Midtronics EBT-965P Manuel utilisateur

www.midtronicseurope.com

EBT-965P

For testing 12-volt automotive batteries

User Manual

EBT-965P

Battery & System

Analyzer

DEC 2019

167-000878EN-B

blank page behind cover

www.midtronicseurope.com

EBT-965P

Contents

1: Introduction 5

Personal Precautions 5

Symbols Conventions 5

Description 5

Consent to Collection and Use of Data: 5

Controls & Connections 6

Main Menu 6

Initial Power Up 7

Inspecting the Battery 7

Testing Out-of-Vehicle 7

Testing In-Vehicle 8

Connecting To A Battery 8

Setting User Preferences 8

2 – Car 9

Battery Test 9

Battery Test Results 10

System Test 11

3 – New Battery Test 12

Battery Test 12

4 – History 14

5 – Messages 15

Accessing Messages 15

Message Types 15

6 – Settings 16

Tool 16

Display 16

Date & Time 16

Print Format 16

Email Format 16

Work Order 17

System Test 17

Version 17

Check For Updates 17

Shop Settings 17

Admin 17

Shop Info 18

Users 18

Network 19

WiFi 19

7 – Maintenance & Troubleshooting 20

Tester Cables 20

Cleaning Clamps 20

Handling Test Cables 20

Storing Test Cables 20

Testing The Cable Set 20

Midtronics EMEA. Hoofdveste 6--8, 3992 DG Houten, The Netherlands

EBT-965P

Test Procedure 20

Connecting The Battery Test Cable 21

Printer Paper 22

Replacing The Paper Roll 22

Printer Problems 23

The internal printer will not print 23

Display Problems 23

The display does not turn on: 23

The display ickers or is dim: 23

Internal Batteries 23

Replacing The Internal Batteries 24

Appendix: Recommended Test Procedure 25

Appendix B:Test Results Decision Tables 26

Battery Test Results 26

Starter Test Results 27

Diode Test Results 28

www.midtronicseurope.com

1: Introduction

EBT-965P

1: Introduction

Personal Precautions

Risk of explosive gases. Never

smoke or allow a spark or ame

in the vicinity of a battery.

Batteries can produce a highly

explosive mix of hydrogen gas and

oxygen, even when the battery is not

in operation. Always work in a well-

ventilated area.

Wash hands after handling.

REQUIRED BY CALIFORNIA PROP. 65:

Battery

posts, terminals, and related accessories contain

lead and lead compounds, chemicals known to

the state of California to cause cancer and birth

defects or other reproductive harm.

Inspect the battery for damage and check the electrolyte level. If the electrolyte level is too

low, replenish it and fully charge the battery. Always use the necessary safety precautions when

working with batteries to prevent severe injury or death. Follow all manufacturers’ instructions

and BCI (Battery Council International) safety recommendations, which include the following

precautions:

9Battery acid is highly corrosive. If acid enters your eyes, immediately ush them thoroughly

with cold running water for at least 15 minutes and seek medical attention. If battery acid

gets on your skin or clothing, wash immediately with a mixture of water and baking soda.

9Always wear proper safety glasses or face shield when working with or around batteries.

9Keep hair, hands, and clothing as well as the analyzer cords and cables away from moving

engine parts.

9Remove any jewelry or watches before you start servicing the battery.

9Use caution when working with metallic tools to prevent sparks or short circuits.

9Never lean over a battery when testing, charging, or jump starting.

Symbols Conventions Description

Symbol Description

!The safety symbol indicates

instructions for avoiding hazardous

conditions and personal injury.

The safety symbol with the

words CAUTION, WARNING, or

DANGER indicates instructions for

avoiding hazardous conditions and

personal injury.

The wrench symbol indicates

procedural notes and helpful

information.

The analyzer uses function-specic applications

accessed through a series of menus and icons

to guide users through the battery testing

process for consistent testing implementation

and accuracy. These are accessed using the

tester’s touch screen display. Test results can

be displayed on the full-color screen, printed,

or wirelessly emailed.

Consent to Collection and Use of Data:

The user of this tool consents that Midtronics may collect, store, transmit, and use technical data

and related information, including but not limited to technical information about this device,

system and application software, test results, and accessories. This inforamtion is gathered

periodically to facilitate the provision of product support, product improvements, product

development, and other services related to use of this battery and electrical system analyzer. The

technical data and related information is in a form that does not personally identify the user.

