MIMAKI UJF-7151plus Guide de configuration

Date: 13-12-2018

Version: 1.1EU

UJF-7151plus

PRODUCTION FLATBED LED UV PRINTER

PRINTING GUIDE

•The contents of this presentation are intended only for Mimaki authorized resellers.

Authorized persons are not permitted to distribute, copy or change this presentation

without explicit approval of Mimaki Europe B.V.

•Contents and technical explanations in this presentation are based on the test results

achieved at Mimaki at the time of testing and are not a guarantee for performance.

Substrates should be tested beforehand.

•

In addition, the contents in this presentation do not lead to any legal obligations from

Mimaki and Mimaki does not take any responsibility. Please verify in advance whether

your intended prints will result in sufficient quality.

•Contents of this presentation are subject to change without prior notice for

improvement. Compositors errors reserved.

AVAILABLE PRINT MODES

O：Available

△：Available, but not recommended

x：Not available

：Default print mode Notes

*1 It causes print mode error on the printer.

*2 Adhesion of the media and ink may not be sufficient.

*3 Not recommended for solid clear since MAPS4 does not work.

*4 Recommended only for undercoat printing.

*5 Undercoat mode is available only when LUS-120 ink is installed.

Print condition Printing method

Print mode Resolution Pass Print time

（full size）Color only White only Clear only Primer only Color

+White

Color

+ Clear

Color

+Primer

Undercoat*4

600x300 4pass 3m47s x *1 x*1 O*4 O*4 x*1 x*1) x*1

Draft

600x600

6pass 5m10s O O x *1 △*2 △*2 x *2 △*2

High speed 8pass 6m55s O O △*3 O O △*3 O

10pass 8m30s OOOOOOO

Standard

600x900

12pass 10m15s O O △*3 O O △*3 O

16pass 13m50s OOOOOOO

1200x1200

12pass 14m10s OOOOOOO

High quality 16pass 18m40s OOOOOOO

MAPS

•Use the MAPS* (Mimaki Advanced Pass System) function to disperse the

pass boundary to make the feeding stripes less visible

•MAPS4 can be switched to “AUTO” or “MANUAL” from printer’s

operation panel:

•Press the “MENU” key in local mode

•With arrow keys select “SETTING”, then press ENTER

•Select “MAPS4”

•Select “AUTO” or “MANUAL”

AUTO Uses the optimal gradation pattern depending on the print condition (Ink type, resolution, profile, etc..)

By default, print with “AUTO” setting should be always used.

MANUAL When there is a problem with the image quality with “AUTO” setting, adjust the gradation level of MAPS by

changing the “smoothing level” in “MANUAL” setting.

* When printing clear ink, MAPS4 does not work in 600x600dpi 8pass and 600x900dpi 12pass modes.

COLOR MATCHING FUNCTION

•Standard RasterLink6plus setting for printing with MkII series is set to “Mimaki Expand

Color”

•Setting conditions are:

•IllustrationColor Matching Method: Relative

•ImageColor matching Method: Relative

•Input profile(ICC)

•RGB：AdobeRGB1998

•CMYK：MimakiHiContrast*

•When printing thin lines or small fonts:

•It is recommended to enable “Pure K” for both

Illustration and Image on the color matching setting

•To create new color matching setting:

•RasterLink6Print Condition Color Matching

•Highlight and delete “Mimaki Expand Color” in Color Matching Window and input new name

•Click on and change the setting

•New setting will be active

*MimakiHiContrast works only with device profiles v3.5 or higher.

PRINTING CLEAR INK

•For printing clear use print modes above 600x600dpi 8pass

•Use recommended ink density settings for printing clear depending on

the substrate and the resolution

•Clear printings will have a better quality by using the optimum density

depending on the print condition

*1 It causes the print mode error on the printer.

*2 Undercoat mode is available only when LUS-120 ink is installed.

Notice on glossy clear print:

•If the density of clear ink is too high, regularly spaced stripes may appear on the printed surface.

Please lower clear density.

Notice on matte clear print

•If the density of clear ink is too, high irregular stripes or gloss may occur.

Please print with lower density.

