Milltronics MultiRanger Plus Manuel utilisateur

MULTIRANGER

PLUS

PROGRAMMABLE

LEVEL SYSTEM

Instruction Manual

PL-443

June 1995

33454430

PRR 1.1

Table of Contents

General Information

Important 1 - 1

MultiRanger Plus 1 - 1

Specifications

MultiRanger Plus 2 - 1

Programmer 2 - 2

Transducer 2 - 2

Temperature Sensor 2 - 2

Current Output Isolator 2 - 2

Cabling 2 - 2

Installation

Multiranger Plus 3 - 1

Outline and Mounting 3 - 1

Circuit Board Layout 3 - 2

Interconnection 3 - 3

Installing the Transducer 3 - 3

Selecting Temperature Source 3 - 4

Current Output 3 - 4

Current Output Isolator 3 - 5

Synchronization 3 - 6

Power Connections 3 - 7

Programmer 3 - 8

Start Up

General 4 - 1

Programmer Keypad Run Mode 4 - 2

Program Mode 4 - 3

Legend 4 - 4

Parameter Entry 4 - 4

Common Display Messages 4 - 6

PL-443 i

Functional

Transceiver 5 - 1

Damping and Process Rate 5 - 1

Temperature Compensation 5 - 2

Sound Velocity 5 - 2

Blanking 5 - 3

Agitator Discrimination 5 - 4

Relays General 5 - 4

Function

Alarm 5 - 5

Pump 5 - 6

Miscellaneous 5 - 7

Analog Output 5 - 10

Applications 6 - 1

Simple Level Application 6 - 2

Pump Control Applications 6 - 4

Pump Run-On 6 - 8

Pump Totalizer Application 6 - 10

Volume Application 6 - 14

Common Tank Shapes 6 - 15

Custom Design Tanks 6 - 16

Compensation 6 - 19

Differential Level Application 6 - 22

OCM Applications 6 - 26

Single Exponential 6 - 33

Palmer-Bowlus 6 - 37

H Flumes 6 - 38

Other 6 - 39

Applications with Standpipes 6 - 42

PL-443 ii

Parameter Description

Parameters 7 - 1

Troubleshooting

General 8 - 1

Oscilloscope 8 - 1

Troubleshooting Guide 8 - 3

Maintenance

Maintenance 9 - 1

Appendices

Sound Velocities 10 - 1

Glossary 10 - 2

Alphabetical Parameter Listing 10 - 4

■

PL-443 iii

GENERAL INFORMATION

IMPORTANT

First and foremost it is essential that this manual be read and understood before

installation and start up of the MultiRanger Plus.

"Applications" provides a general description of the common applications found in

industry and illustrates them with examples. It is suggested that you refer to the

sub-section which most suits your application. The programming of the MultiRanger

Plus can be optimized by referring to Parameter Description or Appendices \

Alphabetical Parameter Listing.

THE MULTIRANGER PLUS

The MultiRanger Plus is a multi-purpose level monitoring system consisting

of a MultiRanger Plus in a CSA type 4 enclosure, a programmer and an

ultrasonic transducer.

The MultiRanger Plus emits an ultrasonic pulse via the transducer. The echo is

reflected from the material and received by the transducer. The echo is processed by

the MultiRanger Plus and the time at which the ultrasonic pulse hits the level or target

is extracted and compared to the time at which it was sent. The time differential is

then converted into distance, material level, volume, flow or differential level as a

basis for display, relay control, analog output and totalling.

As well as simple level measurement, the MultiRanger Plus was designed to handle

specific applications such as: pumped volume totalling, differential level and open

channel flow measurement.

■

PL-443 1 – 1

SPECIFICATIONS

MULTIRANGER PLUS

Power: » 100/115/200/230 V ±15%, stab selective

» 50/60 Hz, 15 VA

» optional: » 12 V dc model, 10 to 18 V dc

» 24 V dc model, 18 to 36 V dc

Fuse: » 1/4 amp MDL Slo-Blo or equivalent

Range: » 0.3 to 15 m (1 to 50 ft)

Accuracy: » 0.25% of range or 6 mm (0.24"), whichever is greater

Resolution: » 0.1% of range or 2 mm (0.08"), whichever is greater

Memory: » EEPROM (non-volatile) no back-up battery required

Display: » Liquid Crystal Display of 4 digits, 18mm (0.7") high

Operating Temperature: » – 20 to 60 °C (– 5 to 140 °F)

Outputs: transducer drive: » 41 KHz, 400 V peak pulses of 1 msec

max duration at a max

repetition rate of 300 msec

analog: » 0 - 20 or 4 - 20 mA

» max loading: » 350 ohms, return to ground

» 750 ohms, return to –12 V

» resolution: 0.1% of range

» optional mA isolator

relays: » 5 multipurpose relays (for alarms, pump control,...)

» 1 Form "C" SPDT contact per relay, rated 5 A at

220 V ac non-inductive

» adjustable deadband

All relays are certified for use in equipment where the short

circuit capacity of the circuits in which they are connected is

limited by fuses having ratings not exceeding the rating of the relays.

Enclosure: » CSA enclosure type 4 (similar to NEMA 4)

» 160 mm W x 250 mm H x 82 mm D

(6.3" W x 9.5"H x 3.2"D)

» polycarbonate

Approvals: » CE

Weight » 1.8 kg (4lb)

96/01/22

PL-443 2 – 1

PROGRAMMER

Enclosure: » general purpose

» 67 mm W x 100 mm H x 25mm D

(2.6" W x 4" H x 1" D)

» ABS plastic

Operating Temperature: » – 20 to 50 °C (– 5 to 122 °F)

Power: » 9 V battery (style - ANSI/NEDA 1604)

TRANSDUCER

Refer to associated Transducer manual.

TEMPERATURE SENSOR

Refer to associated Temperature Sensor manual

CURRENT OUTPUT ISOLATOR (Optional, refer to PL-293)

Model: » LIs-1 loop isolator

Input: » 4 - 20 mA dc (from MultiRanger Plus)

Output: » 4 - 20 mA dc into 600 ohm max

Isolation: » 300 V ac continuous

Common Mode Rejection » 100 dB at 60Hz

CABLING

Optional: » RG-62A/U coax

» max distance to electronics: 365 m (1200 ft)

» must be run in grounded metal conduit

Temperature Sensor: » Belden 8760, 2 wire shielded

» max distance to electronics: 365 m (1200 ft)

» can be run with transducer cable

■

PL-443 2 – 2
