Generation II
Electronic
Remote Control
OPERATIO N
MANUAL
© 2021 Mercury Marine
8M0180922 521 eng
TABLE OF CONTENTS
Section 1 - DTS Controls and Features
Electronic Remote Control (ERC).............................................. 2
Panel Mount ERC............................................................... 4
Single‑Handle Console ERC.............................................. 5
Dual‑Handle Console ERC................................................. 5
ERC Supplemental Display................................................ 7
Supplemental Display Menu Selection............................... 7
Settings...........................................................................7
Active Alarms..................................................................8
Alarms History................................................................ 9
About.............................................................................. 9
Electronic Remote Control (ERC) Operation ..................... 9
ERC Handle Friction and Detent Adjustment................... 10
Active Trim............................................................................... 10
Introduction to Active Trim................................................ 10
Modes of Operation...................................................... 10
Setup and Configuration............................................... 11
Active Trim ERC Controls................................................. 11
Active Trim Operation....................................................... 12
GPS.............................................................................. 12
Resume Functionality................................................... 12
Shallow Water Operation..............................................12
Trailer Position .............................................................13
Selecting the Correct Profile............................................. 13
What Trim Is................................................................. 13
How Trim Affects Boat Operation................................. 13
Boat Loading and Trim................................................. 14
Choosing an Active Trim Profile................................... 14
Active Trim Red Status Light............................................ 14
Single Flashing Red..................................................... 14
Double Flashing Red.................................................... 14
Engine Synchronization (Multiple Engines)............................. 14
Helm Transfer.......................................................................... 15
Transfer Light and Single‑Helm Boats.............................. 15
Requesting Helm Transfer................................................ 15
Helm Transfer and Autopilot............................................. 15
Quick Steer.............................................................................. 16
Throttle and Shift Operation with Three or Four Engines........ 16
Triple‑Engine Throttle and Shift Operation....................... 16
Quad‑Engine Throttle and Shift Operation....................... 17
Single‑Lever Mode (Multiple Engines)..................................... 18
Start/Stop All Engines.............................................................. 18
Engine Indicator LEDs........................................................18
No Engines Running ‑ Start Engines................................. 18
All Engines Running ‑ Stop Engines.................................. 18
Some (Not All) Engines Running ‑ Stop Engines............... 18
Interrupting the Start All Process........................................18
Throttle‑Only Mode.................................................................. 19
Section 2 - Premier ERC Display Software Update
Updating Through Wi‑Fi........................................................... 22 Updating Through USB Drive.................................................. 23
90-8M0180922 eng MAY 2021 Page i
Page ii 90-8M0180922 eng MAY 2021
Section 1 - DTS Controls and Features
Table of Contents
Electronic Remote Control (ERC)............................................ 2
Panel Mount ERC............................................................. 4
Single‑Handle Console ERC............................................ 5
Dual‑Handle Console ERC............................................... 5
ERC Supplemental Display.............................................. 7
Supplemental Display Menu Selection............................. 7
Settings .................................................................... 7
Active Alarms ........................................................... 8
Alarms History .......................................................... 9
About ........................................................................ 9
Electronic Remote Control (ERC) Operation ................... 9
ERC Handle Friction and Detent Adjustment................. 10
Active Trim............................................................................. 10
Introduction to Active Trim.............................................. 10
Modes of Operation ................................................ 10
Setup and Configuration ......................................... 11
Active Trim ERC Controls............................................... 11
Active Trim Operation..................................................... 12
GPS ........................................................................ 12
Resume Functionality ............................................. 12
Shallow Water Operation ....................................... 12
Trailer Position ...................................................... 13
Selecting the Correct Profile........................................... 13
What Trim Is ........................................................... 13
How Trim Affects Boat Operation ........................... 13
Boat Loading and Trim ........................................... 14
Choosing an Active Trim Profile ............................. 14
Active Trim Red Status Light.......................................... 14
Single Flashing Red ............................................... 14
Double Flashing Red .............................................. 14
Engine Synchronization (Multiple Engines)........................... 14
Helm Transfer........................................................................ 15
Transfer Light and Single‑Helm Boats............................ 15
Requesting Helm Transfer.............................................. 15
Helm Transfer and Autopilot........................................... 15
Quick Steer............................................................................ 16
Throttle and Shift Operation with Three or Four Engines...... 16
Triple‑Engine Throttle and Shift Operation..................... 16
Quad‑Engine Throttle and Shift Operation..................... 17
Single‑Lever Mode (Multiple Engines)................................... 18
Start/Stop All Engines............................................................ 18
Engine Indicator LEDs ................................................... 18
No Engines Running ‑ Start Engines ............................. 18
All Engines Running ‑ Stop Engines .............................. 18
Some (Not All) Engines Running ‑ Stop Engines .......... 18
Interrupting the Start All Process ................................... 18
Throttle‑Only Mode................................................................ 19
1
Section 1 - DTS Controls and Features
90-8M0180922 eng MAY 2021 Page 1
Electronic Remote Control (ERC)
Electric steering requires a Digital Throttle and Shift (DTS) electronic remote control (ERC). Because it is electronic, an ERC is
capable of several features beyond the basic remote control functions of throttle and shift.
