Minox Nvmini Manuel utilisateur

MINOX NVmini

Anleitung

Instruction

Mode d’emploi

Minox NV mini

•Deutsch

•English

•Français

Entfernen Sie bitte niemals bei

Tageslicht den Objektivschutzdeckel.

Never remove the lens cap in daylight.

N’enlevez jamais le couvercle de

l’objectif en plein jour.

Achtung! Attention!

Contents

Introduction Page 17

Get familiar with

your night vision ‘scope Page 18

- Control elements Page 18

General information Page 18

Operating instructions Page 19

For use in daylight Page 19

- Inserting the battery Page 19

- Switching on Page 19

- Switching off Page 19

For use at night Page 20

- Switching on Page 20

- Adjustment Page 20

- Infrared illuminator Page 20

- Switching off Page 20

Safe keeping Page 21

Important information Page 21

Advice on care Page 22

Troubleshooting Page 23

Technical Data Page 25

Customer Service Page 26

Conditions of warranty Page 28

Introduction

Dear MINOX Customer,

Congratulations on your purchase of this night

vision ‘scope. You have chosen a product that

boasts highest optical quality and precision me-

chanics.

This User’s Manual will advise you on how to

obtain the best performance results from your

MINOX night vision ‘scope.

We hope this night vision‘scope scope will give

you a great deal of pleasure and always keep

you perfectly in the picture!

21 876

3 5

MINOX NV mini

Get familiar with your

night vision ‘scope

Control elements

1. Housing

2. Main power switch

3. Objective lens

4. Eyepiece and focusing ring

5. Infrared illuminator

6. Infrared illuminator power switch

7. Battery compartment

8. Lens cap*

9. Carrying strap position held

*never remove in daylight!

General information

This top quality optical-electronic product is

fitted with a Generation 1+ residual light am-

plifier. The field of use includes observation

and orientation aid in twilight, moonlight,

starlight or darkness (in combination with the

infra-red illuminator). The temperature range

is from -30° to +50°C / -22° to +122° F. With

its compact dimensions it is easy to handle

and ready for use at any time. When used

and cared for correctly this night vision‘scope

guarantees satisfactory operation for many

years.

Operating instructions

For use in daylight

Inserting the battery

Please ensure that the lens of your Night-

Vision scope is covered by the lens cap.

Remove the battery compartment lid and

insert the battery (1 CR 1/3 N). Always observe

correct poling. Fully close the battery com-

partment again.

Switching on

To protect the sensitive image tube against

irreparable damage, never remove the lens

cap in daylight. The small opening in the

center of the cap is adequately dimensioned

for daylight use.

Actuate the main switch.The green LED display

lights up. When you look through the eye-

piece you will see a bright, green, fluorescing

image.

Switching off

Actuate the main switch. When you look

through the eyepiece you will still see the

green image for a few minutes, before it dis-

appears. This is normal and not a fault, because

the Night-Vision scope always switches off

gradually.

For use at night

Switching on

Remove the lens cap. Actuate the main switch

and hold it down. The green LED lights up.

When you look through the eyepiece you will

see a green, fluorescing image.

Adjustment

Aim at an object situated at a distance of 20

to 30 m (22 to 33 yds). Turn the focusing ring

on the eyepiece to get a sharp image. Then

turn the front focusing ring to make the image

sharper still. Repeat this procedure if necessary.

Infrared illuminator

By actuating the button for the infrared illu-

minator in addition to the main power button

you can achieve a better imaging result in

inadequate light. Hold this switch down as

well to make the image appear brighter.

Switching off

As soon as you let go of the main power

button the device gradually switches off. You

will see the green image for a few more

minutes before it disappears. This function is

normal and is not a cause for a complaint.

Important note:

For longer battery service life we recommend

you not to leave the Night-Vision scope swit-

ched on continuously. It is better to switch it

off every now and again.

Safe keeping

Please protect the lens with the lens cover at

all times.

Important information

To avoid irreparable damage to your MINOX

night vision ‘scope, please always observe the

following instructions:

- Never remove the lens cover when using

the scope in daylight. The small opening in

the center of the cover is perfectly

adequate for using the device in daylight.

- Never disassemble the scope.

- Always insert the batteries as specified

and observe correct poling.

- Do not use an external power supply.

- Remove the batteries from the battery

compartment if the device is not being

used for a prolonged period.

- Always cover the lens with the lens cap

when not in use.

- Do not expose the device to direct sunlight.

- Do not keep the device under extremely low

or high temperatures.

- Do not keep the device in damp, dusty or

dirty areas.

- Keep the device safe from any external

influence.

- Never subject the device to knocks or

impact.

Advice on care

Protect the Night-Vision scope against falling,

damp, dirt and extreme temperatures. Protect

all optical surfaces against damp and abrasive

agents. These may otherwise damage the anti-

reflection coating.

Only remove dust and dirt from the lens using

a soft, dry cloth. For safety reasons please re-

move the batteries!
