Midea MDS70-VR072/A04-AU Manuel utilisateur

Read all instructions and explanations for

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

appliance is sold or passed on, ensure

that the new owner always receives this operation instructions.

delete installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

product is sold or passed on then ensure

that the new owner always receives this

manual. MODEL:

MDS70-VR072/A04-AU

TUMBLE DRYER

Dryer

SAFETY INSTRUCTIONS

Safety Instructions ..................................................

INSTALLATION

Product Description ................................................

Installation ...........................................................

OPERATION

Quick Start .............................................................

Before each Drying ..................................................

Control Panel .........................................................

Drying Programmes Table ........................................

MAINTENANCE

Cleaning and Care ..................................................

Trouble Shooting ....................................................

Technical Specification...........................................

CONTENTS

Warning;Risk of fire / Flammable materials

Explanation of symbols

Read operator’s manual

SAFETY INSTRUCTIONS

Safety Instructions

• The appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play

with the appliance.

• If the power cable is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

• This appliance can be used by children from 8 years and above

and persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a

safe way and understand the hazards involved.

• Children shall not play with the appliance.cleaning and user

maintenance shall not be made by children without supervision.

• The tumble dryer is not to be used if industrial chemicals have

been used for cleaning.

• The lint trap has to be cleaned frequently.

• Lint must not to be allowed to accumulate around the tumble

dryer.

• Do not dry unwashed items in the tumble dryer.

• Items that have been soiled with substance such as cooking oil,

acetone, alcohol, petrol, kerosene, spot removers, turpentine,

waxes and wax removers should be washed in hot water with a

extra amount of detergent before being dried in the tumble dryer.

SAFETY INSTRUCTIONS

• Items such as foam rubber (latex form), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried

in the tumble dryer.

• Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

• The exhaust air must not be discharged into a flue which

is used for exhausting fumes from appliances burning gas

or other fuels.

• The appliance must not be installed behind a lockable door,

a sliding door or a door with a hinge on the opposite side

to that of the tumble dryer, in such a way that a full opening

of the tumble dryer door is restricted.

• Oil-affected items can ignite spontaneously, especially

when exposed to heat sources such as in a tumble dryer.

The items become warm, causing an oxidation reaction in

the oil.Oxidation creates heat. If the heat cannot escape,

the items can become hot enough to catch fire. Piling,

stacking or storing oil-affected items can prevent heat

from escaping and so create a fire hazard.

• The appliance should not be overturned during normal

use or maintenance.

• Remove all objects from pockets such as lighters and

matches.

Never stop a tumble dryer before the end of the drying

cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

Warning!

SAFETY INSTRUCTIONS

Correct Disposal of this product:

This marking indicates that this product should not be disposed

with other household wastes throughout the EU. To prevent

possible harm to the environment or human health from

uncontrolled waste disposal, recycle it responsibly to promote

the sustainable reuse of material resources. To return your used

device, please use the return and collection systems or contact

the retailer where the product was purchased. They can take this

product for environmental safe recycling.

• Ventilation openings in the base must not be obstructed by

carpets.

• Children of less than 3 years should be kept away unless

continuously supervised.

• Plug must be accessible after installation.

• Warning: The appliance must not be supplied through an

external switching device, such as a timer, or connected to

a circuit that is regularly switched on and off by a utility.

• Remove all packages before using the appliance.

Otherwise,serious damage may result.

• Adequate ventilation has to be provided to avoid the back

flow of gases into the room from appliances burning other

fuels, including open fires.

Model Rated capacity

MDS70-VR072/A04-AU

7.0kg

If it is unavoidable that fabrics that contain vegetable or cooking oil or have been

contaminated by hair care products be placed in a tumble dryer they should first be

washed in hot water with extra detergent-this will reduce,but not eliminate,the

hazard.

Warning!

SAFETY INSTRUCTIONS

Power supply and grounding

•

• The dryer employs alternating current with the rated voltage and frequency.

When the voltage fluctuates between 6% of rated voltage, the dryer can work normally.

• A special power socket with a capacity 10A for the dryer had better be set beside the

dryer for convenience and safety. The method of connection of the socket is as the

figure below.

• To be safe, please make improvements as soon as

possible according to the rules and

suggestions mentioned above.

• The appliance corresponds to protection class I and may only be connected to a plug

with a protective conductor that has been installed properly. When connecting the

appliance to the mains, make sure that the mains voltage is correct. You can find more

information about this on the rating plate.

• The electrical safety of this tumble dryer can only be guaranteed when correctly

earthed. It is essential that this standard safety requirement is met. If in any doubt,

please have the household wiring system tested by a qualified electrician.

The manufacturer cannot be held liable for the consequences of an inadequate

earthing system (e.g. electric shock).

