Requirements that the product meets
EMC: EMC Directive 2014 / 30EU
Electricity: Low voltage directive: 2014/35 / EU
EN 60950-1
CE: CE directive according to: 765/2008
Emission: EN61000-6-: 2001 EN55022: 1998: -A1: 2000, A2: 2003 Klass B, EN61000-3-2: 2001
Immunity: EN61000-6-2: 2005, EN61000-4-2, -3, 4, -5, -6, -11
SS-EN 50 130-4: 2011 Edition 2, EN50131-6
Environment REACH Regulation: Directive 1907/2006, WEEE Regulation: Directive 20021961E, RoHS Regulation: Directive
2015/863
SPARE OPERATING TIMES, POWER OUTLET AND LOAD OUTPUT POWER
Charging current for batteries and battery capacity
The unit reads the connected system load and charges the batteries with available residual current
from the power supply. The device performs qualified* battery tests and notifies when batteries need
to be replaced. The batteries are charged gently to extend their life and protection is available against
overcharging.
12 V / 24 V Maximum charging current for batteries
NOVA FLX M 6 A
The battery backup has controlled charging ** (controlled charging) which prevents batteries from being
overcharged and extends their service life significantly. The NOVA series must be used with AGM
batteries.
Battery capacity in 24 V units
24 V Battery ca-
pacity Maximum battery
capacity with 1
battery box
Maximum battery ca-
pacity with 2 battery
boxes
Maximum battery ca-
pacity with 3 battery
boxes
Maximum battery ca-
pacity with 4 battery
boxes
NOVA
FLX M,
24 V
20 Ah (2 x
20 Ah 65 Ah (4 x 20 Ah) 110 Ah (2 x 20 Ah + 2 x
45 Ah) 155 Ah (6 x 20 Ah + 2 x
45 Ah) 200 Ah (2 x 20 Ah + 8 x
45 Ah)
* Battery test is done with power resistor and the unit is tested and certified together with UPLUS 10+ Design life AGM batteries according
to SSF1014. It is these batteries that must be used to maintain the certificate.
** Controlled charging means that when the batteries are fully charged, they will be disconnected electronically for standby mode for up to
20 days or when the batteries have reached 26.7 V (24 V). By discharging the batteries and charging them continuously (instead of never
using them), the system extends the battery life by up to 50%. The batteries connect automatically in less than 50 microseconds.
Power outlet
Unit without
battery box Unit with
1 battery box
Unit with
2 battery boxes
Unit with
3 battery boxes
Unit with
4 battery boxes
Battery 2 pcs. 20 Ah 2 st 45 Ah /
2 st 20 Ah +
2 st 45 Ah
4 st 45 Ah /
2 st 20 Ah +
4 st 45 Ah
6 st 45 Ah /
2 st 20 Ah +
6 st 45 Ah
8 st 45 Ah /
2 st 20 Ah +
8 st 45 Ah
Max battery capacity 20 Ah 45 Ah / 65 Ah 90 Ah / 110 Ah 135 Ah / 155 Ah 180 Ah / 200 Ah
According to.
SSF1014, Alarm Class
1-2
1.6 A 3.7 A / 5.3 A 7.4 A / 9.1 A 11.2 A / 12.8 A 14.9 A / 16.6 A
According to.
SSF1014, Alarm Class
3-4
0.65 A 1.5 A / 2.1 A 3.0 A / 3.6 A 4.5 A / 5.1 A 6.0 A / 6.6 A
Imax A (max discharge
current) 5 A 5 A / 5 A 5 A / 5 A 5 A / 5 A 5 A / 5 A
2022-10-11
