Pulsar EX
EX 700RT / EX 1000RT
EX 1500RT
Installation and User
Manual
MGE UPS SYSTEMS,INC.
SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be followed during
installation and maintenance of the UPS and batteries.
Thank you for selecting an MGE UPS SYSTEMS, INC. product to protect your electrical equipment.
The Pulsar EX RT range has been designed with the utmost care.
We recommend that you take the time to read this manual to take full advantage of your UPS’s many features.
MGE UPS SYSTEMS, INC. pays great attention to the environmental impact of its products.
Measures that have made Pulsar EX RT a reference in environmental protection include:
◗The eco-design approach used in product development,
◗Recycling of Pulsar EX RT at the end of its service life.
To discover the entire range of MGE UPS SYSTEMS, INC. products and the options available for the Pulsar EX RT
range, we invite you to visit our web site at www.mgeups.com or contact your MGE UPS SYSTEMS, INC. representative.
This manual contains important instructions for Pulsar EX RT Models that must be followed during installation, operation
and maintenance of the UPS and batteries.
The Pulsar EX RT models that are covered in this manual are listed below:
UPS EX 700RT (700VA/490W), part number 85070.
UPS EX 1000RT (1000VA/700W), part number 85100.
UPS EX 1500RT (1500VA/1050W), part number 85150.
For extended back up time, the above UPS’s can be used with the optional extended battery module, Pulsar EXB 1500RT
(36Vdc, 14Ah), part number 85001.
The UPS Pulsar EX 700RT, EX 1000RT, and EX 1500RT are intended for installation in an environment within 0 to 40°C,
free of conductive contaminant.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
Important safety instructions
Read before installing product
Introduction
Page 2 - 86-153850-00 A01
86-153850-00 A01 - Page 3
CAUTION: Safety of persons
◗
The UPS has its own internal power source (the battery). Consequently, the power outlets may be energized even if the UPS
is disconnected from the AC power source.
◗
Dangerous voltage levels are present within the UPS. It should be opened exclusively by qualified service personnel.
◗
The UPS must be properly grounded. Measurements are required to ensure that the total leakage current of the UPS and the
protected equipment does not exceed 3.5 mA by checking their characteristics (maximum leakage current of the UPS = 2 mA).
◗
The battery supplied with the UPS contains small amounts of toxic materials. To avoid accidents, the directives listed below
must be observed:
- Never burn the battery (risk of explosion).
- Do not attempt to open the battery (the electrolyte is dangerous for the eyes and skin).
- Comply with all applicable regulations for the disposal of the battery.
- Batteries constitute a danger (electrical shock, burns). The short-circuit current may be very high. Precautions must be
taken for all handling: remove watches, rings, bracelets and any other metal objects, use tools with insulated handles.
- Do not lay tools or metal parts on top of batteries.
CAUTION: Product Safety
◗
The UPS connection instructions and operation described in the manual must be followed in the indicated order.
◗
UPS must be connected to a nearby wall outlet that is easily accessible. The UPS can be disconnected from the AC power
source by removing the power cord.
◗
Check that the indications on the rating plate correspond to your AC powered system and to the actual electrical consumption
of all the equipment to be connected to the UPS.
◗
Never install the UPS near liquids or in an excessively damp environment.
◗
Never let a foreign body penetrate inside the UPS.
◗
Never block the ventilation grates of the UPS.
◗
Never expose the UPS to direct sunlight or source of heat.
◗
If the UPS must be stored prior to installation, storage must be in a dry place.
◗
The admissible storage temperature range is -25ºC to +55ºC.
Special Precautions
◗
All handling operations will require at least two people (unpacking, installation in rack system).
◗
Once installed and connected to the AC power source for the first time, the battery will start to charge. Full charging to obtain
the rated battery backup time requires at least 8 hours.
