Facility Installation Instructions
In-Counter:
The 500-C station can be installed in any type of countertop material and the station has a
stainless-steel trim ring mounted to the unit. The Trim ring is not used when installed in the
optional stainless-steel cabinet.
1. Remove the Counter cut-out template from packaging.
2. Place template on top of counter at desired location with the round portion of the template
facing the front of the counter and the 2 tap cutouts towards the back. When placing
template on counter insure there is a 2” minimum clearance front and back and a 2 ½”
minimum clearance on the sides around the cutout above and below counter. Also make
certain that the centerline of the template is no more 3 –3 ½” offset to either the left or right
side of the drain centerline maximum for proper drain alignment and P-trap fitment. The top
of counter must be a minimum of 16” above the wall drain. Trace the outline of the template
onto the countertop.
a. Additional Notes:
i. Insure when Station is in counter that there is 2 ½” minimum clearance on
both sides of the Station above and below the counter for accessibility to the
inside of the Station.
ii. See drawings on the following pages of this manual for further instructions.
3. Cut out counter using appropriate tools and wearing the proper PPE and following safety
procedures.
4. Run a ¼” bead of clear of silicone ½” away from the entire counter cutout.
5. Slowly lower the hand-wash unit into the counter opening and press down to around the
edges of the plate so the silicone sticks to the countertop and the 500-C trim ring. Verify
station is square with the cabinet countertop front lip.
6. Center the unit in the opening.
7. Run a bead of silicone caulk (color of your choice) around the outside the trim ring and the
countertop and allow time for it to cure and hold the station in place.
8. Connect the hot/cold supply and drain lines. Do not hard pipe to water inlets of the Station –
Use flexible hoses. Plug in power cord. Install hand hygiene solution per instructions.
9. Turn water on and inspect for leaks.
10. Run 2-5 hand washes to prime Station. Station is now ready for operation.
CAUTION: Do not ground metal chassis during installation or operation.
Consult local and national codes: conformity and compliance to local and national codes is the
responsibility of the installer.
