Midland G7 Pro Manuel utilisateur
Midland G7 Pro
Midland G7E Pro
”User manual
DUAL BAND PMR/LPD TRANSCEIVER |
B | Midland G7 Pro user’s manual
Index
Introduction 1
Content of the package 2
Coverage (referred to PMR frequency band) 3
Main functions 4
Above all….Safety! 5
Warnings 5
Identifying the parts 6
LCD Display 6
Transceiver 8
Preparing the transceiver 10
Recharging the NIMH batteries (4 x AA) 10
Recharging the NIMH battery pack PB-ATL/G7 800 mAh 11
Recharging the Li-Ion battery pack ‘PB-PRO’ (optional) 11
Memory effect of rechargeable batteries 12
Installing and removing the belt clip 12
Installing/removing the battery pack 13
Removal 13
Installation 13
Basic operation 14
Turning on/off 14
Volume control 14
Transmission and reception 14
Midland G7 Pro user’s manual | C
MON button (Monitor) 15
Scanning all channels 15
Display backlight 15
5.7 Keypad lock 15
Power Save 16
MENU button 17
Channel selection 17
CTCSS/DCS tones selection 17
Choosing high or low transmission power (PMR band) 18
VOX function 18
Vibra-Call function 19
ROGER BEEP (End transmission tone) 19
CALL function 19
Dual Watch function 20
Keypad beep 20
7. Troubleshooting and radio reset 21
Reset 21
Technical specifications 22
Transmitter 22
Receiver 22
Midland G7 Pro user’s manual | 1
Introduction
Thanks for purchasing Midland G7 Pro!
Midland G7/G7E Pro combines the most advanced technology in radio
communication with extreme reliability. This brand new transceiver, with
its eye-catching design and sturdy mechanical frame is the ideal solu-
tion for both the professionals who need to stay in touch with colleagues
(construction sites, buildings, hotels, trade fairs, shows) or with leisure
users that just want to keep up with friends and family.
Extremely robust and easy to use, G7/G7E Pro is ideal for use in any activi-
ty; it operates on both PMR446 and LPD bands (see the chart‘Restrictions
on use’).
The Midland G7/G7E Pro incorporates all the functions that you would
expect to see on the latest and most advanced transceivers and guaran-
tees maximum efficiency.
The improved audio and Side Tone are the most important features of
this new radio; other key functions include an LCD backlit display, a Vi-
brating call alert feature for use in high-noise areas and an auto power
save function which reduces battery consumption by up to 50%. All of
the features on this outstanding radio are easily accessible thanks to the
centrally mounted controls.
2 | Midland G7 Pro user’s manual
Content of the package
Depending on the version, the content changes.
Single packing:
• 1 transceiver with belt clip
• 1 wall adaptor
• 4 AA rechargeable batteries 1800mAh
• quick guide
Twin packing:
• 2 transceivers with belt clip
• 1 wall adaptor
• 1 double desktop charger
• 2 battery packs 800mAh
• quick guide
It is available the optional Li-Ion battery pack 1200mAh mod. ‘PB-PRO’.
If any item is missing or damaged, contact immediately your supplier.
Midland G7 Pro user’s manual | 3
Coverage (referred to PMR frequency band)
The maximum range depends on terrain condition and is obtained du-
ring use in an open space.
The only limitation to maximum possible range are environmental factors
such as blockage caused by trees, buildings, or other obstructions. Insi-
de a car or a metallic constructions, the range can be reduced. Normally
the coverage in the city, with buidings or other obstructions is about 1
or 2 Km. In open space but with obstructions like trees, leafs or houses
the maximum possible range is about 4-6 Km. In open space, without
obstructions and in sight, like for example in mountain, the coverage can
be more than 12 Km.
4 | Midland G7 Pro user’s manual
Main functions
• G7 Pro: Dual Band LPD/PMR transceiver
G7E Pro: PMR446 transceiver
• Dual PTT for high/low power transmission
• Side Tone: end transmission noise muffler
• New audio level
• VIBRACALL function
• LCD display with backlight
• Low battery indicator
• Auto power save: automatic current economy circuit
• 38 CTCSS and 104 DCS tones in TX and RX
• CALL button with 5 tones selectable
• Automatic squelch adjustment
• Buttons for the channel selection
• SCAN function
• Keypad lock
• Hi/low power selection (PMR band)
• Roger Beep on/off
• VOX for hands-free communications
• Dual Watch
• 2 Pin jack for ext. mike / ext. speaker / battery recharge
The manufacturer, with its effort to constantly improve product quality,
reserves the right to change characteristics and features without prior
notice.
Midland G7 Pro user’s manual | 5
Above all….Safety!
Warnings
! Do not open the radio for any reason! The radio’s precision mechanics
and electronics require experience and specialized equipment; for the
same reason, the radio should under no circumstances be realigned as
it has already been calibrated for maximum performance. Unauthori-
zed opening of the transceiver will void the warranty.
! Do not use detergents, alcohol, solvents, or abrasives to clean the
equipment. Just use a soft, clean cloth. If the radio is very dirty, slightly
dampen the cloth with a mixture of water and a neutral soap.
BATTERIES
! Do not try to charge alkaline batteries or non rechargeable batteries.
Make sure that when you charge the radio, only rechargeable NI-MH
batteries should be contained in the battery compartment! It is very
dangerous attempting to recharge other types of batteries (for exam-
ple alkaline or manganese batteries). Batteries which are not suitable
to be recharged may leak, explode or even burn and cause damage!
! Using a different battery charger other than the one specified can cau-
se damage to your device or may even cause explosions and personal
injuries.
! Do not throw batteries into fire or place them near heat as this may
cause explosions or personal injuries. Dispose of the batteries accor-
ding to procedures set out by local regulations.
! Do not mix old and new batteries or batteries of different types or bat-
teries which have been used in different manners.
6 | Midland G7 Pro user’s manual
Identifying the parts
LCD Display
4 5 6
1
2
3
8
7
10
9
CALL
MENU
EMG
1
2
5
3
4 6 8 7
11
9
10
12
13
14
15
24
23
22
21
20
19
18
17
16
CALL
MENU
EMG
1
2
5
3
4 6 8 7
11
9
10
12
13
14
15
24
23
22
21
20
19
18
17
16
CALL
MENU
EMG
1
2
5
3
4 6 8 7
11
9
10
12
13
14
15
24
23
22
21
20
19
18
17
16
CALL
MENU
EMG
1
2
5
3
4 6 8 7
11
9
10
12
13
14
15
24
23
22
21
20
19
18
17
16
CALL
MENU
EMG
1
2
5
3
4 6 8 7
11
9
10
12
13
14
15
24
23
22
21
20
19
18
17
16
Midland G7 Pro user’s manual | 7
1. Selected channel (P1-P8: PMR446 /1-69:LPD)
2. VOX - Function activated
3. - Keypad lock activated
4. - Battery status indicator
5. - Vibra-Call function activated
6. H/L - Indicates the high / low power selection in transmission
(only in PMR band)
7. RX - Radio in rx mode (busy channel)
8. TX - Radio in transmission (PTT pressed)
9. DCS/CTCSS - Type of sub-audio tone selected
10. Code of the selected CTCSS or DCS tone
(CTCSS: 1-38; DCS: 1-104)