◗
Before and after the installation, if the UPS remains de-energized for a long period, the UPS must be energized for a period of
24 hours, at least once every 6 months (for a normal storage temperature less than 25°C). This charges the battery, thus
avoiding possible irreversible damage. During the replacement of the battery module, it is imperative to use the same type and
number of element as the original battery module provided with the UPS to maintain an identical level of performance and
safety. In case of doubt, don’t hesitate to contact our after sales department (for more information, refer to the web site
www.mgeups.com).
Introduction
Page 4 - 86-153850-00 A01
Using this document
How to use this document
Icon Usage
Information may be found primarily by consulting:
◗The contents,
◗The index.
In the illustrations on the following pages, the symbols below are used:
LED off.
LED on.
LED flashing.
Audio indication.
Action.
Visual indication.
Notes, tips and information, help.
CAUTION: Hazard to personnel or equipment, information that must always be followed.
WARNING: Eminent hazard to personnel or equipment, information must always be followed.
Important information, help.
86-153850-00 A01 - Page 5
1. Presentation
1.1 System configurations ................................................................................................................7
Rack setup ......................................................................................................................................7
Tower setup ....................................................................................................................................7
1.2 Rear panel ......................................................................................................................................8
Pulsar EX 700RT, EX 1000RT, EX 1500RT, EXB 1500RT ............................................................8
1.3 Control panel ................................................................................................................................9
2. Installation
2.1 Unpacking ....................................................................................................................................10
2.2 Installation in rack position ........................................................................................................11
2.3 Installation in tower position ....................................................................................................12
2.4 Connection to the RS232 or USB communication port (optional) ........................................13
2.5 Installation of the optional communication-card ....................................................................13
2.6 Connections ................................................................................................................................14
3. Operation
3.1 Start-up ........................................................................................................................................15
3.2 LED indicators ............................................................................................................................15
3.3 Operation on battery power (following failure of AC input power) ............................................16
Transfer to battery power ..............................................................................................................16
Threshold for the low-battery warning............................................................................................16
End of backup time ........................................................................................................................16
3.4 Personalization (optional) ............................................................................................................17
Function..........................................................................................................................................17
"ON / OFF conditions" tab..............................................................................................................17
"Battery" tab ..................................................................................................................................17
"Output" tab....................................................................................................................................18
"Bypass" tab ..................................................................................................................................18
3.5 UPS Shutdown ............................................................................................................................18
3.6 UPS Remote Power Off ..............................................................................................................19
Contents
Page 6 - 86-153850-00 A01
4. Maintenance
4.1 Troubleshooting ..........................................................................................................................20
4.2 Replacement of the battery module ..........................................................................................22
5. Environment ....................................................................................................................................24
6. Appendices
6.1 Technical characteristics ..........................................................................................................25
6.2 Glossary ......................................................................................................................................26
6.3 Index ............................................................................................................................................27
Contents
PU L SA R
www.mgeups.com
100%
80%
50%
20%
test%
1
2
%
BYPASS
EX
86-153850-00 A01 - Page 7
Tower setup
Rack setup
1.1 System configurations
1. Presentation
www.mgeups.com
P U L S A R
3.4 inches
(2U)
18.75 inches
(EX 700RT/EX 1000RT/EX 1500RT)
17.25 inches (19" Rack mount)
100%
80%
50%
20%
test%
1
2
%
BYPASS
E X
Model Part Weight
Number (Ibs/kg)
Pulsar EX700RT 85070 42.0 lbs (19.0 kg)
Pulsar EX1000RT 85100 42.0 lbs (19.0 kg)
Pulsar EX1500RT 85150 46.0 Ibs (20.5 kg)
Page 8 - 86-153850-00 A01
4
11
10
1
83
2
5
12
9
12
Pulsar EXB 1500RT (optional)
Pulsar EX1500RT
11
10
8
9
7
6
5
4
3
2
1Slot for communication-card option.
RS232 communication port.
USB communication port.
Six NEMA 5-15/20R (EX 1500 RT), six
NEMA-5-15R (EX 700 RT, EX 1000 RT)
receptacles for connection to AC power
load.
