Midland H7 Manuel utilisateur
User Manual
4k
UHD
4K@10fps
150º
Waterproof
up to 30m
1.5 HoursWide Angle
Lens
2-inch
LCD
Cautions
>Do not drop your camera.
>Do not place heavy objects on the
camera.
>Keep the camera away from water
and liquids (unless used in the wa-
terproof case). This may cause the
camera to malfunction.
>Recharge the battery via the USB ca-
ble.
>The camera should not be in heat
over 65ºC.
>When the camera cannot work well,
please don’t disassemble it by your-
self, if your behavior cause damage,
the original factory will not under-
take responsibility.
>Please don’t use the camera while
the battery is charging.
KEY FEATURES
.Video resolution: 4k@10fps, 2.7k@15fps,
1080p@60fps, 720p@120fps, 720@60fps.
.Image resolution: 8MP, 12MP (interpolation).
.Supports Wi-Fi connection, range up to 15 meters.
.Supports 2.4G Wireless remote control.
.Underwater 30 meters when bundled with
waterproof case.
.2”TFT LCD screen.
.3.7V/1000mAh built-in Lithium-ion battery.
WHAT’S IN THE BOX
.Camera
.Remote control
(Optional)
.Waterproof case
.Portable frame
.Curved mount
.Flat mount
.3M adhesive (2)
.Basic mount with screw
.USB Cable
.Screw
CAMERA DIAGRAM
1
2
8
37
10
5
6
4
Shoot Button
Power Button
Wi-Fi Button
LCD screen
Micro SD interface
Mini HDMI interface
USB interface
LED indicator
Lens
Reset Button
1 6
2 7
3 8
4 9
510
9
HOW TO USE YOUR CAMERA
Turn on / o
Turn on: press and hold the Power Button for 2
seconds, the LED indicator will turn red. The cam-
era defaults to video mode when turned on.
Turn o: press and hold the power Button for 2
seconds.
Modes
Midland H7 has 4 dierent operative modes: Vid-
eo, Slow Motion, Picture and Play back.To switch
to dierent modes you have to press Shoot But-
ton for 1,5 seconds:
Video aSlow Motion aPicture aPlay back
Take a Video
By default, the camera is on video mode when it is
turned on.
Press Shoot Button once to start recording.
Press Shoot Button again to stop recording, the
video clip will be saved automatically.
Slow Motion
Slow motion is an eect in lm-making whereby
time appears to be slowed down. It achieved
when each lm frame is captured at a rate much
faster than it will be played back.
Press Shoot Button for 1.5 seconds to switch from
Video mode to Slow Motion mode.
Press Shoot Button once to start recording on
Slow Motion mode.
Press Shoot Button once to stop recording.
Shooting Single Picture
Press and hold Shoot Button for 1.5 seconds to
switch from Slow Motion mode to Picture Mode.
Press Shoot Button once to shoot a single picture.
Playback mode
Press and hold the Shoot Button for 1.5 seconds
to switch from Picture Mode to Playback Mode.
On this mode you can review all your captured
videos and photos.
Use WiFi Button to scroll, Shoot Button to enter
and play, Power Button to enter to protect/delete
le menu.
Press and hold Shoot Button for 1.5 seconds to
swift to Video Mode.
Charging the camera
Connect the camera to the PC via USB cable. The
red indicator will be on, charging is in process.
When the battery is fully charged, the red indica-
tor will turn o. It takes around 2.5 hours to fully
charge the battery.
Insert the TF Card
Insert a Micro SD card into the card slot according
to the direction shown on the camera.
>We suggest using ≥CLASS 6 (High speed) Micro
SD card for smoothly shooting purpose. Lower
CLASS of Micro SD Card may cause video
jammed.
>There is only one correct direction to insert the
Micro SD card into the slot. Do not force the
card into the card slot, as it may damage both
the camera and the Micro SD card.
>A new Micro SD card should be formatted with
the camera before using.
How to use waterproof case
The camera can support underwater 30 meters if
mounted in the waterproof case.
a. Open the waterproof case latch;
b. insert the camera properly;
c. close the waterproof case buckle.
After the use, please carefully clean the case with
clean water and dry with a dry cloth.
SETTING YOUR CAMERA
Video mode setting
When the camera is on Video Mode, press the
Power Button once (release immediately, if it is
held too long, the camera will switch o), then
enter the Video Setting menu. Use the Wi-Fi But-
ton to scroll, Shoot Button to conrm, Power But-
ton to back to last menu.
Resolution: 4k@10fps, 2.7k@15fps, 1080p@60fps,
1080p@30fps, 720p@120fps, 720p@60fps are for
your choice.
Video looping: the video will be separated into
dierent les by the Time Length.
>Selected “O”: the video will be separated into
dierent les by 30-minutes.
>Selected“1 Min”: the video will be separated in-
to dierent les by 1-minute.
>Selected“3 Min”: the video will be separated in-
to dierent les by 3-minutes.
>Selected“5 Min”: the video will be separated in-
to dierent les by 5-minutes.
For example, if you select “5 Min”, time length, a
20 Minutes video will be separated into 4 Video
Clips (5 Minutes each Clip).
White balance: the default set is auto, you can ad-
just the mode as concrete lighting condition.
Microphone:
>Select“On”, shoot video with sound.
>Select“O”, shoot video without sound.
Date Stamp: you can set time and date stamp on
video or not.
Picture mode setting
When the camera is on Picture Mode, press the
Power Button once (release immediately, if it is
held too long, the camera will switch o), then
enter the Picture Setting Menu. Use the Wi-Fi But-
ton to scroll, Shoot Button to conrm, Power But-
ton to back to last menu.
Resolution: 3m, 5m, 8m, 12m. The higher resolu-
tion, the better image quality.
Quality: the higher quality setting, the better
photo image quality.
Metering: dierent options to determine the ex-
posure.
White balance: the default setting is Auto, you can
adjust the mode as concrete lighting condition.
ISO: to determine how sensitive the camera sen-
sor is.
Exposure: light exposure, the higher exposure
the faster image speed, high exposure suit to dark
environment.
Self Timer: if on, the user can auto image capture
every 2 or 10 seconds.
Date Stamp: you can set time and date stamp on
photo or not.
Set-up more
When the camera is on Photo or Video Mode,
press Power Button once, then press and hold
Shoot Button for 1.5 seconds and enter the Set-
up More menu. Use the Wi-Fi Button to scroll,
Shoot Button to conrm, Power Button to back to
last menu.
Screen Saver: select 1, 3, 5 min option, the cam-
era LCD screen will be o if no operation after 1, 3,
5 min.
