Meyer's VB750 Manuel utilisateur

Manufactured in DORCHESTER, WISCONSIN by

MEYER’S EQUIPMENT

Mfg. Corp.

INSTRUCTION AND PARTS BOOK - Rev. S3

HEAVY DUTY MANURE SPREADERS

MODEL: VB750

DO NOT –

NEVER –

Operate This Spreader Until You Have

Completely Read This Book!

Repair or Clean This Spreader While

PTO is Engaged!

2 | P a g e

MODEL SPECIFICATIONS

Width of Box Inside

80”

Overall Width

11’ 1-3/4”

Length of Box Inside

213”

Depth

46”

Overall Length

29’ 3-1/4”

Overall Height (Front)

106-1/2”

Ground Clearance

15”

App. Capacity (Bushel)

750

App. Capacity (Struck Cu. Ft.)

482

App. Weight

13,340

Loading Height

82-1/2”

Apron Chain (Standard)

Twin #67P11

Apron Chain (Optional)

Twin #667XH Pintle / Twin #88W Pintle

Beaters

Twin Ø 39” Vertical Beaters

w/ 15MM Thick Spiral Flighting

Spindle Diameter

3-3/8”

Spindle/Hub Load Rating –Each

15,000 LBS

Tire Size (Standard)

1600-R20

Tire Size (Optional)

600/55 x 26.5 Flotation Tires

PTO Speed

1,000 RPM

Min. Tractor Horsepower

175

Min. Hydraulic Flow

14 GPM

3 | P a g e

INTRODUCTION

Congratulations on the purchase of your new

Meyer’s Manure Spreader. With its optional

equipment this is the simplest, most flexible system

on the market today. With proper operation and

preventative maintenance, it will last for many

years.

This SAFETY ALERT SYMBOL means

ATTENTION! BE CAREFUL! YOUR SAFETY IS

INVOLVED! It stresses an attitude of HEADS UP

FOR

SAFETY. When you see this symbol, be

alert to the

possibility of PERSONAL INJURY and

carefully read

the message that follows.

WARNING:

NEVER OPERATE WITHOUT ALL COVERS,

SHIELDS AND GUARDS IN PLACE. KEEP

HANDS,

FEET AND CLOTHING AWAY FROM

MOVING

PARTS. SOME COVERS AND

GUARDS HAVE

BEEN REMOVED FOR

ILLUSTRATIVE PURPOSES

ONLY IN THIS

MANUAL. FAILURE TO HEED MAY

RESULT IN

SERIOUS PERSONAL INJURY OR

DEATH.

At the front of this manual is a Product Registration

and Inspection Certificate. Be sure your dealer has

completed this certificate and forwarded a copy to the

manufacturer to validate the manufacturer’s warranty.

The product model and serial number are recorded

this certificate for your convenience and for proper

identification of your spreader by your dealer and the

manufacturer when ordering repair parts.

The serial number plate is found on the upper left front

corner of the spreader box or stamped in the left channel

at the front. For information on ordering repair parts, refer

to the repair parts section of this manual. Orders must list

the complete description, correct part number, and total

amount required.

All references to right hand and left hand apply to the

product as viewed from the rear of the machine and

facing the direction of forward travel.

You are urged to study this manual and follow the

instructions carefully. Your efforts will be repaid in better

operation and service as well as a savings in time and

repair expense. Failure to read this manual and

understand the machine could lead to serious injury. If

you do not understand instructions in this manual, contact

either your dealer or Meyer’s Equipment Manufacturing

Corp.

This supersedes all previous published instructions.

Contact Information

Meyer’s Equipment Mfg. Corp.

701 W Bus Cty Rd A

P.O. Box 406

Dorchester, WI 54425

Phone: (715)-654-5200

Fax: (715)-654-5558

Email: emcdorche[email protected]

4 | P a g e


TABLE OF CONTENTS
INTRODUCTION .............................................................................................................................................. 3
 SAFETY................................................................................................................................................... 6
 SAFETY SIGNS......................................................................................................................................... 8
MANURE SPREADER SAFETY.................................................................................................................. 10
MANDATORY SAFETY SHUTDOWN PROCEDURE..................................................................................... 11
PRE-OPERATION ........................................................................................................................................... 12
GENERAL............................................................................................................................................................ 12
TRACTOR HITCH AND PTO REQUIREMENTS ...................................................................................................... 12
TRACTOR SIZE REQUIREMENTS .......................................................................................................................... 13
HYDRAULICSYSTEM........................................................................................................................................... 13
TRANSPORTING ................................................................................................................................................. 15
OPERATION.................................................................................................................................................. 16
TRACTOR HOOKUP............................................................................................................................................. 16
LOADING............................................................................................................................................................ 16
UNLOADING....................................................................................................................................................... 16
 MANDATORY SAFETY SHUTDOWN PROCEDURE...................................................................................... 17
MAINTENANCE, ADJUSTMENTS & LUBRICATION ........................................................................................... 18
WHEEL AND TIRE MAINTENANCE AND REPAIR................................................................................................. 18
LOCK RING RIM.................................................................................................................................................. 18
REAR-AUTOMATIC OVER RUNNING CLUTCH .................................................................................................... 18
 MANDATORY SAFETY SHUTDOWN PROCEDURE..................................................................................... 18
ADJUSTMENTS................................................................................................................................................... 19
LUBRICATION..................................................................................................................................................... 19
CLEANING AND STORAGE.................................................................................................................................. 21




