1 sec. Measurement (Scan-Peak-method)

Mesure en 1 sec. / Medición en 1 seg. / 1 Sek. Messung /

Medição em 1 seg.

Multiple Use (Wide Range 0 °C - 100 °C)

• Body temperature / Température du corps / Temperatura

corporal / Körpertemperatur / Temperatura corporal

• Milk surface temperature / Température de surface du lait /

Temperatura superficial de la leche / Milch-Oberflächen-

temperatur / Temperatura da superficie do leite

• Surface temperature of Baby’s bath / Température de sur-

face du bain de bébé / Temperatura superficial del agua

del baño del bebé / Badewasser-Oberflächentemperatur /

Temperatura superficial del agua del baño

• Ambient temperature / Température ambiante / Tempera-

tura ambiente / Raumtemperatur / Temperatura ambiente

Fever alarm / Silent GlowTM Technology

Alarme de fièvre / Silent GlowTM technologie

Señal de alarma en caso de fiebre / Tecnología Silent GlowTM

Fieberalarm / Silent GlowTM Technologie

Alarme de febre / Tecnologia Silent GlowTM

Illuminated Display

Ecran rétro-éclairé / Pantalla con iluminación / Beleuchtetes

Display / Visor iluminado

12 Memories

12Mémoires / 12Memorias / 12Speicherplätze / 12Memórias

Signal Tone

Signal sonore / Señal acústica / Signalton / Sinal sonor

Probe Cover Free

Sans embout / Sin funda protectora / Schutzhüllenfreies / Sem

cobertura protectora do sensor

Celsius - Fahrenheit switchable

Microlife AG

Espenstrasse 139

9443 Widnau / Switzerland

Tel. +41 / 71 727 70 30

Fax +41 / 71 727 70 39

Email [email protected]

www.microlife.com

1 sec.

IB IR IDE1-1S VarA5 1008

Microlife IR 1DE1

Probe Cover Free Ear Thermometer

Instruction Manual (1-12)

Thermomètre auriculaire sans embout

Mode d’emploi (13-24)

Termómetro de oído sin funda protectora

Manual de Instrucciones (25-38)

Schutzhüllenfreies Ohrthermometer

Gebrauchsanleitung (39-50)

Termómetro de ouvido sem

cobertura protectora do sensor

Manual de Instruções (51-62)

Probe Cover Free Ear Thermometer

Instruction Manual

Please read these instructions carefully before using the

instrument and keep them in a safe place.

The Microlife Probe Cover Free Ear Thermometer IR 1DE1 is a high

quality product incorporating the latest technology and tested in

accordance with international standards. With its unique technology,

the IR 1DE1 can provide a stable, heat-interference-free reading with

each measurement. The instrument performs a self-test every time it

is switched on to always guarantee the specified accuracy of measu-

rements.

The Microlife Probe Cover Free Ear Thermometer IR 1DE1 is intended

for the periodic measurement and monitoring of human body tempe-

rature in the home. It is intended for use on people of all ages.

Batteries and electronic instruments must be disposed of in

accordance with the locally applicable regulations, not with

domestic waste.

Table of Contents

1. The Advantages of this Thermometer

2. Important Safety Instructions

3. Product Description

4. How this Thermometer Measures Ear Temperature

5. Control Displays and Symbols

6. Directions for Use

7. Changing from Fahrenheit to Celsius and vice-versa

8. How to recall 12 readings in Memory Mode

9. Error Messages

10. Cleaning and Storage

11. Replacing the Battery

12. Guarantee

13. Technical Specifications

14. www.microlife.com

1. The Advantages of this Thermometer

Multiple Use (Wide Range Measurement)

The IR 1DE1 offers a wide measurement range feature from 0 - 100.0 °C

(32.0 - 212.0 °F); meaning the unit can be used as an ear thermometer to

measure body temperature, but it can also be used to measure surface

temperature of following objects:

• Milk surface temperature in baby's bottle.

• Surface temperature of baby's bath.

• Ambient temperature.

Probe Cover Free

Since a probe cover is not required with this thermometer it makes

using the IR 1DE1 more user-friendly and more cost-effective.

