P9-0220-B ver. 2.0.2 - March 2011 GB
Quick guide
MC Concept 1121
medemagroup
Quick guide P9-0220-Q 2 of 24 Version 2.0.2/2011
Medema Production A/S
Quick guide P9-0220-Q 3 of 24 Version 2.0.2/2011
Medema Production A/S
Contents
Quick Guide - MC Concept 1121 .............................................................4
Introduction................................................................................................4
Part names.................................................................................................5
Joystick parts ............................................................................................6
Operating....................................................................................................6
Clock on/off ............................................................................................7
Set Speed...............................................................................................8
Setting the seat - back and leg supports................................................9
Light on / off..........................................................................................10
Setting the display environment...........................................................11
Setting the Clock..................................................................................12
Error Code................................................................................................14
Charging...............................................................................................15
Safety check.............................................................................................16
Serial number...........................................................................................16
Driving the MC Concept 1121.................................................................17
11 tips for driving the MC Concept:......................................................18
Driving on public roads:........................................................................19
Driving on stairs/escalators:.................................................................19
Brakes.......................................................................................................20
Motor braking: ......................................................................................20
Parking brake:......................................................................................20
Disengagement:...................................................................................20
Your own notes:.......................................................................................22
Quick guide P9-0220-Q 4 of 24 Version 2.0.2/2011
Medema Production A/S
Quick Guide - MC Concept 1121
Introduction
Congratulations on your new MC Concept 1121 electric mobility wheelchair.
You are now the owner of an electric mobility wheelchair developed for use
indoors as well as outdoors. It is what is called a Class B vehicle according
to the European classification of electric wheelchairs.
For optimum enjoyment of this vehicle - and to avoid breakdowns and
accidents - we recommend that you read the User Manual carefully. If you
are a new user, you should pay particular attention to the section “Driving
the MC Concept 1121”.
Note:
This Quick Guide is to be regarded as a supplement to the User Manual.
The information in the Quick Guide cannot, therefore, be expected to be
complete.
NB: Errors and omissions excepted. Specifications subject to change.
We reserve the right to update this guide as required.
Warning!
The vehicle must not be lent to persons who are not completely familiar
with it.
The vehicle is designed for one person only.
Max. user weight 150 kg. The vehicle can be specially adapted at the
factory for users weighing up to 180 kg.
Mini Crosser A/S is not responsible for any damage or injuries caused by
inappropriate or unsafe use of the MC Concept 1121.
Quick guide P9-0220-Q 5 of 24 Version 2.0.2/2011
Medema Production A/S
Part names
The part names given below refer to the descriptions later in the this guide.
Disengagement
lever. Both sides of
the vehicle.
Pivot wheel
Central
wheel
Anti-tilt wheel
Footplate or footrests
Charging socket
Serial number on
vehicle
Control panel
Armrest
Joystick
Indicators
(optional extra)
Swing-away
release
Headrest
Thermal fuse
to right of serial
number plate
Finger screw to
loosen seat
Eye for restraints
Adjusting the
headrest
Release for
leg supports
Leg length
adjustment
Calf pad
adjustment
Eye for restraints
Quick guide P9-0220-Q 6 of 24 Version 2.0.2/2011
Medema Production A/S
Joystick parts
Dynamic DX2 AJR 1 Start/stop button
2 Indicator left
3 Indicator right
4 Select
5 Display
6 Speed selector
7 Accessory Selector
8 Horn
Operating
At the top of the display you will find the status bar. Battery indicator is
displayed constantly. The clock can be turned on or off as you wish. The
other is lit when the corresponding function is active.
1 Battery indicator
Green = fully charged
Yellow = least half full
Red = almost empty - charge now!
2 Indicator left is active
When hazard warning lights are active, both icons blinks.
3 Lights on
4 Error code - see section on error codes.
5 Indicator right is active
When hazard warning lights are active, both icons blinks.
6 Real time
1
3
5
4
7
8
2
6
1 2 3 4 5 6
Quick guide P9-0220-Q 7 of 24 Version 2.0.2/2011
Medema Production A/S
Clock on/off
Press arrow up/down or joystick (push forward) until the above icon is
showed in the center of the screen.
Use ”Select” to switch between X and .
Accept by pressing the arrow up/down button.
Quick guide P9-0220-Q 8 of 24 Version 2.0.2/2011
Medema Production A/S
Set Speed
When you turn the joystick on, the image shown below will be presented in
the display. The number in the centre shows the speed you have chosen as
max speed. Change the Speed by selecting the plus / minus key. Maximum
speed is 5, lowest is 1.
Find the features in the bottom with the “Select” button.
Chosen speed
Select
Quick guide P9-0220-Q 9 of 24 Version 2.0.2/2011
Medema Production A/S
Chosen speed
Press the arrow up / down until the image shows the chair. Use the “Select”
to choose the function you want modified. Use the joystick to change
example angle of the seat back.
Setting the seat - back and leg supports
Select
Function Icon
Seat angle (Tilt)
Backrest angle
Seat height
Left footrest
Function Icon
Right footrest
footrest both
Lying down
Headrest
Only the available options will be displayed.
Quick guide P9-0220-Q 10 of 24 Version 2.0.2/2011
Medema Production A/S
Light on / off
Push the arrow up / down until the image for light is shown in the centre.
Push the joystick forward to turn the light on. And again to turn of the light.
Push the joystick back to activate the hazard warning lights. Push the
joystick back again to turn it of.
Push the joystick right or left to activate the indicators right or left. Turn of
the indicators by puching the joystick to the same side again.
Press the arrow up / down until the sun i shown i the centre. Push the
joystick forward to enter the settings. Use the Select button or joystick right
/ left to change the brightness.
Use Joystick forward / back or arrow up / down to accept the new settings
and return to the main menu.