There are several DTS ERCs that can be used with electric steering, depending on the number of engines and the desired
features. The following images show the current Mercury ERCs that will function with electric steering.
71712
Panel mount ERC - ES
71715
Single-engine console ERC - ES
71716
Dual-engine console ERC - no trim
71717
Dual-engine console ERC - with trim
71718
Dual-engine console ERC - premier
71719
Triple-engine console ERC - standard
71720
Triple-engine console ERC - premier
71721
Quad-engine console ERC - standard
Section 1 - DTS Controls and Features
Page 2 90-8M0180922 eng MAY 2021
71722
Quad-engine console ERC - premier
71723
Five or six-engine console ERC
The basic styles of ERC are panel mount (single‑engine only), single‑handle console (single‑engine only), and dual‑handle
console (two or more engines).
Section 1 - DTS Controls and Features
90-8M0180922 eng MAY 2021 Page 3
Panel Mount ERC
Panel mount ERCs control a single engine. There are several variations, but only one of these can be used with electric
steering (ES).
71965
a
b
c
d
f
g
h
e
i
Ref Control/LED Function
aNeutral (N) LED Illuminates when the engine is in the neutral gear position.
The light flashes when the engine is in throttle‑only mode.
bBrightness (+ and –)Increases and decreases the brightness settings for the
lights on the ERC and Mercury helm components.
cTHROTTLE ONLY Allows the boat operator to increase engine RPM without
shifting into gear. Refer to Throttle‑Only Mode.
dQUICK STEER (if equipped)
Decreases the number of steering helm turns, lock‑to‑lock,
for quicker response during docking. This feature also limits
engine speed. Refer to Quick Steer.
e
ACTIVE TRIM (if equipped) The ACTIVE TRIM button turns the Active Trim feature ON
or OFF. Refer to Active Trim.
Profile ▲ and ▼Changes the selected Active Trim profile.
Active Trim LEDs (1, 2, 3, 4, 5)
Indicates the currently selected Active Trim profile.
NOTE: If the LED indicators are flashing, Active Trim is in
setup mode.
fLanyard stop switch (emergency
stop)
In conjunction with the lanyard cord, shuts off the engine
when the operator moves away from the ERC.
gSTART/STOP ENGINE Starts or stops the engine.
hUP ▲ and DN ▼—trim control
Raises and lowers the engine/drive for best efficiency, or for
conditions such as shallow water or trailering. Some boats
are equipped with separately‑mounted trim controls.
i Mechanical lock bar
Pressing the mechanical lock bar allows the engine to shift.
The mechanical lock bar must always be pressed when
moving the control handle out of the neutral position.
Section 1 - DTS Controls and Features
Page 4 90-8M0180922 eng MAY 2021
Single‑Handle Console ERC
Single‑handle console ERCs control a single engine. There are several variations, but only one of these can be used with
electric steering (ES).
71966
ab
c
d
e
g
h
f
i
Ref Control/LED Function
aNeutral (N) LED Illuminates when the engine is in the neutral gear position. The light flashes when the
engine is in throttle‑only mode.
bBrightness (+ and –)Increases and decreases the brightness settings for the lights on the ERC and Mercury
helm components.
cTRANSFER Allows boat control to be transferred to a different helm. (The LED will be ON at the active
helm.) Refer to Helm Transfer.
dTHROTTLE ONLY Allows the boat operator to increase engine RPM without shifting into gear. Refer to
Throttle‑Only Mode.
eQUICK STEER (if equipped) Decreases the number of steering helm turns, lock‑to‑lock, for quicker response during
docking. This feature also limits engine speed. Refer to Quick Steer.
f
ACTIVE TRIM (if equipped) The ACTIVE TRIM button turns the Active Trim feature ON or OFF. Refer to Active Trim.
Profile ▲ and ▼Changes the selected Active Trim profile.
Active Trim LEDs (1, 2, 3, 4,
5)
Indicates the currently selected Active Trim profile.
NOTE: If the LED indicators are flashing, Active Trim is in setup mode.
gSTART/STOP ENGINE Starts or stops the engine.
hUP ▲ and DN ▼—trim
control
Raises and lowers the engine/drive for best efficiency, or for conditions such as shallow
water or trailering. Some boats are equipped with separately‑mounted trim controls.
i Mechanical lock bar Pressing the mechanical lock bar allows the engine to shift. The mechanical lock bar
must always be pressed when moving the control handle out of the neutral position.
Dual‑Handle Console ERC
Dual‑handle console ERCs control two, three, four, five, or six‑engines. Dual‑engine ERCs are available with or without integral
trim switches.
Section 1 - DTS Controls and Features
90-8M0180922 eng MAY 2021 Page 5
Ce manuel convient aux modèles suivants
9
Table des matières
Autres manuels Mercury Télécommande
Manuels Télécommande populaires d'autres marques
Panasonic
Panasonic EUR7622KB0 Manuel utilisateur
Bang & Olufsen
Bang & Olufsen Beo4 Manuel utilisateur
Sunwave Tech.
Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur
Multiplex
Multiplex PROFI TX 9 Manuel utilisateur
One Remote
One Remote RMB4 Manuel utilisateur
FUTABA
FUTABA 9ZAP - PART2 Manuel utilisateur