Purpose Print condition Glossy finish Matte finish Profile

Normal

printing

Undercoat

printing Resolution Pass FOREX White

PET Lexan Acrylics Coated

boards

Any

media type

x O 600x300 4pass x*1 x*1 x*1 x*1 x*1 70% For printing undercoat

clear*2

O O 600x600

8pass 100% 80% 80% 80% 100% 60%

For printing color

10pass 100% 100% 100% 100% 100% 60%

O O 600x900

12pass 80% 80% 80% 80% 80% 60%

16pass 100% 100% 100% 100% 100% 60%

O O 1200x1200

12pass 100% 100% 100% 100% 100% 70%

16pass 100% 100% 100% 100% 100% 70%

O：Available

△：Available, but not recommended

x：Not available

PRINTING PRIMER INK

•When printing with 600x600dpi 6pass, the adhesion between ink and media may not

be sufficient.

•Please use print modes above 600x600dpi 8pass

•It is recommended to print Primer with 100% density from RasterLink6

•This setting will automatically adjust the density to the recommended print density

•If density is set to other value than 100%, the recommended print density will change

•E.g. setting “Primer” to 50% at 600x600dpi will set the recommended print density to 25%

•Recommended settings for 3rd party RIP

or resolution other than 600x600:

Resolution Recommended density

Combination with LH-100 Combination with LUS-120

600x300 x*1 70%

600x600 50% 40%

600x900 40% 30%

1200x1200 20% 20%

Printing with other than recommended density might cause the following issues

1. Primer density is set too high:

1. Hardness of the primer layer may decline

2. The primer layer might be scratched off

3. The primer layer might break when it is exposed to temperature

2. Primer density is set too low

1. Adhesion might become weak.

2. The primer layer might break when it is exposed to temperature

*1 It causes the print mode error on the printer.

•A Higher density white ink is available for following print modes:

To activate higher density white print:

1. RasterLink6Print Condition

2. Choose Tab “Print Quality”

3. Check option “Printing of the White-ink at higher density”

PRINTING WHITE INK

Example to lower the white ink density

1. RasterLink6Print Condition

2. Choose Tab “Color Adjust”

3. Input optional name and click to

4. In DensitySpecial ColorWhite lower the value

1. E.g. setting to -10% will set the

white print density to 90%

Print conditions High density printing

Print mode Resolution Pass Print time

（full table）High density white MAPS4 availability

when printing high density white Recommended density

Standard 600x900

12pass 10m15s O x *1 10 - 90% (*2)

16pass 13m50s O O All density

*1 MAPS4 is not available with 600x900 12pass high-density mode. It may cause banding and uneven color.

*2 Adhesion of the media and ink may not be sufficient when the density of white is higher than 90%.

UNDERCOAT PRINTING

•When printing directly on general acrylic substrates, Acrylite, Sumipex or

Plexiglas with LUS-120, the image quality may gets blurred

•By printing undercoat*1 with “primer” or “clear”, thin lines and small

fonts can be printed sharp without being blurry

•Comparison:

•Print speeds for undercoat print in standard mode

Print data LUS-120

w/o undercoat

LUS-120

w/ undercoat

LH-100

(Standard)

Lines & fonts x◎●

Pictures ●O●

Image quality

◎-Very good

O - Good

●- Standard

x -Not good

*1 Refer to recommended density setting of clear and primer for undercoat printing

Print mode

LUS-120 with primer

Speed[㎡/h] Print time per table

Draft 600x600, 6p, Uni, Hi 2.43 8m57s

High speed 600x600, 8p, Uni, Hi 2.04 10m42s

Standard 600x900, 12p, Uni, Hi 1.52 14m22s

High quality 1200x1200, 16p, Uni, Hi 0.97 22m27s

SETTING UNDERCOAT PRINTING: PRIMER

1. Create “Primer” layer by clicking on Color layer and then “Special Plate”

1. Set the Special Color condition

I. Ink: Primer

II. Primer: 100%

III. Created Area: choose one of options

IV. Click on Create

2. Set print condition for Special Plate

1. Select created Special Plate

I. Click to Print Condition Tab

II. Set Media: For base primer print

III. Resolution: 600x300dpi

IV. Pass: 4

2. Create “Color + White” by clicking on Color layer and then “Special Plate”

1. Set the Special Color condition

I. Ink: White

II. White: Set optional density

III. Created Area: choose one of options

IV. Check “Composite automatically”

V. Click on Create

3. Print “Primer” and then “Color +White” Plate

III