Midtronics EMEA. Hoofdveste 6--8, 3992 DG Houten, The Netherlands

1: Introduction EBT-965P

Controls & Connections











Display Screen

Cooling Vent

Arrow Key & Power Button

Mini-USB Port

Thermal Printer

Temperature Sensor



Main Menu

12.74V EBT-965P

Car New Baery History

Messages Sengs

Version



Menu Bar

12.74V Battery Voltage

(if connected) WiFi signal strength

Bluetooth connectivity

status Controller internal battery status

Main Menu Selection Area

 When displayed, the Screen Arrows show which ARROW key on the keypad to press to

display other icons or screens. When displayed under a list of options, the Screen Arrows

show which keypad arrow to press to highlight a character or item in a list.

Additional Screens

The dots at the bottom or side of a menu or results screen indicate additional screens are available,

 Screen 1

 Screen 2

 Screen 3

Press or 



Screen 1

Press or 



Screen 2

www.midtronicseurope.com

1: Introduction

EBT-965P

Main Menu Icons

Icon Description

Car

For testing in- and out-of-vehicle batteries for possible return.

New Baery

Test

Perform a battery test on a new 12V battery in the vehicle.

History

Access archived test histories or search test history by technician.

Messages

Displays alerts and notications for upcoming tests and activities including scheduled

tests, tool software updates and maintenance opportunities.

Sengs

Setup/adjust: WiFi, printer setup,

email settings, user information, default language,

display and sound settings, shop information, and connected devices.

Version

Displays information regarding the version of the software.

Initial Power Up

When powered up for the rst time, the tester will take approximately 8 to 10 seconds to

boot up while testing the integrity of the internal software.

Test Preparation

Inspecting the Battery

Before starting the test visually inspect the battery for:

•Cracked, buckled, or leaking case. If you see any of these defects, replace the battery.

•Corroded, loose, or damaged cables and connections. Repair or replace them as needed.

•Corrosion on the battery terminals, and dirt or acid on the case top. Clean the case and termi-

nals using a wire brush and a mixture of water and baking soda.

•Low electrolyte level. If the electrolyte level is too low, add distilled water to ll up to ½ above

the top of the plates and fully charge the battery. Do not overll.

•Corroded or loose battery tray and hold-down xture. Tighten or replace as needed.

Testing Out-of-Vehicle

The preferred battery test location is In-Vehicle. However, for testing Out-Of-Vehicle:

•Always disconnect the negative cable from the battery rst and reconnect it last.

•Always use a carry tool or strap to lift and transport the battery.

Midtronics EMEA. Hoofdveste 6--8, 3992 DG Houten, The Netherlands

1: Introduction EBT-965P

Failure to properly install lead terminal adapters,

or using adapters that are dirty or worn, may

cause false test results.

When testing side-post or Group 31 batteries, always use

lead terminal adapters provided with the tester—do not

test at the battery’s steel bolts. To avoid damage, never use

a wrench to tighten the adapters more than ¼ turn.

Testing In-Vehicle

The preferred test position is at the battery posts. If you must test at a remote-post location, it

should have both a positive and negative post. Otherwise, you must remove the battery and

perform an out-of-vehicle test.

At the start of the test, make sure all vehicle accessory loads are o, the key is not in the ignition,

and the doors are closed.

Connecting To A Battery

Do not connect the tester to a voltage source

greater than 30 Vdc.

Connect the clamps to the tester: the red clamp to the positive (+) terminal and the black clamp to

the negative (–) terminal. If the clamps are reversed when connected, the tester displays CLAMPS

REVERSED! Reconnect the clamps.

Make sure both sides of the clamps are gripping the terminals by rocking each clamp back and

forth. A poor connection will prevent testing, and the tester will display a CHECK CONNECTION

message. If the message reappears after reconnecting, clean the terminals and reconnect.

Setting User Preferences

Customize the analyzer by setting preferences in the Settings ( ) Menu, described in Chapter 7.

www.midtronicseurope.com

2 – Car

EBT-965P

2 – Car

Car

Use Car Test to test and verify the condition of customer batteries that are in-

or out-of-vehicle for possible return and/or warranty claim. Press  to

return to the previous screen, select options and when necessary, to enter or

continue to the next step.

