Step 2: Install Software

Step 1: Unpack Contents

Start Here

Installing your Microtek ScanMaker s450/s350

Unpack your scanner package and check for

major components.

1. Scanner with built-in transparency adapter

2. Software CD

3. Power adapter

4. Hi-Speed USB cable

5. White mat

6. Film holder

Important: Do not remove the yellow stickers from

your scanner until you are told to do so. You must

install software before connecting your scanner.

Always close any open programs and turn off Anti-

virus utilities before installing software.

MAC:

A. Place the Microtek CD-ROM into the CD-

ROM drive and install all the software

components.

B. Restart your computer.

NOTE: After rebooting your Macintosh, the

Microtek software will attempt to locate your

scanner on the system. Since this is your first

install and you have not yet connected the

scanner, simply ignore the message that appears

and proceed to the next step.

PC:

A. Place the Microtek CD-ROM into the CD-

ROM drive.

B. Follow the on-screen instructions to install

the driver and software.

NOTE: If the Microtek Software Installer screen

does not come up automatically, double-click the

following in succession: “My Computer”; the CD-

ROM icon; then cdsetup.exe to start the installer

program.

I49-004142 A, February 2007

Unlocked Locked

Step 3: Unlock Scanner

NOTE: To lock the scanner (for shipping and other reasons), tilt the scanner and look for the locking

switch on the right corner at the back, then push the locking switch to the "Locked" position. DO

NOT turn the scanner upside down when attempting to lock the unit.

A. Remove the yellow “Step 3” sticker from

your scanner.

B. With the scanner power off, tilt the back

right corner of the scanner to see the

locking switch at the bottom.

C. Push the locking switch to the position as

indicated in the graphic, with the icon on

the lock showing as “Unlocked”.

Step 4: Connect Scanner

To the scanner lid

Make sure the scanner lid (with built-in transparency

adapter) is properly connected to the scanner’s 9-pin

accessory port. Plug the connector into the port if the

scanner lid is not securely connected.

To the power adapter

A. Remove the yellow “Step 4”

sticker from your scanner.

B. Connect the power adapter to the

back of the scanner.

C. Plug the power adapter

into a power source.

To the Hi-Speed USB cable

D. Connect one end of the cable to your computer.

E. Connect the other end of the cable to the scanner.

F. Turn the power switch at the back panel of your scanner to “On”; the LED lights up at the

front panel of the scanner.

The system will detect your scanner automatically.

Scanner Buttons

The ScanMaker s450/s350 is equipped with seven scanner buttons, providing quick access to

the most frequently used functions. These buttons are Cancel/Setup, Scan, Copy, E-mail,OCR,

PDF,and Custom.

Cancel/Setup: Cancels the scanning job when the scanner is scanning. Launches the

Microtek Scanner Configuration (MSC) utility when the scanner is not scanning.

Scan: Captures images that can be saved as files or sent to an image-editing application.

Copy: Scans the image and sends it to your printer.

E-mail: Scans the image and delivers it directly to your e-mail editor.

OCR: Scans a text document, converts, and saves it in text file format. Files may be

immediately edited if configured in the MSC utility.

PDF: Scans the image and saves it in the Adobe Acrobat PDF format.

Custom: Customizes this button to perform your preferred function, such as Power

Saving, Scan, Fax, or Launch Application.

NOTE: If your computer has both

Hi-Speed USB (USB 2.0) and USB

1.1 ports, connect the cable to the

Hi-Speed USB port. Use the USB

1.1 port only if your computer does

not have Hi-Speed USB.

Step 4: Connect Scanner (cont.)

Scanning Basics

NOTE: The scanning procedures outlined here make use of the

Standard Control Panel in ScanWizard 5. To use the Advanced

Control Panel, refer to the Supplement.

1. Place the scan material

A. To scan photos, place the photo to be scanned on the

scanner bed. The top end of the original should be

positioned towards the back of the scanner, with the

surface to be scanned facing down. Then, place the white

mat on top of the photo.

NOTE: Use of the white mat on top of your photo filters out

unwanted light during scanning, and ensures the correct

functioning of the automatic cropping feature when you do a

preview scan.

B. To scan film, use the film holder. See “Using the Film

Holder” for more details.

2. Launch ScanWizard 5

To launch ScanWizard 5 as a stand-alone program, double-

click the ScanWizard 5 icon on your desktop. The scanner will

automatically perform a “fast preview” of your image, based

on settings specified under the Original, Scan Type, and

Purpose categories (buttons).