Two programmable NEMA 5-15/20R
(EX 1500 RT), two programmable
NEMA-5-15R (EX 700 RT, EX 1000 RT)
receptacles.
Pushbutton to test phase/neutral
inversion of AC power source.
LED indicating Site Wiring Alarm
Enable, with flashing and intermittent
buzzer. Reset fault with rear panel
button.
Connector for remote power off (RPO).
Connector for automatic detection of an
additional battery module.
Connector for an additional battery
module.
NEMA 5-15P Input power plug for direct
connection to AC power source.
Circuit breaker for battery ON/OFF and
protection.
1.2 Rear panel
1. Presentation
10 10
7
6
9
NOTE: The EXB 1500RT extended battery module is designed
to work with all EX700RT, EX100RT, EX1500RT UPS units.
Pulsar EX700RT/EX1000RT
4
11
10
1
83
2
5
7
6
9
86-153850-00 A01 - Page 9
27
2625
2423222120191817
16
(*) : ◗flashing LED + buzzer: battery fault (battery must be replaced).
◗flashing LED + long buzzer (once per hour): theoretical end of battery life (replacement recommended).
UPS
overload
Electronics
fault
Battery
fault *
Site Wiring
Fault
26
27
%
load
100%
80%
50%
20%
Press simultaneously at
least 3 seconds to reset
the “End of battery life”
alarm. 24
25
23
22
21
20
19
18
17
16
Status change in
progress.
Supplied with power
Operation on battery power.
Status of programmable outlet 2:
Operation in ON-LINE mode (backup power available).
Operation on bypass (no backup power available).
Status of programmable outlet 1:
1. Presentation
%
battery
remaining
100%
80%
50%
20%
ON / OFF.
◗Lamp test or buzzer OFF.
◗Forced transfer to bypass and back
by pressing button 3 times in less
than 5 seconds.
Hold down to display
percent load:
Alarms
1.3 Control panel
100%
80%
50%
20%
test %
1
2
%
BYPASS
Page 10 - 86-153850-00 A01
33
33
35
34
35
34
30
32
31
30
32
31
RS232 communication cable.
USB communication cable.
Telescopic rails for mounting in 19" bay with mounting hardware.
CD-ROM with the Solution-Pac and UPS Driver software.
Product documentation.
Two tower supports for the upright position.
2.1 Unpacking
2. Installation
PU L S A R
EX
www.mgeups.com
100%
80%
50%
20%
test%
1
2
%
BYPASS
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels MGE UPS Systems UPS
MGE UPS Systems
MGE UPS Systems Upsilon STS 30A Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar Evolution 1100 Tower Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Protection Center 420 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems 11+ Manuel utilisateur
MGE UPS Systems
MGE UPS Systems PULSAR EVOLUTION 3000 XL Manuel d'instructions
MGE UPS Systems
MGE UPS Systems Evolution 2000 RT 2U Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar 700 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Comet EXtreme CLA Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar EXtreme CLA 2000 VA Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Comet Series Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar Evolution 800 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems EX 11RT Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Comet EX 11 RT 3:1 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems 250A Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar Evolution 1100 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Nova 600 AVR Manuel utilisateur
MGE UPS Systems
MGE UPS Systems PULSAR EVOLUTION 2200 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar EXtreme2000 Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar Extreme 1500 VA Manuel utilisateur
MGE UPS Systems
MGE UPS Systems Pulsar EXtreme 1500 Manuel utilisateur
Manuels UPS populaires d'autres marques
Pylontech
Pylontech Victron & Pylontech US5000 Manuel utilisateur
Tecnoware
Tecnoware EVO DSP PLUS MM 6.8 Manuel utilisateur
Mecer
Mecer ME-1000-WTU Manuel utilisateur
Mustek
Mustek PowerMust 530(B) Plus Manuel d'installation et d'exploitation
Emerson
Emerson Liebert NXL series Manuel utilisateur
MAKELSAN
MAKELSAN BOXER SERIES Manuel utilisateur