Measurement in 1 second

The innovative infrared technology allows measurement of ear

temperature in only 1 second.

Accurate and reliable

The unique probe assembly construction, incorporating an advanced

infrared sensor ensure that each measurement is accurate and reliable.

Gentle and Easy to Use

• The ergonomic design enables simple and easy use of the ther-

mometer.

• This thermometer can be used even on a sleeping child, thereby

causing no interruption.

• This thermometer is fast and therefore pleasant to use for children.

Auto-Display Memory

The last reading is automatically displayed for 2 seconds when the

unit is switched ON.

Multiple Reading Recalls

Users will be able to recall the last 12 readings when entering the

recall mode, enabling efficient tracking of temperature variations.

Safe and Hygienic

• No risk of broken glass or mercury ingestion.

• Completely safe for use on children.

• Cleaning of the probe tip can be done with an alcohol-moistened

cotton tissue, making the IR 1DE1 completely hygienic for use by

the whole family.

High Temperature Indication

10 short beeps and a red LCD backlight alert the patient that he/she

may have a temperature above 37.5 °C.

2. Important Safety Instructions

• Never use the thermometer for purposes other than those it has

been intened for. Please follow the general safety precautions

when using on children.

•Never immerse this thermometer into water or other

liquids (not waterproof). For cleaning please follow the

instructions in the «Cleaning and Storage» section.

• Keep the instrument away from direct exposure to the sun and

keep it in a dust-free, dry area at a temperature between

5 - 40 °C (41 - 104 °F).

• Do not use the thermometer if there are signs of damage to the

measuring tip or to the instrument itself. If damaged, do not

attempt to repair the instrument! Please contact your nearest

Microlife customer service department.

• Earwax in the ear canal may cause a lower temperature reading.

Therefore it is important to ensure the subject's ear canal is clean.

• This thermometer consists of high-quality precision parts. Do not

drop the instrument! Protect it from severe impact and shock. Do

not twist the instrument and the measuring probe!

WARNING:

•Use of this thermometer is not intended as a substitute for

consultation with your physician.

•Thermometer is not waterproof! Please NEVER immerse

into liquids without a probe cover.

3. Product Description

(1) Probe

(2) START button

(3) LCD Display

(4) O/I button

(5) Battery Cover

(2)

(3)

(4)

(5)

(1)

4. How this Thermometer Measures Ear Temperature

This thermometer measures infrared energy radiated from the eardrum

and the surrounding tissue. This energy is collected through the lens

and converted to a temperature value. The measured reading obtained

directly from the eardrum (Tympanic Membrane) can ensure the most

accurate ear temperature.

Measurements taken from the surrounding tissue of the ear canal

generate lower readings and may result in misdiagnosis of a fever.

To avoid an inaccurate measurement:

• Switch on the thermometer by pressing the O/I button.

• After one beep is heard (and the temperature scale icon is flas-

hing), straighten the ear canal by gently pulling the middle of the

ear back and up.

• Place the probe firmly into the ear canal, press the START button

and keep the probe in the ear until the thermometer beeps to

identify the completion of the measurement.

This thermometer has been clinically tested and proven to be

safe and accurate when used in accordance with its operating

instruction manual.

5. Control Displays and Symbols

LCD Display Display

Meaning

All segments

displayed

Memory

Ready

Measurement

complete

Out-of-ear

temperature

indication

Low battery

indication

Description

Press the O/I button to

turn on the unit, all seg-

ments will be shown

for 2 seconds.

The last reading will be

shown on the display

automatically for

2 seconds.

The unit is ready for

measurement, the °C or

°F icon will keep

flashing.

The reading will be shown

on the LCD display with

the °C or °F icon flashing,

the unit is ready again for

the next measurement.

A crossed-ear-icon

shown on the LCD if the

reading falls outside the

range 32.0 ~ 42.2 °C

(89.6 ~ 108.0 °F)

When the unit is turned

on, the battery icon will

keep flashing to remind

the user to replace the

battery.

6. Directions for Use

1. Press the O/I button. The LCD is activated

to show all segments for 2 seconds.

2. The last measurement reading will be

shown on the display automatically for

2 seconds with the «M» icon.

