Medema Spider Manuel utilisateur
P9-0271-B ver. 1.0.1 - june 2011 GB
Quick guide
Spider
medemagroup
Quick guide P9-0271-Q 2 of 20 Version 1.0.1/2011
Medema Production A/S
Quick guide P9-0271-Q 3 of 20 Version 1.0.1/2011
Medema Production A/S
Contents
Quick guide - Spider .................................................................................4
Introduction................................................................................................4
Part names.................................................................................................5
Parts Joystick R-net..................................................................................6
Using the Joystick R-net...........................................................................7
LCD Screen............................................................................................8
Mode.........................................................................................................10
Charging...................................................................................................11
Safety check.............................................................................................12
Troubleshooting the R-net......................................................................12
Serial number...........................................................................................14
Driving the Spider....................................................................................14
12 tips for driving the Spider:................................................................15
Driving on public roads:........................................................................16
Driving on stairs/escalators:.................................................................16
Brakes.......................................................................................................17
Motor braking: ......................................................................................17
Parking brake:......................................................................................17
Disengagement:...................................................................................17
Own notes................................................................................................19
Quick guide P9-0271-Q 4 of 20 Version 1.0.1/2011
Medema Production A/S
Quick guide - Spider
Introduction
Congratulations on your new, Spider electric mobility scooter. You are
now the owner of an electric mobility scooter developed for use indoors
as well as outdoors. It is what is called a Class B vehicle according to the
European classification of electric scooters.
For optimum enjoyment of this vehicle - and to avoid breakdowns and
accidents - we recommend that you read the User Manual carefully. If you
are a new user, you should pay particular attention to the section “Driving
the Spider”.
Note:
This Quick Guide is to be regarded as a supplement to the User Manual.
The information in the Quick Guide cannot, therefore, be expected to be
complete.
NB: Errors and omissions excepted. Specifications subject to change.
We reserve the right to update this guide as required.
Warning!
The vehicle must not be lent to persons who are not completely familiar
with it.
The vehicle is designed for one person only.
Max. user weight 130 kg.
Medema Production A/S is not responsible for any damage or injuries
caused by inappropriate or unsafe use of the Spider.
Quick guide P9-0271-Q 5 of 20 Version 1.0.1/2011
Medema Production A/S
Part names
The part names given below refer to the descriptions later in the this guide.
Disengagement
lever. One on each
motor
Pivot wheel
Drag wheel
Footplate or
footrests
Charging
socket
Control
panel
Armrest
Joystick
Headrest
Eye for
restraints
Calfrest
Øje til
bespænding
Serial number on
vehicle.
7
8
9
10
1
2
3
4
5
6
11
Quick guide P9-0271-Q 6 of 20 Version 1.0.1/2011
Medema Production A/S
Parts Joystick R-net
Joystick R-net
1Start/stop button
2Horn
3Lights (Extra)
4Profile-button
5Indicator right (Exstra)
6Speed selection
7Hazard warning lights (Exstra)
8Display
9Mode-button
10
Indicator left (Exstra)
11 Joystick
Quick guide P9-0271-Q 7 of 20 Version 1.0.1/2011
Medema Production A/S
Using the Joystick R-net
Speed selection with joystick R-net
1 To start the wheelchair:
Press button 1 and wait for the battery indicator to stabilise (3-5 seconds)
2Select the maximum speed:
Keep pressing button Speed selection to maximize or minimize the maximum
speed.
Driving
1Start driving by moving the joystick in the direction you want to travel.
The speed depends on how far forward you push the joystick. To brake, return the
joystick to the starting position in the centre.
2It is important to check the battery indicator regularly to prevent the
scooter stopping because of flat batteries.
Note!
If you are driving on a sloping surface with poor grip, e.g. gravel or snow, it
is important to brake gently to avoid losing control of the scooter. To brake
gently: move the joystick to the central position SLOWLY.
Quick guide P9-0271-Q 8 of 20 Version 1.0.1/2011
Medema Production A/S
LCD Screen
Symbol Description
Shown in the top bar.
Color red, yellow and green - fully charged.
Color red and yellow - ok, but need to be charged soon.
Color red, steady - ok, but charge as soon as possible.
Color red slowly blinking - charge NOW!
Shown in the top bar.
When the control system contains more than one method of direct
control, such as a secondary Joystick Module, then the Module that has
control of the wheelchair will display the In Focus symbol.
Shown in the base bar.
The currently selected Profile is shown in numeric form.
Shown in the base bar.
This symbol is displayed when the control system has intentionally
reduced the power to the motors, in order to protect them against heat
damage.
Shown in the base bar.
This symbol is displayed when the control system has intentionally
reduced its own power, in order to protect itself against heat damage.
Shown in the bottom of the main screen area.
This symbol shows the chosen profile.
Shown in the top left corner of the main screen area.
This displays the current time. The clock is user adjustable
- Whether the clock is displayed on screen.
- The display format, 12 or 24 hour
- Adjusting the time.
Shown in the center of the main screen area.
This gives a proportional display of the wheelchairs speed. TheArc
begins at 0% and has a programmable maximum. The programmable
parameter is Max Displayed Speed.
Top bar
Main screen area
Base bar
Quick guide P9-0271-Q 9 of 20 Version 1.0.1/2011
Medema Production A/S
Symbol Description
Shown just below the speed regulation.
This displays the current maximum speed setting.
Shown in the center of the main screen area.
This displays the actual speed of the wheelchair derived from the
motors. The display can be set to mph or km/h.
When the control system is operating in a latched condition this
symbol will be displayed.
If the speed of the wheelchair is being limited; for example, by a
raised seat, then this orange symbol will be displayed.
If the wheelchair is being inhibited from driving, then this red symbol
will be flashing.
Quick guide P9-0271-Q 10 of 20 Version 1.0.1/2011
Medema Production A/S
Mode
Mode Description
Displays the sections of the chair currently selected for
movement.
When Bluetooth Mode is entered the following screen will be
displayed.
When the control system requires a reboot, this
symbol will be flashed.
Waiting symbol. This symbol is displayed when the control system
is changing between different states.
This symbol will be displayed for a short time before the R-net
enters into a sleep state.
If you operate the Joystick before or just after you switch the
control system on, the screen will flash the joystick displaced
screen.
Let go of the joystick whithin 5 secunds, or the system has to be
restarted.
When the control system safety circuits have operated and the
control system has been prevented from moving the wheelchair
a diagnostics screen will be displayed. This example show a
warning of low battery voltage, and a trip code in the top right
corner.
