Miiego AXTIVE MIINI Manuel utilisateur
Quick Start Guide
DK
NOR
ENG 1 - 2
3 - 4
5 - 6
SE
DE
7 - 8
9 - 10
AXTIVE MIINI
WIRELESS SPEAKER
ENG
16
2
3
5
7
8
9
4
SPECIFICATIONS
CARE, MAINTENANCE, SAFETY
1
This device contains a lithium accumulator.
Improper use can cause overheating and fire.
45
67
1
28
9
3
Hanger
Power button: power on/off, playing mode
button, soft reset.
Play button: play, pause, answer call, TWS.
- Volume Down / Previous Song
Press once / Hold
+ Volume Up / Next Song
Press once / Hold
Charging port
LED indicator for
charging
LED Bluetooth indicator
Microphone
Any modification of the product may have consequences for safety, warranty
and proper functioning. Keep out of reach for children and animals. Product
storage and working temperature: from -10 celsius degrees to +40. Do not
expose the product to direct sunlight, heat or naked flames as it may cause
damage or explosion. Do not use the product if a part is damaged or defective.
Replace a damaged or defective device immediately. Disconnect the product
from the electrical outlet and other equipment if problems occur. Do not
charge when the product is wet. Do not leave a battery on prolonged charge
when not in use. Do not dismantle, open or shred batteries. Do not drop the
product and avoid bumping. This product may only be serviced by a qualified
technician for maintenance to reduce the risk of electric shock etc.
Bluetooth v5.0 - Wireless transmission range up to 10-15 m. without
obstacles. Rechargeable 800 mAh Li-ion battery. Full charging time:
around 2.5 hours. IPX5. BT frequency range: 2402-2480MHz. Freq.
Response: 90Hz-20 KHz. Charging input power: 5V DC/1A. RMS audio
output: 3W. Impedance: 4Ω.
ENG
2
Pairing your AXTIVE MIINI MIIEGO® Bluetooth speaker
1: Make sure the speaker is charged and turned OFF.
2: Press and hold the button for 3 seconds until the indicator light
flashes WHITE (pairing mode).
3: Activate Bluetooth on your phone or other device and search for new
Bluetooth device and select: MIIEGO AXTIVE MIINI.
When AXTIVE MIINI is connected the WHITE LED light is constantly on.
The speaker will remember your phone/device and automatically
reconnect the next time you turn it on.
An unpaired speaker will automatically turn off after 6 minutes.
Charging the AXTIVE MIINI speaker
Use a 5V/1A USB adapter for charging.
During charging the red right is on. When fully charged the red light is
off.
Full charging time is around 2.5 hours with 1A.
Next time charging
When you hear a warning tone every 180 seconds, the battery status is
low and needs charging.
Turning Your AXTIVE MIINI On and Off
ON: Press the Button for 3 seconds until a tone is heard.
OFF: Press the Button until a tone is heard.
Activate Siri on iOS-device: Double press the PLAY button (works only in
Bluetooth mode).
Pairing and connecting 2 x AXTIVE MIINI speakers with TWS
TWS only works when connecting two AXTIVE MIINIs by MIIEGO® together.
1: Turn on both speakers (Bluetooth mode). Make sure they are unconnected. 2: Press and
hold the PLAY button on one speaker for 2 seconds. The product emits a tone to indicate
entering TWS-pairing mode.
3: The product emits three tones and the LED indicator light (8) will be constantly on. This is
then the slave speaker. LED indicator light on master speaker will flash to indicate successful
TWS-pairing.
4: Activate Bluetooth on your phone/device and connect with the master speaker.
www.MIIEGO.com
To prevent possible hearing damage, do not listen
at high volume levels for long periods.
.
Model No.: AXTIVE MIINI
Designed in Denmark.
Produced in China.
Miiego A/S
Lejrvejen 4
6330 Padborg
Denmark
tel: +45 70 277 887
e-mail: [email protected]
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
