WINE CABINET
DIONISIO
BACCO
Installation and Operation Manual
S/N: Validfrom: 20.03.2003 Rev.: 2.0
2025330, 2025331,
2025335, 2025336
20.3.2003 Rev. 2.0
Dear Customer,
Congratulations on deciding to choose a Metos appliance for your kitchen activities. You
made an excellent choice. We will do our best to make you a satisfied Metos customer
like thousands of customers we have around the world.
Please read this manual carefully. You will learn correct, safe and efficient working meth-
ods in order to get the best possible benefit from the appliance. The instructions and hints
in this manual will give you a quick and easy start, and you will soon note how nice it is
to use the Metos equipment.
All rights are reserved for technical changes.
You will find the main technical data on the rating plate fixed to the equipment. When you
need service or technical help, please let us know the serial number shown on the rating
plate. This will make it easier to provide you with correct service.
For your convenience, space is providedbelow for you to record your local Metos service
contact information.
METOS TEAM
Metos service phone number:...............................................................................................
Contact person:....................................................................................................................
20.3.2003 Rev. 2.0
20.3.2003 Rev.
1. General .......................................................................................................... 1
1.1 Symbols used in the manual .......................................................................................... 1
1.2 Symbols used on the appliance ...................................................................................... 1
1.3 Checking the relationship of the appliance and the manual .......................................... 1
2. Safety .............................................................................................................. 2
2.1 Safe use of the appliance ............................................................................................... 2
2.2 Disposal of the appliance ............................................................................................... 2
3. Functional description .................................................................................. 3
3.1 Intended use of the appliance ........................................................................................ 3
3.2 Construction .................................................................................................................. 3
3.3 Operating principle ........................................................................................................ 3
3.3.1 Operating switches and indicator lights ................................................................. 3
3.3.2 Alarms and warnings ............................................................................................. 4
4. Operating instructions ................................................................................. 5
4.1 Before using the appliance ............................................................................................ 5
4.2 Operation procedures ..................................................................................................... 5
4.3 After use ........................................................................................................................ 6
4.3.1 Cleaning ................................................................................................................ 6
4.3.2 Periodic checks ...................................................................................................... 6
4.3.3 If the appliance is to be out of use for long periods ............................................... 6
5. Installation ..................................................................................................... 7
5.1 Transporting and handling the appliance ...................................................................... 7
5.2 Installation ..................................................................................................................... 7
5.3 Electrical connections .................................................................................................... 7
6. Troubleshooting ............................................................................................ 8
7. Spare parts .................................................................................................... 9
7.1 Voltage codes .............................................................................................................. 11
7.2 Product codes ............................................................................................................... 11
8. Technical specifications .............................................................................. 21
20.3.2003 Rev.
20.3.2003 Rev. 2.0
General
1
1. General
Carefully read the instructions in this manual as they contain important information re-
garding proper, efficient and safe installation, use and maintenance of the appliance.
Keep this manual in a safe place for eventual use by other operators of the appliance.
The installation of this appliance must be carried out in accordance with the manufactur-
er’s instructions and following local regulations. The connection of the appliance to the
electric and water supply must be carried out by qualified persons only.
Persons using this appliance should be specifically trained in its operation.
Switch off the appliance in the case of failure or malfunction. The periodical function
checks requested in the manual must be carried out accordingto theinstructions. Have the
appliance serviced by a technically qualified person authorized by the manufacturer and
using original spare parts.
Not complying with the above may put the safety of the appliance in danger.
1.1 Symbols used in the manual
This symbol informs about a situation where a safety risk might be at hand. Given instruc-
tions are mandatory in order to prevent injury.
This symbol informs about the right way to perform in order to prevent bad results, appli-
ance damage or hazardous situations.
This symbol informs about recommendations and hints that help to get the best perform-
ance out of the appliance.
This symbol informs about a function that has to be taken into account in self-control.
1.2 Symbols used on the appliance
This symbol on a part informs about electrical terminals behind the part. The removal of
the part must be carried out by qualified persons only.
1.3 Checking the relationship of the appliance and the manual
The rating plate of the appliance indicates the serial number of the appliance. If the man-
uals are missing, it is possible to order new ones from the manufacturer or the local rep-
resentative. When ordering new manuals it is essential to quote the serial number shown
on the rating plate.
20.3.2003 Rev. 2.0
Safety
2
2. Safety
2.1 Safe use of the appliance
Before connecting the appliance to the mains check that the voltage and frequency are as
indicated on the rating plate.
It is recommended to connect the appliance to a specifically provided high sensitivity
(30 mA) differential security breaker.
Before cleaning or servicing the appliance, always disconnect it from the mains power
supply by turning the main switch to the 0 position and by detaching the plug from the
socket.
Never insert screwdrivers or other items between the fan grilles.
Never touch electrical parts with wet hands or barefoot.
To ensure efficient operation of the compressor unit, never block the air intakes.
In case of fire, do not use water. Obtain a CO2 (carbon dioxide) fire extinguisher and cool
the compressor compartment as quickly as possible.
Tampering with or removal of the safety devices adopted is absolutely forbidden.
2.2 Disposal of the appliance
The destroying of the appliance when the end of its economical lifetime has been reached
must be carried out in accordance with local rules and regulations. The appliance may
contain substances/materials which potentially have an adverse impact on the environ-
ment as well as recyclable materials. The best way ofdealing with such substances is best
done by using professional personnel specializing in recycling.
20.3.2003 Rev. 2.0
Functional description
3
3. Functional description
3.1 Intended use of the appliance
The appliance is designed for the storage and display of wine bottles.
3.2 Construction
The cabinet has a wooden frame and it is equipped with glass doors. The inside wall ma-
terial is white melamine. The bottle shelves are made of brass coated tubular steel. The
evaporator is made of aluminium, with corrosion-proof coating.
3.3 Operating principle
3.3.1 Operating switches and indicator lights
1. SET button/alarm
2. Temperature display
3. INCREASE button/Compressor running
4. DECREASE button/Defrosting in progress
5. Light switch (yellow)
6. Main switch (green)
Switching the appliance on
Press the green main switch (6) to supply power to the cabinet. The display will then show
the inside temperature of the cabinet. See “Setting the temperature” for checking or mod-
ifying the value set by the manufacturer.
20.3.2003 Rev. 2.0
Functional description
4
Setting the temperature
Press the SET button (1) for one second to display the temperature set in the factory. After
a while the setting value will start blinking. Now a new temperature setting can be made
by using the buttons(3) (INCREASE) and (4) (DECREASE). Press SET again to confirm
the new value.
Defrosting
Defrosting ofthe evaporatorisfully automatic; it takes place every 8hours and lasts45
minutes.
If necessary, defrosting can be started manually; a defrosting cycle starts if button (4) is
pressed for more than 5 seconds.
3.3.2 Alarms and warnings
E0 BLINKING: inside temperature sensor error
LO BLINKING: low temperature alarm
HI BLINKING: high temperature alarm
EE: thermostat operation error
ED BLINKING: defrosting insufficient
DF BLINKING: defrosting in progress