Battery Test

1. Battery Test Setup - Edit the displayed vehicle and battery information.

Location Inside vehicle Outside vehicle

Brand/Model Exide Tudor

Fulmen Deta

Sonnak Centra

Other

Battery Type Flooded

EFB

GEL

AGM

AGM spiral

Battery Units EN

SAE

DIN

JIS

EN2

IEC

CCA

Battery Rating Hold down or to increase scrolling speed.

When Exide, Tudor, Fulmen, Deta, Sonnak or Centra are selected at brand/model, the option

'rating' will change to 'P/N', which leads to the part number list.

Rating Description Range

EN European Norms. The battery is required to meet a voltage of

7.5V after 10 seconds

100 to 3000

SAE Society of Automotive Engineers norm. The test species that the

battery at a temperature of –18°C will deliver a current equal to

the Cold Cranking Amps for 30 seconds with the voltage staying

above 7.2 volts

100 to 3000

DIN Deutsche Industrie-Norm 100 to 1000

JIS Japanese Industrial Standard test, carried out at -15°C. A list is shown

EN2 European Norms 2. Performing a different second discharge than

with EN.

100 to 3000

IEC International Electrotechnical Commission norm. The IEC test is

performed at -18°C

100 to 1000

CCA Cold Cranking Amps (specied by SAE): The amount of current a

battery can provide at 0 ºF

(–17.8 ºC).

100 to 3000

Select Start to advance to the next screen.

2. Temperature - Hold the tester temperature sensor over the battery being tested.

Midtronics EMEA. Hoofdveste 6--8, 3992 DG Houten, The Netherlands

2 – Car EBT-965P

Temp Sensor

Select Capture to lock in the live temperature reading and begin the battery test.

Battery Test Results

Select Send Results displayed at the bottom of the tester screen to send the test results to the

optional built-in printer or via email. Select Done

to return to the Main Menu.

Email

6Printer

Icons are color-coded to indicate status.

Battery Test Starter Test Alternator Test

Green:Green:

All test parameters were completed

and have passed.

Red:Red: The battery has failed the test.

Yellow:Yellow: Some test parameters may require

further testing. Gray:Gray: Insufcent data to perform the test.

Refer to Appendix B: Decision Tables for a complete explaination of the possible test results.

Test Results - Baery

Good Baery

Rated 575 CCA

Voltage 12.72 V

Measured 599 CCA

Temperature: 24C

Type: Flooded

 

Send Results System Test Done

Table des matières

Autres manuels Midtronics Instrument de mesure

Midtronics

Midtronics MDX-650P MILITARY Manuel utilisateur

Midtronics

Midtronics CPX-900 EU Manuel utilisateur

Midtronics

Midtronics MDX-655P Manuel utilisateur

Midtronics

Midtronics MDX-655 Manuel utilisateur

Midtronics

Midtronics HYB-1000 Manuel utilisateur

Midtronics

Midtronics MDX-652P Manuel utilisateur

Midtronics

Midtronics MDX-650P SOH Manuel utilisateur

Midtronics

Midtronics MDX-640 Manuel utilisateur

Midtronics

Midtronics PowerSensor Micro400 Manuel utilisateur

Midtronics

Midtronics DSS-5000P NI Manuel utilisateur

Midtronics

Midtronics MDX-650 MILITARY Manuel utilisateur

Midtronics

Midtronics PowerSensor MICRO400 Manuel utilisateur

Midtronics

Midtronics PowerSensor MICRO 400 Manuel utilisateur

Midtronics

Midtronics PowerSensor Micro700 Manuel utilisateur

Midtronics

Midtronics Micro400XL Manuel utilisateur

Midtronics

Midtronics DSS-5000 Manuel utilisateur

Midtronics

Midtronics Celltron ULTRA Manuel utilisateur

Midtronics

Midtronics RIVIAN CPX-900 Manuel utilisateur

Midtronics

Midtronics MDX-700P HD Manuel utilisateur

Midtronics

Midtronics MDX-650 MILITARY Manuel utilisateur

Midtronics

Midtronics EXP-1002 Manuel utilisateur

Midtronics

Midtronics PBT-100 AP Manuel utilisateur

Midtronics

Midtronics CPX-900 WiFi Manuel utilisateur

Midtronics

Midtronics MDX-645P Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