3. Specify your preferences

Use the following toolbar buttons to change the settings

according to your preferences.

Original – Defines the category of the media (scan material).

Scan Type – Selects the output image type (color, gray, or

B&W).

Purpose – Sets the image resolution to match your target

application.

NOTE: Click the Scale Output, Adjust, and Reset buttons if you

need to make further adjustments.

4. Scan your material

A. Click the Scan to button from the ScanWizard 5 Control Panel.

B. When the Save As dialog box appears, specify the folder location, a file name, and the

format for the output image, then click Save. The image is scanned and saved to the

specified location.

Send image to application after saving file:

If this option is checked, the scanned image is saved first and then automatically delivered to

an image editing software, a web browser, as the Adobe Acrobat software, as indicated in the

destination box.

Using the Film Holder

A. To load film:

1. Load the film inside the holder, with

the film’s shiny base facing down.

Slide the film along the slots of the

holder until the film is fully loaded.

Do not block

calibration window

(The U-shape

opening at the slide

slot side)

Do not block

calibration window

(The U-shape

opening at the film

slot side)

B. To load slides:

1. Raise the scanner lid, and place the

film holder on the scan bed. The

holder should be positioned against

the top right edge of the bed, with the

slot for slides running down the

center.

Make sure that the red arrow marks

on both the holder and the scanner

are pointing to each other when the

holder are put together.

2. Place the slide in the film holder, with

the slide facing down.

2. Raise the scanner lid, and place the

film holder with the film on the scan

bed. The holder should be positioned

against the top right edge of the

scanner bed, with the slot for the film

running down the center.

Make sure that the red arrow marks

on both the holder and the scanner

are pointing to each other when the

holder are put together.

Select Automatic

Color Restoration

Scanning Film

1. Launch ScanWizard 5. In the Standard

Control Panel, click the Original button.

Choose “Negative Film” to scan negatives,

or choose “Positive Film” to scan slides.

2. Click the Preview button in the Standard

Control Panel to perform a preliminary

scan of the image.

3. Click the Scan to button to scan the

image.

After the scan, the scanned image can be

saved as a file, opened in an image editing

program, sent to a printer, attached in an

e-mail, or saved in the PDF format.

Restoring Color

ColoRescue™ is an automatic color recovery system that restores faded color in

both photos and film to their original luster.

2. In the ScanWizard Settings window,

check the “Automatic Color Restoration”

check box. The next time you scan faded

photos or film, ColoRescue will restore the

faded colors to their original brilliance.

To use ColoRescue:

1. Launch ScanWizard 5. When the

Standard Control Panel appears, click

the Switch icon on the upper right

corner to switch to the Advanced

Control Panel.

Using the Film Holder (cont.)

Problems?

The LED on the button panel indicates the status of the scanner.

Ready to scan.

If you encounter any problems, check the section below and follow the suggested solution if

your problem is listed. You may also want to go over installation steps 1 to 4 of this "Start

Here" document to make sure that you have followed all procedures properly.

1. No light comes on when the scanner is turned on.

Make sure your scanner is connected to your computer and plugged into a power source.

2. Add/Remove Hardware Wizard appears on your screen.

Click the “Cancel” button and close the Control Panel. Disconnect the USB cable from the

back of your computer, and refer to the installation instructions in this guide.

3. When trying to scan, an error message appears on your screen that reads, “Can’t Find

Scanners”.

Make sure your scanner is unlocked (see Step 3).

Make sure your scanner is connected to your computer and plugged in to a power source (see

Step 4).

Uninstall and reinstall the ScanWizard 5 software.

4. After clicking scan, a blank screen appears.

Make sure your scanner is unlocked (see Step 3).

Uninstall and reinstall the ScanWizard 5 software.

5. Having trouble scanning negatives or slides?

Make sure the scanner lid (with built-in transparency adapter) is properly installed, with its

connector securely connected to the scanner’s 9-pin accessory port.

Make sure you place the film holder with the loaded film properly on the scan bed. Do not

block the calibration area (as indicated in the “Using the Film Holder” section).

From the ScanWizard 5 Standard Control Panel, go to the Original button category, then

proceed to the Film subcategory. Make sure you select either the Positive or Negative option.

Flashing

Warming up or scanning.

Off

Scanner is off.