The socket and the grounding wire must be installed by an electrician to prevent

incorrect installation or use of the socket and to guarantee the safe use of

electricity. No connection of the grounding wire and the neutral wire, otherwise the

cabinet will be charged, which is likely to cause the danger of electric shock.

≥

Warning!

Grounding

SAFETY INSTRUCTIONS

• Precautions

Install or store where it will not be exposed

to temperatures below freezing or exposed

to water or weather, which could cause

permanent damage and invalidate the

warranty.

Keep area around the exhaust opening and

adjacent surrounding areas free from the

accumulation of lint, dust and dirt. An

obstructed port might reduce the airflow.

Thoroughly spin the laundry in washing

machine. High spin speed can reduce the

drying time and save energy.

Make sure combustible sprays will not be close

to the dryer when it is working, and once the

leaks, do not touch plug or start/pause it.gas

Do not wash or dry articles that have been

cleaned in, washed in, soaked in or spotted

with combustible or explosive substances

( such as wax, oil, paint, gasoline,

dry-cleaning solvents, kerosene,

etc.).

degreasers,

Never attempt to operate this appliance if it

is damaged, malfunctioning, partially

disassembled,or has missing or broken parts,

including a damaged cord or plug.

Do not allow children on or in the appliance.

Close supervision of children is necessary

when the appliance is used near children.

Do not use the machine when your hands are

wet.

Do not store plastic, paper or clothing that

may burn or melt on top of the dryer during

operation.

The exhaust air must not be discharged into

a flue which is used for exhausting fumes

from appliances burning gas or other fuels.

Do not dry articles containing rubber, plastic

or similar materials such as padded bras,

tennis shoes, galoshes, bath mats, rugs, bibs,

baby pants, raincoats, plastic bags or pillows

that may melt or burn. Some rubber

materials, when heated, can under certain

circumstances produce fire by spontaneous

combustion.

The door shall be opened only after the

programme of the drying machine is

completed.Do not open the door before the

programme finished to avoid the human

skin from being scalded by hot steam or over

heated drying machine.

SAFETY INSTRUCTIONS

Top board

Control panel

Door

Front panel

Side panel

Lint filter

Exhaust duct

Power plug

Door lock

Drum

>10cm

INSTALLATION

Product Description

Installation

Note: Please see the products you purchased in kind prevail.

Dryer should be placed in a ventilated area with

than 10cm distance from the wall. It is suggested there

are no obstacles within 1.5m in front of dryer to assure

ventilation.

not less

• Installation Position Selection

INSTALLATION

work properly.

If the dryer is not placed horizontally (tilt angle more than 2°), the dryer may not

Notice when installing:

• Do not install the dryer in the open air or a place where

it can be damaged easily by rain;

• Do not place the back of dryer near curtain or something

moved by wind;

• Do not place the dryer near gas or flammable materials.

•

• Connect one end of the flex tube to the back vent, then fix it firmly until it's tight.

• The other end of flex tube will be extended to outdoor, for the proper assembly please

refer to the below pictures.

Exhaust duct installation:

Note!

• Level Adjusting

Once in its permanent operating position,

check that the dryer is absolutely level with the aid

of a spirit level. If it is not, adjust the feet with a tool.

Table des matières

Autres manuels Midea Séchoir

Midea

Midea MLTE41N1BWW Manuel

Midea

Midea MDC07 Manuel utilisateur

Midea

Midea MLE45N1BWW Manuel

Midea

Midea MDH210-V042/B01EHS-US Manuel utilisateur

Midea

Midea MDG09H80/W-ES Manuel utilisateur

Midea

Midea DMDHP70 Manuel utilisateur

Midea

Midea MD-7388 Manuel utilisateur

Midea

Midea MD600W Manuel utilisateur

Midea

Midea MDK888HP Manuel utilisateur

Midea

Midea MDV160-V02A2/F01-US1305 Manuel utilisateur

Midea

Midea MDV160-V042/F01-SA Manuel utilisateur

Midea

Midea MLE45N1AWW Manuel

Midea

Midea MLE41N1AWWC Manuel

Midea

Midea MLE25H7BWW Manuel

Midea

Midea MLE52N3AWW Manuel

Midea

Midea MLE52N4AWW Manuel

Midea

Midea MLE52S7AGS Manuel

Midea

Midea MDD160-V062/F01-US1305 Manuel utilisateur

Midea

Midea MDD160-V052/F01-US1305 Manuel utilisateur

Midea

Midea MD-6288 Manuel utilisateur

Midea

Midea MDG09EH80 Manuel utilisateur

Midea

Midea MDV160-V082/F01-US1305 Manuel utilisateur

Midea

Midea MLE27N5AWWC Manuel

Midea

Midea FP-91LFD070GMTM-N Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