5 | P a g e


REPLACMENT PARTS..................................................................................................................................... 22
MAIN FRAME &BOX PARTS................................................................................................................................... 22
HYDRAULIC END GATE &RELATED PARTS, STANDARD SWING GATE.................................................................... 24
AXLES, WHEELS, SPINDLES AND RELATED PARTS .................................................................................................. 26
DRIVELINE &RELATED PARTS, VERTICAL BEATERS................................................................................................ 28
APRON &RELATED PARTS, STANDARD 67P11....................................................................................................... 30
APRON &RELATED PARTS, OPTIONAL 667XH PINTLE............................................................................................ 32
APRON &RELATED PARTS, OPTIONAL 88W PINTLE............................................................................................... 34
LUBE BANK, APRON SHAFT.................................................................................................................................... 36
BEATER HEAD ASSEMBLY, 15MM STANDARD ....................................................................................................... 38
VERTICAL BEATERS &RELATED PARTS................................................................................................................... 40
VERTICAL BEATER LUBRICATION KIT ..................................................................................................................... 42
APRON DRIVE GEARBOX........................................................................................................................................ 44
REMOVABLECVTELESCOPINGUNIVERSALJOINTASSEMBLYWITHGUARD, TRAILER TO TRACTOR ................................. 46
35EUNIVERSALJOINT,TELESCOPINGASSEMBLYW/GUARD-REARWITH OVER-RUNNINGCLUTCH........................... 47
YOKE &CLUTCH HUB ASSEMBLY ........................................................................................................................... 48
OVER-RUNNING CLUTCH ASSEMBLY ..................................................................................................................... 49
HIGHWAY LIGHTING, STANDARD .......................................................................................................................... 50
HYDRAULIC ASSEMBLY, SWING GATE.................................................................................................................... 52
HYDRAULIC ASSEMBLY, APRON, STANDARD......................................................................................................... 54
HYDRAULIC ASSEMBLY, APRON, ELECTRIC FLOW CONTROL ................................................................................. 56
HYDRAULIC ASSEMBLY, APRON, MANUAL FLOW CONTROL ................................................................................. 58
SCALE KIT COMPONENTS....................................................................................................................................... 60
LIMITED WARRANTY STATEMENT ................................................................................................................. 62


6 | P a g e

SAFETY

A brief definition of signal words that may be used in

this manual:

DANGER: Indicates an imminently hazardous

situation that, if not avoided, will result in serious injury

or death.

WARNING: Indicates a potentially hazardous

situation that, if not avoided, could result in death or

serious injury, and includes hazards that are exposed

when guards are removed.

CAUTION: Indicates a potentially hazardous

situation that, if not avoided, may result in minor or

moderate injury.

DECALS ARE ILLUSTRATED ON PAGES 8 and 9.J K D G

Also under

shield

ON PTO FRONT

HALF

FTypical Illustration

Located on Driveline

Shields under spreader

CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST

BE REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE

REPLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU

REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT.

7 | P a g e

DECALS ARE ILLUSTRATED ON PAGES 7 and 8.

CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE

REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE

REPLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU

REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT.

8 | P a g e

DECAL A. PART NO. VB107

SAFETY SIGNS

DECAL B. PART NO. SW105

DECAL D. PART NO. 700

DECAL E. PART NO. 3003

DECAL G. PART NO. 3006

DECAL I. PART NO. 3001

CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE

REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE

REPLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU

REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT.

DECAL C. PART NO. SW102

DECAL F. PART NO. 3004

DECAL H. PART NO. SW406

9 | P a g e

CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE

REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE

REPLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU

REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT.

DECAL S.

PART NO. VB104

DECAL R.

PART NO. VB103

START UP PROCEDURE

1. Make certain everyone is clear of machine before starting

engine or operation.

2. Turn Flow Control to Slowest Position.

3. Engage P.T.O.

4. RAISE END GATE.

5. Engage Tractor Hydraulic Lever to Full Flow Position.

6. Start Apron by Rotating Flow Control Dial Clockwise.

DECAL O. PART NO. 3011

DECAL P.

PART NO. VB101

DECAL Q.

PART NO. VB102

DECAL M. REFLEC-

TIVE TAPE-RED

PART NO. PM17-5915

DECAL L. REFLEC-

TIVE TAPE-YELLOW

PART NO. PM17-5910

DECAL K. PART NO. SW2000

DECAL J. PART NO. SW2001

DECAL U.

PART NO. VB106

DECAL V.

PART NO. 3014

10 | P a g e

MANURE SPREADER SAFETY

CAUTION

THERE ARE INHERENT HAZARDS ASSOCIATED WITH THE OPERATION OF A MANURE SPREADER.

FOR YOUR SAFETY:

•Never Enter Spreader Box While In Operation For Any Reason.

•Only Properly Instructed People Should Operate The Spreader. Do Not Allow Children Or Inexperienced Persons

To Operate Spreader.

•Keep All Guards and Shields In Place. Moving Parts Can Crush And Dismember.

•Clear The Area Before Equipment Start Up.

•Keep Hands, Feet, and Loose Clothing Away From Moving Parts.

•Do Not Go Near The Spreader Beaters While Machine Is Operating.

•Make Sure The PTO Is Securely Locked To Both The Tractor And Spreader Before Operating The Unit.

•Do Not Operate The PTO At Speeds Higher Than The Manufacturers Recommendations.

•Highway Traffic Is Not To Exceed 20 Mph. The Tires Supplied Are For Farm Use Only And Are Not Designed For

Use Above This Speed Unless Equipped With High Speed Highway/Off-Road Farm Tires.

•Use Adequate Safety Chains When Towing The Spreader.

•The Use of a Slow moving Vehicle Sign Is Required on All Public Roads Unless Equipped with Flashing Hazard

Lights. Obey All Applicable Highway Safety Laws And Rules.

•Always Use A Tractor Large Enough To Provide Sufficient Braking Assistance When Towing A Loaded Spreader.

•Use Caution When Traveling Over Uneven Terrain And When Approaching Stops.

•Do Not Load The Spreader Unless It Is Hitched To The Tractor.

•Do Not Unhitch A Loaded Spreader From The Tractor, Leaving It Supported By Only The Jack.

•Park Your Spreader on Level Ground and Place Blocks Ahead Of and Behind The Wheels Before Unhooking

From Tractor To Avoid Unexpected Rolling When Separated From The Tractor.

•Do Not Allow Riders on Spreader.

FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH

CAUTION

THERE ARE ADDITIONAL HAZARDS ASSOCIATED WITHTHE SERVICE AND MAINTENANCE OF YOUR

SPREADER.

FOR YOUR SAFETY:

•Inspect When First Delivered And Regularly Thereafter; That All Connections And Bolts Are Tight And Secure

Before Operating.

•Retighten All Wheel Bolts After The First Hour Of Towing. Check Periodically Thereafter. See Maintenance,

Wheels.

•Maintain Proper Tire Air Pressure At All Times. See Maintenance, Tires.

•Always Wear Eye Protection When Operating Or Servicing Spreader.

•Be Sure All Movement Has Stopped, The PTO Is Disconnected, The Tractor Is Shut Off And The Ignition Key Is

Removed Before Servicing The Spreader Or Components.

•Escaping Hydraulic Fluid Under Pressure Can Penetrate The Skin And Cause Serious Injury. Relieve All

Pressure From The Hydraulic System Before Connecting Or Disconnecting The Lines Or Making Repairs. Check

All Hoses and Fittings Before Start-up and Periodically During Operation.

•Never Make Any Alterations Or Modifications To This Equipment.

FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH

Autres manuels pour VB750

Table des matières

Autres manuels Meyer's Matériel agricole

Meyer's

Meyer's VB560 Manuel utilisateur

Manuels Matériel agricole populaires d'autres marques

GSi

GSi PNEG-2314 Manuel utilisateur

Checchi & Magli

Checchi & Magli TEXDRIVE Manuel utilisateur

Amazone

Amazone Cenius 4003-2TX Manuel utilisateur

MASSEY FERGUSON

MASSEY FERGUSON MF 9313S Manuel utilisateur

Cima

Cima BLITZ Instructions d'utilisation et d'entretien

Amazone

Amazone CombiDisc 3000 Instructions d'installation

HE-VA

HE-VA Disc-Roller XL Contour Manuel utilisateur

AGT

AGT AGT-SSFM Manuel utilisateur

Milestone

Milestone 72-84 Manuel utilisateur

KUHN

KUHN Hector 3000 Manuel utilisateur

Krone

Krone X-Disc 6200 Manuel utilisateur

Eliet

Eliet DZC450 Manuel utilisateur

Taarup

Taarup BIO+ B4000 Manuel utilisateur

Garland

Garland SHAKER 310 DPG Manuel utilisateur

stable comfort

stable comfort StableWall System Manuel utilisateur

Raven

Raven AccuBoom Manuel utilisateur

International

International 710 Manuel utilisateur

Ashland

Ashland HDW-3217-14 Manuel utilisateur
