Miele KM 451 Manuel utilisateur

Installation instructions

Ceramic Cooktop

KM 451

To prevent accidents

and machine damage,

read the Operating Manual

before installation or use.

M.-Nr. 05 361 940

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety distance above the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Appliance dimensions and countertop cut out . . . . . . . . . . . . . . . . . . . . . . . . . 6

KM 451. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the spring clips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Granite countertops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the cooktop. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Contents

Note to the installer:

Please leave this instruction book

with the consumer for the local

electrical inspector’s use.

The minimum distances given in

these Installation Instructions must

be observed in order to ensure safe

operation. Failure to do so increases

the risk of fire.

The cabinetry and venting hood

should be installed first, to prevent

damage to the cooktop.

The countertop must be bonded

with heat resistant (212 °F/100 °C)

adhesive to prevent distortion or

dissolving.

The cooktop can only be installed

as shown in the illustrations, while

maintaining the required safety

distances shown. Do not install the

cooktop between two tall cabinets, this

is a fire hazard.

aA minimum distance of 2"

(50 mm) from the cooktop to the rear

wall and a side wall or cabinet must

be maintained for safety reasons.

To eliminate the risk of burns or fire

by reaching over heated surfaces,

cabinet storage space above the

cooktop should be avoided. If cabinet

storage is necessary, the risk can be

reduced by installing a venting hood to

project horizontally a minimum of 5"

(127 mm) beyond the bottom of the

cabinets.

recommended

not recommended.

not allowed

IMPORTANT SAFETY INSTRUCTIONS

50mm

2 ”

This equipment has not been

designed for maritime use or for

use in mobile installations such as

aircraft or recreational vehicles.

However, under certain circumstances

it may be possible for installation in

these applications. Please contact the

nearest Miele Dealer or the Miele

Technical Service Department with

specific requirements.

Because of the heat radiated

downwards from this type of

appliance we do not recommend

installing it over a drawer. It should be

installed in a cabinet base unit with a

dummy drawer front and an additional

protective barrier beneath the unit.

If, in spite of this, there is a drawer

directly underneath the cooktop, do not

store aerosols, combustible liquids or

easily flammable materials in it. If

cutlery inserts are placed in the drawer,

they must be heat resistant.

The cooktop must not be installed

over a dishwasher, washer, dryer,

refrigerator or freezer. The high

temperatures radiating downwards from

this type of cooktop could damage

these appliances.

Make sure that the power cord to

the cooktop does not come in

contact with any mechanical parts once

the cooktop has been installed.

Safety distance above the

appliance

As a general rule there must be a safety

distance of at least 30" (760 mm), b,

between the appliance and any

flammable objects above it, e.g.

cabinetry, venting hood or utensil rail.

The minimum distance of combustible

surfaces located above and to the side

of the cooktop, c, is 18" (457 mm).

If the manufacturer of these items

states a different figure, follow that

manufacturer’s recommendation.

If more than one appliance is

installed beneath a venting hood,

e.g. an electric cooktop and a gas

wok cooktop, and they have different

minimum safety distances to the

hood, select the larger safety

distance of the two.

IMPORTANT SAFETY INSTRUCTIONS

KM 451

aSpring clips

^Make the countertop cut-out following

the dimensions given in the

illustration.

^Remember to maintain a minimum

distance of 2" (50) mm between all

walls surrounding the cooktop. See

also "Important Safety instructions".

bThere must be at least 3 1/4" (83 mm)

of usable depth to the right hand

side of the cut out.

^Seal the cut surfaces with a suitable

sealant to avoid swelling caused by

moisture. Be sure the materials used

are heat resistant.

If, during installation, the seal around

the frame does not sit flush with the

countertop or the corners, the

corner radius max. R4 (3/16") can be

carefully filed down to fit.

Appliance dimensions and countertop cut out

(930mm)

(83mm)

(916mm)

(500mm)

(514mm)

max. R4

(min.50)

(8mm)

(58mm)

1116

416

116

516

416

Installing the spring clips

^Fix the supplied spring clips, a, at

the marked positions as shown

above, by laying them on the upper

edge of the cut-out and then

securing them with the 3.5 x 25 mm

screws supplied.

Granite countertops

For granite countertops, the spring

clips, a, must be placed in position

and secured with strong, double-sided

adhesive tape. In addition coat the

edges of the spring clips with silicone

sealant.

The screws are not needed for granite

countertops.

Installation

(75mm)

3 ”

Installing the cooktop

^Feed the power cord down through

the cut-out and connect the

appliance to the power supply.

^Position the cooktop on the spring

clips, a.

^Then with a hand on each side of the

cooktop press down on the edges

evenly until it clicks into position.

When doing so make sure that the

cooktop seal sits tightly on the

countertop to ensure a correct seal is

provided.

The cooktop can now only be

removed with a special tool.

The cooktop must not be

permanently sealed into the

countertop when installed. The

sealing strip under the edge of the

top part of the cooktop provides a

sufficient seal for the countertop.

If the cooktop is sealed into position,

the countertop or appliance could be

damaged if the cooktop needs to be

removed for maintenance or service.

Installation

Caution:

All electrical work should be

performed by a qualified electrician

in accordance with local and

national codes.

Disconnect the appliance from the

main power supply before servicing.

To reduce the risk of electric shock,

make sure that the appliance is

properly grounded after installation.

Power supply

Please check the data plate for

240 VAC, 60 Hz,

208 VAC, 60 Hz

and make sure your electrical supply

matches the data plate.

WARNING:

THIS APPLIANCE MUST BE

GROUNDED

The appliance is provided with 3 leads;

L1 (black), L2 (red) and GND (green).

They must be connected to a

dedicated line through the use of an

approved junction box.

For further information, see the wiring

diagram provided with the appliance.

Note to the installer:

Please leave these instructions with

the consumer.

Electrical connection
