MEGAWHEELS S10 Manuel utilisateur
Thank you for purchasing our product. For optimum performance and safety,
please read these instructions carefully before operating the product.
Please keep this manual for future reference.
Read the information supplied by the manufacturer.
Wear personal protective equipment.
USER MANUAL
EN14619 Class A
1. GENERAL INFORMATION
2. PRODUCT OVERVIEW
2.1 General information
2.2 What you need to know
3. PRODUCT DESCRIPTION
3.1 Assemble the front wheel
3.2 Unfold
3.3 Assemble the handles
3.5 Fold
4. HOW TO RIDE
4.1 Ride
4.2 Display description
4.3 Front light description
4.4 Rear light description
5. SCOOTER SAFETY PRECAUTIONS
6. WEIGHT AND SPEED LIMITATIONS
6.1 Weight Restrictions
6.2 Speed Limits
7. OPERATING RANGE
8. BATTERY INFORMATION AND SPECIFICATIONS
8.1 Battery Specifications
8.2 BATTERY WARNING
9. CHARGING YOUR SCOOTER
10. INSPECTION, MAINTENANCE, AND STORAGE
11. SCOOTER SPECIFICATIONS
----------------------------------------------01
----------------------------------------------------02
------------------------------------------------------02
-------------------------------------------------02
-----------------------------------------------02
-----------------------------------------------02
------------------------------------------------------------------------03
----------------------------------------------------04
----------------------------------------------------------------------------04
-----------------------------------------------------------------05
---------------------------------------------------------------------------05
--------------------------------------------------------07
----------------------------------------------------08
-----------------------------------------------------08
-----------------------------------09
------------------------------------10
----------------------------------------------------------10
--------------------------------------------------------------------10
----------------------------------------------------------10
----------------11
--------------------------------------------------------11
------------------------------------------------------------11
--------------------------------------------12
-----------------13
--------------------------------------------13
CATALOG
1. GENERAL INFORMATION
01
Front Wheel
Motor
Kickstand
Charging Port
Deck
Rear Brake Rear Light
Hook Hole
Handle
Folding Wrench
Long Pole
LED Light
Buckle Lock
Accelerate Throttle
LCD Display
Electric Brake
Folding Hook
2. PRODUCT OVERVIEW 3. PRODUCT DESCRIPTION
02
2.1 General information 3.1 Assemble the front wheel
2.2 What you need to know
The original scooter is an intuitive, technologically advanced solution.
Using the latest technology and production processes, each scooter
undergoes strict testing for quality and durability. With its lightweight,
portable design, ease of use, range, and low carbon footprint.
1. Step on the base, lift the fork firmly to remove the base.
2. Remove the rubber plugs on both sides of the front fork, and unscrew
the front axle with the two 6mm hexagon wrenches in the package.
Before you first experience your scooter, please read the USER
MANUAL thoroughly and learn the basics to ensure your safety and the
safety of others. The power will be shut down if nobody operate in five
minutes, you need press power button before you ride.
WARNING: Failure to follow the basic instructions and safety
precautions listed in the USER MANUAL, can lead to damage to your
scooter, other property damage, serious bodily injury,and even death.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
3.2 Unfold
03
1. Right hand presses down the back fender and the left hand pulls up the
long pole until folding hook gets out of the hook hole on back fender.
3. When installing the front wheel ( please pay attention to the direction
of the tread of the tire, as shown in the lower right or the inflation port
to the right), and tighten the front wheel axle.
4. Plug back the rubber plugs on both sides of the front fork. 2. Get the long pole stand up, then pull up the folding wrench towards
the upright pole and force it to stay close to upright pole
04
3.3 Assemble the handles 3.4 Fold
1. Right index finger lift the buckle lock up, push the folding wrench
outward with the thumb to put down the upright pole.
2. Press the upright pole down until the folding hook is fixed into the
hook hole on back fender.
Install the Handles and tighten the handles:
LR
RL
Before installing the handles, please make sure to differenciate the
left & right handles carefully.
Please see the difference of left & right handles from below images.
4. HOW TO RIDE
4.1 Ride
1. Turn on the Scooter by press the Power key for 2 seconds and check
the battery power.
Skillfully use the accelerate throttle to speed up or slow down when riding.
Warning: There is risk of falling down during learning, so make sure to wear helmet and protection kits all the time.
05
2. once the power is on it is safer to start riding with one foot on the deck
and give a kick by other foot to speed up the scooter to 5km/h, then
push accelerator and place the other foot on the deck, this is safer and
more controlled than pulling off with two feet on the deck as you will
have less control and stability with two feet on the deck.
4. Turn off the scooter when finish using the product by press the power
key for 3seconds.
3. To stop riding, release the throttle and use the electric brake to gradually
coast to a stop then step off the scooter one foot at a time. Be extra
cautions when dismounting for the first time.
Warning: If scooter has both electric brake and rear physic rear brake, the electric brake is prior to rear brake, which is only used as auxiliary
brake when electric brake does not work properly, or in an urgent situation, use the eletric brake and rear brake at the same time.
DO NOT step on rear brake for a long time, or it will break the tyre and fender.
Mechanism to reduce speed will get hot from continuous use, do not touch after braking.
06
07
Battery power 75%-100% power
When the icon is white, it is at low speed mode, max speed is 10km/h.
When the icon is yellow, it is middle speed mode, max speed is 20km/h.
When the icon is red, it is high speed mode, max speed is 25km/h.
When the icon is on, the front light and rear light are turned on,
When the icon is off, the front light and rear light are turned off.
Press 2sec to turn it ON / OFF.
When the scooter is on, turn on the front light and rear light by pressing the power button twice;
turn it off by pressing the power button twice again.
Speed level
Light status
Power key
50%-75% power 25%-50% power 0%-25% power
When the scooter is on, switch the speed modes at low speed, middle speed and high
speed by pressing this button
Mode key
4.2 Display description
08
4.3 Front light description
4.4 Rear light description
TURN ON TURN OFF
When the light is on，press
twice in short time to turn off the front light.
When the scooter is on ，press
twice in short time to turn on the front light；
TURN ON TURN OFF
When the light is on，press
twice in short time to turn off the rear light.
When the scooter is on ，press
twice in short time to turn on the rear light；
When we turn on the light,the rear light will be half bright,when we brake,the rear light will be fully bright.
When we turn off the light,the rear light is off.
