderframe,

gentlydepressthegreenrelease

button(2).Thattriggerstheshutterto

takethepicture.

Onpressingtherelease,theself-

timerLED(9)brieflylightsuponthe

camerafront.Duringtheexposurethe

redslowspeedwarningLEDlightsup

onthecameratop(6)andinthefinder

atthebottomright.Thisredsignal

remainslituntiltheshuttercloses- a

usefulindicationduringlongtime

exposureswiththecameramounted

onatripod.

Pullthefilmtransportlever(19)-at

thetoprightofthecameraback-

fullyouttotherightandforward.

Repeatthis.

Ifyoufailedtopulltheleverfullyfor-

wardeithertime,pulloncemore.

Ifyouhaveloadedthefilmanditis

advancingcorrectly,theknobwith

therewindcrank(8)atthetopleftof

thecameraalsorotatesasyouoper-

atethetransportlever.Sodonot

obstructthisknobasyouwind.

Alightdotontherewindcrank(8)

showsupthismovement.

Whenthewholefilmisexposed,the

transportlevernolongerswingsout

fullyandthereleaseisblocked.

Youcanadvancethefilmwiththe

frontcoveropenorclosed.

Theframecounter(1)- thewhite

windowatthefarrightofthecamera

top–tellsyouhowmanypicturesyou

havetakenonthefilm.

Theframecounterreturnstoits

startpositionwhenyouremovethe

camerabacktochangethefilm(see

page24)orassoonasyouthenpress

therelease(2).

EveryfilmpackagecarriesanASA

speedrating(andoftenDIN).

Tosettheautomaticexposurepro-

gramofthe35PLforthefilmspeed,

turnthedial(23)inthecamerabase

totheappropriateASA(orDIN)

ratingofthefilm.

Thedialengagesateveryspeed

setting.Theunmarkeddotsbetween

thearrowheadsIndicateinterme-

diatespeeds,forinstance64and80

ASAbetween50and100ASA.

ASAspeedfiguresaremarkedIn

red,DINfiguresingreen.

Ifyouhavesettoohighafilmspeed,

yourpictureswillbeunderexposed;

toolowaspeedsettingyieldsoverex-

posedshots.

Programautomation

Forallshotswithoutflashsetthe

whitearrowheadonthelensmount

(12)toA (automaticcontrol).

AtthisA settingthecameraauto-

maticallyselectsa correctaperture

andshutterspeedcombinationforthe

subjectbrightnessandfilmspeed.

Thef-stops,forinstance2.8- 4 -

5.6etc.ontheaperturering(12)are

onlyusedforflashshots(page18).If

youaccidentallysettheringtoan

aperturefigureinsteadoftoA,day-

lightandothershotswithoutflash-

e.g.brightinteriorslitbyartificiallight

-may bewronglyexposed.

Theelectronicprogramofthe

Minox35PLyieldsaperture/speed

combinationsfromf/16tof/2.8and

from1/500to4secondsat100ASA(up

to15secondsat25ASAorupto1

secondat400ASA).

Theslow-speedwarning

Ifthecameraisreadytoshoot

(frontcoveropen,filmadvanced)at

anexposuretimelongerthanabout

1/30second,a redflashingsignal

warnsoflikelycamerashakewith

hand-heldshots.

Theredsignalflashesclearlyon

topofthecamera(6)andalsointhe

finder(atthebottomright).Thereit

appearsweakertoavoidglareinthe

finderimage.

TheautomaticcontroloftheMinox

35PLcanalsogenerateexposures

muchlongerthan1/30second.The

redflashingsignalisthusnot an

underexposurewarningbutonlya

recommendationtousea flashunit

(pages27to29)whenphotographing

movingsubjects(e.g.people)in-

doors.Or-forstaticsubjects-mount

thecameraonatripod(page32).

Theslow-speedwarningusesbat-

terypower.Soclosethefrontcover

whenyouputawayyourMinox35PL.

Thebacklightswitch

Ifyoupushthebacklightswitch(4)

-thesmallrectangularbuttonnextto

thehotshoe– fullyforward,thisauto-

maticallydoublestheexposure.

Aredwindowwith2xinwhite

remindsyouthatyouhaveswitched

onthebacklightswitch.

Apartfromlighteningshadowsin

backlitsubjects,usethebacklight

switchalsoforoutdoorviewswhere

predominantsnoworabrightskyarea

couldcausethemetertosetinsuffi-

cientexposure.

ThehotshoeoftheMinox35PL

takesanyelectronicflashunitwitha

centrecontactinthefoot- aswellas

theMinoxTC35andFC35computer

flashunitswhicharespecially

matchedtotheMinox35.

Pushtheblackblankingplateout

ofthehotshoetowardstherear.Fully

pushthefootoftheflashunitintothe

shoe.

Thisdisengagestheautomatic

exposurecontroloftheMinox35PL

andsetsafixedshutterspeedof1/90

second.

Donottakeflashshotswiththe

aperturering(12)settoA (automa-

tic).Forflashshotsselectoneofthe

markedaperturesbetweenf/2.8and

f/16(includingintermediatevalues)

-checktheinstructionsoftheflash

used.

Withsomeelectronicflashunits

(notwiththespecialMinoxflashes)

youmustoperatethefilmtransportof

the35PLimmediatelyaftereveryflash

shot.Forunlesstheshutteristension-

ed,suchflashunitseitherfailtogivea

readysignalforthenextflashor(more

rarely)mayautomaticallytriggerthe

nextflashafterrecycling.(Thisisnota

faultbutafeatureoftheelectroniccir-

cuit.)

Pushdownthesmallslidingswitch

(18)attherightofthefindereyepiece

touncovera redwindowwithT

(timer)inwhite.Thisdelaystheshut-

terreleasebyabout12secondsafter

youhavepressedthegreenrelease

button(orreleasedwitha cable

release).

AredflashingLEDonthecamera

front(9)signalsthattheselftimeris

runningbuttheexposurehasnotyet

started.Theflashingratedoubles

after4 secondsandagainafter8

secondsofthedelayperiod.

Autres manuels Minox Appareil photo numérique

Minox

Minox 110 S Manuel utilisateur

Minox

Minox DC 5222 Manuel utilisateur

Minox

Minox CD 25 Manuel utilisateur

Minox

Minox DC 8122 Manuel utilisateur

Minox

Minox DC 6211 Manuel utilisateur

Minox

Minox DCC Leica M3 Manuel utilisateur

Minox

Minox DCC Rolleiflex AF 5.0 Manuel utilisateur

Minox

Minox DC 5211 Manuel utilisateur

Minox

Minox DD100 Manuel utilisateur

Minox

Minox Camera Manuel utilisateur

Minox

Minox MobiDV Manuel utilisateur

Minox

Minox DC 3311 Manuel utilisateur

Minox

Minox DD1 Manuel d'instructions

Minox

Minox MobiDV Manuel utilisateur

Minox

Minox DD200 Manuel utilisateur

Minox

Minox DTC 460 Manuel utilisateur

Minox

Minox DC 1422 Manuel utilisateur

Minox

Minox DC 8111 Manuel utilisateur

Minox

Minox DC 2122 Manuel utilisateur

Minox

Minox GT-S Manuel utilisateur

Minox

Minox DD100 Manuel utilisateur

Minox

Minox DIGITAL CLASSIC CAMERA 5.1 Manuel utilisateur

Minox

Minox DC 5011 Manuel utilisateur

Minox

Minox DC 2111 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
