MicroNet SP616EB Manuel utilisateur

Quick Installation Guide

EtherFast 10/100M Switch

Model No.: SP616EB

http://www.micronet.info

Introduction

Micronet SP616EB 10/100M Switch provides powerful,

high-performance Ethernet switch, with all 16 ports capable of 10M

and 100M auto-negotiation operation. With its intelligent addressing

engine, it provides users with a wire-speed filtering and forwarding

of the traffic.All ports support auto-uplink detection, so users don't

have to worry about the cable type. Each port will automatically

communicate for best speed and to run in half- or full-duplex mode.

Store-and-forward switching function prevents damaged packets

and network errors from being passed on into the network.

Package Contents

Before installing the device, please verify the following items are in

the package:

yEtherFast 10/100M Switch

yQuick Installation Guide

yPower cord

Features

yCompliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX

and IEEE802.3x flow control

ySupports speed (10/100Mbps) and duplex mode(Half/Full) and

auto-detection

ySupports MDI/MDI-X auto crossover

ySupports full and half duplex operation on all ports

ySupports back-pressure (Half/Full) and flow control (IEEE 802.3x)

ySupports extensive LED indicators for network diagnostics

yWire-speed packet filtering and forwarding rate

yStore-and-forward architecture filters fragment & CRC error

packets

y10” and 19” rack-mountable

Physical Description

SP616EB front view

Please refer to the following table for LED definition.

LED Status Operation

On Power is on.POWER Off Power is off.

On/Green Connection established.

Blink/Green Transmitting or receiving data.

LNK/ACT Off No link.

Installation

Installation is easy-- simply connect the cables and the power cord.

The system is ready, and you can use all the features.

Connect each station to the switch by twisted-pair cable. Plug one of

the RJ-45 connectors into a RJ-45 port of the switch, and plug the

other RJ-45 connector into the station’s network adapter. Power on

the switch and then the system is ready.

All ports could be used to connect with another switch. As all the

ports support auto-uplink (MDI / MDI-X) function, user can choose to

use a straight cable or a crossover cable to make a switch-to-switch

connection.

For cable selection, refer to the following table：

Network

Speed Connector Cable Type Max.

Length

10BaseT RJ-45 Cat. 3, 4, 5 UTP/STP 100 m

100BaseTX RJ-45 Cat. 5 UTP/STP 100 m

Note: To prevent costly equipment damage and downtime, please

consider installing a surge suppression device or a UPS

(Un-interrupted Power Supply).

Specifications

Standard IEEE802.3, IEEE802.3u, IEEE802.3x,

compliant

Interface 16 * 10/100M RJ-45 ports

Cable Connections 10BASE-T: Cat. 3, 4, 5 UTP/STP

100BASE-TX: Cat. 5 UTP/STP

MAC address 8K

Buffer Memory 160K Byte for the whole system

NWay Protocol Network speed:10Mbps and 100Mpbs

Duplex mode: Full and Half

Uplink Auto Uplink (Auto MDI / MDI-X)

Filtering/Forwarding

Rate 10Mbps: 14,880pps/14,880pps

100Mbps: 148,800pps/148,800pps

Emission FCC Class A, CE

Operating Temperature 0o - 40o C (32o - 104o F)

Operating Humidity 10% - 90% (Non-condensing)

Dimension (mm) 267 × 161 × 44

Weight (kg) 1.2

Power Supply 100 ~ 240V AC, 50/60Hz

Full range internal power supply

CE Mark Warning

This equipment complies with the requirements relating to

electromagnetic compatibility, the essential protection requirement

of Council Directive 89/336/EEC on the approximation of the laws of

the Member States relating to electromagnetic compatibility.

Company has an on-going policy of upgrading its products and it

may be possible that information in this document is not up-to-date.

Please check with your local distributors for the latest information.

No part of this document can be copied or reproduced in any form

without written consent from the company.

Trademarks:

All trade names and trademarks are the properties of their

respective companies.

P/N:
