Magnetic precision has a name

Magnetic Field Camera

MFC2046

EN Installation and Safety Manual

FR Manuel d'installation et de sécurité

Version 1.0 (Revision 1.5)

December 2019

www.metrolab.com

REVISION HISTORY

v. 1.0 r. 1.0

August 2018

First release

v. 1.0 r. 1.1

August 2018

Text updates

v. 1.0 r. 1.2

December 2018

Text updates on remote

v. 1.0 r. 1.3

December 2018

FCA7046 Specification updates

v. 1.0 r. 1.4

May 2019

Temperature specification updates on MFC9046

v. 1.0 r. 1.5

December 2019

Update RB8045 connection on FCA7046

i www.metrolab.com

CONTENTS

1- General............................................................................................................1

1-1 Scope 1

1-2 Intended Use....................................................................................................................................... 1

1-3 Manufacturer Contact Information....................................................................................................... 1

2- Equipment Specifications .............................................................................2

2-1 Dimensions ......................................................................................................................................... 2

2-2 Ratings................................................................................................................................................ 4

2-2-1 PT2026 Main unit.................................................................................................................... 4

2-2-2 FCA7046 Amplifier Box ......................................................................................................... 5

2-2-3 MFC9046 Probe-Array ........................................................................................................... 5

2-3 Back Panel Connections ..................................................................................................................... 7

2-3-1 PT2026 Main unit.................................................................................................................... 7

2-3-2 FCA7046 Amplifier Box ......................................................................................................... 8

3- Unpacking.....................................................................................................10

4- Installation ....................................................................................................11

5- Operation ......................................................................................................13

5-1 Start-Up............................................................................................................................................. 13

5-2 Shut-Down ........................................................................................................................................ 13

5-3 Reset and Forced Power-Down ........................................................................................................ 13

6- Maintenance and Service ............................................................................15

6-1 Quality maintenance ......................................................................................................................... 15

6-1-1 PT2026 Calibration............................................................................................................... 15

6-1-2 MFC9046 Normalization ...................................................................................................... 15

6-2 Upgrades .......................................................................................................................................... 16

6-3 Troubleshooting ................................................................................................................................ 16

6-4 Repairs.............................................................................................................................................. 16

6-5 Warranty ........................................................................................................................................... 16

7- Disposal ........................................................................................................17

1 www.metrolab.com

BASICS

General

1-1 SCOPE

This manual describes the procedures for safe installation, operation,

maintenance, service and disposal of the Metrolab Magnetic Field Camera system

MFC2046. The latest version of this document can be downloaded from our web

site (see Section 1-3).

The Ue Maa, MFCToolV10 Ue Maa, describes the installation and

ea f he fae, a e a echca dea cceg he e

computer interface and software driver. This document is provided in electronic

form with the instrument, and can also be downloaded from our web site (see

Section 1-3).

1-2 INTENDED USE

The Magnetic Field Camera MFC2046 is a magnetometer, used to very precisely

eae ad a he f de (feld strength) of magnetic fields (e.g. MRI,

NMR ecc, ).

1-3 MANUFACTURER CONTACT INFORMATION

Metrolab Technology SA

110 Chemin du Pont-du-Centenaire

1228 Plan-les-Ouates, Switzerland

E-mail: [email protected]

Web site: www.metrolab.com

Telephone: +41 22 884 33 11

2 www.metrolab.com

BASICS

Equipment Specifications

2-1 DIMENSIONS

Main unit -

PT2026

210 x 125 x 324 mm

Amplifier Box -

FCA7046

210 x 61 x 112 mm

Probe-Array -

MFC9046, model

(HMxx-500)

337.4 x 29.4 x 524.4 mm

3 www.metrolab.com

Probe-Array -

MFC9046, model

HMxx-250

212.4 x 29.4 x 273.4 mm

Probe-Array

MFC9046, other

models

Other geometries available on request.

