Milesight VS132 Manuel utilisateur
VS132
All software & files can be downloaded from
https://www.milesight-iot.com/documents-download/
Cloud App Quick Start Guide
Milesight IoT Co., Ltd. www.milesight-iot.com 3D ToF People Counting Sensor
Featuring LoRaWAN®
Table of Contents
1.Packing List………………………………………………………………………………..........................
2.Hardware Introduction………………………………………………………………………………………..
3.Installation………………………………………………………………….......................................
4.Power Supply…………………………………………....................................................……
5.Access from Web Browser……………………...………...........................................…
2
2
3
5
6
11
www.milesight-iot.com
www.milesight-iot.com www.milesight-iot.com
1. Packing List
2. Hardware Introduction
Please check the package contents to verify that you have received the items below.
Since the detection range is 0.5m to 3m, the maximum installation height should be 3m and
the minimal installation height should always be 0.5m higher than the object.
Monitored areas for people counting at different heights:
3. Installation
12 131 2 13
Recommended Height
If any of the above items is missing or damaged, please contact your sales
representative.
1 × Warranty Card1 × Quick Start Guide4 × Wall Mounting Kits
1 × VS132 Sensor 1 × DC Power Adapter 2 × Ear Mounting Kits
Ethernet Port（PoE）
DC Power Interface
Threaded Hole（UNC 1/4-20）
5.01 × 3.18
5.22 × 3.31
5.43 × 3.44
5.64 × 3.57
5.85 × 3.71
6.06 × 3.84
6.27 × 3.97
2.4
2.5
2.6
2.7
2.8
2.9
3.0
Height (m) Monitored Area (m)
max 3.0m
min object height + 0.5 m
www.milesight-iot.com www.milesight-iot.com
4. Power Supply
1. Fix the two mounting ears to both side of the device with screws.
2. Drill 4 holes on the ceiling or wall according to the mounting ear’s hole and fix the wall
plugs into the holes, then fix the device to the wall plugs with mounting screws. When
installing the device, it’s suggested to fix the two screws on the top at first.
Besides, this device can be mounted with the mounting stand via the threaded hole.
VS132 can be powered by 802.3at standard PoE or DC power adapter. Choose one of the
following methods to power up the device:
Make sure the detection part of sensor is facing straight down and in line with the
ceiling.
Avoid strong light, like direct sunlight or IR LED, in the detection area.
Do not install the sensor close to glass or mirror.
Whenthesensorismountedonthewall,ensurethedetectionpartofthesensoris
horizontallyclosetothelintelofthedoor.
Installation Notes
1 4
Installation Steps Top-Lintel Mount at Entrance
5
Ceiling Mount
Embedded Mount
Powered by DC Power Adapter
www.milesight-iot.com www.milesight-iot.com
5. Access from Web Browser
VS132 sensor provides user-friendly web GUI for configuration and users can
access it via Wi-Fi connection or Ethernet port. Users need to set the
password when using the device for the first time. The default settings are
as below:
Here are 2 ways of accessing the web GUI:
Wireless Mode: Enable the Wireless Network Connection on your computer,
search for corresponding Wi-Fi SSID to connect it, then type 192.168.1.1 to
access the web GUI.
Wired Mode: Connect the device to computer via Ethernet port, assign the IP
address of computer to 192.168.5.xxx manually, then type 192.168.5.220 to
access the web GUI.
Wi-Fi SSID: People Counter_xxxxxx (can be found on the label)
Wi-Fi IP: 192.168.1.1
ETH IP: 192.168.5.220
1 6 17
Powered by a PoE Switch
Powered by a PoE Injector
DC Power Adapter
VS132
PoE Switch
Ethernet Cable
Ethernet Cable Power Cable
VS132
VS132 PoE Injector
www.milesight-iot.com
1 8
VS132
Thank you
for choosing
Milesight Product
Milesight IoT Co., Ltd.
Building C09, Software Park Phase III,
Xiamen 361024, Fujian, China
200g铜版纸+80g双胶纸
VS132_英文版
120x85mm
封面覆哑膜（翻页版）
V1.0
客 户
编 码
机 型
材 质
尺 寸
工 艺
版 本
VS132 Datasheet
Features
Up to 99.5% accuracy basing on advanced 3D Time-of-Flight technology
Obtain depth map without images capturing, free from privacy concerns
Effective in low-light or complete darkness environments
Bi-directional Counting
Able to store locally one million data records
DC or PoE power supply optional
Exquisite design for multiple installation scenarios
Equipped with Wi-Fi and Ethernet port for web GUI configuration
Acquire people counting data either from LoRaWAN®or Ethernet port (CGI)
VS132
3D ToF People
Counting Sensor
VS132 is a LoRaWAN®3D ToF people counting sensor designed to count
the number of people entering and exiting. Applied the most advanced
Time-of-Flight technology, VS132 only obtains depth maps instead of
images to protect privacy and provide a high level of accuracy up to 99.5%.
Cooperating with Milesight LoRaWAN®gateway and the Milesight IoT
Cloud solution, it allows users to monitor the flow of people and trigger
linkage to control other devices via browser or mobile App remotely.
With easy installation, VS132 has great use in entrances or corridors of
retail stores, malls, offices, subways, etc.
F e a t u r i n g L o R a W A N ®
VS132 Datasheet
Function well with standard LoRaWAN®gateways and network servers
Quick and easy management with Milesight IoT Cloud
Applications
Offices and meeting rooms occupancy monitoring
Customer flow analysis on stores and shopping malls
Passenger flow analysis on buses or subways
Specifications
Wireless Transmission
Protocol
LoRaWAN®
Frequency
CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4
Max Tx Power
22 dBm (915 MHz)
Sensitivity
-137 dBm @300bps
Mode
OTAA/ABP Class C
People Counting
ToF FoV
92.5 ° Horizontal, 67 ° Vertical
Detection Range
0.5 to 3m
Installation Height
≤ 3m
Accuracy
>99.5%
Local Storage
1, 000, 000 data records
Advanced Setting
Entrance and exit area customization
Interface
Wi-Fi
IEEE 802.11 b/g/n, 2.4GHz, only support configuration
Ethernet Port
1 × RJ45 10/100 Mbps Ethernet Port (PoE PD), provides CGI for
integration
Power Input
2-pin 5.08 mm Terminal Block
Physical Characteristics
Power Supply
1. 12 VDC, 2A by Terminal Block
2. 1 × 802.3 at PoE input
Power Consumption
Typical 7.5 W, max 28 W
Operating
Temperature
-10°C ~ +60°C
Storage Temperature
-20°C ~ +60°C
VS132 Datasheet
Relative Humidity
0 ~ 95% (Non-condensing)
Color & Material
Black, Aluminum Alloy
Dimension
140 × 50 × 50 mm (5.51 × 1.97 × 1.97 in)
Installation
Ceiling Mounting, Wall Mounting, Embedded Mounting
Monitored Area
VS132 is engineered for bi-direction entrances or corridors. Since the detection range is 0.5m to
3m, the maximum installation height should be 3m and the minimal installation height should
always be 0.5m higher than the object.
Installation Height (m)
Monitored Area (m)
2.4
5.01 × 3.18
2.5
5.22 × 3.31
2.6
5.43 × 3.44
2.7
5.64 × 3.57
2.8
5.85 × 3.71
2.9
6.06 × 3.84
3.0
6.27 × 3.97
