DT Pro MPIII Systems Quick Start Guide
Program Wizard Screen Three
• In most applications, this screen will not require any adjustment. Press the F1 key for in-
depth detail.
• Select your desired MPRF Stop Option.
-Stop Logging when Full: Recommended setting. Logger will log data points up to
capacity and then stop logging.
-Use Data Compression: When selected, allows logger to log twice as many data
points by compressing data. Compressed data will be limited to two decimal places of
resolution.
-Never Stop: Newly collected data removes and replaces the oldest data in the logger’s
memory once full data capacity is reached.
• Select your RF Data Transmission Rate. Within limits, this allows adjustment of how often
logged data is transmitted via radio.
-The data transmission rate will usually be the same as the logging interval, but may be
less when the interval is short or the number of loggers is large. For example, it is not
usually necessary to transmit data collected every 2 seconds. In that instance, battery
life and real-time data reliability will be improved by setting the data transmission
interval to 10 seconds (5 data points per transmission) or 20 seconds (10 data points per
transmission).
-DT Pro automatically determines a minimum allowed transmission interval using
the default standard data packing. High Density Data Packing will allow a reduced
transmission interval, but there will be a decrease in RF communication reliability.
• Select Next.