Probe-Array

cable length

4 m; custom upon request

4 www.metrolab.com

2-2 RATINGS

2-2-1 PT2026 Main unit

Power

55 VA, 100 240 VAC, 50-60 Hz

See warnings below.

Overvoltage

Accepts temporary overvoltages occurring on the

mains supply. Transient overvoltages up to the levels

of overvoltage category ll.

Fuse

3.15 A (T), 5x20 mm, 250 V

See warning below.

Environment

Indoor use; no air inlet (IP 50)

Operating temperature

10 40 °C

Storage / transport

temperature

-25 80 °C

Altitude

 2000 m

Relative humidity

Maximum 80 % for temperatures up to 31 °C,

decreasing linearly to 50 % relative humidity at 40 °C

Pollution

Pollution degree 2: only non-conductive pollution

occurs, except that occasionally a temporary

conductivity caused by condensation is to be

expected.

Magnetic environment

< 0.2 T

Electromagnetic

environment

Equipment intended to be used in an industrial

electromagnetic environment, class A.

See warning below.

5 www.metrolab.com

2-2-2 FCA7046 Amplifier Box

Environment

Indoor use; IP 40

Operating temperature

10 40 °C

Storage / transport

temperature

-25 80 °C

Altitude

 2000 

Relative humidity

Maximum 80 % for temperatures up to 31 °C,

decreasing linearly to 50 % relative humidity at 40 °C

Pollution

Pollution degree 2: only non-conductive pollution

occurs, except that occasionally a temporary

conductivity caused by condensation is to be

expected.

Magnetic environment

< 1 T

Electromagnetic

environment

Equipment intended to be used in an industrial

electromagnetic environment, class A.

See warning below.

2-2-3 MFC9046 Probe-Array

Frequency

Depends on model. See Probe-Array specification.

Environment

Indoor use

Operating temperature

10 40 °C

Storage / transport

temperature

-25 80 °C

Altitude

 2000 

Relative humidity

Maximum 80 % for temperatures up to 31 °C,

decreasing linearly to 50 % relative humidity at 40 °C

Pollution

Pollution degree 2: only non-conductive pollution

occurs, except that occasionally a temporary

conductivity caused by condensation is to be

expected.

Electromagnetic

environment

Equipment intended to be used in an industrial

electromagnetic environment, class A.

See warning below.

6 www.metrolab.com

CAUTION

Always use a three-prong IEC detachable power cord that is grounded,

rated for 250 V 10 A, and with adequate temperature ratings. The cord

should satisfy IEC 60245-1 for rubber insulated cables or IEC 60227-1 for

PVC insulated cables, as well as all applicable standards and legislation for

your region.

To avoid electric shock, the power cord protective grounding conductor

must be connected to ground.

The disconnecting device is the power plug. Ensure that it can be reached

in case of emergency.

For continued fire protection, use only the specified fuse see above.

The PT2026 Main Unit and the FCA7046 Amplifier Box contain

ferromagnetic components and may be subject to violent forces in a strong

magnetic field gradient.

The MFC2046 system is a class A product. In a domestic environment this

product may cause radio interference in which case the user may be

required to take adequate measures.

7 www.metrolab.com

2-3 BACK PANEL CONNECTIONS

2-3-1 PT2026 Main unit

Power

See Section 2-2 for ratings and warnings

Fuse

See Section 2-2 for ratings and warnings

Power switch

The front- and back-panel switches have the same

functions:

Power on: with power off, hold ~1 sec

Power off: with power on, press momentarily

Factory reset: with power on, hold until power-off

(~5 sec)

Forced shutdown: when system is hung, hold

until power-off (~10 sec)

FCA7046

The same connector is used for FCA7046 and other

PT2026 peripherals; proprietary pin-out. Plug the

male plug of the 3026 extension cable.

Trigger signal

BNC connector, TTL Level; trigger output or input:

Trigger output: flags when field attains a given

value; B rising, falling or either; pulse or level

; ca de 50.

Trigger input: determines when measurement is

taken; rising or falling edge; high impedance

input.