DoYou Need Assistance?

Manuals

If you have additional questions and need further instruction or information, we provide

electronic manuals for:

1. Using your ScanMaker s450/s350 (Supplementary information)

2. Using the ScanWizard 5 scanning software

3. Using the bundled third-party software

To access the electronic manuals: Insert the scanner’s software CD-ROM into your

computer’s CD-ROM drive. Next, locate and click the “Manuals” option when the software

installer window appears on your screen. Finally, select and click the title of the manual

you wish to view.

Missing Items

If your package is missing items, please call the Microtek Customer Service Department.

trademarks of their respective companies: Microtek, ScanMaker, ScanWizard of Microtek

International, Inc. All other trademarks or registered trademarks are the property of their

respective holders. Specifications, software and hardware bundles are subject to change

without notice. Delivery of technical support services subject to change without notice.

Not responsible for typographical errors. 021507

Power Adapter

Use only power supplies (AC/DC adapters) listed below:

Voltage Manufacturer Model No.

200V to 240V HARD HDAD15W101-124

100V to 120V HARD HDAD15W101-123

NOTE: Please make sure that the electrical outlet to where the scanner

will be connected is nearby and readily accessible.

Energy Star Notice

As an ENERGY STAR Partner, Microtek International,

Inc. has determined that this scanner meets the ENERGY

STAR guidelines for energy efficiency.

Autres manuels pour ScanMaker s380

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Microtek Scanner

Microtek

Microtek FileScan 3125c Manuel utilisateur

Microtek

Microtek ScanMaker 6000 Manuel utilisateur

Microtek

Microtek ArtixScan 3200XL Mode d’emploi

Microtek

Microtek ArtixScan 6000XY Manuel utilisateur

Microtek

Microtek ScanMaker i800 Plus Mode d’emploi

Microtek

Microtek ScanMaker V6USL Manuel utilisateur

Microtek

Microtek ScanMaker 4 Manuel utilisateur

Microtek

Microtek ScanMaker i700 Manuel utilisateur

Microtek

Microtek ScanMaker 3700 Manuel utilisateur

Microtek

Microtek ArtixScanDI 4020 Plus Manuel utilisateur

Microtek

Microtek ObjectScan 1600 Manuel utilisateur

Microtek

Microtek ArtixScanDI 2015c Manuel utilisateur

Microtek

Microtek ScanMaker 1000XL Plus Mode d’emploi

Microtek

Microtek ScanMaker 8700 Pro Manuel utilisateur

Microtek

Microtek XT5750 HS Manuel utilisateur

Microtek

Microtek ArtixScan DI 2125c Manuel utilisateur

Microtek

Microtek ScanMaker X12USL Manuel utilisateur

Microtek

Microtek ScanMaker 8700 Manuel utilisateur

Microtek

Microtek XT7000 HS Manuel utilisateur

Microtek

Microtek ScanMaker i900 Manuel utilisateur

Microtek

Microtek ScanMaker i800 Plus Manuel du propriétaire

Microtek

Microtek ScanMaker i4800 Manuel utilisateur

Microtek

Microtek ArtixScan 2500 Manuel utilisateur

Microtek

Microtek ScanMaker i300 Manuel utilisateur

Manuels Scanner populaires d'autres marques

Plustek

Plustek Scanner Manuel utilisateur

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manuel utilisateur

Renkforce

Renkforce DS100-5M Manuel utilisateur

Image Access

Image Access WideTEK A2 Manuel utilisateur

Canon

Canon imageFORMULA CR-120N Manuel utilisateur

Fujitsu

Fujitsu FI-4860C2 Manuel utilisateur

GeoSlam

GeoSlam ZEB Horizon Instructions d'installation

Kodak

Kodak i5800 Scanner Manuel utilisateur

Kodak

Kodak i7300 Manuel utilisateur

Revopoint

Revopoint POP Manuel utilisateur

Fujitsu

Fujitsu fi-4860C Manuel utilisateur

Eddyfi Technologies

Eddyfi Technologies Floormap X Manuel utilisateur

Faselase

Faselase F6 Manuel utilisateur

Fujitsu

Fujitsu CardMinder Manuel utilisateur

Uniden

Uniden BC340CRS Manuel utilisateur

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manuel utilisateur

Mustek

Mustek PageExpress 4800 Pro Manuel utilisateur

Optex

Optex 750830 Manuel utilisateur