3. When the °C or °F icon is flashing, a beep

sound is heard and the thermometer is

ready for measurement.

4. Straighten the ear canal by pulling the ear

up and back to give a clear view of the

eardrum.

• For children under 1 year:

Pull the ear straight back.

• Children above 1 year and adults:

Pull the ear up and back.

5. While gently pulling the ear, insert the probe

snugly into the ear canal and press the

START button. Release the button and wait

for the beep sound. This is the indication that

confirms the end of measurement.

6. Remove the thermometer from the ear canal.

The LCD displays the measured temperature.

NOTE:

• 10 short beeps will sound and a red LCD backlight will illuminate

when the temperature is higher than 37.5 °C (99.5 °F) in order to

alert the patient that he/she may have a temperature above 37.5 °C.

•In order to assure the accurate readings, plase wait at least

30 seconds after 3-5 continuous measurements.

• Accumulation of ear wax on the probe tip can result in less accurate

temperature readings or cross infection between users. Therefore,

it is essential that a clean probe tip is used before each

measurement. Please follow the instructions in the «Cleaning and

Storage» section for cleaning.

•After cleaning the probe tip with alcohol, it is necessary to

wait 5 minutes before taking the next measurement, in order to

allow the thermometer to reach its operating reference temperature.

• For an infant, it is best to have the child laying flat with his head

sideways so the ear is facing upwards. For an older child or adult,

it is best to stand behind and slightly to the side of the patient.

• Always take the temperature in the same ear, since the tempera-

ture readings may be different from the right ear and left ear.

• Wait for a few minutes to take the ear temperature after sleeping.

• In the following situations it is recommended that 3 measurements

are done in the same ear and the highest one is taken as the reading:

1) New born infants in the first 100 days.

2) Children under three years of age with a compromised immune

system and for whom the presence or absence of fever is critical.

3) When the user is learning how to use the IR thermometer for the

first time until he/she has familiarized himself/herself with the

instrument and obtains consistent readings.

7. Changing from Fahrenheit to Celsius and vice-versa

The thermometer can display temperature measurements in either Fah-

renheit or Celsius. To switch the display between °C and °F, simply turn

OFF the unit, press and hold the START button for 5 seconds until «-- -»

and the flashing °C or °F icon is shown on the LCD. Switch the measure-

ment scale between °C and °F by pressing the START button again. When

the measurement scale has been chosen, wait for 5 seconds and the unit

will enter the ready for measuring mode automatically.

Autres manuels pour IR 1DE1

Table des matières

Langues :

Autres manuels Microlife Thermomètre

Microlife

Microlife NC 150 Manuel utilisateur

Microlife

Microlife 16F1 Manuel utilisateur

Microlife

Microlife IR 1DE1 Manuel utilisateur

Microlife

Microlife MT 600 Manuel utilisateur

Microlife

Microlife MT18L1-PRO Manuel utilisateur

Microlife

Microlife FR1MF1 Manuel utilisateur

Microlife

Microlife VT 1831 Manuel utilisateur

Microlife

Microlife IR210 Manuel utilisateur

Microlife

Microlife MT 3001 Manuel utilisateur

Microlife

Microlife IR200 Mode d’emploi

Microlife

Microlife VT 1831 Manuel utilisateur

Microlife

Microlife mt 16c2 Manuel utilisateur

Microlife

Microlife MT16K1-PRO Manuel utilisateur

Microlife

Microlife NC300 Manuel utilisateur

Microlife

Microlife NC 400 Manuel utilisateur

Microlife

Microlife MT 60 Manuel utilisateur

Microlife

Microlife MT 100 Manuel utilisateur

Microlife

Microlife MT 1931 Instructions d'utilisation et d'installation

Microlife

Microlife MyColor MT 16B1 Manuel utilisateur

Microlife

Microlife PT 200 Manuel utilisateur

Microlife

Microlife NC 150 Manuel utilisateur

Microlife

Microlife FR 1DZ1 Manuel utilisateur

Microlife

Microlife IR 120 Manuel utilisateur

Microlife

Microlife MT 1951 Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur

Veridian Healthcare

Veridian Healthcare 09-349 Manuel utilisateur
