Minebea CSD-891B Manuel utilisateur

DIGITAL INDICATOR

CSD-891B

Instruction Manual

EN294-1143-M

FOREWORD

Thank you very much for your purchasing our Digital Indicator CSD−891B.

This manual explains installation procedures and connecting method and also operating

method for the Digital Indicator CSD−891B. Make use of it properly after reading through

the manual carefully.

Be sure to deliver the manual to the end user. Moreover, the end user should keep the

manual at hand after reading it over.

Marks and arrangements used in this manual

The following marks are attached to the explanation on the matters that indicate “Don’t do

this.”, “Take care.” and “For reference”.

Be sure to read these items where these marks are attached.

Warning ●Warning may cause injury or accident that may harm to the operator.

Don’t do these things described here.

●Caution during operation and working.

Be sure to read the item to prevent malfunction.

Mark during operation.

●Press the switch.

III

For safe operation

Be sure to read this instruction manual before use.

1. Installation place

●Use the instrument where the temperature/humidity specifies with

the range as follows：

Environmental temperature ：−10 ℃to 50 ℃

Environmental humidity ：Less than 85 %R.H. (Non condensing)

(1) Location where installation is not allowed.

Warning ●Don’t locate the instrument on the places as follows :

It may cause an unexpected faulty in the instrument.

DDo not locate the instrument in direct and/or high temperature area.

DDo not use the instrument in a high humid area.

DDo not install the instrument where there are vibrations and shocks.

DDo not use the instrument where there is excess of dusts and fine particles.

DDo not use the instrument where there are corrosive gas and salt and like

that.

DDo not install the instrument where there is rapid change of temperature

and humidity.

DDo not install the instrument near the devices that are magnetized or

generate an electromagnetic field.

DDo not install the instrument where the instrument may be affected by

radioactivity or radial rays.

DAvoid the location where chemical reaction may take place such as in a

laboratory, or like that.

(2) Installation

●When installing the instrument, install as referring to the following

figures and secure the space around the instrument.

Each dimensions of the instrument and required dimensions for the environmental

spaces are as follows:

Outline dimensions

Front Side

Unit：mm

208

200

140.7

185

2. Power supply

Warning ●Be sure to check that the power supply is off in connecting each cable.

If the work is done while the power is on, there may have the case that

electric shock to the operator or even may have damage to the

instrument.

●Before supplying the power, check that the indication of power supply

voltage/specifications for the instrument and the power going to

supply should be the same.

If they are not equal, contact us.

If you use the instrument without checking them, it may cause a

damage in the instrument or electric shock to the operator.

●Earth wire should be grounded securely.

When earth wire is not connected, it may cause a malfunction of the

instrument or electric shock to the operator.

3. Application note

Warning ●Before using a new instrument or exchanging the strain gage applied

transducer for a new one, be sure to make calibration. If calibration

will not be made, the correct measuring results may not be obtained

nor which may cause malfunction in the instrument and there may

exist damage in peripheral equipments.

Besides, even though calibration has been made, there may occur the

similar case when the results are not correct, so make calibration,

again.

Warning ●In case of using the instrument, check that the connections are

executed properly. If not connected properly, the correct measuring

result will not be obtained, nor it may cause malfunctions of the

instrument, damage to the peripheral equipments or even more

serious accidents.

Warning ●When change of setting is made carelessly on the instrument during

measurement, correct measured results may not be obtained and it

may cause malfunction in the instrument and even have the

possibility of damage in peripheral instruments.

Warning ●Do not shock the instrument such as throwing something on it.

If neglected, it may cause destruction of the parts and damage to the

electrical circuits.

Warning ●Do not push the panel sheet on the instrument with the excessive

strong force nor push it with sharp edge object such as a driver.

If neglected, it may cause a damage to the panel switch and even have

the possibility of damage to resist to environments or operational

performances.

Warning ●Don’t remove the cover of the case of the instrument, nor peel off the

panel sheet nor take the instrument into pieces.

If neglected, it may cause a damage to the case and the panel sheet

and even have the possibility of damage to resist to environments or

operational performances.

●At the time of shipment from the factory, the instrument has been

plated with a clear sheet on the panel sheet for protective purpose.

In case of application, use the instrument after removing the

clearsheet first.

VII

History of revision

Date Instruction manual No. Details of revised point

Oct. 2001 DRW. NO.EN294−1143 Version ROM Ver. 1.000 or later

Jun. 2002 DRW. NO.EN294−1143-A

Due to ECN No.FN02−02066

−Change −

Wiring instruction seal affixation is changed right, and the

outline drawing is also changed.

−Additional −

8−2., 13−3. Add F−87

Sept. 2004 DRW. NO.EN294−1143-B

Due to ECN No.FN04−02111

−Change −

7−14. “The backup time is over ten years.” has

changed to “The backup time is about ten years.”

Apr. 2005 DRW. NO.EN294−1143-C

Due to ECN No.FN05−02035

−Addition −

At the warning column in the wiring section, the clause of “

As there is a case which standard wiring color is different,

please confirm the inspection data sheet of the load cell

being used.” is added.

Aug. 2005 DRW. NO.EN294−1143-D

Due to ECN No.FN05−02085

−Correction −

11−8. General specifications

Outline dimensions from “208 mm x 67 mm x 143 mm”

to “208 mm x 67 mm x 140.7 mm”

Jan. 2010 DRW.No.EN294-1143-E

Due to ECN No.FN10−02013

ROM Ver. 1.800 or later

−Addition −

8−2., 13−3. Add F−84

Feb. 2010 DRW.No.EN294-1143-F

Due to ECN No.FN10−02013A

−Addition −

8−2. F−84 “Restriction and warning” is added.

May. 2010 DRW.No.EN294-1143-G

Due to ECN No.FN10−02058B

−Addition −

7−3−1. Analog filter

7−7. Detection of stability

7−7−1. Range to detect stability

7−7−2. Time to detect stability

Due to ECN No.FN10−02026B

−Change −

Front cover logo is changed.

Oct. 2010 DRW.No.EN294-1143-H

Due to ECN No.FN10−02140

−Change −

MInebea logo is changed.

Date Instruction manual No. Details of revised point

Jan. 2011 DRW.No.EN294-1143-I

Due to ECN NO.FN11−02018

−Correction −

9−3−4.“DE−9S−N(JAE)”

to “DE−9S−NR by JAE or equivalent.”

May 2012 DRW.NO.EN294-1143-J Due to ECN No.FN10−02140−D

−Change −

MInebea logo is changed.

Aug. 2012 DRW.NO.EN294-1143-K

Due to ECN No.FN12−02115

ROM Ver. 2.000 or later

−Change −

7−9

”104digit：Optional BCD output”

to ”104digit：Optional output(BCD output, CC−Link load

output, RS−232C load output, RS−422/485 load output)”

−Addition −

7−9 Caution is added.

−Correction −

7−9

”Comparator S1, S2 open collector output”

to ”Comparator S1, S2, S3 and S4 open collector output”

Feb.2018 DRW.NO.EN294-1143-L Due to ECN FN17-02017

・Delete the company name in the cover page.

・Delete the company name in the contents.

Jul.2018 DRW.NO.EN294-1143-M

Due to ECN FN18-02079

−Change −

10-3 Error display

･Remedy BAT.L/ER−B

SHIFT/ENTER to CHECK/FUNC.
